Samson XPDm Bedienungsanleitung

XPDm Digital Wireless System

Owner’s Manual

XPDm Digital Wireless

Important Safety Information

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE COVER

(OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

This lightning ﬂash with arrowhead

symbol within an equilateral

triangle is intended to alert the user

to the presence of non-insulated

“dangerous voltage” within the product’s

enclosure that may be of sufﬁcient magnitude

to constitute a risk of electric shock.

The exclamation point within an

equilateral triangle is intended

to alert the user to the presence

of important operating and

maintenance instructions in the literature

accompanying the appliance.

ATTENTION

RISQUE D’ÉLECTROCUTION !

NE PAS OUVRIR !

WARNING

TO PREVENT FIRE OR SHOCK HAZARD. DO NOT USE THIS PLUG WITH AN EXTENSION

CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED

TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE. TO PREVENT ELECTRICAL SHOCK, MATCH WIDE

BLADE PLUG TO WIDE SLOT AND FULLY INSERT.

Samson Technologies Corp.

278-B Duffy Ave

Hicksville, NY 11801

www.samsontech.com

If you want to dispose this product, do not mix it with general household waste. There is

a separate collection system for used electronic products in accordance with legislation

that requires proper treatment, recovery and recycling.

Private households in the 28 member states of the EU, in Switzerland and Norway may

return their used electronic products free of charge to designated collection facilities or to a

retailer (if you purchase a similar new one).

For Countries not mentioned above, please contact your local authorities for a correct method of

disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment,

recovery and recycling and thus prevent potential negative effects on the environment and

human health.

Owner’s Manual

Important Safety Information

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings.

Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including ampliﬁers)

that produce heat.

9. Do not defeat the safety purpose of

the polarized or grounding type plug.

A polarized plug has two blades with

one wider than the other. A grounding

type plug has two blades and a third

grounding prong. The wide blade or the

third prong are provided for your safety.

If the provided plug does not ﬁt into

your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked

on or pinched particularly at the plugs,

convenience receptacles, and at the

point where they exit from the apparatus.

11. Only use attachments/accessories

speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod,

bracket, or table speciﬁed by the

manufacturer, or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination to

avoid injury from tip-over.

13. Unplug the apparatus during lightning

storms, or when unused for long periods

of time.

14. Refer all servicing to qualiﬁed personnel.

Service is required when the apparatus

has been damaged in any way, such as

power supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the apparatus, has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

15. This appliance shall not be exposed to

dripping or splashing water and no object

ﬁlled with liquid such as vases shall be

placed on the apparatus.

16. Caution-to prevent electrical shock,

match wide blade plug wide slot fully

insert.

17. Please keep a good ventilation

environment around the entire unit.

18. The direct plug-in adapter is used as

disconnect device, the disconnect device

shall remain readily operable.

19. Batteries (battery pack or batteries

installed) shall not be exposed to

excessive heat such as sunshine, ﬁre or

the like.

XPDm Digital Wireless

Important Safety Information

FCC Notice

1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may

cause undesired operation.

2. Changes or modiﬁcations not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

RF Exposure Statement (SAR)

This device is designed and manufactured not to exceed the emission limits for exposure to

radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Gov-

ernment.

Hereby, Samson Technologies Corp., declares that this XPDm Digital Wireless System is in com-

pliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.

The declaration of conformity may be consulted at:

http://www.samsontech.com/site_media/support/manuals/XPDm_DOC.pdf

Owner’s Manual

Introduction

Congratulations on purchasing the Samson XPDm Digital Wireless System.

The XPDm Digital Wireless System, available in Handheld, Lavalier, and Headset

conﬁgurations, operates in the license free 2.4GHz frequency range.This system is a

unique wireless microphone solution that is ideal for presenters, ﬁtness instructors,

educators, interviewers and more.

The RXD1M tabletop receiver is compact enough to ﬁt in any carry bag and includes

XLR, 1/4”, and 1/8” outputs for easy connection to mixers and PA systems. One-

touch pairing allows for straight forward connection between transmitter and receiver.

Samson’s XPDm Digital Wireless Systems have a range of 100’ and offer up to 20

hours of operation using two AA batteries.

