1. PRESENTATION.

1.1. VIEWS.

Fig. 1. View of the NIMBUS MAXI card.

Fig. 2. View of the NIMBUS MINI card.

Description Function

1COM1 port Serial interface to connect the card to other

devices using a mini USB cable.

2COM2 port Serial interface to connect the card to other

devices using a USB cable.

3RS-232 port Serial interface to connect the card using the

RS-232 protocol.

4RS-485 port Serial interface to connect the card using the

RS-485 protocol.

5RJ-45 port 10/100Mbit Ethernet interface.

6External DC input Powered by a 5V adapter.

7Modbus port Serial interface for modbus communication

with the device. Powers the card internally.

8Power LEDs Turned on when the card is powered with the

DC input (internal or external).

9RTC Real-time clock to keep the time of the card

updated in case of mains failure.

10 HDMI port HDMI interface to connect the card using an

HDMI micro cable.

11 MicroSD connector Enables the NIMBUS card version to be

updated using a MicroSD.

12 Display connector Connector for flat bus cable to connect the card

to an LCD.

Tab. 1. Description of the constituent parts

1.2. DESCRIPTION OF THE SYSTEM.

1.2.1. Introduction.

The SALICRU devices are usually installed in locations far away

from the area of production, which means that information pro-

vided by the device about its status can often be overlooked.

The NIMBUS card solves this problem by offering a remote

maintenance service that provides real-time information about

the current status of the device.

Remote communication with the device enables maintenance

and repair work to be carried out without the need to travel to

the installation site to find out about its status.

The functionalities of the NIMBUS card are specially designed

to work with SALICRU devices, making it currently compatible

with the following series:

•DC POWER-S

•DC POWER-L

•SLS CUBE3 / CUBE3+

•SLC CUBE4

•EMI3

•SLC ADAPT/X

•SLC ADAPT2

•SLC X-PERT

•SLC X-TRA

•SLC TWIN RT2

•SLC TWIN PRO2

•SLC TWIN/3 PRO2

SALICRU

5NIMBUS cardUSER MANUAL

1.2.2. NIMBUS MAXI vs NIMBUS MINI compatibility.

Depending on the type of device, either a NIMBUS-MAXI

card or a NIMBUS-MINI card is required. Both have the same

functionalities and the same operating mode. To determine

how each card corresponds to the different compatible series,

please refer to the following table:

Nimbus MAXI Nimbus MINI

UPS 3x400/230 V

SLC CUBE3/3+ X -

SLC X-PERT X -

SLC X-TRA X -

SLC ADAPT-X - X

SLC ADAPT2 - X

SLC CUBE4 - X

SLC TWIN RT2 - X

SLC TWIN PRO2 - X

SLC TWIN/3 PRO2 - X

DC Systems

DC POWER-S X -

DC POWER-L X -

Voltage stabiliser

EMi3 X -

Tab. 2. Compatibility table (X Compatible, - Not compatible)

1.2.3. Features of the system.

The NIMBUS card features various basic integrated services to

enable basic connection to the device.

Basic service Description

Onboard panel Web panel that enables remote monitoring of the

device. As it is dependent on the NIMBUS card, if it

is not connected it will not be possible to access the

panel.

Communication

through MODBUS

Reading data through MODBUS.

RTC The card’s internal real-time clock.

Auto-

configuration of

the device

When installing the card in any of the compatible

devices, it will automatically detect which device it is.

Alarm notification Notification alert through the onboard panel in real

time.

DNS server Possibility of assigning domain names to the device.

IP address Choice of DHCP or static web address.

Tab. 3. Basic integrated services

1.2.4. Optional systems.

Although the NIMBUS card is already capable of providing re-

mote maintenance with the basic features of the system and

access to device data, these optional systems make it more

effective.

There are two types of optional systems:

•Communication protocols: improve the adaptability and

compatibility of the card with different industrial commu-

nication protocols.

•Web panel in the cloud: it allows you to monitor all devices

from a single web page, without having to go through them

one by one to detect problems. It allows you to receive

more advanced notifications: web push, email or SMS.

The remote maintenance with the web panel also offers

faster technical support in real time as it is a web page to

which SALICRU’s professionals have access. This reduces the

average time it takes to repair a device in unexpected cases.

Optional

service

Description

Communication protocols

Modbus TCP Secondary communication protocol derived from MODBUS

(main communication protocol).

