RuggedCom RuggedSwitch RS900GP Handbuch

RuggedSwitch™

RS900GP

Hardware Installation Guide

Revision 101 - November 1, 2012

www.RuggedCom.com

RuggedSwitch™ RS900GP

RuggedSwitch™ RS900GP: Hardware Installation Guide

Dissemination or reproduction of this document, or evaluation and communication of its contents, is not authorized except where expressly

permitted. Violations are liable for damages. All rights are reserved, particularly for the purposes of patent application or trademark registration.

This document contains proprietary information, which is protected by copyright. All rights are reserved. No part of this document may be

photocopied, reproduced or translated to another language without the prior written consent of RuggedCom Inc.

Disclaimer Of Liability

We have checked the contents of this manual against the hardware and software described. However, deviations from the description cannot

be completely ruled out.

RuggedCom shall not be liable for any errors or omissions contained herein or for consequential damages in connection with the furnishing,

performance, or use of this material.

Theinformationgiveninthisdocumentisreviewedregularlyandanynecessarycorrectionswillbeincludedinsubsequenteditions.Weappreciate

any suggested improvements. We reserve the right to make technical improvements without notice.

Registered Trademarks

ROX™, RuggedBackbone™, RuggedRated™ and eRSTP™ are trademarks of RuggedCom Inc. ROS®, RuggedRouter® and RuggedSwitch®

are registered trademarks of RuggedCom Inc. Other designations in this manual might be trademarks whose use by third parties for their own

purposes would infringe the rights of the owner.

Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.

The registered trademark Linux® is used pursuant to a sublicense from LMI, the exclusive licensee of Linus Torvalds, owner of the mark on

a world-wide basis.

Third Party Copyrights

RuggedCom recognizes the following third party copyrights:

Warranty

Five (5) years from date of purchase, return to factory. For warranty details, visit www.RuggedCom.com or contact your customer service

representative.

Contacting RuggedCom

Corporate Headquarters US Headquarters Europe Headquarters

RuggedCom Inc.

300 Applewood Crescent,

Concord, Ontario

Canada, L4K 5C7

Tel: +1 905 856 5288

Fax: +1 905 856 1995

Toll-free: 1 888 264 0006

RuggedCom

1930 Harrison Street, Suite 209

Hollywood, Florida

USA, 33020

Tel: +1 954 922 7938 ext.103

Fax: +1 954 922 7984

Toll-free: 1 888 264 0006

RuggedCom

Unit 41, Aztec Centre,

Aztec West, Almondsbury, Bristol

United Kingdom BS32 4TD

Tel: +44 1454 203 404

Fax: +44 1454 203 403

Email: [email protected]

Technical Support

Toll Free (North America): 1 866 922 7975

International: +1 905 856 5288

Email: [email protected]

Web: www.RuggedCom.com

RuggedSwitch™ RS900GP

RuggedCom® RuggedSwitch™ 3 RS900GP Installation Guide Rev 101

Table of Contents

FCC Statement And Cautions ................................................................................................... 6

1. Product Overview ................................................................................................................... 7

1.1. RS900GP Front Panel ................................................................................................ 9

2. Installation ............................................................................................................................ 10

2.1. DIN Rail Mounting ..................................................................................................... 10

2.2. Panel Mounting Options ............................................................................................ 11

2.2.1. RS900GP Front Panel Mount Option ............................................................. 11

2.2.2. RS900GP Rear Panel Mount Option ............................................................. 12

2.2.3. RS900GP Side Panel Mount Option .............................................................. 13

2.3. DC Power Supply Wiring and Grounding ................................................................. 14

2.4. Failsafe Output Wiring and Specifications ................................................................ 15

2.5. RS232 Port Wiring .................................................................................................... 15

2.6. RJ45 Ports: Signal Description ................................................................................. 16

3. Specifications ....................................................................................................................... 17

3.1. Operating Environment ............................................................................................. 17

3.2. Power Supply Specifications ..................................................................................... 17

3.2.1. General ........................................................................................................... 17

3.2.2. IEEE802.3AF .................................................................................................. 17

3.2.3. IEEE802.3AT .................................................................................................. 17

3.3. Failsafe Relay Specifications .................................................................................... 17

3.4. Twisted Pair Data Port Specifications ....................................................................... 18

3.5. Fiber Optic Port Specifications .................................................................................. 19

3.6. Physical Dimensions ................................................................................................. 20

3.7. Type Test Specifications ........................................................................................... 21

3.7.1. IEC 61850-3 Type Tests ................................................................................ 21

3.7.2. IEEE 1613 Type Tests ................................................................................... 22

3.7.3. IEC Environmental Type Tests ...................................................................... 22

3.8. Agency Approvals ..................................................................................................... 23

A. Warranty .............................................................................................................................. 24

RuggedSwitch™ RS900GP

RuggedCom® RuggedSwitch™ 4 RS900GP Installation Guide Rev 101

List of Figures

1.1. RS900GP Front Panel ........................................................................................................ 9

2.1. DIN Rail Mounting ............................................................................................................ 10

