Refrigerator

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsung.com/global/register

RFG299AA

English

Features of your new Refrigerator

KEY FEATURES OF YOUR NEW REFRIGERATOR

Your Samsung French Door Refrigerator comes equipped with various innovative storage and energy-efﬁcient

features.

• Twin Cooling System

The Refrigerator and Freezer have separate evaporators. Due to this independent cooling system,

the Freezer and Refrigerator cool more efﬁciently.

Additionally, this separate air ﬂow system prevents food odor of one compartment from seeping into

other compartments.

• 7inch LCD

An easy access interface for users with a Touch Screen Panel



• Cool Select PantryTM

The Cool Select pantryTM is a full-width drawer with adjustable temperature control.



• Bigger & Wider Space

The wide shelf area and pantry provide enough space for larger items like a pizza box, etc.

The wide freezer drawer also provides enough space for 2~3 turkeys.

• Secure Auto Close

The Secure Auto Close feature will automatically close a door that is slightly open.

• Compact Ice Maker

The Ice maker can dispense cubed or crushed ice.

• Digital Display and Temperature Control

• Water Filtration System

• Door Alarm

A helpful beeper alerts you if a door is ajar.

• Tilting Pocket

The Tilting pocket can be used to store up to a 16” pizza.

• Auto Pull Out Drawer

The upper drawer in the freezer comes out automatically as you just open the freezer door.

• Easy Handle

Freezer door can be opened with less effort.

• Energy Star

This Energy star labeled product may save you money on your energy costs.

2_ Features

For easy future reference, write the model and serial

number down. You will ﬁnd your model number and

serial number on the left side of the refrigerator.

Model #

Serial #

Safety Information

SAFETY INFORMATION

Before using your new Samsung French Door Refrigerator, please read this manual thoroughly to

ensure that you know how to safely and efﬁciently operate the features and functions that your

new appliance offers.

Because the following instruction covers various models, the characteristics of your Refrigerator

may differ slightly from the Refrigerator described in this manual. If you have any question, contact

us at 1-800-SAMSUNG or ﬁnd help and information online at www.samsung.com.

What the icons and signs in this user manual mean :

WARNING Hazards or unsafe practices that may result in severepersonalinjuryordeath.

CAUTION

Hazards or unsafe practices that may result in minorpersonalinjuryorproperty

damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or personal injury when using your

refrigerator, follow these basic safety precautions:

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent electric shock.

Call the service center for help.

Thesewarningsignsareheretopreventinjurytoyouandothers.

Pleasefollowthemexplicitly

Keepthismanualinasafeplaceforfuturereference.

SEVERE WARNING SIGNS

Do not plug several appliances into the same power receptacle.

•

Large appliances draw a lot of power. Powering more than one appliance or machine from a single power source

could cause overheating and cause a ﬁre.

Make sure that the power plug is not kinked or damaged by the back of the Refrigerator.

• A damaged power plug may overheat and cause a re.

Do not spray water directly into or on the outside of the Refrigerator/Freezer drawer.

• Water could get into the interior machine parts and cause electric shock.

Do not use aerosols near the Refrigerator.

• Aerosols used near the Refrigerator may cause an explosion or re.

Safety Information _3

Do not put undue stress on the power cord or place heavy articles on it.

•    Placing heavy articles on the power cord may create the risk of explosion or ﬁre.

Do not insert the power plug with wet hands.

• It may cause electric shock.

Do not put a container ﬁlled with water on the Refrigerator.

• If it spills, it may cause ﬁre or electric shock.

Do not install the Refrigerator in a damp place or place where it may come in contact

with water.

• Wet and/or deteriorated insulation of the internal electrical parts may cause electric shock or ﬁre.

Do not store volatile or ﬂammable substances in the Refrigerator.

• Storing benzene, thinner, alcohol, ether, LP gas and other such products may cause explosions.

Do not disassemble or repair the Refrigerator by yourself.

• You may run the risk of ﬁre, appliance malfunctions and/or personal injury. Call your nearest service center

for help from a qualiﬁed service technician.

Unplug the Refrigerator before changing the interior light.

