INSTRUCTIONS AND WARRANTY

RHCM3

Russell Hobbs 5 in 1 coffee maker

Congratulations on purchasing our Russell Hobbs 5 in 1 coffee maker. Each unit is

manufactured to ensure safety and reliability. Before using this appliance for the first

time, please read the instruction manual carefully and keep it for future reference.

FEATURES OF THE RUSSELL HOBBS 5-IN-1 COFFEE MAKER

5 in 1 coffee maker (filter coffee, espresso, latte, mocha and cappuccino)

1.5 litre water tank

15 bar pressure pump

10 cup filter capacity

4 cup espresso capacity

Permanent filter

Steam nozzle for frothing milk

2 independent thermostats

Warming plate for keeping coffee warm for longer

IMPORTANT SAFEGUARDS

When using any electrical appliance, basic safety precautions should always be followed

including the following:

1. Please read the instructions carefully before using any appliance.

2. Always ensure that the voltage on the rating label corresponds to the mains

voltage in your home.

3. Incorrect operation and improper use can damage the appliance and cause injury

to the user.

4. The appliance is intended for household use only. Commercial use invalids the

warranty and the supplier can not be held responsible for injury or damage

caused when using the appliance for any other purpose than that intended.

5. Avoid any contact with moving parts.

6. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

7. Children should be supervised to ensure that they do not play with the appliance.

8. Check the power cord and plug regularly for any damage. If the cord or the plug

is damaged, it must be replaced by the manufacturer or a qualified person in

order to avoid an electrical hazard.

9. Do not use the appliance if it has been dropped or damaged in any way. In case

of damage, take the unit in for examination and/or repair by an authorised service

agent.

10. To reduce the risk of electric shock, do not immerse or expose the motor

assembly, plug or the power cord to water or any other liquid.

11. Never immerse the unit in water or any other liquid for cleaning purposes.

12. Remove the plug from the socket by gripping the plug. Do not pull on the cord to

disconnect the appliance from the mains. Always unplug the unit when not in

use, before cleaning or when adding or removing parts.

13. The use of accessory attachments that are not recommended or supplied by the

manufacturer may result in injuries, fire or electric shock.

14. A short cord is provided to reduce the hazards resulting from becoming

entangled in or tripping over a longer cord.

15. Do not let the cord hang over the edge of a table or counter. Ensure that the cord

is not in a position where it can be pulled on inadvertently.

16. Do not allow the cord to touch hot surfaces and do not place on or near a hot gas

or electric burner or in a heated oven.

17. Do not use the appliance on a gas or electric cooking top or over or near an open

flame.

18. Use of an extension cord with this appliance is not recommended. However, if it

is necessary to use an extension lead, ensure that the lead is suited to the power

consumption of the appliance to avoid overheating of the extension cord,

appliance or plug point. Do not place the extension cord in a position where it can

be pulled on by children or animals or tripped over.

19. This appliance is not suitable for outdoor use. Do not use this appliance for

anything other than its intended use.

20. DO NOT carry the appliance by the power cord.

21. Do not leave this appliance unattended during use. Always unplug the unit when

not in use or before cleaning.

22. Always operate the appliance on a smooth, even, stable surface. Do not place

the unit on a hot surface.

23. Ensure that the switch is in the “Off” position after each use.

24. The manufacturer does not accept responsibility for any damage or injury caused

by improper or incorrect use, or for repairs carried out by unauthorised

personnel.

25. In case of technical problems, switch off the machine and do not attempt to repair

it yourself. Return the appliance to an authorised service facility for examination,

adjustment or repair. Always insist on the use of original spare parts. Failure to

comply with the above mentioned pre-cautions and instructions, could affect the

safe operation of this machine.

ADDITIONAL SAFEGUARDS

PARTS DIAGRAM

A. water tank cover B. water tank C. warming jug facility

D. nylon filter E. removable brew basket F. drip carafe

G. removable shelf H. drip tray I. measuring spoon and

tamper

J. Metal funnel (for Espresso)

K. press bar（press steel filter with it when pour coffee residue to avoid its slipping

out）

L. Espresso jug M. steel mesh N. adjustable steam outlet

O. steam wand P. Control panel (See Fig.1) Q. Transition knob

OPERATING INSTRUCTIONS

BEFORE FIRST USE:

Please rinse the coffee maker with warm water as follows:

Pour the water into the water tank according to the gauge, then replace its cover.