In these pages, you’ll ﬁnd a detailed description of the features of the XPDm Digital

Wireless System, instructions for its setup and use, and speciﬁcations. If your

wireless system was purchased in the United States, you’ll also ﬁnd a registration

card enclosed—don’t forget to follow the instructions so that you can receive

technical support and so that we can send you updated information about this and

other Samson products in the future. Also, be sure to check out our website (www.

samsontech.com) for complete information about our full product line.

We recommend you keep the following records for reference, as well as a copy of your

sales receipt.

Transmitter & Receiver Serial number: _________________________________

Date of purchase: ___________________________________________________

If you have any questions or comments regarding the XPDm Digital Wireless

Microphone System or any other products from Samson, do not hesitate to contact us

at [email protected].

With proper care and maintenance, your XPDm Digital Wireless System will operate trouble-

free for many years. Should your XPDm Digital Wireless System ever require servicing, a

Return Authorization (RA) number must be obtained before shipping your unit to Samson.

Without this number, the unit will not be accepted. Please visit www.samsontech.com/ra for

an RA number prior to shipping your unit. Please retain the original packing materials and,

if possible, return the unit in its original carton. If your XPDm Digital Wireless System was

purchased outside of the United States, contact your local distributor for warranty details

and service information.

XPDm Digital Wireless

RXD1M Receiver Features

1. VOLUME/Power Control - This rotary knob controls the level of the receiver

output and powers the RXD1m on and off. Turn clockwise to power on and

counterclockwise to power off. The light ring around the VOLUME/Power Control

will illuminate white when powered on.

2. PAIR button - Press and hold for more than three seconds to enter pairing mode,

the READY LED will begin flashing. NOTE - the system is paired at the factory

prior to shipment.

3. READY Indicator - This LED displays the operation mode. Solid AMBER means

normal operation, flashing AMBER means pairing, no light means not paired or

that the transmitter is either out of range or powered off.

Owner’s Manual

1. DC Input - Connect the suplied adapter here. WARNING: Do not substitute any

other kind of power adapter. Doing so can cause severe damage to your RXD1m

and void your warranty.

2. Unbalanced Outputs - Use these unbalanced 1/4” and 1/8” jacks when

connecting the RXD1m to consumer (-10 dBV) audio equipment. Wiring is as

follows: tip hot, sleeve ground

3. Balanced Output - Use this electronically balanced low impedance (600

Ohm) XLR jack when connecting the RXD1m to professional (+4 dBu) audio

equipment. Pin wiring is as follows: Pin 1 ground, Pin 2 high (hot), and Pin 3

low (cold)

RXD1m Receiver Features Rear Panel

1 2 2 3

XPDm Digital Wireless

1. Status Indicator - This LED displays the operation

mode. Amber: Normal Operation

Flashing Amber: Pairing / Low Battery

2. Power/Pair Switch - Press <5 seconds to turn the

unit on or off. Press >5 seconds to enter pairing

mode.

3. Battery Cover - Unscrew the battery cover and

slide down to open the HXD1 Handheld battery

compartment.

4. Battery Holder - Open the battery holder by

pressing the tab and lifting the cover. Insert two

standard AA (LR6) batteries here, being sure to

observe the plus and minus polarity markings

shown.

WARNING: Do not insert the batteries backwards;

doing so can cause severe damage to the

transmitter and will void your warranty.

5. Input GAIN Control - This control adjusts the

transmitter input sensitivity. This input sensitivity

control has been factory preset to provide

optimum level for the particular microphone

capsule provided with the XPDm system and

so we recommend that this not be adjusted

manually. If necessary, however, you can use the supplied screwdriver to raise or

lower the input level.

6. Screwdriver - Used to adjust the input GAIN control.

HXD1 Handheld Transmitter Callouts

Owner’s Manual

PXD1 Beltpack Transmitter Callouts

1. Input Connector - Connect

the input device via this

mini-XLR input jack.

The PXD1 is supplied

with either a lavalier or

headset microphone that is

wired to a P3 connector.

2. Status Indicator - This LED

displays the operation mode.

Amber: Normal Operation

Flashing Amber: Pairing / Low

Battery

3. Power/Pair Switch - Press <5

seconds to turn the unit on or

off. Press >5 seconds to enter

pairing mode.

4. Input GAIN Control - This

control adjusts the transmitter

input sensitivity.

5. Battery Holder - Open the battery holder by pressing the tab and lifting the cover.

Insert two standard AA (LR6) batteries here, being sure to observe the plus and

minus polarity markings shown.

