Samsung SCH-811 Bedienungsanleitung

Owner’s Manual

Please read this manual before operating the phone,

and keep it for future reference.

SCH-811

Series CDMA

DIGITAL PORTABLE

CELLULAR TELEPHONE

SCH-811(E-US) 1/20/99 10:32 AM Page ii

Introduction

Introduction Table of ContentsPrecautions

Getting Started

Features 6

Description of Your Phone 7

Screen Display 8

Key Functions 9

Status Indicators 10

Display Messages 11

Battery 12

Call Quality 15

Basic Operations

Basic Operations of Your Phone 16

Turn On/Off 17

Placing Calls 18

Receiving Calls 19

The Menu

Menu Organization 21

Calls Options 24

Sounds Options 26

Display Options 31

Setup Options 33

Phone Book

Overview of the Phone Book 36

Storing Phone Numbers 37

Viewing Stored Entries 38

Displaying Your Phone Number 39

Important Information

This manual is based on the production version of the

included portable cellular telephone. Software

changes may have occurred after this printing.

Safety Precaution

For more detailed safety information,see “Safety”on

page 65.

• Do not use your phone while driving;park the

vehicle first.

• Do not use your phone when near medical

equipment.

• Do not use your phone at any time while traveling

on board a plane.

• Do not use your phone where a blasting operation

is in progress.

• Do not use your phone at a refueling point.

FCC/IC Notice

This device complies with part 15 of the FCC rules.

Operation is subject to the following two condition:

(1)This device may not cause harmful interference,

and (2) this device must accept any interference

received,including interference that may causing

undesired operation.

SCH-811(E-US) 1/20/99 10:32 AM Page 2

Electronic Devices 66

Aircraft 66

Blasting Areas 66

Other Dangerous Areas 67

Accessories

Batteries 68

Dual-Slot Desktop Charger 68

Cigarette Lighter Adapter 68

Travel Charger 68

Hands-Free Car Kit 68

Earbud Headset 68

Glossary of Terms 70

Index 73

Dialing from the Phone Book 39

Editing Phone Book Entries 40

Storing Secret Numbers 40

Erasing Phone Book Entries 41

Electronic Notebook 42

Voice Dial

Voice Dialing 46

Training the Phone 46

Checking Recorded Name 47

Activation 48

Using Voice Dialing 49

Security Options

Security Menu 51

Lock Mode 52

Call Restriction 54

Emergency Numbers 55

Other Options 56

Message Services

Short Message Services and Voicemail 59

Reviewing Messages 60

Transmitting Messages 63

Safety

Compliance with Safety Standards 65

Driving 65

SCH-811(E-US) 1/20/99 10:32 AM Page 4

Getting Started

Features

Congratulations on the purchase of your SAMSUNG

Phone. Using the latest digital technology,the phone

operates in a similar manner to other wireless phones,

while providing superior resonance and tone quality.

The following options make your phone both fun and

easy to use:

•Active Folder

•Variable Character Display

• Phone Book Memory - 79 Locations

•Voice Dialing - 20 Locations

• Programmable Lock Code

• Short Message Services (SMS) andVoicemail

• 9 RingTypes,4 MelodyTones,VibratorAlert

• Call Logs - 9 Locations Each:Outgoing and

Incoming Calls

• Pause Dialing

• Ringer Mute During Incoming Call

•Alarm

• EVRC

Description of Your Phone

Function keys and other controls activate the features

of your phone. The following illustration identifies the

function keys,controls,and indicators:

1) Power On Light

2) Earphone Mic Jack

3) LCD Screen

4)Volume Control

5) SEND Key

6) Scroll Keys

7) Power Key

8) Clear Key

9) Microphone

10) Folder

11) OK (Store) Key

12) Menu Key

13) End Key

14) Messages Key

15) Earpiece

16)Antenna

ABC

END/

DEF

JKL

MNO

GHI

TUV

WXYZ

PQRS

OPER

. '

SEND

MENU OK /

(not actual size)

SCH-811(E-US) 1/20/99 10:33 AM Page 6

Getting Started

Screen Display

This phone features dynamic character sizing,which

enables the screen to display from 12 to 16 characters

per line. The five-line screen includes four text lines

and one icon line,which displays active options and

selected menu items.

