Getting Started Guide

WHITEVERSIONREVERSED

Table of Contents

Welcome to AT&T 4

What’s in the Box? 4

Samsung BlackJackTM Features 5

Set Up Your Samsung BlackJackTM 6

Insert and Charge the Battery 6

Get to Know Your Samsung BlackJackTM 7

Use the Samsung BlackJackTM 8

Learn to Navigate & Type 8

Check Your AT&T Wireless Network Connection 9

Make a Phone Call 9

Set Up Voicemail & Browse the Web 10

Browse the Web 11

Set Up Your Samsung BlackJackTM Email 12

Set Up Email on Your Device 12

Personal Email Setup with Xpress Mail 13

Corporate Email Set Up with Xpress Mail™ 16

Enterprise Email (IT Managed) 22

Sync Contacts, Calendar, Email and More (Optional) 23

More Samsung BlackJackTM Features 24

Sync Contacts, Calendar, Email and More (Optional) 24

Send Text and MMS Messages 25

Take a Picture, Send it To a Friend 26

View Your Pictures 26

Transferring Music 27

Playing Music on Your Device 28

AT&T MusicTM 28

Cellular VideoTM 29

Instant Messaging 30

Troubleshooting 32

Tips & Tricks 34

Remove These Items From the Box

Thank you for purchasing the Samsung BlackJackTM.

To get started, we recommend the following:

• Carefully follow the step-by-step instructions in this guide to set up your Samsung

BlackJack TM device.

• Review the User Manual on the Getting Started CD to learn about the full power of the

Samsung BlackJackTM.

Take note of the following components included in the box:

Getting Started CD for

with Windows Mobile 5.0 Software

GH46-00395A

Portions 2005 Microsoft

Corporation. All rights

reserved.

Knowledge Ventures.

CD Includes:

User Manual

Getting Started Guide

ActiveSync 4.2

Microsoft Office Outlook Mobile

Warranty Information

End User License Agreement

and more

Cyan Magenta Yellow Black White Flood

Standard and

Extended Battery

with Cover

Battery Charger Getting Started CD

Travel Adapter Data Cable

Samsung BlackJack™

Parental Controls

What’s in the

Welcome to AT&T

Power on/off key

Quick List key

Volume keys

Headset/Power adapter jack/

USB or data cable OK key

Left soft key (LSK)

Home key (short press)/

Task Manager key (long press)

Send (short press)/

Speakerphone key (long press)

Hold/Unhold (short press during a call)

Microphone

End key (short press)/

Lock key (long press)

Back/Clear key

Right soft key (RSK)

Display

4-Way Navigation key

Earpiece

Messaging (short press)

Backlight on/off (long press)

microSD card slot

Thumbwheel

Select/execute (short press)

Run a quick launcher (long press)

External Speaker

Camera lens

Mirror

Back/Clear key (short press)

Camera (long press)

™

WHITEVERSIONREVERSED

Samsung BlackJackTM Features

Insert the Battery

1. Remove the battery cover by

pressing it down and sliding it

away as shown.

2. Align the gold tabs on the

battery with the gold tabs in

the phone (1) and then press

the bottom of the battery down

until (2) it snaps into place.

3. Place the cover back on the

handset and slide it in until it

clicks.

Note: Your BlackJack™ will not turn on automatically when you insert the battery.

You must turn it on using the power button on top of the device.

Note: Your battery comes partially charged. To completely charge your battery, it

may take an hour or more.

Charge the Battery

Use the travel adapter to charge the battery.

1. Plug the connector of the travel

adapter into the jack on the left

side of the phone.

2. Plug the adapter into a standard

AC wall outlet. When charging

is complete, unplug the adapter

from the power outlet.

Warning: Use only Samsung-approved batteries and chargers for your handset.

Insert and Charge the Battery

Steps?

Takes?

1 minute

Steps?

Takes?

1 minute

Set Up Your Samsung BlackJackTM

WHITEVERSIONREVERSED

Get to Know your Samsung BlackJackTM

Turn on Your Device

To turn your Samsung BlackJack™ device on,

press and hold the Power ON/OFF Button.

The Home screen displays with time and

date/status indicators and any appointments

you may have set.

Lock Your Device Keypad

To lock your device keypad, press and hold

on the key.

Backlight

After 10 seconds your screen will dim to save

battery power. To turn your screen on, press

any key.

Note: To change the backlight dim settings, press the LEFT

SOFT key to select “Start”. Then use the NAVIGATION key

to scroll down and highlight “Settings”. Press OK to select

“Settings”, then select “Display”, then “Home Screen”, then

scroll down to select “Time out”. Use the LEFT and RIGHT

NAVIGATION keys to change the setting. Select “Done” to

save that setting.

Backlight Dim with Keypad Locked

If you have locked your device keypad and the device

goes dim, then you must first press the Power ON/OFF

Button to display the screen. Then press the LEFT SOFT key to select “Unlock” then press the

* key to unlock the device.