WARNING: Do not insert the batteries backwards; doing so can cause severe

damage to the transmitter and will void your warranty.

6. Screwdriver - Used to adjust the input GAIN control.

XPDm Digital Wireless

In order for the XPDm Digital Wireless System to work correctly, both the RXD1m

receiver and HXD1 handheld or PXD1 beltpack transmitter must be paired together.

(NOTE: The XPDm Digital Wireless System will come paired from the factory).

Follow this basic procedure for setting up and using your XPDm Digital Wireless

System:

1. Physically place the RXD1m receiver where it will be used. We suggest you keep

receiver and transmitter within line of sight for optimal performance, meaning

the performer using or wearing the transmitter can see the receiver.

2. Connect the included power adapter to the RXD1m receiver before turning the

power on. Turn the RXD1m on momentarily to confirm that it is receiving power,

then turn it off (figure 1).

3. With your amplifier or mixer powered off and

volume control down connect the RXD1m

receiver output jack to the mic or line input

using the balanced XLR output, unbalanced

1/4” or 1/8” output jacks. Turn the RXD1m

power on but keep the volume at minimum

level (figure 2).

4. Place a fresh set of AA (LR6) batteries in the

transmitter’s battery compartment being sure to observe polarity markings (figure

3).

Quickstart

Figure 2

Figure 3

Figure 1

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samson Mikrofonsystem Handbücher

Samson

Samson AirLine AX1 Bedienungsanleitung

Samson

Samson Concert 88 Bedienungsanleitung

Samson

Samson VHF Series Bedienungsanleitung

Samson

Samson AIRLINE CR77 Bedienungsanleitung

Samson

Samson AirLine SYNTH AR300 Bedienungsanleitung

Samson

Samson Airline 77 Bedienungsanleitung

Samson

Samson Concert 288x Bedienungsanleitung

Samson

Samson DK705 Bedienungsanleitung

Samson

Samson STAGE 266 HT6 Bedienungsanleitung

Samson

Samson SynthSeven Bedienungsanleitung

Samson

Samson Stage 266: Dual Handheld Wireless System Bedienungsanleitung

Samson

Samson Stage XPD1 Bedienungsanleitung

Samson

Samson Concert 288 Bedienungsanleitung

Samson

Samson Stage 200 Bedienungsanleitung

Samson

Samson CONCERT XD2 Bedienungsanleitung

Samson

Samson Stage 212 Bedienungsanleitung

Samson

Samson AIRLINE CR77 Bedienungsanleitung

Samson

Samson EXPEDITION XP40iw Bedienungsanleitung

Samson

Samson Stage 55 Bedienungsanleitung

Samson

Samson UHF Micro 32 Bedienungsanleitung

Samson

Samson Go Mic Bedienungsanleitung

Samson

Samson XPD2m Bedienungsanleitung

Samson

Samson AirLine Bedienungsanleitung

Samson

Samson QV Bedienungsanleitung

Beliebte Mikrofonsystem Handbücher anderer Marken

Paso

Paso R824 Bedienungsanleitung

Naxa

Naxa NAM-982 Bedienungsanleitung

Motorola

Motorola PMNN4461 Bedienungsanleitung

Xvive

Xvive U3 Bedienungsanleitung

Tekon

Tekon DUOS Bedienungsanleitung

Heyuan Intelligence

Heyuan Intelligence IOT-G2S-01 Bedienungsanleitung

Devine

Devine WMD-IE Bedienungsanleitung

LG LF-D7150 Bedienungsanleitung

GE S768DAV Bedienungsanleitung

LD U305 HBH 2 Bedienungsanleitung

Chainway

Chainway URA8 Bedienungsanleitung

ORATOR

ORATOR D860TD Bedienungsanleitung

Sennheiser

Sennheiser Evolution Wireless Digital EW-DX EM 2 Bedienungsanleitung

Alpha Technologies

Alpha Technologies RBMS Bedienungsanleitung

SWIT Electronics Co.,LTD.

SWIT Electronics Co.,LTD. CW-S150 Bedienungsanleitung

Shure

Shure UA844 Bedienungsanleitung

Panasonic

Panasonic SHFX70 - DVD HOME THEATER WIRELESS SYSTEM Bedienungsanleitung

Pyle

Pyle PDWM5000 Bedienungsanleitung
