Rocstor EAGLEROC E7 Bedienungsanleitung

Quick Installation Guide

EAGLEROC E7

Desktop - External Hard Drive

FireWire 800 & USB 3.0

ROCSTOR |EAGLEROC E7 quick installation guide Page \ 2

Contents

System Requirements

Mac Users

Hardware:

• FireWire 800 (1394b) or

• USB 3.0 (2.0) port(s).

• PowerPC or Intel processor

• Mac OS 9, X, Leopard or Snow Leopard

Min. recommended memory: 512 MB RAM

PC Users

Hardware:

• FireWire 800 (1394b) or

• USB 3.0 (2.0) port

• Microsoft Windows 2000, Me, XP, Vista, or Windows 7

Min. recommended memory: 512 MB RAM

*If you wish to utilize FireWire ports and your computer does not support such interfaces you may be required to purchase an interface as an optional device.

You may also utilize your Host (Computer) FireWire 400 port to connect to the FireWire 800 port on Eagleroc E7 via an optional standard cable or a small

adaptor. Please note that transfer rate will be reduced to FireWire 400 speeds at about 400 Mbits/s.

EAGLEROC E7 USB Cable FireWire 800

(9-pin to 9-pin) Cable

Stand AC Adaptor Quick Installation

Guide

Quick Installation Guide

EAGLEROC E7

Desktop - External Hard Drive

FireWire800 & USB 3.0

3. Using only one interface cable at a time, select the interface port you wish to use on your computer. When using FireWire, connect one

end of the FireWire cable to the appropriate FireWire port (FW800 or FW400) of your computer and then the other end to the FireWire port

in the Eagleroc E7. When using USB, connect one end of the USB cable to the USB port of your computer (or via Power Hub that is

connected to your computer) and then the other end to the USB port in the Eagleroc E7.

NOTE: The AC adaptor MUST BE connected first to both the hard drive and to the electricity; however, the drive will not come “ON” until the

USB interface cable is fully connected.

4. The hard drive is preformated for Plug-and-Play operation. After a few seconds a Rocstor HD icon will show up on “My Computer” folder

under the Windows OS. Under the Mac OS, the ROCSTOR HD will appear on the “Desktop.”

5. Click (double click) on the Rocstor HD icon to access the drive.

*You may also refer to the Rocstor website to view or download a full version of the Eagleroc E7 manual. www.ROCSTOR.com

Page \ 3

ROCSTOR |EAGLEROC E7 quick installation guide

Connecting the Drive

1. Turn ON your computer and wait until it fully boots up to load all programs.

2. Connect one end of the adaptor cord directly into the Eagleroc, and connect the other end to an AC outlet, surge protector or battery

backup (UPS).

USB

3.0

FireWire

800

Power

(Daisy Chain Optional)

FireWire

800 or 400 FireWire

800 or 400

USB 3.0

Page \ 4

ROCSTOR |EAGLEROC E7 quick installation guide

General Noces

• Consistently make mulple backup copies of your data for your protecon. Hard disk drives are subject to failure at

any me.

• Rocstorage, Inc. shall not be held liable for loss of data or the restoraon or recovery of data on the device. Please see

complete Limited Warranty Informaon in the User’s Manual or on the Rocstor website (www.rocstor.com) for

further details.

Capacity Disclaimer

Actual accessible hard drive capacity will indicate up to 10% lower than stated under diﬀerent Operang Systems and formang. Therefore, a 500GB capacity drive may

show up as a 450GB drive (approximately.)

Warranty Period

The Limited warranty period for Rocpro external hard drives is two years for parts and labor.

Technical Support / RMA

Tel: (888) 877-7716 (USA and Canada)

Tel: +1 (818) 449-2000 (Domesc and Internaonals)

Fax: +1 (818) 884-8777

Hours: 9:00 am - 5:00 pm PST, Mon - Fri (excluding holidays)

Email: support@Rocstor.com

Trademarks Acknowledgements

"secure your future" and “power your future” are the slogan marks of Rocstorage, Inc. Apple, the Apple logo, Mac, Power Macintosh, FireWire, and Mac Pro, Leopard

(Snow) ... are trademarks of Apple Computer, Inc. Microso, MS-DOS, Windows CE, Windows NT, Windows 98, So Windows, Vista, Windows 7 ... are registered trademarks

Designed/assembled/integrated in the U.S.A. using domesc and/or foreign components. Enclosure

(without hard drive) is made in China

Speciﬁcaons, terms, warranes, descripons, product and services herein are subject to change without noce.

Ver.0801K
