Salton FSCM100 SPECIAL SELECT Kurzanleitung
USE & CARE INSTRUCTIONS
10 CUP PROGRAMMABLE COFFEEMAKER
FSCM100
SPECIAL SELECT
1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock, and injury to persons,
do not immerse cord, plug, or Coffee Maker in water or
other liquid.
4. Close supervision is necessary when any appliance is used by or
near children.
5. Unplug from outlet when not in use and before cleaning.
Allow to cool before putting on or taking off parts, and before
cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug, or
after the appliance malfunctions, or has been damaged in any
manner. Contact Consumer Service.
7. The use of accessory attachments not recommended by the
appliance manufacturer may result in fire, electric shock, or
injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a
heated oven.
11. To disconnect, slide the AUTO/OFF/ON Switch to OFF, then
remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Be certain Lids are securely in place before operating appliance.
14. Scalding may occur if the Lid is removed during the
brewing cycles.
15. This Carafe is designed for use with this Coffee Maker. It must
never be used on a range top
16. Do not set a hot Carafe on a wet or cold surface.
17. Do not use a cracked Carafe or a Carafe having a loose or
weakened handle.
18. Do not clean Carafe with cleansers, steel wool pads, or other
abrasive material.
SAVE THESE INSTRUCTIONS
This product is for household use only.
2
WARNING: This appliance generates heat and escaping steam
during use. Use proper precautions to prevent the risk of
burns, fires, or other injury to persons or damage to property.
1. Do not pour liquid other than water and the cleaning solution
specified in this manual into the Water Reservoir.
2. Coffeemaker must be left to cool down for approximately
15 minutes before adding more water.
3. DO NOT attempt to move an appliance containing hot liquids.
Allow appliance to cool completely before moving.
4. DO NOT leave empty Carafe on Warming Plate when appliance is
turned ON, as the Carafe may crack or become otherwise damaged.
5. Always use fresh, cool water in your Coffeemaker. Warm water or
other liquids, except as listed in cleaning section, may cause damage
to the appliance.
6. DO NOT lift Water Reservoir Lid or Swing-Out Filter Basket until
brewing is complete and all parts have cooled.
7. DO NOT put Carafe into a microwave.
CAUTION: To prevent injury when utilizing Drip Stop Feature, replace
Carafe within 20 seconds of removing during brewing process.
ADDITIONAL IMPORTANT SAFEGUARDS
3
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to
fit into a polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
A short power-supply cord is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord.
Longer detachable power-supply cords or extension cords are
available and may be used if care is exercised in their use.
If a longer detachable power-supply cord or extension cord is used,
(1) the marked electrical rating of the cordset or extension cord
should be at least as great as the electrical rating of the appliance,
and (2) the cord should be arranged so that it will not drape over
the counter top or table top where it can be pulled on by children
or tripped over unintentionally.
ELECTRIC POWER
If the electrical circuit is overloaded with other appliances, your
appliance may not operate properly. It should be operated on a
separate electrical circuit from other appliances.
This appliance is FOR HOUSEHOLD USE ONLY and may be
plugged into any 120V AC electrical outlet. Do not use any other
type of outlet.
GETTING TO KNOW YOUR FARBERWARE®
10 CUP COFFEEMAKER
1. Water Reservoir Lid (P/N 30654)
2. Swing-Out Filter Basket (P/N 30651)
3. Water Reservoir
4. Carafe Lid (P/N 30652)
5. Control Panel
6. Polarized Plug
7. Warming Plate
8. Carafe w/Lid (P/N 30653)
9. Drip Stop Assembly (P/N 30781)
10. Water Level Indicator
11. Removable Filter Basket Assembly
(P/N 30650)
1.
2.
9. 4.
8.
10.
11.
(inside)
7.
6.
5.
3.
4
5
AUTO OFF ON
ONHOUR
MIN.
