Getting Started

1422104502

Version 06

(>F:]2)

This document describes the R&S®SMB100B, stock no. 1422.1000.02 and its

options.

Muehldorfstr. 15, 81671 Muenchen, Germany

Phone: +49 89 41 29 - 0

Email: [email protected]

Internet: www.rohde-schwarz.com

Subject to change – data without tolerance limits is not binding.

R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.

All other trademarks are the properties of their respective owners.

1422.1045.02 | Version 06 | R&S®SMB100B

The following abbreviations are used throughout this manual: R&S®SMB100B is abbreviated as

R&S SMB100B, R&S®VISA is abbreviated as R&S VISA

Contents

R&S®SMB100B

3Getting Started 1422.1045.02 ─ 06

Contents

1 Safety and regulatory information....................................... 7

1.1 Safety instructions................................................................................7

1.2 Labels on R&S SMB100B................................................................... 10

1.3 Warning messages in the documentation........................................ 11

1.4 Where to find key documents on Rohde & Schwarz....................... 11

1.5 Korea certification class B.................................................................12

2 Documentation overview.................................................... 13

2.1 Getting started manual.......................................................................13

2.2 User manuals and help.......................................................................13

2.3 Service manual....................................................................................13

2.4 Instrument security procedures........................................................ 14

2.5 Printed safety instructions.................................................................14

2.6 Data sheets and brochures................................................................14

2.7 Release notes and open source acknowledgment (OSA)...............14

2.8 Application notes, application cards, white papers, etc................. 15

2.9 Videos.................................................................................................. 15

3 Key features......................................................................... 17

4 Preparing for use................................................................. 19

4.1 Lifting and carrying............................................................................ 19

4.2 Unpacking and checking....................................................................19

4.3 Choosing the operating site.............................................................. 20

4.4 Setting up the R&S SMB100B............................................................20

4.4.1 Placing the R&S SMB100B on a bench top..........................................20

4.4.2 Mounting the R&S SMB100B in a rack................................................. 22

Contents

R&S®SMB100B

4Getting Started 1422.1045.02 ─ 06

4.5 Considerations for test setup............................................................ 23

4.6 Connecting to power.......................................................................... 24

4.7 Connecting to LAN............................................................................. 24

4.8 Connecting USB devices................................................................... 25

4.9 Connecting to RF coaxial connectors.............................................. 26

4.10 Connecting to RF 50 Ω....................................................................... 28

4.11 Connecting to Ref In/Ref Out.............................................................28

4.12 Switching on or off............................................................................. 29

5 Instrument tour.................................................................... 31

5.1 Front panel tour.................................................................................. 31

5.1.1 Utility keys.............................................................................................32

5.1.2 Touchscreen..........................................................................................32

5.1.3 Function keys........................................................................................33

5.1.4 Navigation controls............................................................................... 33

5.1.4.1 Rotary knob...........................................................................................33

5.1.4.2 Editing keys...........................................................................................34

5.1.4.3 Navigation keys.....................................................................................34

5.1.5 Display keys..........................................................................................35

5.1.6 USB connector......................................................................................35

5.1.7 RF 50 Ω.................................................................................................36

5.1.8 Keypad..................................................................................................36

5.1.9 On/Standby........................................................................................... 36

5.2 Rear panel tour....................................................................................36

5.2.1 Connectors............................................................................................37

6 Trying out the instrument................................................... 41

6.1 Generating an unmodulated carrier.................................................. 41

6.2 Generating an RF frequency sweep signal...................................... 45

Contents

R&S®SMB100B

5Getting Started 1422.1045.02 ─ 06

6.3 Saving and recalling settings............................................................ 47

7 Instrument control............................................................... 51

7.1 Possible ways to operate the instrument......................................... 51

7.2 Means of manual interaction............................................................. 52

7.3 Understanding the display information............................................ 52

7.3.1 Status bar..............................................................................................53

7.3.2 Tile diagram.......................................................................................... 53

7.3.3 Taskbar................................................................................................. 54

7.3.4 Additional display characteristics.......................................................... 55

7.4 Accessing the functionality............................................................... 56

7.5 Entering data....................................................................................... 57

7.5.1 Entering numeric parameters................................................................58

7.5.2 Entering alphanumeric parameters.......................................................59

7.5.3 Undo and redo actions..........................................................................59

7.6 Getting information and help.............................................................59

7.7 Remote control....................................................................................61

7.8 Remote operation over VNC.............................................................. 62

8 Contacting customer support............................................ 63

Index..................................................................................... 65

Contents

R&S®SMB100B

6Getting Started 1422.1045.02 ─ 06

Safety and regulatory information

R&S®SMB100B

7Getting Started 1422.1045.02 ─ 06

1 Safety and regulatory information

The product documentation helps you use the product safely and efficiently. Fol-

low the instructions provided here and in the following chapters.