• Changing the light while the Refrigerator is plugged in may cause electric shock.

If you wish to dispose of the Refrigerator, remove the doors and seals before throwing

it away.

• The doors(and their seals) can entrap a child if they climb into the Refrigerator.

Make sure that the doors are off, and ensure that no one is suffocated by being locked inside.

The Refrigerator must be safely grounded

• Always make sure that you have grounded the Refrigerator before attempting to investigate or repair any

part of the appliance. Power leakages can cause severe electric shock.

Never use gas pipes, telephone lines or other potential lightning attractors as an

electrical ground.

• Improper use of the grounding plug can result in a risk of electric shock. If it is necessary to use an

extension cord to power the Refrigerator, use only a 3-wire extension cord that has a 3-blade ground plug

and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension

cord should be AC 115V~120V, 10A, or more. Additionally, if a grounding adapter is used, make sure the

receptacle box is also fully grounded.

Safety Information

4_ Safety Information

CAUTION SIGNS

Use good judgment when ﬁlling the Refrigerator with food and drinks.

• In an overfull Refrigerator, heavy, fragile, bulky or breakable items may fall out and cause personal injury

and/or damage to surrounding objects.

Do not put bottles or glass containers in the Freezer drawer.

• When the contents freeze and then expand, the glass may break and cause personal injury or leave

dangerous glass shards in the Freezer.

If the electrical wall socket is loose, do not insert the power plug.

• There is a risk of electric shock or ﬁre. Have the plug looked at by a licensed electrician.

Never unplug your Refrigerator by pulling on the power cord.

• Always grip the power cord ﬁrmly and pull straight out from the outlet. Yanking or pulling on the power

cord may cause a short-circuit, ﬁre and/or electric shock.

• A damaged power cord must be replaced by the manufacturer, a certiﬁed service agent or qualiﬁed service

personnel.

Do not store articles on the top of the appliance.

• When you open or close the door, the articles may fall and cause personal injury and /or damage to

surrounding objects.

Do not store pharmaceutical products, scientiﬁc materials and temperature-sensitive

products in the refrigerator.

• Products that require exact temperature controls should not be stored in the Refrigerator.

Do not allow children to climb, stand or hang on shelves and handles of the

Refrigerator. They could damage the Refrigerator and seriously injure themselves.

Do not sit on the freezer door. The door may break.Do not allow children to climb into

the freezer basket.

If you notice a chemical or burning plastic smell or see smoke, unplug the Refrigerator

immediately and contact your Samsung Electronics Service Center.

After your Refrigerator is in operation, do not touch the cold surfaces in the Freezer

compartment. Particularly when hands are damp or wet, skin may adhere to these

extremely cold surfaces.

• Skin may stick to the surface and you may get frostbite.

Do not put your hands under the appliance.

• Any sharp edges may cause personal injury.

Safety Information _5

CAUTION

Neverputngersorotherobjectsintothewaterdispenserholeoricechute.

• It may cause personal injury and/or material damage.

IftheRefrigeratorwillnotbeusedforalongperiodoftime(forexample,over

severalmonths),unplugthepowerfromthewall.

• Over time, deterioration in the power cord insulation may cause re.

Donotuseawetordampclothwhencleaningtheplug.

Removeanydustorforeignmatterfromthepowerplugpins.

• A dirty power plug can increase the risk of re.

IftheRefrigeratorisdisconnectedfromthepowersupply,youshouldwaitfor

atleastveminutesbeforepluggingitbackin.

Donotplacetherefrigeratordirectlyinsunlight.

Theappliancemustbepositionedforeasyaccesstopowersource.

Ifthepowercordisdamaged,itmustbereplacedbythemanufacturer,a

certiedserviceagentorqualiedservicepersonnel.

Ifyouhavealongvacationplanned,emptytheRefrigeratorandturnitoff.

• Wipe excess moisture from the inside and leave the doors open to keep odor and mold from

developing.

ServicewarrantyandModication

• Any changes or modications performed by a 3rd party on this nished appliance is not covered

under Samsung warranty service, nor can Samsung be responsible for safety issues that result

from 3rd party modiﬁcations.

