RTX RTX8200 Bedienungsanleitung

RTX8200 LOCATION GATEWAY GUIDE 4.6 1 |P a g e

Proprietary and Confidential

RTX8200

Location Gateway

Technical Reference Document

Version 1.0

RTX8200 LOCATION GATEWAY GUIDE 4.6 2 |P a g e

Proprietary and Confidential

Trademarks

RTX and the combinations of its logo thereof are trademarks of RTX A/S, Denmark.

Other product names used in this publication are for identification purposes and maybe the trademarks of their

respective companies.

Disclaimer

The contents of this document are provided about RTX products. RTX makes no representations with respect to

completeness or accuracy of the contents of this publication and reserves the right to make changes to product

descriptions, usage, etc., at any time without notice. No license, whether express, implied, to any intellectual property

rights are granted by this publication

Confidentiality

This document should be regarded as confidential, unauthorized copying is not allowed

http://www.rtx.dk

RTX8200 LOCATION GATEWAY GUIDE 4.6 3 |P a g e

Proprietary and Confidential

INDEX

RTX8200 LOCATION GATEWAY GUIDE 4.6 4 |P a g e

Proprietary and Confidential

1About This Document

This document describes the configuration, customization, management, operation, maintenance and troubleshooting

of the RTX8200 Location Gateway in RTX generic mode. For customer, specific modes refer to specific customer

agreements, which describe the software operational deviations from this document.

1.1 Audience

Who should read this guide? First, this guide is intended for networking professionals responsible for designing and

implementing RTX based enterprise networks.

Second, network administrators and IT support personnel that need to install, configure, maintain, and monitor

elements in a “live” SME VoIP network will find this document helpful. Furthermore, anyone who wishes to gain

knowledge on fundamental features in the Beatus system can also benefit from this material.

1.2 When Should I Read This Guide

Read this guide before you install the core network devices of VoIP SME System and when you are ready to setup or

configure SIP server, NAT aware router, advanced VLAN settings, base stations, and Location Gateway’s in a multi cell

setup.

This manual will enable you to set up and connect your RTX8200 Location Gateway in a Multi Cell system.

1.3 Important Assumptions

This document was written with the following assumptions in mind:

•You understand network deployment in general

•You have working knowledge of basic TCP/IP/SIP protocols, Network Address Translation, etc...

•A proper site survey has been performed, and the administrator have access to these plans

1.4 What’s Inside This Guide

We summarize the contents of this document in the table below:

WHERE IS IT?

CONTENT

PURPOSE

CHAPTER 2

TBD

CHAPTER 3

TBD

CHAPTER 4

TBD

CHAPTER 5

TBD

RTX8200 LOCATION GATEWAY GUIDE 4.6 5 |P a g e

Proprietary and Confidential

1.5 What’s Not in This guide

This guide provides overview on, how-to configure RTX8200 Location Gateway to an RTX Generic System.

It is not intended as a comprehensive reference to all detail and specific steps on how to configure other vendor

specific components/devices needed to make the SME VoIP System functional. For such a reference to vendor

specific devices, please contact the respective vendor for documentation.

Configuration on specific Alarm/Messaging servers are not included in this guide.

1.6 Abbreviations

For this document, the following abbreviations hold:

DHCP: Dynamic Host Configuration Protocol

DNS: Domain Name Server

HTTP(S): Hyper Text Transfer Protocol (Secure)

(T)FTP: (Trivial) File Transfer Protocol

IOS: Internetworking Operating System

PCMA: A-law Pulse Code Modulation

PCMU: mu-law Pulse Code Modulation

PoE: Power over Ethernet

RTP: Real-time Transport Protocol

RPORT: Response Port (Refer to RFC3581 for details)

SIP: Session Initiation Protocol

SME: Small and Medium scale Enterprise

VLAN: Virtual Local Access Network

TOS: Type of Service (policy based routing)

URL: Uniform Resource Locator

UA: User Agent

1.7 References/Related Documentation

RTX8430 Handset_Manual_Operations_v4.6

RTX8630 Handset_Manual_Operations_v4.6

RTX8631_Handset_Manual_Operations_v4.6

RTX8632_Handset_Manual_Operations_v4.6

RTX8633_Handset_Manual_Operations_v4.6

RTX8830_Handset_Manual_Operations_v4.6

How to Deploy SME VOIP System v1.4

Provisioning of SME VoIP System (23)

1.8 Document History

REVISION

AUTHOR

ISSUE DATE

COMMENTS

4.6

HDJ

01-04-2019

Updated to V460 Firmware

RTX8200 LOCATION GATEWAY GUIDE 4.6 6 |P a g e

Proprietary and Confidential

1.9 What is new

What new features have been added.

