Rocstor COMMANDER 2UE Bedienungsanleitung

store your future

eSATA & USB 2.0

Secure, Encrypted, Ruggedized mobile Hard Drive

COMMANDER 2UE

Quick Installation Guide

Page \ 2

eSATA& USB 2.0

Secure, Encrypted, Ruggedized mobile Hard Drive

Quick Installation Guide

Quick Installation

Guide

store your future

COMMANDER 2UE

Quick Installation Guide

COMMANDER 2UE Key Token (x2) eSATA Cable

USB Cable Carrying Case

Contents

System Requirements

Mac Users

Hardware:

eSATA or

USB (1.1 or 2.0) port(s).

PowerPC or Intel processor

Mac OS 9, X, Leopard or Snow Leopard

Min. recommended memory: 512 MB RAM

PC Users

Hardware:

eSATA or

USB (1.1 or 2.0) port

Microsoft Windows 2000, Me, XP, Vista, or Windows 7

Min. recommended memory: 512 MB RAM

*If you wish to utilize FireWire or eSATA ports and your computer does not support such interfaces you may be

required to purchase an interface as an optional device.

ROCSTOR |Commander 2UE quick installation guide

Page \ 3

1. Insert the digital key (key-token) in the back of the Commander 2UE for authentication First.

2. Connect one end of the SATA cable to the SATA ports of your computer and then the other end to the SATA

port in the COMMANDER 2UE device.

NOTE: eSATA port does not provide power to the drive. Therefore you must connect the SATA cable FIRST, then connect the USB

Cable to power the drive. If USB is connected first, the computer will read the divice as USB and not as SATA.

3. Using the two ends of the USB “Y” cable, connect them to the USB ports of your computer (or via Power Hub

that is connected to your computer) and the other end to the USB port in the COMMANDER 2UE. After a few

seconds, the light will turn blue and a Rocstor HD icon will show on “My Computer” folder under the Windows OS.

Connecting via SATA port:

Connecting via USB port:

USB 2.0

eSATA

USB eSATA

NOTE: For security reasons REMOVE (and store in safe place) the Key-token once access to the data is granted. As long as the

2UE device is ON, the data is accessible. At this stage, the COMMANDER device acts as any other standard external drive on the

market. Once the drive is powered OFF you are required to insert the key-token and repeat the procedures for authentication again.

You may also refer to the Rocstor website to view or download a full version of the COMMANDER 2UE manual. www.ROCSTOR.com

Connecting the Drive

4. The Hard drive is preformatted for Plug-and-Play operation. After a few seconds, a Rocstor HD icon will show on

“My Computer” folder under the Windows OS. Under the Mac OS, the Rocport HD will appear on the “Desktop.”

5. Click (double click) on the Rocstor HD icon to access the drive.

ROCSTOR |Commander 2UE quick installation guide

Page \ 4

Capacity Disclaimer

Actual accessible hard drive capacity will indicate up to 10% lower than stated under different Operating

Systems and formatting. Therefore, a 500GB capacity drive may show up as a 450GB drive (approximately.)

Warranty Period

The Limited warranty period for Commander hard drives is two years for parts and labor.

Trademarks Acknowledgements

age, Inc. "store your future", "secure your future" and “power your future” are the slogan marks of Rocstorage, Inc. Apple, the Apple logo, Mac,

Power Macintosh, FireWire, and Mac Pro, Leopard … are trademarks of Apple Computer, Inc. Microsoft, MS-DOS, Windows CE, Windows NT,

Windows 98, Soft Windows, Vista … are registered trademarks of Microsoft Corporation. All other names are trademarks of their respective

Technical Support / RMA

Tel: (888) 877-7716 (USA and Canada)

Tel: +1 (818) 449-2000 (Domestic and Internationals)

Fax: +1 (818) 884-8777

Hours: 9:00 am - 5:00 pm PST, Mon - Fri (excluding holidays)

Email: support@Rocstor.com

General Notices

• Consistently make multiple backup copies of your data for your protection. Hard disk drives are subject to

failure at any time.

• Rocstorage, Inc. shall not be held liable for loss of data or the restoration or recovery of data on the device.

Please see complete Limited Warranty Information in the User’s Manual or on the Rocstor website

(www.rocstor.com) for further details.

Specifications, terms, warranties, descriptions, product and services herein are subject to change without notice. Ver.0427I

Designed/assembled/integrated in the U.S.A.

using domestic and/or foreign components.

Enclosure (without hard drive) is made in China

ROCSTOR |Commander 2UE quick installation guide