ChildrencangettrappedinsideRefrigerators.

BeforeyouthrowawayyouroldRefrigeratororFreezer,makesurethatyou;

• Take off the doors.

• Leave all shelves in places so that children may not easily climb inside and shut the door while they

are inside.

Thisapplianceisnotintendedforusebysmallchildrenorinrmpersonswithout

capable,adultsupervision.Smallchildrenshouldbesupervisedwhenusingthe

appliance.

Donotblockairholes

• If the air holes are blocked, especially with a plastic bag, the refrigerator can be over cooled.

If this cooling period lasts too long, the water ﬁlter may break and cause water leakage.

Safety Information

6_ Safety Information

CAUTION

Contents

SETTINGUPYOUR

FRENCHDOORREFRIGERATOR

OPERATINGYOURSAMSUNG

FRENCHDOORREFRIGERATOR

TROUBLESHOOTING

WARRANTY

08 Getting ready to install the refrigerator

09 Removing the refrigerator doors

11 Disassemble the Freezer Drawer

12 Reattaching the refrigerator doors

14 Assemble the Freezer Drawer

15 Adjusting the doors

16 Making minor adjustments between doors

17 Adjusting the freezer drawer level

18 Checking the water dispenser line

19 Installing the water line

21 Digital panel

21 View of panel

22 Plug in.

22 How to calibrate touch point.

23 Slide Show.

24 Home.

24 Dispenser.

26 Child Lock.

27 Cooling off.

28 Door open Alarm.

28 Calendar.

29 Temp. Control.

31 Water Filter.

32 Photo Album.

36 Nutrition Facts.

37 Conversions.

37 Settings.

42 Parts and Features

43 Storing food in the refrigerator

43 Storing food in the freezer drawer

44 Using the Cool Select Pantry™

45 Removing the refrigerator accessories

46 Using the doors

46 Using the tilting pocket

47 Removing the freezer accessories

48 Cleaning the refrigerator

49 Changing the interior lights

50 Troubleshooting

52 Warranty

Contents _7

Setting up your French Door Refrigerator

GETTING READY TO INSTALL THE REFRIGERATOR

Congratulations on your purchase of the Samsung French Door Refrigerator. We hope you enjoy the state-of-art

features and efﬁciencies that this new appliance offers.

SelectingthebestlocationfortheRefrigerator

• A location with easy access to the water supply.

• A location without direct exposure to sunlight.

• A location with level (or nearly level) ooring.

• A location with enough space for the Refrigerator doors to

open easily.

• Allow sufcient space for air circulation of the internal

cooling system.

If the Refrigerator does not have enough space, the internal

cooling system may not work properly.

8_ Setting Up

First thing! Make sure that you can easily move your Refrigerator to its ﬁnal location by measuring doorways

(both width and height), thresholds, ceilings, stairways, etc.

The following chart details the exact height and depth of Samsung French Door Refrigerator.

Depth

MODEL

Capacity(Cu.Ft)

Dimension

(inches)

Width

Case Height with Hinge

without Hinge

with Door

without Door

RFG299AA

28.5

35 ¾

68 ⅝

35 ¾

29 ⅛

FLOORING

For proper installation, this refrigerator must be placed on a level

surface of hard material that is the same height as the rest of the

ﬂooring. This surface should be strong enough to support a fully loaded

refrigerator, or approximately

660lbs(299kg). To protect the ﬁnish of the ﬂooring, cut a large section

of the cardboard carton and place under the refrigerator where you are

working. When moving, be sure to pull the unit straight out and push

back in straight.

• Allow clearance to the right, left, back and top when installing. This will help reduce power consumption and keep

your energy bills lower.

• Do not install the Refrigerator where the temperature will go below 50ºF (10ºC).

CAUTION

When moving your refrigerator

To prevent ﬂoor damage be sure the front leveling legs are in

the up position(above the ﬂoor).

Refer to ‘Leveling the refrigerator’ in the manual(at page 15)

ControlLeverScrewdriver(-)

Setting Up _9

01 SETTING UP

Disassemble the Refrigerator doors

1. With the door opened, remove the Hinge Cover

cap ( 1

)with a Flat head screwdriver, and close

the door.