BREW
CONTROL PANEL
REMOVABLE FILTER BASKET
AM/PM
AUTO ON
ON/
BREWING
AUTO/OFF/ON
Switch
GETTING TO KNOW YOUR COFFEEMAKER (Cont.)
To remove the Removable Filter Basket for cleaning, pull Basket
straight up and out of the machine. After cleaning, the Removable
Filter Basket must be pushed all the way into the Swing-Out Filter
Basket. Before use, make sure the Swing-Out Filter Basket fits
securely back into the unit.
Removable
Filter Basket
Drip Stop
Assembly
Swing-Out
Filter Basket
6
INSTRUCTIONS FOR USE
BEFORE BREWING COFFEE FOR THE FIRST TIME
CAUTION: To protect against electric shock, do not submerge the
Coffeemaker or allow AC cord to come into contact with
water or other liquids.
1. After carefully unpacking from carton, the inside of your
Coffeemaker and Carafe must be cleaned.
2. Brew 10 cups of fresh water only. Follow the instructions
under BREWING COFFEE Section but do not add coffee
grounds to the paper filter.
3. When all the water has brewed into the Carafe, slide the
AUTO/OFF/ON Switch to OFF.
4. Allow the Coffeemaker to cool for 10 minutes, discard the
water from the Carafe, then repeat steps 2 and 3.
5. After the second pot of water has cooled, discard the water and
thoroughly wash the Removable Filter Basket (see illustration on
page 5), Carafe and Carafe Lid in warm, soapy water. Dry all
parts thoroughly.
FOR BEST RESULTS
We recommend using coffee which has been ground specifically
for automatic drip coffeemakers. This type of coffee is prepared
specifically for your Coffeemaker’s brewing system and promotes
fuller extraction to provide rich, full-bodied coffee.
Use only cone-shaped filters with this Coffeemaker. Cone-shaped
paper filters are available locally at grocery stores. Use standard, #4
filters. You may also purchase permanent gold filters, which
eliminate the need for disposable paper filters. Do not use basket-
style paper filters.
7
DRIP STOP FEATURE
This FARBERWARE®Coffeemaker has an Automatic Drip Stop
Feature. During the brewing cycle, the Carafe can be removed
to pour a cup of coffee from the Carafe. The Drip Stop Feature will
prevent the Coffeemaker from continuing to brew coffee for up to
one minute until the Carafe is returned to its proper position.
IMPORTANT: The Carafe must be replaced on the Warming Plate,
under the Filter Basket in less than a minute to prevent the
Filter Basket from overflowing.
AUTOMATIC START-UP FEATURE
This FARBERWARE®Coffeemaker has an Automatic Start-Up
feature. This feature allows you to pre-program the Coffeemaker to
begin brewing coffee at a specific time. By leaving the
AUTO/OFF/ON Switch in the AUTO position, the Coffeemaker
will start-up automatically every day at the programmed start-up
time. You may override the Automatic Start-Up feature at any time
(without affecting the program) by sliding the AUTO/OFF/ON
Switch to ON. To restore the program, slide the AUTO/OFF/ON
Switch back to AUTO.
AUTOMATIC SHUT-OFF FEATURE
The Automatic Shut-Off feature automatically turns off the
Coffeemaker two hours after a programmed brew time. This
prevents the Coffeemaker from being left on for an extended period
of time, which is harmful to both the Coffeemaker and
the Carafe.
NOTE: The Automatic Shut-Off feature will only work when the
Coffeemaker is in the AUTO position and a pre-programmed
start-up time has been scheduled.
8
BREWING COFFEE IN YOUR
FARBERWARE®10 CUP
PROGRAMMABLE COFFEEMAKER
CAUTION: Use this product with proper AC voltage rating only.
Be sure to unplug the power cord when Coffeemaker is not in
use for extended periods of time.
1. Lift the Carafe Lid. Fill the Carafe with
cold water to the level for the desired
number of cups (1-10). Open the Water
Reservoir Lid, and pour the water from
the Carafe into the Water Reservoir.