Set nylon filter in removable brew basket (add NO coffee ground), then fix

removable brew basket in the coffee maker.

Set steel mesh into the metal funnel (no coffee in the metal filter mesh) then

place them upwards into the snap and you can fix them into coffee maker firmly,

turn it anticlockwise until it is at the lock position.

Place drip carafe on keeping warm plate and espresso jug or the coffee jug on

removable shelf.

CAUTION: there is a tube outlet under the removable shelf, this is the

overpressure release outlet. In the event of pressure being over-generated inside

the appliance, the pressure release device inside the appliance will operate to

discharge the over steam pressure to normal level to prevent the risk of

explosion. The steam will then be released from the tube. NEVER block the tube

outlet. Empty the Drip tray frequently.

Connect to power source, 12:00 will show on display.

Press ON/OFF button once, the red indicator light will be illuminated, and hot

water will come out of the removable brew basket bottom.

After a few seconds, press the ON/OFF button twice again, the red indicator light

will go out and the coffee maker will stop working.

Press down / button, both the yellow and green

indicator will be illuminated and the internal heating element

starts working, the coffee maker begins to pre-heat. When the

Fig. 2

OFF

MIN

ON/OFF PROG

RED INDICATOR: it will be on if

the drip coffee is been made.

12 00

Press continuously you can

adjust the hour number.

Press one time the power

for drip coffee can be

switched on or off

YELLOW INDICATOR: The presetting

function is work if the light is on.

Press continuously you can

adjust the minute number.

You can adjust the time set whether it

is present time or presetting time

through press continuously.

YELLOW INDICATOR: The unit is

preheating if it is on; you can turn

the transition switch to froth or

espresso when it goes out.

Power switch for espresso coffee/frothing

YELLOW INDICATOR: Pre-set

function is on.

Press continuously to adjust

the minutes.

Press once to switch

the drip coffee function

ON/OFF

GREEN INDICATOR:

Espresso Coffee/Steam

power is switched on.

Press continuously to

adjust the hours.

RED INDICATOR:

Indicates that drip coffee

has been made.

YELLOW INDICATOR: Indicates

that the unit is pre-heating. You can

turn the transition switch to froth or

espresso when it goes off.

Press button continuously to set

the timer, whether it is to the

present time or pre-set time.

yellow is extinguished, you can turn the transition knob to left “ ”position

(see Fig.2) ，the yellow indicator will illuminate again and water will run out of the

metal funnel.

After the water has stopped dripping, you can pour out the water from each

container then clean them thoroughly, now you can start brewing!

NOTE: There may be noise when the machine pumps the water out for the first

time, it is normal; the appliance is just releasing air that is in the appliance. After

about 20s, the noise will stop.

MAKE DRIP COFFEE:

Take off the water tank cover, pour water into the water tank according to the

water level mark in the tank.

Replace the water tank cover, only then must you connect the appliance to the

power supply source, the display will show 12:00.

Add ground coffee to the removable nylon filter with measuring spoon, a spoon of

ground coffee power can make one cup of top-grade coffee, but you can adjust

the taste accordingly ( the max capacity of coffee powder cannot exceed 10

spoons）

Set nylon filter into the removable brew basket and place brew basket into the

coffee maker.

Push drip carafe on the keeping warm plate, make sure that the centre line of the

carafe aligns with that of the brew basket.

Press down the ON/OFF button once, the red indicator will illuminate and coffee

will drip out automatically after a while. NOTE: you can take out the carafe at any

time to serve but the time cannot exceed 20 seconds, otherwise the coffee may

overflow from the edge of brew basket.

The coffee maker will turn to the keep warm function if brewing coffee is finished.

You can switch the power off, otherwise the coffee maker will do

automatically after two hours.

SET THE CLOCK AND PROGRAM AUTOMATIC START-UP (only

fit for making drip coffee)

The appliance has a pre-set function which can be set as follows:

Press PROG button once, the word CLOCK will appear at the top-right corner of

the display.

Press the HR and MIN button continuously to set the present time (See fig. 3(1)).

NOTE: if you keep pressing down HR or MIN button more than two seconds, the

hour or minute number on display will increase rapidly.

Press PROG button once again and the word TIMER shows on the bottom left

corner of the display.

You can set the pre-setting time in the same way by pressing HR button and MIN

button continuously, that is 20:15 (see Fig. 3. Note: the word on display will

disappear automatically and enter normal state if no button is touched for more

than 10 seconds at setting state.