2.2. Front Panel Mounting ....................................................................................................... 11

2.3. Rear Panel Mounting ........................................................................................................ 12

2.4. Side Panel Mounting ......................................................................................................... 13

2.5. DC Power Supply Wiring and Grounding ......................................................................... 14

2.6. RS900GP Chassis Ground Connection ............................................................................ 14

2.7. Failsafe Output Relay ....................................................................................................... 15

2.8. RS232 Female Connector ................................................................................................ 15

2.9. RJ45 Port Connector ........................................................................................................ 16

3.1. RS900GP Physical Dimensions ........................................................................................ 20

RuggedSwitch™ RS900GP

RuggedCom® RuggedSwitch™ 5 RS900GP Installation Guide Rev 101

List of Tables

1.1. Front Panel LED Definitions ............................................................................................... 9

2.1. RS232 Female DCE Pinout .............................................................................................. 15

2.2. RJ45 Ethernet Pin Assignment ......................................................................................... 16

3.1. Operating Environment ..................................................................................................... 17

3.2. RS900GP Power Supply Specifications ........................................................................... 17

3.3. IEEE802.3AF Power Supply Ratings ................................................................................ 17

3.4. IEEE802.3AT Power Supply Ratings ................................................................................ 17

3.5. Failsafe Relay Specifications ............................................................................................ 17

3.6. Twisted Pair Data Port Specifications ............................................................................... 18

3.7. Fiber Optic Port Specifications ......................................................................................... 19

3.8. Physical Specifications ...................................................................................................... 20

3.9. RS900GP IEC 61850-3 Type Tests ................................................................................. 21

3.10. RS900GP IEEE 1613 Type Tests .................................................................................. 22

3.11. IEC Environmental Type Tests ....................................................................................... 22

3.12. Agency Approvals ........................................................................................................... 23

FCC Statement And Cautions

RuggedCom® RuggedSwitch™ 6 RS900GP Installation Guide Rev 101

FCC Statement And Cautions

Federal Communications Commission Radio Frequency Interference

Statement

This equipment has been tested and found to comply with the limits for a Class A digital device

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedin

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at his own expense.

Caution: LASER

This product contains a laser system and is classified as a CLASS 1 LASER

PRODUCT. Use of controls or adjustments or performance of procedures other than

those specified herein may result in hazardous radiation exposure.

Caution: Service

This product contains no user-serviceable parts. Attempted service by unauthorized

personnel shall render all warranties null and void.

Changesor modifications notexpressly approved byRuggedCom Inc. couldinvalidate

specifications, test results, and agency approvals, and void the user’s authority to

operate the equipment.

Should this device require service, refer to Appendix A, Warranty in this guide.

Caution: Physical Access

This product should be installed in a restricted access location where access can only

be gained by service personnel or users who have been instructed about the reasons

fortherestrictionsappliedtothelocationandaboutanyprecautionsthatshallbetaken;

and access is through the use of a tool or lock and key, or other means of security,

and is controlled by the authority responsible for the location.

Caution: Hot Surfaces

When in operation, regions of the unit surface may be hot.

Caution: Lithium Battery

This product contains a Lithium battery that is not replaceable by the operator or by

service personnel.

1. Product Overview

RuggedCom® RuggedSwitch™ 7 RS900GP Installation Guide Rev 101

1. Product Overview

The RuggedSwitch™ RS900GP is an industrially hardened, fully managed Ethernet switch

providing dual fiber optical Gigabit Ethernet ports and eight Fast Ethernet copper ports - each

capable of supplying high power 802.3at compliant power over Ethernet. Designed to operate

reliably in harsh industrial environments, the RS900GP provides a high level of immunity to

electromagnetic interference and heavy electrical surges typical of environments found in electric

utility substations, factory floors or in curb side traffic control cabinets. An operating temperature

range of -40°C to +85°C coupled with hazardous location certification, a powder coated aluminum

enclosureandoptional conformal coatingallowstheRS900GPto beplaced inalmostanylocation.

The embedded Rugged Operating System (ROS™) provides advanced networking features such

as Enhanced Rapid Spanning Tree (eRSTP™), Port Rate Limiting and a full array of intelligent

functionality for high network availability and manageability.

Ethernet Ports

• Up to 2 - Fiber Optic Gigabit-Ethernet Ports(100/1000BaseX)

• 8 - Fast Ethernet Ports (10/100BaseTX) all external 802.3af/802.3at compliant PoE

• Up to 2 - 10/100/1000 BaseTX copper ports

• Full compliance with IEEE: 802.3, 802.3u and 802.3z

• Non-blocking, store and forward switching

• Full duplex operation and flow control (IEEE 802.3x)

• Industry standard fiber optical connectors: LC, SC, SFP

• Bi-Directional simplex fiber support

• Long haul optics allow Gigabit distances up to 70km

Power Over Ethernet (PoE)

• 8-10/100 BaseTx 802.3af/802.3at compliant ports

• Data and power over a single Ethernet cable

• Auto-sensing ports that provide power only to PoE end devices

RuggedRated™ for Reliability in Harsh Environments

• Meets IEEE 1613 (electric utility substations)