During conversation,the screen displays the call timer

and the name and number of the other party,if

available.Active in-use options,such as Mute and Call

Waiting,also display during conversation.

The following icons display at power-on:

Key Functions

Press SEND to:

• place a call after dialing the number,

• answer an incoming call,

• initiateThree-way calling,

• access Call Logs.

Press CLR to:

• erase one character at a time while

entering names and numbers,

• go back one menu level at a time while

viewing menu options,

Press and hold CLR to:

• erase all displayed characters while

entering names and numbers,

• return to Standby mode while viewing

menu options.

Press END to:

• end a call,

• exit the current menu and return to

Standby mode.

• mute the ringer during an incoming call.

• Press and hold END to turn the phone

on and off.

Press MENU to:

• display the Main Menu,

• scroll through menus,

• enter a pause while entering numbers.

Press OK to save menu option settings.

Press the arrow keys to scan menu

options.

Press and hold to:

•

initiateVoice Dialing when the folder is

open.

Press and hold to:

•

switch between bell and vibrator setting.

SEND

END/

OK /

Signal

Strength Vibrator OnDigital Battery

Strength

No Service

/In Use Message Roaming

(not actual size)

SCH-811(E-US) 1/20/99 10:33 AM Page 8

Getting Started

Press theVolume button to:

• adjust voice volume during

conversation.

• adjust ring volume in Standby mode,

• scroll Call Logs and Phone Book

entries.

Status Indicators

Signal Strength

Indicates a current signal strength.

No Service

Indicates that the phone is outside a

service area and cannot send or receive

calls.

Roaming

Displays when the phone is outside the

home service area but within the

network.

Message

Indicates messages.

Digital

Indicates a Digital mode.

Vibrate

Indicates aVibrate mode.

Battery Charge

Indicates a battery charge level.

Display Messages

MAINTENANCE The phone number is not registered in

REQUIRED the base station.

PHONE BOOK You have tried to access the memory

RESTRICTED while the phone is in the memory

restricted mode.

New Entry will A phone number is already stored in

replace selected memory location.

OK:Replace

MATCHING ENTRY The phone number you are trying to

NOT FOUND recall does not exist.

NO INCOMING You have not received any incoming

CALL LOG calls.

NO OUTGOING You have not made any outgoing

CALL LOG calls.

NO SERVICE The phone is out of the service area.

INCOMING CALL IS While the phone is restricted,

RESTRICTED you have tried to answer a call.

OUTGOING CALL IS While the phone is restricted,

RESTRICTED you have tried to make a call.

CALL FAILED The call cannot be made completely

even after automatic redialing.

SCH-811(E-US) 1/20/99 10:33 AM Page 10

Getting Started

Charging the Battery

To charge the battery using the Dual-Slot Desktop

Charger:

1.Plug the power cord of the charger into a wall

outlet.

2.Select one of the following options:

• Insert the entire phone with battery attached

into the front compartment of the charger.

•

Insert a single battery (alone,not attached to the

phone) into the rear compartment of the charger.

When two batteries are in the charger,the batteries

charge simultaneously. If you charge the battery while

it is attached to your phone,the Battery Charge

Indicator activates. A green LED indicates a full

battery charge.

Note: Use only the SAMSUNG-approved Dual-Slot

Desktop Charger with your phone by Samsung. Using

the wrong charger could damage the battery.

Battery Charge Indicator

The Battery Charge Indicator displays in the upper

right corner of the screen and indicates three levels of

charge. Three solid bars indicate a fully charged

battery. When the battery charge level is low or

empty,a clear Battery Charge Indicator (no bars

displayed) flashes on the screen.

Battery

Your phone package includes a partially charged

rechargeable battery so that you can use the phone

immediately after it is activated.

Installing the Battery

To attach the battery to your phone:

1.Hold the battery so that the metal contacts on the

base of the battery line up with the metal

contacts on the base of the phone.

