Schumacher Electric SL1441 Bedienungsanleitung

0099002273E-00

Jump Starter/

Power Pack

Arrancador /

Pack de energía

Aide de Démarrage /

Bloc d’alimentation

OWNER’S MANUAL / MANUAL DEL USUARIO

MANUEL D’UTILISATION

PLEASE SAVE THIS OWNER’S MANUAL AND READ BEFORE

EACH USE. This manual will explain how to use the unit safely

and effectively. Please read and follow these instructions and

precautions carefully.

POR FAVOR GUARDE ESTE MANUAL DEL PROPIETARIO Y

LEER ANTES DE CADA USO. En este manual se explica cómo

utilizar la unidad segura y efectiva. Por favor, lea y siga las siguientes

instrucciones y precauciones.

ESSAYER DE GARDER LE MANUEL D’INSTRUCTIONS ET LE

LIRE AVANT CHAQUE UTILISATION. Ce manuel explique comment

utiliser l’unité d’une façon sûre et efcace. S’il vous plaît lisez et suivez

ces instructions et précautions.

MODEL / MODELO / MODÈLE

SL1441

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS ...................................................... 5

PERSONAL PRECAUTIONS......................................................................... 6

PREPARING TO USE THE UNIT .................................................................. 7

FOLLOW THESE STEPS WHEN CONNECTING TO A BATTERY.............. 7

FEATURES..................................................................................................... 8

CHARGING THE JUMP STARTER ............................................................... 8

OPERATING INSTRUCTIONS ...................................................................... 9

MAINTENANCE INSTRUCTIONS................................................................11

STORAGE INSTRUCTIONS.........................................................................11

TROUBLESHOOTING ..................................................................................11

SPECIFICATIONS........................................................................................ 12

REPLACEMENT PARTS.............................................................................. 12

BEFORE RETURNING FOR REPAIRS....................................................... 12

LIMITED WARRANTY.................................................................................. 12

CONTENIDOS

INSTRUCCIONES IMPORTANTES DE SEGURIDAD ............................... 13

PRECAUCIONES DE SEGURIDAD PERSONAL....................................... 14

PREPARACIÓN PARA EL USO................................................................... 15

SIGA ESTOS PASOS CUANDO SE CONECTE A LA BATERÍA................ 15

CARACTERÍSTICAS.................................................................................... 16

CARGAR EL ARRANCADOR...................................................................... 16

INSTRUCCIONES DE OPERACIÓN........................................................... 17

INSTRUCCIONES DE MANTENIMIENTO.................................................. 19

INSTRUCCIONES DE ALMACENAMIENTO .............................................. 19

RESOLUCIÓN DE PROBLEMAS................................................................ 19

ESPECIFICACIONES .................................................................................. 21

REPUESTOS................................................................................................ 21

ANTES DE DEVOLVER A REPARACIONES.............................................. 21

GARANTÍA LIMITADA.................................................................................. 21

TABLE DES MATIÈRES

CONSIGNES DE SÉCURITÉ IMPORTANTES ........................................... 22

MESURES DE SÉCURITÉ PERSONNELLE.............................................. 23

PRÉPARATION UTILISER L’APPAREIL...................................................... 24

SUIVEZ CES ÉTAPES LORSQUE CONNEXION À UNE BATTERIE........ 24

CARACTÉRISTIQUES................................................................................. 25

CHARGE LE DÉMARREUR........................................................................ 26

CONSIGNES D’UTILISATION ..................................................................... 26

CONSIGNES D’ENTRETIEN....................................................................... 28

INSTRUCTIONS DE STOCKAGE ............................................................... 28

TABLEAU DE DÉPANNAGE........................................................................ 29

SPÉCIFICATIONS........................................................................................ 30

PIÈCES DE RECHANGE............................................................................. 30

AVANT DE RETOURNER POUR LES RÉPARATIONS.............................. 30

GARANTIE LIMITÉE.................................................................................... 30

• 5 •

1. IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS.

WARNING – RISK OF EXPLOSIVE GASES.

WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS

DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES

DURING NORMAL OPERATION. IT IS IMPORTANT THAT YOU

FOLLOW THESE INSTRUCTIONS EACH TIME YOU USE THE UNIT.