• Exceeds IEC 61850-3 (electric utility substations)

• Exceeds IEEE 61800-3 (variable speed drive systems)

• Exceeds IEC 61000-6-2 (generic industrial environment)

• Exceeds NEMA TS-2 (traffic control equipment)

• Hazardous Location Certification: Class 1 Division 2

• -40 to +85°C operating temperature (no fans)

• Conformal coated circuit boards (optional)

• Rugged powder coated aluminum enclosure

1. Product Overview

RuggedCom® RuggedSwitch™ 8 RS900GP Installation Guide Rev 101

Power Supply

• 2 (redundant) 54VDC inputs (51-57VDC)

• Supports 8 30W PoE powered devices (minimum 260W total output)

• Supports power supply sharing

• Reverse polarity protection

• CSA/UL 60950 safety approved to +85°C

Simple Plug and Play Operation

• Plug and play operation 802.3af/802.3at

• Automatic learning of up to 8192 MAC addresses

• Auto-negotiation on all 10/100BaseTX ports

• Auto-MDI/MDIX (crossover) on all 10/100BaseTX ports

• LED indicators for Link/Activity and Power

ROS™ Advanced Network Management

• Enhanced Rapid Spanning Tree (eRSTPTM)

• Quality of Service (802.1p) for real-time traffic

• Port rate limiting: 128kbps to 8Mbps

• VLAN (802.1q) with double tagging

• IGMP Snooping for multicast filtering

• Port configuration, status, statistics, mirroring, security

• Loss of link management on fiber ports

• Web-based, Telnet, CLI management interfaces

• SNMP v2 and RMON

• Rich set of diagnostics with logging and alarms

1. Product Overview

RuggedCom® RuggedSwitch™ 9 RS900GP Installation Guide Rev 101

1.1. RS900GP Front Panel

Figure 1.1. RS900GP Front Panel

LED Indicator LED Color and State Description

Power LED Green, steady. Power is on.

Alarm LED Red, steady. Alarm condition exists.

Ethernet Port 1-8 Link LED Green, steady. Network link.

Ethernet Port 1-8 Link LED Green, blinking. Network activity.

Ethernet Port 1-8 PoE LED Orange, steady. PoE is enabled and powered on.

Ethernet Port 1-8 PoE LED Orange, blinking. PoE is enabled and powered off.

Ethernet Port 1-8 PoE LED Off. PoE is disabled.

Table 1.1. Front Panel LED Definitions

2. Installation

RuggedCom® RuggedSwitch™ 10 RS900GP Installation Guide Rev 101

2. Installation

2.1. DIN Rail Mounting

An optional DIN rail mounting bracket is available for the RS900GP.

Figure 2.1. DIN Rail Mounting

Inhaltsverzeichnis

Andere RuggedCom Netzwerk-Router Handbücher

RuggedCom

RuggedCom RuggedSwitch RSG2100P Bedienungsanleitung

RuggedCom

RuggedCom RuggedSwitch M2100 Bedienungsanleitung

RuggedCom

RuggedCom RuggedSwitch M2200 Bedienungsanleitung

RuggedCom

RuggedCom RuggedRouter RX1000 Bedienungsanleitung

RuggedCom

RuggedCom RuggedSwitch RSG2200 Bedienungsanleitung

RuggedCom

RuggedCom RUGGEDSWITCH RS900G Bedienungsanleitung

RuggedCom

RuggedCom RuggedVDSL RS900L Bedienungsanleitung

RuggedCom

RuggedCom RUGGEDSWITCH RS900G Bedienungsanleitung

RuggedCom

RuggedCom RuggedVDSL RS930L Bedienungsanleitung

RuggedCom

RuggedCom RuggedRouter RX1000 Bedienungsanleitung

RuggedCom

RuggedCom RuggedVDSL RS900L Bedienungsanleitung

RuggedCom

RuggedCom RuggedServer RS910 Bedienungsanleitung

RuggedCom

RuggedCom RuggedServer RS401 Bedienungsanleitung

RuggedCom

RuggedCom RuggedSwitch RSG2100 Bedienungsanleitung

RuggedCom

RuggedCom RuggedServer RS400 Bedienungsanleitung

RuggedCom

RuggedCom RuggedVDSL RS930 Bedienungsanleitung

RuggedCom

RuggedCom RuggedSwitch RSG2300 Bedienungsanleitung

RuggedCom

RuggedCom RuggedRouter RX1000 Bedienungsanleitung

RuggedCom

RuggedCom RUGGEDBACKBONE RX1510 Handbuch

RuggedCom

RuggedCom RUGGEDBACKBONE RX5000 Handbuch

RuggedCom

RuggedCom RuggedSwitch RS500 Bedienungsanleitung

RuggedCom

RuggedCom RuggedServer RS400 Bedienungsanleitung

RuggedCom

RuggedCom RuggedServer RS401 Bedienungsanleitung

RuggedCom

RuggedCom RuggedSwitch RS940G Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
