CS0415 – 50 lb Cube Ice Machine

Scotsman Ice Systems

775 Corporate Woods Parkway

Vernon Hills, IL 60061

1-800-SCOTSMAN

Fax: 847-913-9844

E-mail: customer.service@scotsman-ice.com

www.scotsman-ice.com

Features

Self-Contained Under Counter Cuber with Storage

Designed with a

unique inside door

flap to prevent spillage

and maximize storage.

Warranty

• 1 years parts and labor on all components.

Warranty valid in North, South & Central America.

Contact factory for warranty in other regions.

24 Hour Volume Production

Cube Ice

Produces up to 49 lb of small cube ice in 24 hours and stores up to 26 lb of ice.

Compact design allows for placement in tight locations.

15” cabinet width.

Ideal for any under counter bar application.

Unique door flap prevents spillage and maximizes storage.

Produces clear, cube shape ice which is ideal for

mixed drinks and carbonated beverages.

Air Cooled

70˚F/21˚C

50˚F/10˚C

lb/kg

Air

Water

ARI

90˚F/32˚C

70˚F/21˚C

lb/kg

49/22 44/20

Small Cube

¾” x ¾” x ⁄”

(2 x 2 x .95 cm)

Common ice

form, ideal for

mixed drinks.

PRELIMINARY

CS0415 – 50 lb Cube Ice Machine

Scotsman Ice Systems

775 Corporate Woods Parkway

Vernon Hills, IL 60061

1-800-SCOTSMAN

Fax: 847-913-9844

E-mail: customer.service@scotsman-ice.com

www.scotsman-ice.com

The Smart Choice in Ice.

SIS-SS-CU-CS0415 7-07

Specifications

Operating Requirements

All Models

Dimensions (W x D x H):

Unit:

14.9” x 21.9” x 34”

(37.8 x 55.6 x 86.4 cm)

Shipping Carton:

17.375” x 28.5” x 36.375”

(44.1 x 72.4 x 92.4 cm)

Shipping Weight:

CS0415A-1A 101 lb / 46 kg

CS0415PA-1A 107 lb / 49 kg

BTUs per hour:

N/A

Accessories

* Scotsman recommends all ice machines have water filtration. See Scotsman Sanitation Matrix for details.

Model Number

Condenser

Unit

Storage

Capacity

lb/kg

Basic Electrical

Volts/Hz/

Phase

Max. Fuse Size

or HACR Circuit

Breaker (amps)

Circuit

Wires

Min. Circuit

Ampacity

Energy Consumption

kWh/100 lb (45.4 kg)

90˚F(32˚C)/70˚F(21˚C)

Potable

90˚F(32˚C)/

70˚F(21˚C)

Condenser

90˚F(32˚C)/

70˚F(21˚C)

CS0415A-1A Air 25/11 115/60/1 15 2 Cord 16.7 48/12.7 -

CS0415PA-1A Air 25/11 115/60/1 15 2 Cord 16.7 48/12.7 -

Water Usage

Gallons/100 lb (liters/45.4 kg)

Model Number Description

KCSWFILL Filler kit for installing icemaker in 18” opening.

KCSWTRIM Trim kit for putting wood cabinet front on icemaker door.

Minimum Maximum

Air Temperatures 50°F (10°C) 100°F (38°C)

Water Temperatures 40°F (4.4°C) 100°F (38°C)

Remote Cond. Temps -20°F (-29°C) 120°F (49°C)

Water Pressures 20 PSIG (1.4 bar) 80 PSIG (5.5 bar)

Electrical Voltage -10% +10%

Finish: White, high gloss baked enamel steel.

CS0415PA-1A comes with a pump drain instead of a gravity drain. Maximum vertical pumping height 10’.

Refrigerant - R134a.

Installation Note: Allow 6”space at back for utility connections.