2.Place the battery on the back of the phone with

the top of the battery about a quarter of an inch

from the latch.

3.Gently slide the battery toward the top of the

phone until it snaps into place.

Removing the Battery

Make sure to turn the power off before removing

the battery. Then press the battery release button

while sliding the battery out of position.

Dual-Slot Desktop Charger

The Dual-Slot Desktop Charger contains:

• Front compartment for charging the battery while

attached to the phone

• Rear compartment for charging the battery alone

(not attached to the phone)

• Red light to indicate that the battery is charging

(A yellow light indicates that the battery is

operating at a temperature that is too high or too

low,or that the battery is misaligned in the

charger.Please check the charger and battery.)

• Green light to indicate that the battery is fully

charged

SCH-811(E-US) 1/20/99 10:33 AM Page 12

Getting Started

Call Quality

For optimum call quality with your phone,please

follow these guidelines:

• Fully extend the antenna. While it may be possible

to place calls with the antenna retracted,the

phone operates best with the antenna fully

extended.

• Hold the phone as you would hold any other

telephone handset. Speak directly into the

microphone,and position the antenna up and over

your shoulder while talking.

• Do not hold the antenna while using the phone,as

this may affect call quality.

Table 1: Phone and Battery Specifications

PhoneType: Dual Mode CDMA/AMPS 800MHz

Graphic LCD: 5 Lines (4Text Lines,1 Icon Line)

BatteryType: Standard:1000mAh Li-Ion

Long-Life:1600 mAh Li-Ion

Phone with: Standard Battery Long-Life Battery

Dimensions (H✕W✕D): 88✕56✕27.5 mm 88✕56✕32 mm

Weight: 133g 153g

TalkTime: up to 1.88 hours up to 3.5 hours

or or

StandbyTime: up to 77 hours up to 122 hours

Caring for the Battery

Use only SAMSUNG-approved batteries,Desktop and

Travel chargers. These chargers maximize battery life

and performance. Using other batteries or chargers

may invalidate your warranty and may damage the

battery.

For proper battery care,please follow these guidelines:

•To avoid damage,charge the battery in

temperatures that range from 32˚F to 104˚F

(O˚C to 40˚C).

• Do not use the battery charger in direct sunlight

or in high humidity areas (such as a bathroom).

• Never dispose of the battery by incineration (fire).

• Keep the metal contacts at the battery base clean.

• Do not attempt to disassemble or short-circuit the

battery,as injuries or burns may result.

• Replace the battery when it no longer provides

acceptable performance.

• Do not store the battery in high-temperature

areas for a long time.

• Do not allow metal objects or liquids to contact or

short-circuit the battery terminals,as injuries or

burns may result.

Battery Disposal and Recycling

Please be aware of the following guidelines when

disposing of or recycling the battery:

• Do not dispose of the battery in a fire;the cell

may explode. Check the regulations in your area

for special disposal instructions.

• Do not open or puncture the battery;the released

electrolyte is corrosive and may cause damage to

the eyes and skin. This substance also can be

toxic if swallowed.

• Charge the battery in accordance with the

instructions specified in this manual.

SCH-811(E-US) 1/20/99 10:33 AM Page 14

Basic Operations

Turn On/Off

Turning On

To power on your phone,press and hold .

The red light flashes,an alert sounds. The display

updates to reflect the following conditions:

•When the system locates service,the greeting

message displays,along with the date and time.

You can now place and receive calls.

• If the system cannot locate service,only the

greeting message displays without the date and

time. In this case,you cannot place and receive

calls.Power off the phone,and then try again later

when service is available.

• If your phone is locked, displays. Press ,

and enter the four-digit lock code to unlock the

phone.

Turning Off

To power off your phone,press and hold .

When your power is off,nothing displays on the

screen (unless your are charging your battery).

Standby Mode

When your phone is on but no call is in progress,the

phone is in standby mode.

END/

Basic Operations of Your Phone

Power On/Off Press and hold .

