CentralizedVideoManagementSoftwareSVM‐S1

SVMS1



QuickReferenceGuide



English



CentralizedVideoManagementSoftwareSVM‐S1

SVMS1QuickReferenceGuide

SVM–S1maynotrunpropertyifthePCdoesnotmeetminimum

requirements.OtherapplicationsshouldnotrunonthesamePCwhere

SVM‐S1isrunning.



zSystemRequirements

SectionMinimum

Requirements

Recommended

Requirements

CPUCore2duoE4300ormoreCore2duoE7400ormore

MainMemory1GBormore2GBormore

VideoMemory256MBormore512MBormore

Display1024ⅹ768(with32bitcolor)ormore/OpenGL

compatibility

HardDisk80GBormore

OSWindows2000SP4/WindowsXPProfessional/

WindowsVista

EtcDirectX9.0ormore

¾NotSupportedProducts:SVM‐S1doesnotsupportSVR‐1630/440

/430andSWC‐304.

SamsungTechwincaresfortheenvironmentatallproduct

manufacturingstagestopreservetheenvironment,andis

takinganumberofstepstoprovidecustomerswithmore

environment‐friendlyproducts.

TheEcomarkrepresentsSamsungTechwin’swilltocreate

environment‐friendlyproducts,andindicatesthatthe

productsatisfiestheEURoHSDirective.



CentralizedVideoManagementSoftwareSVM‐S1

1. Installation

zInstallSVMS1Software

1).Doubleclicktheontheprovided[SVM‐S1Setup.exe]file,and

selectpreferredlanguage.

2).Clickthe[Next]button.

3).Select[Iacceptthetermsofthelicenseagreement],andclickthe

[Next]button.

4).SelectinstallationlocationofSVM‐S1,andclickthe[Next]button.

1. Installationㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ 3

zSVM‐S1SoftwareInstallation

2. GettingStartedㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ 3

zLogin

zMainScreenComposition

zRegisteringaDevice

zConnectingToaDevice

zAddingaScreenLayout

CONTENTS

CentralizedVideoManagementSoftwareSVM‐S1

ÖThedefaultdirectoryis‘C:\ProgramFiles\SamsungTechwin\SVM‐

S1’Toselectadifferentdirectory,clickthe[Change]button.

5).Clickthe[Install]Button.

2. GettingStarted

zLogin

1).Runningthesoftware.

2).EnterID/Password.

zMainScreenComposition

Afterloggingin,userhasaccesstoavarietyofviewpanelsandpanes.

===Default===

ID:Admin

Password:12345

Live

Area

PTZ

Control

EventStatus

Device

Tree

ToolBar

Menu

CentralizedVideoManagementSoftwareSVM‐S1

¾Menu:Setupprogram,Changeconstitutionofscreen,Theother

executionShortcuts.

¾ToolBars:Changethemulti‐screenchannel,Theotherexecution

shortcuts.

¾DeviceTree/ScreenLayout/MapTree:Displaysdevice,channel,

layout,andmap.

¾LiveImage:Displayslivevideofromconnecteddevice(s)or

channel(s).

¾EventList:Displayseventsfromdevice,anddisplayvideosof

eventsthroughInstantViewer&Player.

¾Image/PTZControl:Controlselectedchannel&PTZof

configuration.

zRegisteringDevice

1).Select[Tool–DeviceManager]onMenu,orselect[ 

button]onToolbar.

2).Click[AddDeviceAutomaticallybutton].

3).Click[Searchbutton].

4).Selectthedesireddevice&EnterID/PW,clickthe[Addbutton

].

5).Ifregistrationissuccessful,theselecteddeviceisdisplayedinthe

[DeviceTree]ontheleft.

6).Clickthe[CloseDeviceManager]button.

zConnectingToaDevice

Whenadeviceisregistered,theresultdisplaysintheDeviceTreeon

theleftoftheapplication.

CentralizedVideoManagementSoftwareSVM‐S1

1).Connectingallchannelsofadeviceatonce

ClickonadeviceiconintheDeviceTree.

Screenlayoutisconstitutedautomaticallydependingonthe

numberofchannels,andallchannelsaredisplayedatonceinlive

area.

2).Connectingtoselectedchannel(s)/device(s).

Clickthe[Device]iconorthe[Channel]iconattheDeviceTree.

Selectedchannelsareconnectedanddisplayedonthescreen.

DeviceSelection:V[  ]mark/ChannelSelection:[  ]mark.

DVR&NVR

NetworkCamera

isteredMa

RegisteredLayout

1.Caseofconnectingdevice(IconisBolded)

2.Caseofdisconnectingdevice(Iconisdimmed)

3.Caseofoutputtingdeviceimage

4.Caseofoutputtingchannelimage

Icon

CentralizedVideoManagementSoftwareSVM‐S1

Usermaychangethescreenpartitionasdesiredamongoptionsof

1,4,6,8,9,16,25,36,49,64.

Dual‐monitor:Displayimagesintwoscreensbyusinganextended

monitor.

Fullscreenmonitoring:Clickthe[OnlyView  ]buttononTool

bar.

3).ControlPTZ:SelectlivevideoofPTZcamera,andusePTZcontrol.

Pan&Tilt:Clickthe[ArrowButton]thatyouwanttomoveatPTZ

control.

Zoom:Clickthe[  /  ]buttonsassociatedwithZoom.

SetupPTZSpeed:Clickthe[  /  ]buttonsassociatedwith

Speed.

Focus:Clickthe[  /  ]buttonsassociatedwithFocus.

Preset:StoreandusePresetbyusing. 

zAddingaScreenLayout

1).Select[Tool–LayoutManager]onMenuorthe[  button]on

Toolbar.

2).Ifyouwanttouseextendedmonitor,checkthe[Monitor2].

3).Selectscreenpartitionandarrangethechannels.

4).EnterthenameofScreenLayout.

5).IfyouwanttolinkaMap,check[MapViewer]andselectthe

desiredMap.

6).ClicktheSavebutton[  ],andclicktheexit

button[].

7).IfyouselectLayoutstoredunderLayoutFolderintheDeviceTree,

screenispartitionedtospecifiedpartitionmode,andimagesof

devicesaredisplayedatspecifiedplaces.

CentralizedVideoManagementSoftwareSVM‐S1

zSearchingLogHistory

1).Select[Tool–LogHistory]onMenuorthe[  button]onToolbar.

2).SelectPC/Devicetimeanddate.

3).Selectadevice[]/Default:Alldevices.

4).Selecteventtype[]/Default:All

devices.

5).Selectstarttimeofsearch(1,3,6,12,24Hour)

[].

6).Clickthe[SearchButton].

7).ClickonthelogresultanduseInstantViewer/Player[/

]toplaythevideoassociated.

※Ifyouwanttodetaildescription,pleaserefertouserguide.


