RSA Lighting MICROGEM RECESSED MLV3055 Bedienungsanleitung

DESCRIPTION Catalog # Type

Project

Comments Date

Prepared by

www.cooperlighting.com

SPECIFICATION FEATURES

A Trim

35˚ adjustable regressed reﬂector trim for

downlight and accent applications. 4.3”

o.d. trim face.

B Lamp

For use with 12V MR16 lamp 71W max.

Lamp not included.

C Socket

GU5.3 bi-pin socket for 12V MR16.

(Included with Microgem housing sold

separately)

D Lens

Includes clear protective glass lens.

Can hold up to 2 optical accessories total.

E Finish

MLV3055 Powder coated white trim

with clear reﬂector.

MLV3057 Powder coated white trim

with black reﬂector.

MLV3061 Chrome trim with clear

reﬂector.

MICROGEM

RECESSED

MLV3055 - 3061

4.3” O.D.

Round Die Cast

Trim w/ Regressed

Reﬂector 35˚

Adjustability

FOR 12V MR16 71W max.

Compatible Housings:

C500 / C500-SH

C600 / C600-EL

C700

C800

C900

SH2A

ORDERING INFORMATION

Fixture

MLV3055 White Trim w/ Clear Reﬂector

MLV3057 Black Trim w/ Black Reﬂector

MLV3061 Chrome Trim w/ Clear Reﬂector

4.3” round recessed adjustable regressed reﬂector trim for downlight

and accent applications. For use with 12V MR16 lamp 71W max.

Speciﬁcations and Dimensions subject to change without notice.

RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031

rev. 102406

2.25” dia.

4.31” dia.

2.125”

35˚
