Ross Vision Crosspoint Module Bedienungsanleitung

Ross Video Limited

Crosspoint Module

Installation Guide

V I S I O N

2• Crosspoint Module Installation Guide

Crosspoint Module Installation Guide

• Ross Part Number: 4800DR-345-02

• Release Date: July, 2010. Printed in Canada

The information contained in this document is subject to change without notice or

obligation.

Contents of this publication may not be reproduced in any form without the

written permission of Ross Video Limited. Reproduction or reverse engineering of

copyrighted software is prohibited.

Patents

This product is protected by the following US Patents: 4,205,346; 5,115,314;

5,280,346; 5,561,404; 7,034,886; 7,508,455. This product is protected by the

following Canadian Patents: 2039277; 1237518; 1127289. Other patents pending.

Notice

The material in this document is furnished for informational use only. It is subject to

change without notice and should not be construed as commitment by Ross Video

Limited. Ross Video Limited assumes no responsibility or liability for errors or

inaccuracies that may appear in this document.

Trademarks

•

is a registered trademark of Ross Video Limited.

• Ross, ROSS, ROSS®, MLE, Vision, Octane, Squeeze & Tease, Squeeze

& Tease WARP, OverDrive, RossGear, openGear, DashBoard Control

System, and SoftMetal are registered and unregistered trademarks of Ross

Video Limited.

• Windows is a registered trademark of Microsoft Corporation in the United

States and other countries.

• All other product names and any registered and unregistered trademarks

mentioned in this document are used for identification purposes only and

remain the exclusive property of their respective owners.

Important Regulatory and Safety Notices to Service

Personnel

Before using this product and any associated equipment, refer to the "Important

Safety Instructions" listed in the front of your Engineering Manual to avoid

personnel injury and to prevent product damage.

Crosspoint Module Installation Guide • 3

Product may require specific equipment, and/or installation procedures to be carried

out to satisfy certain regulatory compliance requirements. Notices have been

included in this publication to call attention to these specific requirements.

General Handling Guidelines

• Careful handling, using proper ESD precautions, must be observed.

• Power down the system before PCB removal.

ESD Susceptibility: Avoid handling the switcher circuit

boards in high static environments such as carpeted areas,

and when synthetic fiber clothing is worn. Touch the frame

to dissipate static charge before removing boards from the

frame, and exercise proper grounding precautions when

working on circuit boards.

Environmental Information

The equipment that you purchased required the extraction and use of natural

resources for its production. It may contain hazardous substances that could

impact health and the environment.

To avoid the potential release of those substances into the environment and to

diminish the need for the extraction of natural resources, Ross Video encourages

you to use the appropriate take-back systems. These systems will reuse or recycle

most of the materials from your end-of-life equipment in an environmentally

friendly and health conscious manner.

The crossed-out wheeled bin symbol invites you to use these systems.

If you need more information on the collection, reuse, and recycling systems, please

contact your local or regional waste administration.

You can also contact Ross Video for more information on the environmental

performances of our products.

4• Package Contents

Package Contents

The contents of a Crosspoint Module kit is listed below. If any items are missing, or

damaged, contact Ross Video Technical Support.

Qty Part# Item

1 V-110M Crosspoint Module

1 727-024R Module Control Link Cable (Black, CAT5e, 2’ long)

1 727-025R Module Control Link Cable (Black, CAT5e, 1’ long)

1 4800CR-375 Module Power Cable Adapter

5 650-005R Retaining Nuts

Removing a Module • 5

Removing a Module

To remove an existing module, you must first disconnect the communications and

power cables from the existing module, and then remove the module. If you are

removing a blank module plate, there are no communications or power cables to

disconnect.

Warning Hazardous Voltages: Hazardous voltages are

present in the control panel as long as any of the power

supplies are connected to the AC power.

1. Power down the control panel. The frame can remain on during this

procedure. Refer to your Vision switcher documentation for information on

shutting down the control panel.

2. Unplug the Primary and Redundant (if installed) power from the control

panel.

3. Lift up on the control panel lid to gain access to the control panel tub.

4. Identify the module, or blank module plate, that you want to remove.

5. Disconnect the Module Power Cable from the existing module you want to

remove. This 4-conductor ribbon cable delivers power to all the modules

in the row. When removing it, ensure that you do not accidentally unplug it

from any neighboring modules.

PMC Board

To Front of Control Panel

Power Connector

Figure 1: Power Connector

6. Disconnect both of the Module Control Link Cables from the existing

module you want to remove. These CAT5e cables deliver all the command

signals to and from the module, as well as the other modules in the same

row.