To reduce the risk of battery explosion, follow these instructions and

those published by the battery manufacturer and the manufacturer

of any equipment you intend to use in the vicinity of a battery.

Review cautionary markings on these products and on the engine.

WARNING! RISK OF ELECTRIC SHOCK OR FIRE.

1.1 Read the entire manual before using this product. Failure to do so

could result in serious injury or death.

1.2 Keep out of reach of children.

1.3 Do not put ngers or hands into any of the unit’s outlets.

1.4 Do not expose the unit to rain or snow.

1.5 Use only recommended attachments (SA900 jump cable). Use of an

attachment not recommended or sold by the jump starter manufacturer

for the unit may result in a risk of re, electric shock or injury to persons

or damage to property.

1.6 To reduce the risk of damage to the electric plug or cord, pull by the

adaptor rather than the cord when disconnecting the unit.

1.7 Do not operate the unit with damaged cables or clamps.

1.8 Do not operate the unit if it has received a sharp blow, been dropped or

otherwise damaged in any way; take it to a qualied service person.

1.9 Do not disassemble the unit; take it to a qualied service person when

service or repair is required. Incorrect reassembly may result in a risk of

re or electric shock.

WARNING! RISK OF EXPLOSIVE GASES.

1.10 To reduce the risk of a battery explosion, follow these instructions and

those published by the battery manufacturer and the manufacturer of

any equipment you intend to use in the vicinity of the battery. Review

the cautionary markings on these products and on the engine.

1.11 Do not set the unit on ammable materials, such as carpeting,

upholstery, paper, cardboard, etc.

1.12 Never place the unit directly above battery being jumped.

1.13 Do not use the unit to jump start a vehicle while charging the internal battery.

Jump Starter/Power Pack

OWNER’S MANUAL

PLEASE SAVE THIS OWNERS MANUAL AND READ BEFORE EACH

USE. This manual will explain how to use the unit safely and effectively.

Please read and follow these instructions and precautions carefully.

MODEL

SL1441

• 6 •

2. PERSONAL PRECAUTIONS

WARNING! RISK OF EXPLOSIVE GASES. A SPARK NEAR THE

BATTERY MAY CAUSE A BATTERY EXPLOSION. TO REDUCE THE

RISK OF A SPARK NEAR THE BATTERY:

2.1 NEVER smoke or allow a spark or ame in the vicinity of a battery or engine.

2.2 Remove personal metal items such as rings, bracelets, necklaces and

watches when working with a lead-acid battery. A lead-acid battery

can produce a short-circuit current high enough to weld a ring to

metal, causing a severe burn.

2.3 Be extra cautious, to reduce the risk of dropping a metal tool onto the

battery. It might spark or short-circuit the battery or other electrical

part that may cause an explosion.

2.4 Do not permit the internal battery of the unit to freeze. Never charge a

frozen battery.

2.5 To prevent sparking, NEVER allow clamps to touch together or

contact the same piece of metal.

2.6 Consider having someone nearby to come to your aid when you work

near a lead-acid battery.

2.7 Have plenty of fresh water, soap and baking soda nearby for use, in

case battery acid contacts your eyes, skin, or clothing.

2.8 Wear complete eye and body protection, including safety goggles and

protective clothing. Avoid touching your eyes while working near the

battery.

2.9 If battery acid contacts your skin or clothing, immediately wash

the area with soap and water. If acid enters your eye, immediately

ood the eye with cold running water for at least 10 minutes and get

medical attention right away.

2.10 If battery acid is accidentally swallowed, drink milk, the whites of eggs

or water. DO NOT induce vomiting. Seek medical attention immediately.

2.11 Neutralize any acid spills thoroughly with baking soda before attempting

to clean up.

2.12 This product contains a lithium ion battery. In case of re, you

may use water, a foam extinguisher, Halon, CO2, ABC dry chemical,

powdered graphite, copper powder or soda (sodium carbonate)

to extinguish the re. Once the re is extinguished, douse the

product with water, an aqueous-based extinguishing agent, or other

nonalcoholic liquids to cool the product and prevent the battery from

re-igniting. NEVER attempt to pick up or move a hot, smoking, or

burning product, as you may be injured.

