Scotsman MAR1400RL-32A Bedienungsanleitung

Suggested List Price Schedule

MAR Industrial Flake Ice Machines

Scotsman Ice Systems

775 Corporate Woods Parkway

Vernon Hills, IL 60061

1-800-SCOTSMAN

Fax: 847-913-9844

E-mail: customer.service@scotsman-ice.com

www.scotsman-ice.com

Bin: BH Series

Warranty

• 10 year parts on Drum

• 10 year parts on Evaporator Seals

• 3 year parts and labor on the entire machine

• Remote High Side Condenser Warranty is

1 year parts

Features

Eective August 1, 2008

Flake Ice

Model MAR2000

• 1,400 to 2,000 lb. of ake ice per day

• Heavy duty construction

• Outstanding reliability–only one moving part

• Stainless steel nish

24 Hour Volume Production

MAR1400RL-32A MAR2000RL-32A

1430/649 1260/572 1980/898 1700/771

70˚F/21˚C Air 90˚F/32˚C

50˚F/10˚C Water 70˚F/21˚C

lb/kg lb/kg

70˚F/21˚C Air 90˚F/32˚C

50˚F/10˚C Water 70˚F/21˚C

lb/kg lb/kg

Scotsman

™

Dry, sub-cooled,

ake ice. Ideal for

seafood and

produce displays.

MAR Industrial Flake Ice Machines

Scotsman Ice Systems

775 Corporate Woods Parkway

Vernon Hills, IL 60061

1-800-SCOTSMAN

Fax: 847-913-9844

E-mail: customer.service@scotsman-ice.com

www.scotsman-ice.com

Specications

Remote High Side Package for RL

Bin Tops (Special bin tops are required for large BH series bins)

Extended Compressor Warranty for RHS

Model Number

Basic Electrical

Volts/Hz/Phase

Dimensions

(W” x D” x H”)

Ship Weight

lb/kg

List Price

Stainless

List Price

Stainless

Operating Requirements

Air Temperatures

Water Temperatures

Remote Cond. Temps

Water Pressures

Electrical Voltage

50°F (10°C)

40°F (4.4°C)

-20°F (-29°C)

20 PSIG (1.0 bar)

-10%

Minimum Maximum

100°F (38°C)

120°F (49°C)

120 PSIG (5.2 bar)

+10%

The Smart Choice in Ice.

MAR1400RL-32A 34.5 x 24.5 x 20.4 208-230/60/1 114/52 $13,308

MAR2000RL-32A 34.5 x 24.5 x 20.4 208-230/60/1 114/52 $16,910

KBT58 SS top for use on BH1100 80/36 $1,302

KBT59 SS top for use on BH1300 and BH1600 80/36 $1,424

Option Model Number

Model RHS-AC RHS-WC

5 year MAR1400-RHS A/C & W/C COMPWARMAR1400 $500 $536

Compressor MAR2000-RHS A/C & W/C COMPWARMAR2000 $535 $572

Warranty

Model Number Description

Ship Weight

lb/kg

List Price

Stainless

Model Number

Basic Electrical

Volts/Hz/Phase

Dimensions

(W” x D” x H”) AMPS MCA MOPD

Ship Weight

lb/kg

MAR1400-RHS-A/C 43.38 x 30.25 x 29.75 19.2 28 45 208-230/60/3 334/152 $8,123

MAR2000-RHS-A/C 43.38 x 30.25 x 29.75 21.5 30 50 208-230/60/3 334/152 $8,543

MAR1400-RHS-W/C 27 x 22 x 28 19.2 24 40 208-230/60/3 221/100 $9,721

MAR2000-RHS-W/C 27 x 22 x 28 21.5 27 45 208-230/60/3 221/100 $10,503

Extended warranty for the compressor gives you an additional 4 years on the compressor parts only.

All machines come equipped with a chute.