Modbus API-

REST

By enabling the external connection of the card, it is

possible to make calls to the communication services

without having to access the inside of the card.

RCCMD This service enables you to perform a controlled shutdown

of the servers, in the event that certain conditions are

detected by the device.

SNMP Secondary communication protocol. This enables

notifications to be sent to the user’s IP when an alarm is

activated.

Web panel in the cloud

Panel Web panel in the cloud with access to all contracted

devices with active NIMBUS card.

Alarm

notification

Notification alert via web page, email and SMS.

Tab. 4. Optional services available

2. INSTALLATION AND STARTUP.

1. Remove the protective plastic from the battery from the

NIMBUS card.

Fig. 3. Unlocking the battery of the NIMBUS card

2. Insert the NIMBUS card into the appropriate slot of the

device. It needs to be well inserted.

The card will be powered directly by the device, meaning

that no external power is necessary. If the card has been

correctly inserted, the power LEDs will light up. See the red

box in Fig. 4.

Fig. 4. NIMBUS card inserted into its slot

3. Connect one end of an RJ45 cable to the card and the other

end to the Ethernet socket. The RJ45 port lights on the card

should light up. See the red box in Fig. 5.

Fig. 5. Connection of the RJ-45 cable

4. Once the NIMBUS card is correctly powered by the device,

it will be ready for use. The NIMBUS card will come with

the latest available version already installed by default.

Once the NIMBUS card protective cover is in place, it

should look like the image shown in Fig. 6.

Fig. 6. The NIMBUS card with protective cover in place.

2.1. INITIAL CONNECTION.

Important: The card has a preset IP address to enable initial

connection. This address is fixed and always available; how-

ever, it is necessary to configure a secondary IP address in order

to use the card correctly.

Once the NIMBUS card has been correctly installed in the de-

vice via the corresponding slot, an available IP address must

then be correctly configured in order to gain remote access to

the card’s onboard panel. There are two ways to do this.

2.1.1. Point-to-point connection (Ethernet cable).

The fixed IP is always available at the address 100.0.0.1.

To access it, connect one end of the Ethernet cable to the dedi-

cated slot on the NIMBUS card and the other end to your com-

puter.

Configure the point-to-point connection by accessing network

connections and creating a new connection with the following

parameters:

Fig. 7. Network parameters for point-to-point connection.

After you have correctly created the point-to-point connec-

tion, you should be able to access the NIMBUS card via this

IP address. If you access the card via this address in the web

browser (https://100.0.0.1), change the card’s final address in

the panel’s ‘Network’ section (3.5.1 Network).

SALICRU

7NIMBUS cardUSER MANUAL

2.2. INITIAL CONFIGURATION.

The NIMBUS card comes already configured with the neces-

sary parameters so that you can immediately use the onboard

panel and all of its functionalities.

These are the following:

•Auto-configuration of the device into which it is installed.

•NTP servers.

•Active communication services (Modbus).

•IP address by DHCP (default).

•Active RTC.

•Slave modbus address default to 1 and other communica-

tion parameters adapted to the needs of each device.

Any of these parameters can be modified at any time. For more

information, see section 3.5 System.

Keep in mind that modifying some parameters could

cause the panel to behave incorrectly. Do not modify

them if you are unsure of your actions.

3. ONBOARD PANEL.

This service allows you to monitor the status of the device

remotely and in real time, enabling you to directly access the

device without having to be at the installation site.

3.1. ACCESS TO THE PANEL.

Once the card is correctly installed in the device, follow the

steps detailed below. After making the initial connection be-

tween the card and the device, wait around five minutes before

accessing the card via the panel.

Access to the panel is through https://, meaning that you need

to write it before the card’s IP address every time you wish to

access the panel. Otherwise, correct connection will not occur.

If you have not yet configured the card correctly for your net-

work, please refer to section "2.1 Initial connection". You must

use the following IP address:

Access to the panel is through a self-signed https certificate,

meaning that the browser will identify it as not secure. To re-

move this warning, follow the steps described below.

3.1.1. Import certificate.

Depending on the browser you use for access, you will see one

of the following messages. Refer to the corresponding section

according to your browsing preferences.

It is only necessary to import the certificate once with

any of the browsers. The system will save the certifi-

cate for all of them. If the certificate has already been imported

into the computer and an attempt is made to reimport it, the

option will be shown as locked (Fig. 8).

Fig. 8. Screen for importing the certificate locked.

