Samsung M9900 Installationsanleitung

SAMSUNG

M9900/M9600 PJT(DRYER)

Training Manual

BASIC MODEL MODEL CODE MODEL NAME

DM9900M

DVE60M9900V/A3 DVE60M9900V

DVE60M9900W/A3 DVE60M9900W

DVG60M9900V/A3 DVG60M9900V

DVG60M9900W/A3 DVG60M9900W

DVE60M9900V/AC DVE60M9900V

DM9600M

DVE55M9600V/A3 DVE55M9600V

DVE55M9600W/A3 DVE55M9600W

DVG55M9600V/A3 DVG55M9600V

DVG55M9600W/A3 DVG55M9600W

DVE55M9600V/AC DVE55M9600V

DV*60M9900*

DV*55M9600*

“This document can not be used without Samsung's authorization”

Contents

Product Introduction: 8-14

Changed Part list: 15-17

Instruction Of Function: 18-26

Test Mode & Error Check: 27-34

Reference Information: 35-54

7Disassembly & Reassembly: 56-72

1Safety Warning 3-7

“This document can not be used without Samsung's authorization”

1.Safety Warnings

WARNING - RISK OF FIRE

•Clothes dryer installation must be performed by a qualified installer.

•Install the clothes dryer according to the manufacturer’s instructions and local codes.

•Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil type) duct is

installed, it must be of a specific type identified by the appliance manufacturer as suitable for use with

clothes dryers. Flexible venting materials are known to collapse, be easily crushed, and trap lint. These

conditions will obstruct clothes dryer airflow and increase the risk of fire.

•To reduce the risk of severe injury or death, follow all installation instructions.

“This document can not be used without Samsung's authorization”

TO REDUCE THE RISK OF FIRE OR EXPLOSION:

• Do not dry items that have been previously cleaned, washed, soaked, or spotted with gasoline, dry

cleaning solvents, or other flammable or explosive substances. They emit vapors that could ignite

or explode. Any material that has been in contact with a cleaning solvent or flammable liquids or

solids should not be placed in the dryer until all traces of these flammable liquids or solids and

their fumes have been removed. There are many highly flammable items used in homes, such as

acetone, denatured alcohol, gasoline, kerosene, some liquid household cleaners, some spot

removers, turpentine, waxes, and wax removers.

• Do not dry items containing foam rubber (may be labeled latex foam) or similarly textured rubber-

like materials on a heat setting. Heated foam rubber materials can, under certain circumstances,

produce fire by spontaneous combustion.

1.Safety Warnings

“This document can not be used without Samsung's authorization”

1.Safety Warnings

WHAT TO DO IF YOU SMELL GAS:

•Do not try to light any appliance.

• Do not turn on the appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s

instructions.

• If you cannot reach your gas supplier, call the fire department.

• Installation and service must be performed by a qualified installer, service agency, or

the gas supplier.

“This document can not be used without Samsung's authorization”

1.Safety Warnings

Important safety instructions

WARNING

To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic

precautions, including the following:

1. Read all instructions before using this appliance.

2. Do not dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline,

dry-cleaning solvents, or other flammable or explosive substances, because they give off vapors that could

ignite or explode.

3. Do not use the dryer to dry clothes which have traces of any flammable substance, such as vegetable oil,

cooking oil, machine oil, flammable chemicals, thinner, etc., or anything containing wax or chemicals, such as

mops and cleaning cloths. Flammable substances may cause the fabric to catch fire by itself.

4. Do not store or use gasoline or other flammable vapors and liquids near this or any other appliance.

5. Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary

when the appliance is used near children and pets.

6. Before the appliance is removed from service or discarded, remove the door to the drying compartment

to prevent children or animals from becoming trapped inside.

7. Do not reach into the appliance when the drum is moving.

8. Do not install or store this appliance where it will be exposed to the weather.

9. Do not tamper with the controls.

10. Do not repair or replace any part of the appliance or attempt any servicing unless specifically

recommended in the user-maintenance instructions or published in the user-repair instructions that you

understand and have the skills to carry out.

“This document can not be used without Samsung's authorization”

1.Safety Warnings

11. Do not use fabric softeners or products to eliminate static unless recommended by the

manufacturer of the fabric softener or product.

