Saramonic Vmic Bedienungsanleitung
www.saramonic.com
The Saramonic logo is trademark which is registered
and owned by Saramonic International.
COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL
A brand of DSQN
Email: [email protected]
8
9
6
7
9
8
10
1
2
Audio output jack
Headphone output jack
Battery compartment
Integrated shock mount
Cold shoe mount
2 Set Up Guide
2.1 Install the battery
Unlock the battery compartment
Insert the AA batteries into place aligning + and - polarity as shown
Lock the battery compartment
1 Product Introduction
1.1 General Introductions
The Saramonic Vmic Stereo is a stereo cardioid condenser
microphone that provides professional audio for DSLR cameras and
camcorders. The left and right microphone capsules record
high-quality stereo sound into your cameras and camcorders.
The Vmic Stereo allows you to adjust level control (-10dB, 0dB,
+20dB), high-pass filter (150 Hz) and high-frequency boost (+6dB) to
increase intelligibility of dialogue. The detachable 3.5mm cable
connects the Vmic Stereo to your camera's audio input, while the
stereo headphone output allows you to monitor the incoming audio.
The Saramonic specially designed shock mount system provides
isolation from vibration and mechanical noise.
1.2 Highlights
• Stereo cardioid condenser video microphone
• Integrated shock mount system
• High pass filter (150 Hz)
• High frequency boost (+6dB)
• Three position level control (-10dB, 0dB, +20dB)
• Headphone monitor output
• 1/8’’ audio output to camera
• LED power on/low battery indicator
• Pop shield included
• Lightweight all-metal construction
• Powered by two AA batteries
1.3 Product Structure
LED indicator
Three position level control (-10dB, 0dB, +20dB)
Power button
High-pass filter (150Hz)
High frequency boost (+6dB)
1
2
3
4
5
1
2
3
4
5
6
7
9
10
3
2
Vmic Stereo
Stereo Cardioid Condenser Microphone for DSLR Cameras and
Camcorders
3
Type Condenser Microphone
Polar Pattern Stereo Cardioid
Frequency Response 35HZ---20KHZ
Sensitivity -37±3dB(0dB=1V/Pa,at 1kHZ)
Signal to Noise Ratio 75dB or more
Output Impedance 600hm or less
Power Two AA batteries
Plug Mini-pin plug (3.5mm)
Filter High-pass filter (150Hz)
Dimensions(LxHxD) 116 x 90 x 171 mm
Net Weight 244g (8.6oz.)
Frequency Response
Vmic Stereo
Stereo Cardioid Condenser Microphone for DSLR Cameras and
Camcorders
www.saramonic.com
The Saramonic logo is trademark which is registered
and owned by Saramonic International.
COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL
A brand of DSQN
Email: [email protected]
2.2 Attach the Vmic Stereo to the hot shoe of your camera or
camcorder. Connect the supplied audio transmission cable from
the audio output of Vmic Stereo to the MIC input of the camera
or camcorder.
2.3 Turn on the Vmic Stereo, the LED indicator will turn green.
When the battery power is low, the LED indicator will turn red.
2.4 Adjust the level control according to your needs.
The -10dB level: Ideal for recording loud sound sources, such as
live music, motorsport, or interviews where the subject is very
close to the camera.
The +20dB level boost: For use with DSLR cameras, allowing the
user to reduce the camera's preamp level (or mic-input level).
Effectively reducing the amount of noise generated by the camera's
comparatively low quality audio circuitry.
2.5 Plug a headphone to the headphone output of the Vmic Stereo,
to monitor the audio.
We suggest you could do a test recording and playback the audio
to see if it is acceptable.
3. Specifications