Menu Scrolling Press ,then or .

Make Calls Enter number,and then press .

Correct Mistakes

Press .

Redial Call Press twice.

End Call Press ,or close folder.

Answer Call Press ,or open folder.

Save Numbers Enter phone number,press ,

and then follow screen prompts.

Outgoing Call Press , , ,to review

the last 9 outgoing calls.

Incoming Call Press , , ,to review

the last 9 incoming calls.

Name Search Press in Standby Mode.

OK /

ABC

. '

OK /

SEND

END/

SEND

END/

SCH-811(E-US) 1/20/99 10:33 AM Page 16

Basic Operations

To prepend existing phone numbers in the Phone

Book or Call Logs:

1.Access the phone number entry.

2.When the phone number displays,press to

display context-specific options.

3.Press for prepend.

4.Enter the area code or feature code.

5.Press to call the number.

Correcting a Misdialed Number

To correct a misdialed number:

• Press to erase the digit,and then enter the

correct dlgit.

• Press and hold to erase the entire entry,and

then enter the correct phone number.

Receiving Calls

Answering a Call

To answer an incoming call,press ,or open the

folder.

Ending a Call

To end a call,press ,or close the folder.The call

time displays,along with the name/number of the

called party (if available). The phone returns to

Standby mode automatically.

END/

SEND

DEF

Placing Calls

Placing a Call

To place a call:

1.Press and hold to power on your phone. An

active screen display indicates that the phone is

on.(No dial tone sounds.)

2.Enter the phone number,up to 36 digits,by

pressing the digit keys. The phone number

displays on the screen.

3.Press . The phone places the call to the

entered phone number.

Emergency Dialing

You can place calls to 911 or one of the three

emergency numbers that are in your emergency

number list even if your phone is locked.

Prepend Dialing

The prepend option enables you to add up to three

digits,such as area codes and network feature

activation codes,to a phone number of up to 10 digits.

You can prepend a phone number before dialing,or

prepend an existing entry in the Phone Book or Call

Logs.

To use prepend,select one of the following options:

• Enter the area code or feature activation code,and

then enter the phone number.

•Access a phone number stored in the Phone Book

or Call Logs,and then prepend the number.

SEND

END/

SCH-811(E-US) 1/20/99 10:33 AM Page 18

Andere Handbücher für SCH-811

Inhaltsverzeichnis

Andere Samsung Handy Handbücher

Samsung

Samsung GH68-09490A Bedienungsanleitung

Samsung

Samsung GT-S5230W Bedienungsanleitung

Samsung

Samsung galaxy note 5 Bedienungsanleitung

Samsung

Samsung GT-I8530 Bedienungsanleitung

Samsung

Samsung SGH-X700 Bedienungsanleitung

Samsung

Samsung Galaxy J3 Luna Pro Bedienungsanleitung

Samsung

Samsung GH68-06534A Bedienungsanleitung

Samsung

Samsung Galaxy Galaxy 5 Bedienungsanleitung

Samsung

Samsung GT-N7105 Bedienungsanleitung

Samsung

Samsung SGH-E848I Bedienungsanleitung

Samsung

Samsung Knack SCH-U310 Bedienungsanleitung

Samsung

Samsung SCH-R250 Bedienungsanleitung

Samsung

Samsung SM-A500Y Bedienungsanleitung

Samsung

Samsung SM-A105F Bedienungsanleitung

Samsung

Samsung SGH-F266 Bedienungsanleitung

Samsung

Samsung Galaxy S22 Bedienungsanleitung

Samsung

Samsung SPH-W3600 Bedienungsanleitung

Samsung

Samsung Galaxy J36 Bedienungsanleitung

Samsung

Samsung GT-I9003 Bedienungsanleitung

Samsung

Samsung SGH-x507 Series Bedienungsanleitung

Samsung

Samsung SM-A115M Bedienungsanleitung

Samsung

Samsung SGH-E200 Bedienungsanleitung

Samsung

Samsung i600 Bedienungsanleitung

Samsung

Samsung SPH-I325 ACE Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