Remove the 3 screws holding down the Hinge

Cover and remove the Hinge Cover ( 2

REMOVING THE REFRIGERATOR DOORS

If the Refrigerator is too large to pass through your doorway easily, you can remove the refrigerator doors.

Tools you will need

Philips screwdriver Flat-blade screwdriver Wrench Pliers Allen wrench(3/16”)

SETTING UP THE REFRIGERATOR

Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features and

functions of the appliance. By completing the following steps, your Refrigerator should be fully operational.

1. Place the Refrigerator in an appropriate location with reasonable clearance between the wall and the

Refrigerator. Refer to installation instructions in this manual.

2. Once the Refrigerator is plugged in, make sure the interior light comes on when you open the doors.

3. Set the Temperature control to the coldest temperature and wait for an hour. The Freezer will get slightly

chilled and the motor will run smoothly.

4. After powering the Refrigerator, it will take a few hours to reach the appropriate temperature. You can

store food and drinks in the Refrigerator after the temperature is sufﬁciently cool.

Check the accessory list below.

Water ﬁlter

(DA29-00003B)

Hex wrench

(DA80-00002C)

Compression ﬁtting

(DA62-00305A)

Compression nut

(DA74-00070B)

Fastener

(DA60-00143B)

Setting up your French Door Refrigerator

10_ Setting Up

4. Lift the door straight up to remove.

5. With a Philips head screwdriver, remove the two screws ( 10

)

attached to the lower left and right door hinges.

With an wrench(10mm), remove the two hex head bolts ( 11

)

attached to the lower left and right door hinges.

Remove the lower left and right door hinges ( 12

3. Remove the 3 hex head bolts ( 7

) attached to the upper

left and right door hinges with a wrench(10mm).

With a Philips head screwdriver, remove the ground

screw ( 8

) attached to the upper left and right door

hinges.

Remove the upper left and right door hinges ( 9

2. Disconnect the electrical connector ( 3

) above

the upper right door hinge and the 3 electrical

connectors ( 4

) above the upper left door hinge.

Disconnect the water tube ( 5

) by pulling the tube

ﬁtting ( 6

) apart as shown in the picture.

Andere Handbücher für RFG299AARS

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Kühlschrank Handbücher

Samsung

Samsung RB195ACRS Bedienungsanleitung

Samsung

Samsung SRS583NW Bedienungsanleitung

Samsung

Samsung SRL349MW Bedienungsanleitung

Samsung

Samsung RFG237AA Bedienungsanleitung

Samsung

Samsung RF24FSEDBSR/AA Bedienungsanleitung

Samsung

Samsung RF31FMEDBSR Bedienungsanleitung

Samsung

Samsung RF23J9011SR Bedienungsanleitung

Samsung

Samsung RF4287HARS/XAA Bedienungsanleitung

Samsung

Samsung RF197ACRS Bedienungsanleitung

Samsung

Samsung RL34EC series Bedienungsanleitung

Samsung

Samsung RH62K Series Bedienungsanleitung

Samsung

Samsung RF266 Bedienungsanleitung

Samsung

Samsung RS25H5002SL Bedienungsanleitung

Samsung

Samsung RB215LASH Bedienungsanleitung

Samsung

Samsung RF28T5001SR/AA Bedienungsanleitung

Samsung

Samsung rs61681gdsr Bedienungsanleitung

Samsung

Samsung RL44Q Series Bedienungsanleitung

Samsung

Samsung RF22 Series Bedienungsanleitung

Samsung

Samsung RM257AC Series Sicherheitsleitfaden

Samsung

Samsung RF265AARS RF266AARS RF26NBRS1RF265AABP RF266AABP RF26NBBP1RF265AAWP RF266AAWP RF26NBSH1RF265AASH... Bedienungsanleitung

Samsung

Samsung RB34A7B5E12/EF Bedienungsanleitung

Samsung

Samsung RS265BBWP Bedienungsanleitung

Samsung

Samsung RB38 6 Series Bedienungsanleitung

Samsung

Samsung RB33J3200 Series Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