• 7 •

3. PREPARING TO USE THE UNIT

WARNING! RISK OF CONTACT WITH BATTERY ACID. BATTERY

ACID IS A HIGHLY CORROSIVE SULFURIC ACID.

3.1 Make sure the area around the battery is well ventilated while the unit

is in use.

3.2 Clean the battery terminals before using the jump starter. During

cleaning, keep airborne corrosion from coming into contact with your

eyes, nose and mouth. Use baking soda and water to neutralize the

battery acid and help eliminate airborne corrosion. Do not touch your

eyes, nose or mouth.

3.3 Determine the voltage of the battery by referring to the vehicle

owner’s manual and make sure that the output voltage is 12V.

3.4 Make sure that the unit’s cable clamps make tight connections.

4. FOLLOW THESE STEPS WHEN CONNECTING TO A BATTERY

WARNING! A SPARK NEAR THE BATTERY MAY CAUSE A BATTERY

EXPLOSION. TO REDUCE THE RISK OF A SPARK NEAR THE BATTERY:

4.1 Plug the clamps into the unit, and then attach the output cables to

the battery and chassis as indicated below. Never allow the output

clamps to touch each other.

4.2 Position the DC cables to reduce the risk of damage by the hood,

door and moving or hot engine parts. NOTE: If it is necessary to close

the hood during the jump starting process, ensure that the hood does

not touch the metal part of the battery clips or cut the insulation of the

cables.

4.3 Stay clear of fan blades, belts, pulleys and other parts that can cause injury.

4.4 Check the polarity of the battery posts. The POSITIVE (POS, P, +)

battery post usually has a larger diameter than the NEGATIVE (NEG,

N, -) post.

4.5 Determine which post of the battery is grounded (connected) to the

chassis. If the negative post is grounded to the chassis (as in most

vehicles), see step 4.6. If the positive post is grounded to the chassis,

see step 4.7.

4.6 For a negative-grounded vehicle, connect the POSITIVE (RED) clamp

from the jump starter to the POSITIVE (POS, P, +) ungrounded post

of the battery. Connect the NEGATIVE (BLACK) clamp to the vehicle

chassis or engine block away from the battery. Do not connect the

clamp to the carburetor, fuel lines or sheet-metal body parts. Connect

to a heavy gauge metal part of the frame or engine block.

4.7 For a positive-grounded vehicle, connect the NEGATIVE (BLACK)

clamp from the jump starter to the NEGATIVE (NEG, N, -) ungrounded

post of the battery. Connect the POSITIVE (RED) clamp to the vehicle

chassis or engine block away from the battery. Do not connect the

clamp to the carburetor, fuel lines or sheet-metal body parts. Connect to

a heavy gauge metal part of the frame or engine block.

4.8 When nished using the jump starter, remove the clamp from the

vehicle chassis and then remove the clamp from the battery terminal.

Disconnect the clamps from the unit.

• 8 •

5. FEATURES

1. Display button

2. LCD display

3. Jump start output socket

4. LED light

5. USB input port

for recharging

6. 2.4A USB output port

7. 3A USB output port

8. Battery clamps/

smart cable

Not shown:

9. USB charging cable

10. Carrying bag

6. CHARGING THE JUMP STARTER

IMPORTANT! CHARGE IMMEDIATELY AFTER PURCHASE,

AFTER EACH USE AND EVERY 30 DAYS, OR WHEN THE

CHARGE LEVEL FALLS BELOW 85%, TO KEEP THE INTERNAL

BATTERY FULLY CHARGED AND PROLONG BATTERY LIFE.

6.1 CHECKING THE LEVEL OF THE INTERNAL BATTERY

1. Press the display button. The LCD display will show the battery’s

percentage of charge. A fully charged internal battery will read 100%.

Charge the internal battery if the display shows it is under 85%.

2. To reduce the risk of electric shock, unplug the unit’s charging cable from

a USB or wall charger before attempting any maintenance or cleaning.

Simply turning off the controls will not reduce this risk.

3. When charging the internal battery, work in a well ventilated area and do

not restrict the ventilation in any way.

• 9 •

6.2 CHARGING THE INTERNAL BATTERY

Use a 2A USB charger (not included), to quickly recharge the

jump starter.