Intended use

The product generates radio frequency (RF) signals for the development, produc-

tion and verification of electronic components, modules or devices. The product is

intended for industrial use, for example for production and conformance testing,

maintenance and engineering laboratories.

Use the product only for its designated purpose. Any other use is considered

improper use. Observe the operating conditions and performance limits stated in

the data sheet.

Target audience

This document targets at all users, including technicians, operators, administra-

tors and maintenance personnel. The required skills and experience of the users

depend on the test setup and application of the product.

Where do I find safety information?

Safety information is part of the product documentation. It warns you of potential

dangers and gives instructions on how to prevent personal injury or damage

caused by dangerous situations. Safety information is provided as follows:

●In Chapter 1.1, "Safety instructions", on page 7. The same information is

provided in many languages as printed "Safety Instructions". The printed

"Safety Instructions" are delivered with the product.

●Throughout the documentation, safety instructions are provided when you

need to take care during setup or operation.

1.1 Safety instructions

Products from the Rohde & Schwarz group of companies are manufactured

according to the highest technical standards. To use the products safely, follow

the instructions provided here and in the product documentation. Keep the prod-

uct documentation nearby and offer it to other users.

Safety instructions

Safety and regulatory information

R&S®SMB100B

8Getting Started 1422.1045.02 ─ 06

Use the product only for its intended use and within its performance limits. Inten-

ded use and limits are described in the product documentation such as the data

sheet, manuals and the printed "Safety Instructions". If you are unsure about the

appropriate use, contact Rohde & Schwarz customer service.

Using the product requires specialists or specially trained personnel. These users

also need sound knowledge of at least one of the languages in which the user

interfaces and the product documentation are available.

Reconfigure or adjust the product only as described in the product documentation

or the data sheet. Any other modifications can affect safety and are not permitted.

Never open the casing of the product. Only service personnel authorized by

Rohde & Schwarz are allowed to repair the product. If any part of the product is

damaged or broken, stop using the product. Contact Rohde & Schwarz customer

service at https://www.rohde-schwarz.com/support.

Lifting and carrying the product

The maximum weight of the product is provided in the data sheet. You can lift or

carry the product by yourself, if you can manage the weight on your own. Alterna-

tively, you can use lifting or transporting equipment. Follow the instructions provi-

ded by the equipment manufacturer.

Choosing the operating site

Only use the product indoors. The product casing is not waterproof. Water that

enters can electrically connect the casing with live parts, which can lead to elec-

tric shock, serious personal injury or death if you touch the casing. If

Rohde & Schwarz provides accessories designed for your product, e.g. a carrying

bag, you can use the product outdoors.

Unless otherwise specified, you can operate the product up to an altitude of

2000 m above sea level. The product is suitable for pollution degree 2 environ-

ments where nonconductive contamination can occur. For more information on

environmental conditions such as ambient temperature and humidity, see the

data sheet.

Setting up the product

Always place the product on a stable, flat and level surface with the bottom of the

product facing down. If the product is designed for different positions, secure the

product so that it cannot fall over.

Safety instructions

Safety and regulatory information

R&S®SMB100B

9Getting Started 1422.1045.02 ─ 06

If the product has foldable feet, always fold the feet completely in or out to ensure

stability. The feet can collapse if they are not folded out completely or if the prod-

uct is moved without lifting it. The foldable feet are designed to carry the weight of

the product, but not an extra load.

If stacking is possible, keep in mind that a stack of products can fall over and

cause injury.

If you mount products in a rack, ensure that the rack has sufficient load capacity

and stability. Observe the specifications of the rack manufacturer. Always install

the products from the bottom shelf to the top shelf so that the rack stands

securely. Secure the product so that it cannot fall off the rack.

Connecting to power

The product is an overvoltage category II product. Connect the product to a fixed

installation used to supply energy-consuming equipment such as household

appliances and similar loads. Keep in mind that electrically powered products

have risks, such as electric shock, fire, personal injury or even death. Replace

parts that are relevant to safety only by original parts, e.g. power cables or fuses.