Press ON/OFF button two times, the yellow indicator turn on.

The yellow indicator will go off automatically, at the same time the red indicator

will turn on when the time is 20:15 and the unit will start brewing. NOTE：If no

one there, the appliance will cut off power automatically after two hours.

PRE-HEATING FUNCTION:

To make a cup of good hot Espresso coffee, we recommend you pre-heat the

appliance before making coffee, including the funnel, filter and cup, so that the

coffee flavour cannot be influenced by the cold parts.

Take down water tank cover, add water into the water tank. Then replace the

water tank cover.

Set steel mesh into metal filter (WITHOUT coffee powder ), then place them

upwards into the snap and you can fix them into coffee maker firmly by turning it

anticlockwise until it is at the lock position.(See fig. 4).

Place espresso jug on the removable shelf.

Connect the appliance to the power supply. Make sure the transition knob is on

the OFF position.

Press down / button, the yellow and green indicators will both illuminate,

the internal heat element begins to preheat. After about 3 minutes, the yellow

indicator goes out, you can turn the transition knob to now and the yellow will

illuminate again, the coffee will drip down after a few seconds.

After making a jug hot water, you must turn the transition

knob to “OFF”position. The preheating process is finished.

MAKE ESPRESSO COFFEE:

Remove the funnel by turning it in clockwise, add ground

coffee to steel mesh with measuring spoon, a spoon of

ground coffee power can make one cup of coffee, then press

the ground coffee powder tightly with the tamper.

Set the steel mesh into metal filter, then place them upwards into the snap and

you can fix them into coffee maker firmly, turn it anticlockwise until it is on the

lock position.

Pour out the hot water in the jug. Place espresso jug on removable shelf. Make

sure that the transition knob is at the OFF position.

At the time, the yellow indicator will go out, you can turn the transition knob to

now and the yellow light will illuminate again, the coffee will start to drip down

after a few seconds. When the jug is filled with coffee, you must turn the

transition knob to “OFF”position.

NOTE: during operating, do not touch the warming jug facility. When moving the

appliance, never carry the handle on the warming jug. The handle is ONLY to

prevent the warming jug from slipping.

If you want to make more coffee, wait for a moment, once the yellow indicator is

extinguished, turn the transition to position and make coffee. You should

press down / button manually when desired coffee is obtained or the colour

of coffee changes, the yellow and green indicator will switch off and the coffee

maker will stop working, at any time, make sure to turn transition knob to the OFF

position, your coffee is ready now!

WARNING: Do not leave the coffee maker unattended while making coffee, as

you may need to operate the machine manually at times!

After making the coffee, you can take the metal funnel out by turning it clockwise,

and then pour the coffee residue out with the steel mesh by pressing the press

bar.

Let the machine cool down completely, before rinsing the parts under running

water.

GENERATE STEAM/ MAKE CAPPUCCINO:

FFig

NOTE: Steam function can be used to froth milk(make cappuccino, hot chocolate

and so on) or heat water(make tea and other hot drinks)

Prepare espresso first with espresso jug, make sure that the transition knob is at

the OFF position.

Press down power button / for Espresso coffee, both the yellow and green

indicators below will be illuminated, the internal heat element starts working to

preheat the appliance.

Fill espresso jug/cup with about 100 grams of milk for each cappuccino to be

prepared, you are recommended to use fresh cream milk at refrigerator

temperature (do not heat up the milk)

When the yellow indicator is off, rotate the transition knob on the right side of unit

clockwise to position and the yellow indicator will illuminate again, steam will

come out from the adjustable steam outlet.

Insert the steam outlet into the milk about two centimetre, froth milk by moving

the vessel up and down.

When the required temperature is reached, you can turn the Transition knob to

OFF position to stop the steam generating. NOTE: Clean steam outlet with wet

the sponge immediately after steam stops generating, be very careful when

doing this as the steam may scald you.

Pour the frothed milk into the espresso prepared; now the cappuccino is ready.

Sweeten to taste and if desired, sprinkle the froth with a little cocoa powder.

Press the button / once to cut the power source off.

NOTE: we recommend you allow the coffee maker to cool down for at least 5

minutes otherwise burnt odour may arise in your Espresso coffee and please DO

NOT make drip coffee, espresso coffee or cappuccino at the same time.

