RODE Microphones NT1 Bedienungsanleitung

INSTRUCTION MANUAL ENGLISH

www.rodemic.com/nt1

World’s Quietest

1” Cardioid Condenser

Microphone

NT1

148-950-1-13_NT1_multilingual_manual.indd 1148-950-1-13_NT1_multilingual_manual.indd 1 13/08/2013 2:51:34 PM13/08/2013 2:51:34 PM

2Introduction

The NT1 is a studio quality condenser microphone, designed for

highly detailed sound reproduction. It features a cardioid polar

pattern, meaning that it will pick up sound from directly in front of

the microphone, and reject sound from the rear of the mic. This

pickup pattern allows for recording of the desired sound source

while reducing the sound of other instruments or sound sources.

The NT1 is not only ideal for recording music, but is a fantastic

microphone for podcasting and voiceovers, as well as sound design.

The extremely low inherent noise of the NT1 also makes it perfect

for recording very quiet sound sources.

148-950-1-13_NT1_multilingual_manual.indd 2148-950-1-13_NT1_multilingual_manual.indd 2 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

Features

• Large capsule (1”) with gold-plated membrane

• Cardioid polar pattern

• Internal Rycote®Lyre®based capsule shock mounting system

• Ultra-low noise transformerless circuitry

• State-of-the-art surface mount electronics

• Heavy-duty matte black ﬁnish

• Gold plated output connectors

• Designed & manufactured in Australia

• Free 10 year extended warranty when you register online at

www.rodemic.com/warranty

148-950-1-13_NT1_multilingual_manual.indd 3148-950-1-13_NT1_multilingual_manual.indd 3 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

4Warranty

The NT1 is covered by a limited warranty for one (1) year from the

date of purchase. This can be extended free of charge to a full ten

(10) year warranty by registering your microphone online by visiting

our website as above.

validate your free 10 year warranty.

Scan the QR code with a smartphone, or visit

www.rodemic.com/warranty

148-950-1-13_NT1_multilingual_manual.indd 4148-950-1-13_NT1_multilingual_manual.indd 4 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

Speciﬁcations

0˚

90˚ 270˚

180˚

-2.0

-20.0

-10.0

0.0

-2.0

-4.0

-6.0

-8.0

-10.0

-12.0

-14.0

-16.0

-18.0

-20.0

-22.0

-24.0 -25.0

dB rel. 1V/Pa

+5.0

Frequency:

500 Hz:

1000 Hz:

4000 Hz:

8000 Hz:

14000 Hz:

Polar Response

Frequency

Response

148-950-1-13_NT1_multilingual_manual.indd 5148-950-1-13_NT1_multilingual_manual.indd 5 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

6Speciﬁcations

Acoustic Principle Pressure Gradient

Active Electronics JFET impedance converter with

bipolar output buffer

Directional Pattern Cardioid

Frequency Range 20Hz ~ 20kHz

Output Impedence 100 Ω

Equivalent Noise 4.5 dBA SPL (as per IEC651)

Maximum Output +8 dBu (1kHz, 1% THD into 1K Ω load

Sensitivity -29 dB re 1V/Pa

(35mV @ 94dB SPL)

± 2dB @ 1kHz

Dynamic Range 128 dB SPL

148-950-1-13_NT1_multilingual_manual.indd 6148-950-1-13_NT1_multilingual_manual.indd 6 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

Maximum SPL 132 dB SPL

Signal / Noise 90 dBA SPL (as per IEC651)

Power Requirements 24V phantom power

48V phantom power

Output Connection 3 Pin XLR

Balanced output between pin 2 (+),

pin 3 (-) and pin 1 (ground)

Net Weight 395g

Accessories SMR shock mount

Microphone Dust Cover

148-950-1-13_NT1_multilingual_manual.indd 7148-950-1-13_NT1_multilingual_manual.indd 7 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

Connect all cables before supplying phantom power to the

microphone and never remove the microphone cable while the

power is connected.

The NT1 requires 48V DC (P48) or 24V DC (P24) phantom power.

If the mixer or preamp does not contain this phantom power

requirement, then an external phantom power supply is needed.

Some phantom power supplies do not supply the voltage at which

they are rated. If the required voltage is not supplied, the dynamic

range and general performance of the microphone will be reduced.

We strongly suggest the use of a reputable high quality power

supply. Damage caused by a faulty power supply is not covered

under warranty.

Powering the NT1

148-950-1-13_NT1_multilingual_manual.indd 8148-950-1-13_NT1_multilingual_manual.indd 8 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

What is Phantom Power?

All condenser microphones require a power source to operate the

internal circuitry of the microphone.

Phantom power is a DC voltage, supplied to the microphone

through the XLR cable, providing the microphone circuit with the

power it requires to operate, without the need for an external

microphone power supply.

Most mixing desks, audio interfaces, and preamp units have a

phantom power switch inbuilt. If your equipment doesn’t have a

phantom power supply, an external one can be purchased and used

in-line between the preamp and the NT1. Be sure to check that your

phantom power supply is either P48 (48V DC) or P24 (24V DC) to

operate the NT1 correctly.

148-950-1-13_NT1_multilingual_manual.indd 9148-950-1-13_NT1_multilingual_manual.indd 9 13/08/2013 2:51:42 PM13/08/2013 2:51:42 PM

The SMR shock mount

The NT1 is supplied with

the SMR shock mount.

Featuring suspension based

around the Rycote® Lyre®

system, it is designed to

isolate the microphone from

mechanical noise caused

by vibrations, bumps, and

other low frequency noises

in the recording space.

To mount the NT1, ﬁrst

remove the threaded ring

from the bottom of the

microphone. From there,

place the microphone in

the mount from above, and

attach the ring underneath

the mount to secure the

microphone in place.

Mounting the NT1

Diagram 1 Mounting the NT1 in the

SMR shock mount
