SATO M8485S Bedienungsanleitung

M8485S

Parts List

Please note that this list is divided into two sections. Use the second section

(pages 30-56) if your printer S/N is between 50100000 and 70699999.

For all other serial numbers please use the first section (pages 3-29)

P/N 9001033 REV. D

M8485S

Parts List

(Use this section for all serial numbers other then 50100000 to 70699999)

Sato America, Inc.

10350-A Nations Ford Rd.

Charlotte, NC 28273

Phone (704) 644-1650

Fax (704) 644-1662

P/N 9001033 REV. D

M8485S

Description Page #

Frame Assembly 4-8

Thermal Head Assembly 9-12

Ribbon Assembly 13-17

Feed Roller Assembly 18-21

Pressure Roller Assembly 22-23

Cover Assembly 24-26

Main PCB Assembly 27-27

Check PCB Assembly 28-28

Memory PCB Assembly 29-29

(Option)

M8485S

FRAME ASSEMBLY

ITEM # PART NUMBER DESCRIPTION QTY

1PL1730700 Engine frame 1

2PT2108006 Dry metal 1

3PB0540101 Guide post 1

4MC0401022 Pan head screw 1

5PR1730500 Stay 1

6MC0401222 Pan head screw 2

7PA3732500 Spring bracket 1

8MC0300622 Pan head screw 1

9PB0731500 Shaft (support) 1

10 MC0401022 Pan head screw 2

11 PB0732800 Shaft (ribbon adjust) 1

12 PR1730300 Roller 1

13 PA3736200 Dispense bar bracket 1

14 MN0300824 Hex bolt 1

15 PD1731300 Dispense bar 1

16 MN0300624 Hex bolt 1

19 PB0733500 Shaft (holder) 1

20 NB0040022 Wave washer 2

21 PA4730500 Plate spring 2

22 PL1730800 Platen frame 2

23 PR0730100 Platen roller 2

24 PB2730100 Collar 2

25 MJ1300424 W-point screw 2

26 PT1112060 Ball supporter 2

27 PT1109050 Ball supporter 2

28 PA3736301 Supporter clamp 1

29 MN0400824 Hex bolt 2

31 PB0730500 Post (latch) 1

32 PB2740100 Collar 1

33 PE3720300 Roller 1

34 MD4301222 Pan head screw 1

35 PA3736400 Latch handle (holder) 1

36 PB0733400 Shaft (latch handle) 1

37 PC3730101 Spring 1

38 PE1730700 Handle (C) 1

39 NG2201030 Pin 1

40 ND0030030 E-snap ring 2

43 MN0402524 Hex bolt 2

M8485S

FRAME ASSEMBLY

ITEM # PART NUMBER DESCRIPTION QTY

44 MN0402024 Hex bolt 1

45 MN0401024 Hex bolt 1

46 PE8730200 Pulley 2

47 ND0040030 E-snap ring 2

49 PA3734800 Pulley bracket 1

50 PA2730700 Plate nut 1

51 PB0731600 Shaft (roller) 1

52 PR1730600 Tension roller 1

53 ND0040030 E-snap ring 1

54 MD4402022 Pan head screw 2

55 PT8190064 Timing belt 1

56 PL1720100 Motor pulley 1

57 MJ1400524 W-point screw 2

58 RH1730600 Stepper motor assy. 1

59 MC0401222 Pan head screw 2

61 PB0731701 Shaft 1

62 PE8730100 Gear 1

63 PE8730300 Pulley 1

64 PT1112060 Ball supporter 2

65 ND0040030 E-snap ring 1

66 PT8150064 Timing belt 1

67 PA1730500 Shaft bracket 1

68 MC0401022 Pan head screw 2

70 PA1730700 Tension bracket 1

71 PB0730600 Post (tension) 1

72 MD4400822 Pan head screw 1

73 PR1730600 Tension roller 1

74 ND0040030 E-snap ring 1

75 MD4300822 pan head screw 2

78 PR4730501 Key board cover 1

79 MD4301222 Pan head screw 4

80 RJ2730200 Key board PCB 1

82 MH0300821 P-tight screw 4

83 RH1731300 PSW cable 1

85 RJ2730100 DSW PCB set 1

86 MD3300822 Pan head screw 2

87 PH0730200 DSW cover 1

88 RH1731600 DSW cable set 1

M8485S

FRAME ASSEMBLY

M8485S

FRAME ASSEMBLY

M8485S

FRAME ASSEMBLY

M8485S

THERMAL HEAD ASSEMBLY

ITEM # PART NUMBER DESCRIPTION QTY

1RH1731100 SEN 5 Cable 1

2MD3201221 Pan head screw 1

4PR1730700 Pressure cam 1

5ND0060030 E-snap ring 3

7PR0730200 Feed roller 1

8PT1112060 Ball supporter 1

9PT1109050 Ball supporter 1

10 PE8730100 Gear 1

11 ND0040030 E-snap ring 1

14 PA2730200 Head frame 1

15 MC0401022 Pan head screw 3

16 PA1730300 Plate (adjust) 1

17 PL2720100 Adjust collar 1

18 MD4300822 Pan head screw 1

19 MC0401022 Pan head screw 1

20 PL2730100 Adjust collar 1

21 MD4401022 Pan head screw 1

23 PE1730400 Handle (B) 1

24 PD1730600 Handle (A) 1

25 PA2730600 Latch handle (C) 1

26 PD1731200 Handle (B) 1

27 MD4301022 Pan head screw 2

28 MJ1300424 W-point screw 2

31 PA3732300 Head bracket 1

32 PV9730200 Bushing 1

33 PB0731400 Shaft (adjust cam) 1

34 PE1730300 Adjust cam 2

35 ND0050030 E-snap ring 2

36 PC1730200 Spring (head) 2

37 PR4731100 Head bracket 1

38 PR1730200 Adjust plate (head) 1

39 MD4300622 Pan head screw 2

40 PB0731100 Shaft (head bracket) 1

41 ND0070030 E-snap ring 2

42 PA3732100 Ribbon plate 1

43 MD3250522 Pan head screw 2

44 PA4730401 Plate spring (head cam) 1

45 PC0730200 Spring (head open) 1

M8485S

THERMAL HEAD ASSEMBLY

ITEM # PART NUMBER DESCRIPTION QTY

47 GH000441A Print Head Assy 1

48 RH1731200 HDS cable 1

49 RH1732200 HDP cable 1

51 PB5730300 Screw (head) 1

52 MC0401022 Pan head screw 2