7. Remove the four (4) Retaining Nuts located at each corner of the existing

module, or blank module plate, and keep them in a safe place. A ¼ inch hex

driver or wrench is required.

8. Remove the existing module, or blank module plate, from the control panel.

6• Installing a Crosspoint Module

Installing a Crosspoint Module

To install the Crosspoint module, you must remove the plate from the Crosspoint

module, install the plate into the module slot in the control panel, and then install the

Crosspoint module onto the plate.

1. Remove the five (5) Retaining Screws securing the plate to the Crosspoint

module and remove the plate.

Retaining Screw Holes

Figure 2: Crosspoint Module and Plate

2. Slide the Crosspoint plate into the open module slot that you want to install

the module into.

3. Install the four (4) Retaining Nuts located at each corner of the Crosspoint

plate to a maximum torque of 5 in-lbs (6 cm-kg). A ¼ inch hex driver or

wrench is required.

Front of Control Panel

Retaining Nuts

Figure 3: Crosspoint Module Plate Retaining Nuts

4. Align the Crosspoint module so the Retaining Screw Holes on the

Crosspoint module line up with the mounts on the Crosspoint plate.

5. Using the screws obtained from removing the Crosspoint plate from the

Crosspoint module, secure the Crosspoint module to the Crosspoint plate.

Next, you must install the Module Control Link cables and the Module Power cable

to the Crosspoint module.

Cabling a Crosspoint Module • 7

Cabling a Crosspoint Module

If you are installing the Crosspoint module into a slot on the right-hand side of the

control panel, the Module Power Cable must be twisted to properly connect to the

Power Connector on the Crosspoint module. In this case, you may want to replace

the Module Power Cable with the longer cable provided (4800CR-361).

1. Connect and secure the existing Module Control Link Cable to the PREV

port on the first module (1). This CAT5e cable with an RJ-45 connector on

either end is already installed in the control panel.

1 2

Front of Control Panel

Module Control

Link Cable

Figure 4: Module Control Link Cable

2. Connect and secure the free end of the Module Control Link Cable

connected to the PREV port of the second module (2), to the NEXT port on

the first module (1).

3. Connect the black and white end of the Module Power Cable Adapter to the

Module Power Cable.

Front of Control Panel

Module Power

Cable

Module Power

Cable Adapter

Figure 5: Module Power Cable Adapter

4. Connect the orange end of the Module Power Cable Adapter to the

Crosspoint module.

5. Ensure that the Module Power Cable is properly connected to the remaining

modules.

8• Upgrading a PMC

Upgrading a PMC

The Panel Module Controllers (PMCs) may need to be upgraded if you perform a

software upgrade or replace a module. If PMCs need to be upgraded, the message

PMCs need to be upgraded; please go to Panel Modules

menu is displayed on the Main Menu.

1. Press HOME > More > Setup > More > Panel Modules .

A warning is displayed, asking you if you want to enter the menu. Press

Yes to display the Panel Modules Menu.

Figure 6: Panel Modules Menu - Panel Row & Crosspoint

2. Press Upgrade PMCs.

The switcher starts upgrading the PMC on the control panel.

Mapping a Single Module • 9

Mapping a Single Module

If you are mapping a single modules to a panel row, you can use select the link and

node that you installed the module on and assign it to a panel row.

1. Press HOME > More > Setup > More > Panel Modules .

A warning is displayed, asking you if you want to enter the menu. Press

Yes to display the Panel Modules Menu.

Figure 7: Panel Modules Menu - Panel Row & Crosspoint

2. Use the Link/Node knob to select the link and node that the module you

want to assign to a row is installed on. You can also press a button on the

module to go to the link and node.

3. Press Panel Row & Crosspoint.

4. Use the Panel Row knob to select the panel row that you want to assign

the module to. You can select either an internal row (Row 1 to Row 8), or

an external row (Row 1 to Row 16).

5. Use the First Crosspoint knob to select the number of the first crosspoint

button on the module you are setting up. Each crosspoint module has 8

buttons, so the first button on module 1 is 1, the first button on module 2 is

9. If the module does not have crosspoint buttons, this knob is gray.

6. Set up a Custom Control module as follows:

a) Use the Link/Node knob to select the link and node that the module

you want to assign to a row is installed on. You can also press a button

on the module to jump to the link and node.

b) Press Custctrl & GPI Group.

c) Use the First Custctrl knob to select the number of the first custom

control button on the module you are setting up. Each custom control

module has 8 buttons, so the first button on module 1 is 1, the first

button on module 2 is 9. If the module does not have custom control

buttons, this knob is gray.

10 • Mapping a Single Module

Figure 8: Panel Modules Menu - Custctrl & GPI Group