VERSION

FEATURE

V460

All new product

1.10 Documentation Feedback

We always strive to produce the best and we also value your comments and suggestions about our documentation. If

you have any comments about this guide, please enter them through the Feedback link on the RTX website. We will

use your feedback to improve the documentation.

RTX8200 LOCATION GATEWAY GUIDE 4.6 7 |P a g e

Proprietary and Confidential

2. Introduction –System overview

In a typical DECT telephony system, you have base station, repeaters and handsets, allowing the users to

make/receive calls and messages.

A typical setup could look like this:

Increasing demand for locating equipment, personal or pushing information to specific handset on a specific location,

demands the system to know exactly where the device is located.

This can be done be adding RTX8200 Location gateway devices to the DECT system.

RTX8200 LOCATION GATEWAY GUIDE 4.6 8 |P a g e

Proprietary and Confidential

Wireless Bands

The bands supported in the SME VoIP are summarized as follows:

Frequency bands:

1880 –1930 MHz (DECT)

1880 –1900 MHz (10 carriers) Europe/ETSI

1910 –1930 MHz (10 carriers) LATAM

1920 –1930 MHz (5 carriers) US

System Capacity (in Summary)

SME network capacity of relevant components can be summarized as follows:

DESCRIPTION

CAPACITY

MAX BASE STATION

4.000

MAX LOCATION GATEWAYS

16.000

MAX TERMINALS (SELECT BETWEEN 6 HANDSETS AND 1 HEADSET MODELS

16.000

MAX ACTIVE CALLS (NARROW BAND)

32.000

MAX ACTIVE CALLS (WIDE BAND)

16.000

RTX8200 LOCATION GATEWAY GUIDE 4.6 9 |P a g e

Proprietary and Confidential

Installation of Location Gateways

After planning the network, installing the base stations, the Locations gateways must be added, therefore, we briefly

describe how to install the location gateways. One important thing that must be decided before installing the location

gateways is how to power them.

Package –Contents/Damage Inspection

Before Package Is Opened:

Examine the shipping package for evidence of physical damage or mishandling prior to opening. If there is a proof of

mishandling prior to opening, you must report it to the relevant support center of the regional representative or

operator.

Contents of Package:

Make sure all relevant components are available in the package before proceeding to the next step.

Every shipped base unit package/box contains the following items:

•Location Gateway

Please only use screws and actors with the following dimensions.

Screws: 30,7 mm (L), 2,6 mm (W)

Actors: 24,8 mm (L), 5,8 mm (W)

Damage Inspection:

The following are the recommended procedure for you to use for inspection:

1. Examine all relevant components for damage.

2. Make a “defective on arrival –DOA” report or RMA to the operator. Do not move the shipping carton until

the operator has examined it. If possible, send pictures of the damage. The operator/regional representative

will initiate the necessary procedure to process this RMA. They will guide the network administrator on how

to return the damaged package if necessary.

3. If no damage is found, then unwrap all the components and dispose of empty package/carton(s) in

accordance with country specific environmental regulations.

RTX8200 LOCATION GATEWAY GUIDE 4.6 10 |P a g e

Proprietary and Confidential

RTX8200 Location Gateway Mechanics

The Location Gateway front

How to insert batteries or PoE module

To open the Location gateway, you need to use a screwdriver or other flat tool.

Insert the screwdriver on the left side and press the small metal lock to open the Location gateway.

Now insert the batteries (2xAA) or the PoE module.

If using PoE module remember to remove the small piece of plastic covering the Ethernet plug.

RTX8200 Location Gateway –Tamper Alarm

The RTX8200 Location Gateway is equipped with a tamper alarm, in case someone tries to tamper with the device.

The tamper alarm allows the system admin to receive a warning if tampering is detected. Tampering alarm is activated

if the front is removed.
