Rohnson R-810 Bedienungsanleitung
INSTRUCTIONS MANUAL
MOD. R-810 BOX FAN
IMPORTANT INSTRUCTIONS
1. Read all instructions carefully before you use the appliance.
2. Remove the packages and ensure that the appliance is undamaged. In case of doubt do
not use the fan and contact with your supplier.
3. Do not let children play with parts of the packages (such as plastic bags).
4. Before plugging to the socket, check that if the voltage of your main supply matches the
voltage marked on the rating label of the appliance.
5. Before assembling or dismantling the fan, must sure that the fan is unplugged.
6. Before unplugging the power cord, turn off the switch.
7. Do not insert any object into the guard while the fan is operating .IT WILL CAUSE INJURY
TO THE PERSON.
8. The fan shall be used for temperate climates, do not use the fan at the high humidity area
or dusty area. Do not use the fan where acid or alkali is stored.
9. Do not hang any clothes on the fan guards.
10. Do not use the fan outdoors.
11. Do not continuously to blow the baby or the patient directly for a long time.
12. The appliance is not intended for use by young children or infirm persons without
supervision.
13. Children should be supervised to ensure that they do not play with the appliance.
14. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Parts of description
1. Front cover 2.Louver
3. Louver cap 4.Blade
5. Base 6.Feet
7. Rear cover
8. Speed switch
9. Louver switch
11
Caution
This appliance is for household use only. Any servicing other than cleaning and user
maintenance should be performed by authorized service representative. Do not immerse the
unit in water. To reduce the risk of fire or electric shock, do not remove the housing, no user
serviceable parts inside. Only authorized service personnel shall handle repair work.
Operations
Extend the Feet before use. The feet can be folded
after use to aid storage
1. Speed Control
Rotate the knob for desired speed “1”,“2”or“3”.
2. Control the louver
Turn the control knob to position “ ON “ to make the louver operate.
Turn the control knob to position “ OFF “ to make the louver stop operating.
3.The angle of your box fan can be adjusted up to 20
degrees from the vertical.
0: OFF
1: LOW
2: MED
3: HIGH
Cleaning
1. Use a coin to loosen the louver cap. Unscrew the cap in a clockwise direction. Fig.1.
2. Remove the cap and louver.Fig.2.
3. Unscrew the four screws which hold the guard on the rear of the fan.
4. Remove the guard, release the screw which holds the fan blade. Fig.4.
5. Remove the fan blade. Fig.5.
6. After cleaning, follow assembly instructions in reverse order to assemble the fan.
Maintenance
BEFORE MAITENANCE, REMOVE THE PLUG FROMTHE SUPPLYSOCKET.
Do not let water get into the appliance during the cleaning.
Use a soft damp cloth to clean the fan blade and the guards, then dry them.
Do not use thinner, alcohol, or other chemical liquid to clean the fan.
Preservation
After maintenance, please follow the following steps to keep the fan stored.
1. Apply a few drops of lubricant on motor shaft to prevent from corrosion.
2. Remove the oil or dirty stains from the body to prevent the fan from damage.
3. Follow assembly instructions in reverse order, get the fan back to the carton and store the
fan at dry place.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer
providing this service.
Disposing of a household appliance separately avoids possible negative consequences for
the environment and health, deriving form inappropriate disposal and enables the constituent
materials to be recovered to obtain significant savings in energy and resources. As a reminder
of the need to dispose of household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
5
2
3
1
4