Close the Water Reservoir Lid.
2. Swing out the Coffee Filter Basket
and place a #4 paper coffee filter
(or a permanent gold filter) inside
the Removable Filter Basket.
3. Put coffee grounds in the filter, using
one level tablespoon of drip grind
coffee for each cup of brewed coffee.
(See Figure 1.)
4. Make sure the Removable Filter Basket is
pushed all the way into the Swing-Out
Filter Basket. Make sure the Swing-Out
Filter Basket fits securely back into the unit.
IMPORTANT: When using the Timer feature,
and at all times before brewing, remember
to place Carafe on the Warming Plate.
5. Place the Carafe on the Warming Plate,
making sure the Carafe Lid is on the Carafe.
6. Make sure the AUTO/OFF/ON Switch is in
the OFF position. Plug the appliance into a
standard 120V AC electrical outlet.
7. The LCD will flash “12:00” until you set the
time. (See Figure 2.)
FIGURE 1
*
AUTO OFF ON
ONHOUR
MIN.
BREW
*
*
FIGURE 2
9
SETTING THE CLOCK / TIMER
1. Set the Timer to the correct time of
the day by pushing the HOUR Button
until the correct hour appears on the
LCD Display. Then push the MIN.
Button to the current minutes. Be sure
to note a.m. and p.m. times.
NOTE: The LED in the upper-left corner
of the Display indicates the P.M.
hours. (See Figure 3.)
2. To program the Coffeemaker for
Automatic Start-Up, push and HOLD
the BREW Button. While holding the
BREW Button, push the HOUR Button
to the desired start-up time hour.
Continue to hold the BREW Button,
and push the MIN. Button until the
correct minutes appears. Be sure to
note a.m. and p.m. times.
(See Figure 4.)
NOTE: Once the BREW button is
released, the exact time of the day
will be shown. To see the
programmed start-up time, press the
BREW Button.
3. To start the Coffeemaker
immediately:
Slide the AUTO/OFF/ON Button to
the ON position. The ON LED will
illuminate as the Coffeemaker begins
brewing the coffee. (See Figure 5.)
BREWING COFFEE (Cont.)
AUTO OFF ON
ONHOUR
MIN.
BREW
*
*
*
FIGURE 3
AM/PM Indicator
AUTO OFF ON
ONHOUR
MIN.
BREW
**
*
FIGURE 5
Brew Coffee
**
AUTO OFF ON
ONHOUR
MIN.
BREW
*
FIGURE 4
Set Auto Start-Up times
Inhaltsverzeichnis
Andere Salton Kaffeemaschine Handbücher
Salton
Salton SCM100 Installationsanleitung
Salton
Salton SCM80 Installationsanleitung
Salton
Salton Expresso Pro EX-1040 Bedienungsanleitung
Salton
Salton SCM200 Installationsanleitung
Salton
Salton JUMBO java FC1667TH Bedienungsanleitung
Salton
Salton FC-3T Bedienungsanleitung
Salton
Salton EX-1016 Bedienungsanleitung
Salton
Salton FC-120E Bedienungsanleitung
Salton
Salton CAPPUCCINO EXPRES EX-182 Bedienungsanleitung
Salton
Salton CU1777 Bedienungsanleitung
Salton
Salton JVPM1B Bedienungsanleitung
Salton
Salton Elite SCM30E Leitfaden
Salton
Salton FC-1026 Bedienungsanleitung
Salton
Salton EX-1091 Bedienungsanleitung
Salton
Salton FC1952 Bedienungsanleitung
Salton
Salton FC-1180 Bedienungsanleitung
Salton
Salton FC-1191 Bedienungsanleitung
Salton
Salton FC-120ET Bedienungsanleitung
Salton
Salton FC1214 Bedienungsanleitung
Salton
Salton Jumbo Java FC1667 Bedienungsanleitung