3.1.1.1. Internet Explorer.

Run Internet Explorer as administrator. To do this, search for

‘Internet Explorer’ using the system search function, right click

and select the ‘Run as administrator’ option, as shown in Fig. 9.

Fig. 9. ‘Run as administrator’ screen

•Access the panel normally. An error window will be dis-

played. Click on ‘Continue to website (not recommended)’.

•The web page of the panel will load normally. In the ad-

dress bar, it will appear a message with ‘Certificate error’;

you must click there (Fig. 10).

Fig. 10. Certificate error.

•A window will be displayed. Click on ‘View certificate’ and

then on ‘Install certificate’. Lastly, click on ‘Yes’ to confirm

the installation.

•Restart the browser and access the panel. This time, the

warning message will not be displayed.

SALICRU

9NIMBUS cardUSER MANUAL

3.1.1.2. Mozilla Firefox.

•The first time you access the panel, you will see the following

screen. Click on ‘Advanced...’ to display more options.

Fig. 11. Mozilla Firefox panel

Once all the options have been displayed, click on ‘View

certificate’.

Fig. 12. Mozilla Firefox panel

•A new screen will appear with all of the information about

the site certificate. Click on the ‘Details’ tab and select the

‘Export...’ option that appears at the end of it.

Fig. 13. ‘Export ...’ window

•Save and download the file to the desired location, then run

it. A screen similar to the one shown in Fig. 14 will appear.

Click on ‘Import...’.

Fig. 14. ‘Import...’ window

•The system will require the password of your computer

before proceeding. When prompted for the label, enter

‘Nimbus’ and click on ‘OK’.

Fig. 15. ‘Label’ window.

•Once this step is completed, the certificate will have been

imported correctly. Start the browser to confirm it. In ‘Prefer-

ences’, click on the left-hand side menu to navigate to ‘Pri-

vacy & Security’. Navigate to the end of the tab until you find

the section of ‘Certificates’. Click on ‘View certificates...’

(Fig. 16).

Fig. 16. Firefox ‘Privacy & Security’ menu

•Look for the name of the installed certificate on the list to

check that it was correctly imported:

Fig. 17. ‘Certificate manager’ window.

•Restart the browser, access the panel and click on ‘Accept

the risk and continue’. The next time you access the panel,

the warning message will no longer be displayed:

Fig. 18. ‘Accept risk and continue’ window

3.1.1.3. Chrome / Opera.

•The first time you access the panel, the following screen

will be displayed:

Fig. 19. Chrome / Opera browser home screen.

•In the address bar, click on the ‘Not secure’ button to dis-

play the available options. Click on ‘Certificate’.

Fig. 20. Available options window

•A new screen will appear with all of the information about

the site certificate. Click on the ‘Details’ tab, followed by the

‘Export ...’ button that appears at the end of it (Fig. 21).

SALICRU

Andere Handbücher für NIMBUS

Inhaltsverzeichnis

Andere Salicru Netzwerkkarte Handbücher

Salicru

Salicru NIMBUS Bedienungsanleitung

Beliebte Netzwerkkarte Handbücher anderer Marken

FirstComm

FirstComm OBiWiFi5G Bedienungsanleitung

Sun Microsystems

Sun Microsystems Interface Adapter Bedienungsanleitung

TRENDnet

TRENDnet TU2-ETG Bedienungsanleitung

YASKAWA

YASKAWA SI-EN3 Bedienungsanleitung

Paradyne

Paradyne BitStorm 2600 IP DSLAM Bedienungsanleitung

Belkin

Belkin F5D7050 Bedienungsanleitung

3Com

3Com EtherLink 3C509B Bedienungsanleitung

TRENDnet

TRENDnet TEG-PCITX Bedienungsanleitung

Cisco

Cisco MC16E Bedienungsanleitung

Delta Electronics

Delta Electronics Braking Modules VFDB Series Bedienungsanleitung

TwinMOS

TwinMOS Booming Bedienungsanleitung

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Bedienungsanleitung

Buffalo

Buffalo AirStation WLI-PCM-L11GP Bedienungsanleitung

National Instruments

National Instruments NI 9234 Bedienungsanleitung

Hama

Hama 49276 Bedienungsanleitung

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Bedienungsanleitung

Compaq

Compaq Wireless LAN 100 Bedienungsanleitung

Bose

Bose PowerMatch Dante Bedienungsanleitung