CLEANING AND MAINTENANCE

This appliance is for household use only and is not user-serviceable.

Do not open or change any parts by yourself. Please refer to a qualified electrical

service department or return to the supplier if servicing is necessary.

Always remember to unplug the unit from the electrical outlet when not in use

and before cleaning. Ensure that the speed control is set to “0”.

It is much easier to clean the accessories directly after they have been used.

Wash them in warm, soapy water, rinse and dry well.

The body of the appliance and the stand should be cleaned with a damp cloth.

Do not let water enter the appliance or the stand.

Do not use bleach or other abrasive substance or solvents to clean your

appliance as it can be damaging to the finish.

Do not immerse the appliance in water or any other liquid, or hold it under a

running tap to clean.

To remove stubborn spots/marks, wipe the surfaces with a cloth slightly

dampened in soapy water or mild non-abrasive cleaner. Rinse and dry a clean,

dry, soft cloth.

STORING THE APPLIANCE

Unplug the unit from the wall outlet and clean all the parts as instructed above.

Ensure that all parts are dry before storing.

Store the appliance in its box or in a clean, dry place.

Never store the appliance while it is still wet or dirty.

Never wrap the power cord around the appliance.

SERVICING THE APPLIANCE

There are no user serviceable parts in this appliance. If the unit is not operating

correctly, please check the following:

You have followed the instructions correctly

That the unit has been wired correctly and that the wall socket is switched on.

That the mains power supply is ON.

That the plug is firmly in the mains socket.

If the appliance still does not work after checking the above:

- Consult the retailer for possible repair or replacement. If the retailer fails to resolve the

problem and you need to return the appliance, make sure that:

The unit is packed carefully back into its original packaging.

Proof of purchase is attached.

A reason is provided for why it is being returned.

Inhaltsverzeichnis

Andere Russell Hobbs Kaffeemaschine Handbücher

Russell Hobbs

Russell Hobbs 24210-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs Attentiv Bedienungsanleitung

Russell Hobbs

Russell Hobbs Essentials 18542 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 18504-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 21702-56 Retro Cream Bedienungsanleitung

Russell Hobbs

Russell Hobbs 18663-56 Installationsanleitung

Russell Hobbs

Russell Hobbs Reflections 10650 Produktinformationsblatt

Russell Hobbs

Russell Hobbs 3201147 Bedienungsanleitung

Russell Hobbs

Russell Hobbs RHCMRET Installationsanleitung

Russell Hobbs

Russell Hobbs Buckingham 20680 Bedienungsanleitung

Russell Hobbs

Russell Hobbs RHGES 127V Bedienungsanleitung

Russell Hobbs

Russell Hobbs 22620-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 19721-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs Abbey Lane RHG601 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 12591 Bedienungsanleitung

Russell Hobbs

Russell Hobbs Black Glass 23370-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs Illumina Bedienungsanleitung

Russell Hobbs

Russell Hobbs 14752 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 20682 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 14597 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 24391-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 20132-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 21170-56 Bedienungsanleitung

Russell Hobbs

Russell Hobbs 21703-56 Bedienungsanleitung

Beliebte Kaffeemaschine Handbücher anderer Marken

Taurus

Taurus Livorno 6 Bedienungsanleitung

Delta-q

Delta-q QUICK Bedienungsanleitung

Bunn

Bunn LCA-1 Fehlerbehebungshandbuch

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Montageanleitung

Saeco

Saeco Vienna Plus Sup 018M Bedienungsanleitung

DeLonghi

DeLonghi DC300 Bedienungsanleitung

INCAPTO

INCAPTO BXCO1470E Bedienungsanleitung

Bosch

Bosch TASSIMO finesse TAS16B Series Bedienungsanleitung

Exido

Exido 245-072 Bedienungsanleitung

Animo

Animo OptiVend Choco Bedienungsanleitung

Siemens

Siemens TQ505DF Series Bedienungsanleitung

DeLonghi

DeLonghi ECI341 Bedienungsanleitung

Krups

Krups KT406511 Bedienungsanleitung

Cimbali

Cimbali M32 Classic Bedienungsanleitung

Philips

Philips HL3844N Bedienungsanleitung

Bosch

Bosch TES 515 SERIES Bedienungsanleitung

Tekmatix

Tekmatix TMFM - 65 Bedienungsanleitung

Scarlett

Scarlett SC-CM33005 Bedienungsanleitung
