Sanan SA-1393 Benutzerhandbuch
Outdoor IR Day & Night Water-Proof Camera
SA-1393
Quick Operation Guide
Packing List
Please ensure the Outdoor IR Day & Night Water-Proof Camera
(referred to as "camera") is integrated when you open the package
at first time, to verify all accessories are complete referenced by
below chart.
Camera×1
screw×4
Description & Explanation (The overall appearance of camera front)
Camera: photoresistor + infrared light + HD lens
Power Interface: to connect the power adapter(DC12V/1.5A)
LAN Interface: connect to internet
Optional:1. Brief Function
Camera
LAN Interface
Power Interface
Appearance Introduction
3. Full functions
PS: 1. Brief functions WIFI: Increase WIFI antenna, reset button
(press 5 seconds to restore original setting).
2. Full functions: Increase reset button, audio input interface
(for external audio receiver connection), antenna (WIFI antenna or
Reset button
Audio input interface
wireless alarm antenna optional).
2. Brief function WIFI
Operation Reading
1. Network Connection
After power on the camera, connect one end of the Ethernet cable
to the camera Ethernet interface, and the other end to the router
LAN interface (make sure the router DHCP function is on), if
successfully connected, the yellow light on, the green light flashes.
2. APP Download
IOS clients can search and download "Yoosee" from Apple APP
Store.
Android clients can search and download "Yoosee" from Google
Play.
3. Add Device
Plug power supply and network cable to camera first, login in
APP→"Smartlink"→"+"→"Manually add".
PS: 1. Camera default password is 123.
2.If you want to change to wifi status, pls follow the below in
structions after you added the camera:
3.
My camera --> "Setting" --> "Network Settings"--> select wifi
--> input wifi password --> change "wifi"--> succeed, plug out
enthernet cable. (Implementation in WIFI cameras)
4.If you want to add the device directly to the wifi,please try
these steps:
1)Click smartlink
2)input your wifi password (please note the cell phone wifi function
should open,)
3)Click “Next”,it will show the camera connect successfully.
4. Check Update
We are always keeping hard working for a more perfect customers
experience, please check and update both the device and APP
timely.
Check the updated APP:
Sliding menu --> "About" --> "Check about version"
Check the updated camera:
My Camera --> "Setting" --> "Device Update"
Function Introduction
·Real 720P HD Network Camera
·Support audio input, could connect external audio receiver
(implementation in audio function cameras)
·Support Smart wifi link, free of Ethernet cable connection to
configure wifi (implementation in WIFI cameras)
·Alarm linkage: call several mobiles、snapshoot to your E-mail
·Support Motion Detection trigger alarm
·Support 64 wireless alarm sensors linkage (implementation in
wireless alarm function cameras)
·vandal-proof camera, hidden 3-axis bracket, anti thunder design
for power supply port, global highest IP67 waterproof level
·Standard TF card slot, support max 128G
FAQ
1.Q: When adding a device, APP did not prompt the discovery of a
new equipment
A: Please check if the cameras and cell phone are in the same
LAN;
Please check if the camera's Network indicator keeps on;
If cameras and cell phone are not in the same LAN, it is
recommended to use the ID number manually add cameras;
2. Q: When viewing live video, the device reminds the password is
wrong
A: Please check if the remote access password which being set
when add the device is right or not. If not, please select edit to
re-set it from the list of entries in the camera;
3. Q: “Device list” reminds the device is offline
A: Please check whether the network of the cameras is normal,
and network indicator of device is on;
Please check whether the router network is normal.