1. Plug the

USB end of the charging cable into the charger port. Next,

plug the USB end of the charging cable into a charger’s USB port.

2. Plug your charger into a live AC or DC power outlet.

3. The LCD display will light, the digit begins to ash and show “IN”, indicating

that charging has begun.

4. The jump starter will fully charge in 4-5 hours. When the unit is fully

charged, the display will show “100%”.

5. When the battery is fully charged, disconnect your charger from the outlet,

and then remove the charging cable from the charger and the unit.

7. OPERATING INSTRUCTIONS

7.1 JUMP STARTING A VEHICLE ENGINE

NOTE: Use only model number SA900 jump cable.

IMPORTANT: Do not use the jump starter while charging its internal battery.

IMPORTANT: Using the jump starter without a battery installed in the

vehicle will damage the vehicle’s electrical system.

NOTE: The internal battery must have a charge if at least 40% to

jump start a vehicle.

1. Turn the ignition OFF.

2. Plug the battery clamp cable into the jump starter’s output socket.

3. Lay the DC cables away from any fan blades, belts, pulleys and other

moving parts. Make sure all of the vehicle’s electrical devices are turned off.

4. For a negative-grounded vehicle, connect the POSITIVE (RED) clamp

from the jump starter to the POSITIVE (POS, P, +) ungrounded post

of the battery. Connect the NEGATIVE (BLACK) clamp to the vehicle

chassis or engine block away from the battery. Do not connect the

clamp to the carburetor, fuel lines or sheet-metal body parts. Connect

to a heavy gauge metal part of the frame or engine block.

5. For a positive-grounded vehicle, connect the NEGATIVE (BLACK)

clamp from the jump starter to the NEGATIVE (NEG, N, -) ungrounded

post of the battery. Connect the POSITIVE (RED) clamp to the vehicle

chassis or engine block away from the battery. Do not connect the

clamp to the carburetor, fuel lines or sheet-metal body parts. Connect to

a heavy gauge metal part of the frame or engine block.

6. The green LED on the smart cable should light.

NOTE: If the vehicle battery is extremely discharged, the initial current

draw from the jump starter may activate short circuit protection in the

smart cable. When the condition is corrected, the smart cable will

automatically reset.

7. After a proper connection has been made, crank the engine. If the engine

does not start within 5-8 seconds, stop cranking and wait at least 1 minute

before attempting to start the vehicle again.

NOTE: If the car does not crank a second time, check the smart cable to

see if the green LED is lit. If you hear beeping or an LED is ashing, refer

to section 10, Troubleshooting. When the condition is corrected, the

smart cable will automatically reset.

• 10 •

NOTE: Cold weather may affect the performance of the jump starter’s

lithium battery. If you hear only a click and the engine does not turn

over, try the following:

With the jump starter connected to the car battery and the green LED

illuminated on the smart cable, turn on all lights and electrical accessories

for one minute. This draws current from the jump starter and warms the

battery. Now try to crank the engine. If it does not turn over, repeat the

procedure. Extremely cold weather may require two or three battery

warmings before the engine will start.

NOTE: If no activity is detected, the smart cable will automatically shut

off after 90 seconds, and the red and green LEDs will be solid. To reset,

disconnect the clamps from the vehicle battery, and then reconnect.

IMPORTANT: DO NOT attempt to jump start your vehicle more

than three consecutive times. If the vehicle will not start after three

attempts, consult a service technician.

8. After the engine starts, unplug the battery clamps from the jump starter

socket and then disconnect the black clamp (-) and the red clamp (+),

in that order.

9. Recharge the unit as soon as possible after each use.

7.2 CHARGING A MOBILE DEVICE, USING THE USB PORTS

The unit includes two USB ports. One provides up to 2.4A at 5V DC;

the other is a USB Fast Charging port, which provides up to 5V at 3A,

9V at 2A or 12V at 1.5A.

1. Consult your mobile device manufacturer for proper charging power

specications. Connect a mobile device cable to the appropriate USB port.

2. Charging should begin automatically. The display will show which port

is in use.

3. Charging time will vary, based on the mobile device’s battery size and the

charging port used.

NOTE:

Most devices will charge with either USB port, but may charge

at a slower rate.