Take the following measures for your safety:

●Before switching on the product, ensure that the voltage and frequency indica-

ted on the product match the available power source. If the power adapter

does not adjust automatically, set the correct value and check the rating of the

fuse.

●Only use the power cable delivered with the product. It complies with country-

specific safety requirements. Only insert the plug into an outlet with protective

conductor terminal.

●Only use intact cables and route them carefully so that they cannot be dam-

aged. Check the power cables regularly to ensure that they are undamaged.

Also ensure that nobody can trip over loose cables.

●If you connect the product to an external power supply, use the one delivered

with the product or recommended in the product documentation. The external

power supply must conform to the country-specific regulations.

●Only connect the product to a power source with a fuse protection of maxi-

mum 20 A.

●Ensure that you can disconnect the product from the power source at any

time. Pull the power plug to disconnect the product. The power plug must be

easily accessible. If the product is integrated into a system that does not meet

Safety instructions

Safety and regulatory information

R&S®SMB100B

10Getting Started 1422.1045.02 ─ 06

these requirements, provide an easily accessible circuit breaker at the system

level.

Cleaning the product

Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that

the casing is not waterproof. Do not use liquid cleaning agents.

Meaning of safety labels

Safety labels on the product warn against potential hazards.

Potential hazard

Read the product documentation to avoid personal injury or product damage.

Electrical hazard

Indicates live parts. Risk of electric shock, fire, personal injury or even death.

Hot surface

Do not touch. Risk of skin burns. Risk of fire.

Protective conductor terminal

Connect this terminal to a grounded external conductor or to protective ground. This

connection protects you against electric shock if an electric problem occurs.

1.2 Labels on R&S SMB100B

Labels on the casing inform about:

●Personal safety, see "Connecting to power" on page 9.

●Product and environment safety, see Table 1-1.

●Identification of the product, see the serial number on the rear panel.

Table 1-1: Labels regarding R&S

SMB100B and environment safety

Labeling in line with EN 50419 for disposal of electrical and electronic equipment after

the product has come to the end of its service life. For more information, see the prod-

uct user manual, chapter "Disposal".

Labels on R&S SMB100B

Andere Handbücher für SMB100B

Inhaltsverzeichnis

Andere Rohde & Schwarz Tragbarer Generator Handbücher

Rohde & Schwarz

Rohde & Schwarz TETRA Release 2 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz AREG100A Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMCVB-K980 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz HMF2525 Bedienungs- und Wartungshandbuch

Rohde & Schwarz

Rohde & Schwarz SMB100B Anleitung zur Verwendung

Rohde & Schwarz

Rohde & Schwarz SMB100B Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMBV100A Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMB100B Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S SMCV100BP2 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S SMW-K52 DVB-H/T Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMIQ03HD Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz AM 300 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMBV100B Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz HMF2525 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMM100A Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S SMU200A Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S SMA100A Anleitung zur Verwendung

Rohde & Schwarz

Rohde & Schwarz SMW-K141 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMBV-K52 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMA100B Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMIQ02B Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S AREG800A Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMC100AP31 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz SMBV-K48 Bedienungsanleitung

Beliebte Tragbarer Generator Handbücher anderer Marken

Kohler

Kohler 20EORZ Bedienungsanleitung

Powerhorse

Powerhorse 83171 Bedienungsanleitung

HURST

HURST ML-630-SI Bedienungsanleitung

ETQ

ETQ TG4000 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 40265 Einrichtungshandbuch

ConMed

ConMed 7550 Bedienungsanleitung

Owon

Owon Waveform Generator Bedienungsanleitung

evertz

evertz 7700 Series Bedienungsanleitung

Power Stroke

Power Stroke PS906025 Bedienungsanleitung

Firefly

Firefly Cygnus CYG2400/460/24 Bedienungsanleitung

Draper

Draper PG950S Firmware-Update

PowerBoss

PowerBoss PowerBoss Bedienungsanleitung

SDMO

SDMO SH 4000 Bedienungsanleitung

EINHELL

EINHELL STE 5500 Bedienungsanleitung

Wanco

Wanco WI3000P Bedienungsanleitung

Full Boar

Full Boar FBT-3300 Bedienungsanleitung

Dwyer Instruments

Dwyer Instruments ASG Bedienungsanleitung

Westinghouse

Westinghouse WH1000i Series Bedienungsanleitung
