RSA Lighting C-700 Bedienungsanleitung

DESCRIPTION Catalog # Type

Project

Comments Date

Prepared by

www.cooperlighting.com

SPECIFICATION FEATURES

A...Housing

Low voltage recessed ﬁxture housing for

insulated ceiling. Includes integral low

voltage magnetic transformer. 14 ga. steel

junction box.

B ...Electrical

Socket is pre-wired to the j-box 18AWG

SF-1 leads. Primary lead is 120V or 277V.

Transformer is rated 180˚ Class H. State of

Washington AirTite approved.

C ...Mounting

Provided with two (2) adjustable 16 ga.

steel hanger bars which can be extended

to 25.25”.

D...System Protection

Transformers have thermal protection

and operate at 11.5 volts nominal.

Ceiling Cut-Out: 3.75” dia.

MICROGEM

HOUSING

C700

Insulated Ceiling

AirTite Housing w/

Integral Low

Voltage Magnetic

Transformer

FOR 12V LAMP 50W max.

ORDERING INFORMATION

Insulated ceiling AirTite (I.C.) Microgem recessed low voltage housing

with integral magnetic transformer 50W max. 120V

For use in insulated ceiling (I.C.) applications. Housing may be covered

on all sides with insulation material.

Speciﬁcations and Dimensions subject to change without notice.

RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031

rev. 102406

Housing

C700 =

Microgem insulated ceiling

AirTitr recessed housing.

C700

3.75" dia.

19.125"

17.125"

14.188"

9.88"10.75"

7.5"

14" min.

25.25" max.

A

D

C

B