12. Clean the lint screen before or after each load.

13. Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.

14. Keep the area around the exhaust opening and surrounding areas free from lint, dust, and dirt.

15. The interior of the dryer and exhaust duct should be cleaned periodically by qualified service

personnel.

16. Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils

may contribute to a chemical reaction that could cause a load to catch fire.

17. This appliance must be grounded. See “Electrical requirements” and “Grounding” in the “Installing

your dryer” section.

18. This appliance must be properly grounded. Never plug the power cord into a receptacle that is not

grounded adequately and in accordance with local and national codes. Refer to installation

instructions for grounding this appliance.

19. Ensure pockets are free from small irregularly shaped hard objects and foreign material, i.e. coins,

knives, pins, etc. These objects could damage your dryer.

20. Gas leaks may occur in your system, resulting in a dangerous situation.

21. Gas leaks may not be detected by smell alone.

22. Gas suppliers recommend you purchase and install a UL-approved gas detector.

“This document can not be used without Samsung's authorization”

Concept

Main

Feature

2. Product introduction

Delicate Dry (Low Temperature dry)

The Largest Capacity

Smart Care

Vent Sensor

Steam Cycle

Sanitize Cycle

Energy Saving

Time Saving

Easy Reversible Door

4-way Vent(Elec.)

Wi-fi Embedded

New design and one of the best

dryer options and care all clothes

material.

“This document can not be used without Samsung's authorization”

2. Product introduction

Extra Large Capacity

Ultra drying capabilities are at your fingertips! Now you can dry extra-large loads.

Our ultra large 7.5 cu.ft. capacity dryer circulates more air through your clothes getting

them dry faster, for a wrinkle-free result.

Time Saving Our cycles are designed with you in mind. All our dryers are designed to dry your

clothes in less time... just 42 minutes! Giving you time for more important things in life.

Energy Saving

Samsung dryers are super energy efficient, that you can dry up to 3.31 pounds of

laundry with 1kWh. Also, both the large capacity and Fuzzy Logic Control save energy

by automatically drying your clothes the most efficient way.

Easy Reversible Door Our dryers will fit just about anywhere and without a door conflict. The direction of our

easy reversible door can be changed with just four screws.

Pedestal With Storage

Drawers

An option 15’’ pedestal is available to raise the dryer for easier loading and unloading. It also offers

a built-in storage drawer that can hold a 100 oz., bottle of detergent.

Various Drying Cycles &

Fuzzy Logic Algorithm

Simply turn the job dial to select one of the 13 automatic drying cycles, including normal, heavy

duty and bedding, or let the fuzzy logic control measure the degree of dampness and automatically

set the drying time. Precision drying has never been easier tan with Samsung.

Smart Care

Samsung’s Smart Care, an automatic error-monitoring system, detects and diagnoses problems at

an early stage and provides a quick and easy solutions, with the innovative Smart Remote Control

technology, you can also be alerted when the problems occurs via your Smart phones.

4-way Vent(Elec.) You can install the exhaust vent in the following four (4) positions: back, either side,

bottom.

Delicate Dry You can use “Delicate dry” with tumble dry. Samsung dryer can save your clothes damage by high

temperature heat.

“This document can not be used without Samsung's authorization”

Specification

Model DM9900M/D9600M DV7500K

Product

Specification

Capacity (kg) 7.5 CU.FT 7.5 CU.FT

Power source ELECTRIC/GAS ELECTRIC/GAS

Drying Cycle 12 13

Heater 5300W (ELEC)

22000 BTU/hr (GAS)

5300W (ELEC)

22000 BTU/hr (GAS)

Drying Level 5 5

Temp Select 4 4

Steam Cycle YES YES

Display residue time YES YES

Drum light YES YES

Child lock YES YES

Reversible Door YES YES

Drum material STS STS

Window Size 20 inch 20 inch

SET Size (WxDxH : Inch) 27 X 32.5 X 46.9 27 X 32.4 X 38.7

Performance Cycle time

(AHAM 8lbs) 75 min 75 min

Appearance

Door Crystal Blue (TOC) Chrome Trim

Control Panel LED LED

Display Color Black Caviar Black Caviar

2. Product introduction

“This document can not be used without Samsung's authorization”