Get to Know Your Samsung BlackJackTM

The Home

Power ON/OFF Button

Screen display

LEFT SOFT key

NAVIGATION key

RIGHT SOFT key

Learn to Navigate & Type

Your Samsung BlackJack™ is equipped with an innovative

keyboard. You can easily and accurately type words with the

phone keypad. When you select a field that requires text or

numbers, the phone automatically selects the appropriate

input mode. However, if you need to switch between modes,

press one of the keys listed in the following illustration. See

the indicator at the top of the Home Screen to identify the

current text mode setting.

• To move around the screen,

press top, bottom, left, and right

of the NAVIGATION key, and

press OK to enter.

• To select bottom left and

right item on the screen,

use the LEFT and RIGHT

SOFT keys.

• To enter a number or symbol, press

the FUNCTION key, and then press

the corresponding key.

• To type a single uppercase letter, press

CAPS/SHIFT key, and then press the

corresponding key.

• To change the mode to Numeric input, press the

NUM LOCK key.

• To input symbols, press the */SYM key and choose the

corresponding symbol.

Learn to Navigate & Type

Use the Samsung BlackJackTM

WHITEVERSIONREVERSED

Steps?

Takes?

1 minute

Check Your AT&T Wireless Network

Connection

To connect to the wireless network successfully, your Samsung BlackJackTM

must be powered on, your wireless service must be active, and you must

be in a coverage area. On the top right corner of the home screen, you will

find the network coverage indicator.

Full wireless coverage

Full wireless coverage using data in 3G coverage

No wireless coverage

Wireless is turned off

Make a Phone Call

1. From the Home screen, you can access the Phone screen by pressing

the SEND key or by directly entering a phone number by pressing the

numeric keys on the keypad.

2. Press the SEND key .

Note: To activate the speakerphone, press and hold the SEND key

for 2 seconds.

Note: To place a call on hold or unhold with, press quickly on the

SEND key .

3. To end the call, press the END key .

Check Your AT&T Wireless Network Connection & Make a Phone Call

Steps?

Takes?

1 minute

Steps?

Takes?

3 minutes

Set Up Voicemail

Press and hold the 1/E key on your Samsung BlackJackTM. You will

be connected to the voicemail system, which will then ask you to:

1. Create your password.

2. Record your name.

3. Record a greeting.

Check Your Voicemail Messages

1. Press and hold the 1/E key .

2. Follow the voice prompts.

Check Your Voicemail Messages From Another Phone

1. From another phone, dial your 10-digit wireless number.

2. Press the *key (#, Puerto Rico) when you hear your personal greeting.

3. Enter your personal password and follow the voice prompts.

Browse the Web

Use Internet Explorer®Mobile to directly access the wireless web on your

Samsung BlackJack™. Use MEdia Net™ to access AT&T’s premium content

service.

Open Internet Explorer

1. Select “Start” by pressing the LEFT

SOFT key.

2. Press the LEFT SOFT key again to

select “More”.

3. Use the NAVIGATION key to

highlight “Internet Explorer”.

Set Up Voicemail & Browse the Web

Use the Samsung BlackJackTM

Andere Handbücher für BlackJack

Inhaltsverzeichnis

Andere Samsung Handy Handbücher

Samsung

Samsung Galaxy S 4 mini Bedienungsanleitung

Samsung

Samsung SM-G930W8 Bedienungsanleitung

Samsung

Samsung SGH-i728 Bedienungsanleitung

Samsung

Samsung GT-I9506 Bedienungsanleitung

Samsung

Samsung Galaxy S4 Mini Bedienungsanleitung

Samsung

Samsung SGH-G400 Bedienungsanleitung

Samsung

Samsung SM-A260F Bedienungsanleitung

Samsung

Samsung SGH-X480 Bedienungsanleitung

Samsung

Samsung SGH-i560V Bedienungsanleitung

Samsung

Samsung Galaxy S III Bedienungsanleitung

Samsung

Samsung Instinct S30 SPH M810 Bedienungsanleitung

Samsung

Samsung Intrepid SPH-I350 Benutzerhandbuch

Samsung

Samsung SM-G350 Bedienungsanleitung

Samsung

Samsung E1110 Bedienungsanleitung

Samsung

Samsung SCH U340 - Cell Phone - Verizon Wireless Bedienungsanleitung

Samsung

Samsung SGH T301G Bedienungsanleitung

Samsung

Samsung SGH-E390 Bedienungsanleitung

Samsung

Samsung GT-E2121L Bedienungsanleitung

Samsung

Samsung GT-C3310 Bedienungsanleitung

Samsung

Samsung SGH-i900 Bedienungsanleitung

Samsung

Samsung Galaxy A12 Bedienungsanleitung

Samsung

Samsung SCH a950 - Cell Phone - Verizon Wireless Bedienungsanleitung

Samsung

Samsung SCHR261A Bedienungsanleitung

Samsung

Samsung SGH-C180 Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