4. When nished using the USB port, disconnect the charging cable from

your mobile device and then disconnect the charging cable from the unit.

5. Recharge the unit as soon as possible after each use.

NOTE:

If no USB device is connected, power to the USB ports will

automatically shut off after 30 seconds.

7.3 USING THE LED LIGHT

1. Hold down the display button for 2 seconds.

2. Once the LED light is on, press and release the display button to cycle

through the following modes:

• Steady glow

• Flash for an SOS signal

• Flash in strobe mode

3. When nished using the LED light, press and hold the display button

until the light turns off.

4. Recharge the unit as soon as possible after each use.

Inhaltsverzeichnis

Sprachen:

Andere Schumacher Electric Fernstartsystem Handbücher

Schumacher Electric

Schumacher Electric SL1327 Bedienungsanleitung

Schumacher Electric

Schumacher Electric SL1314 Bedienungsanleitung

Schumacher Electric

Schumacher Electric SL1314 Bedienungsanleitung

Schumacher Electric

Schumacher Electric BE01258 Bedienungsanleitung

Schumacher Electric

Schumacher Electric DSR119 Bedienungsanleitung

Schumacher Electric

Schumacher Electric BE01253 Bedienungsanleitung

Schumacher Electric

Schumacher Electric INSTANT POWER IP-1875C Bedienungsanleitung

Schumacher Electric

Schumacher Electric INSTANT POWER XP400 Bedienungsanleitung

Schumacher Electric

Schumacher Electric BE01255 Bedienungsanleitung

Schumacher Electric

Schumacher Electric SL1464 Bedienungsanleitung

Schumacher Electric

Schumacher Electric FARM & RANCH FR01241 Bedienungsanleitung

Schumacher Electric

Schumacher Electric PSJ-1812 Bedienungsanleitung

Schumacher Electric

Schumacher Electric SL1474 Bedienungsanleitung

Schumacher Electric

Schumacher Electric SL1519 Bedienungsanleitung

Schumacher Electric

Schumacher Electric XJS22 INSTANT POWER Bedienungsanleitung

Schumacher Electric

Schumacher Electric SL1517 Bedienungsanleitung

Schumacher Electric

Schumacher Electric INSTANT POWER XPF2260 Bedienungsanleitung

Schumacher Electric

Schumacher Electric INSTANT POWER XP400 Bedienungsanleitung

Schumacher Electric

Schumacher Electric INSTANT POWER IP-1850FL Bedienungsanleitung

Schumacher Electric

Schumacher Electric INSTANT POWER XP400W Bedienungsanleitung

Schumacher Electric

Schumacher Electric DSR142 Bedienungsanleitung

Schumacher Electric

Schumacher Electric INSTANT POWER XP400 Bedienungsanleitung

Schumacher Electric

Schumacher Electric DSR116 Bedienungsanleitung

Schumacher Electric

Schumacher Electric SL1435 Bedienungsanleitung

Beliebte Fernstartsystem Handbücher anderer Marken

AstroStart

AstroStart 803U Bedienungsanleitung

Durite

Durite 0-649-20 Handbuch

EINHELL

EINHELL BT-PS 1000 Handbuch

Linear

Linear ACCESS AK-21 Technische Daten

Soundstream

Soundstream TARANTULA RS.2 Bedienungsanleitung

Jaycar Electronics

Jaycar Electronics MB3752 Bedienungsanleitung

Ultra Start

Ultra Start 72 Series Bedienungsanleitung

ADS

ADS FLASHLOGIC FLRSVW1 Bedienungsanleitung

Selecta

Selecta JS012 Bedienungsanleitung

Black Widow Security

Black Widow Security BW RAS 400 Bedienungsanleitung

Vector

Vector Power City DK080706 Beilage

Code Alarm

Code Alarm CA-535 Bedienungsanleitung

Ozito

Ozito OJS-800 Bedienungsanleitung

Profi-Partner

Profi-Partner 46387 Bedienungsanleitung

EZ STARTER

EZ STARTER EZ-45 Bedienungsanleitung

Viper

Viper 4204 Bedienungsanleitung

Essex Electronics

Essex Electronics KE-1701 Bedienungsanleitung

EINHELL

EINHELL EGS 3600 Handbuch
