Scott PATRON MY22 Bedienungsanleitung
PATRON MY22
MANUAL
2ENGLISH / PATRON TECH MANUAL
Technical Data:
Seatpost: 31.6 mm
Seatpost Clamp: 34.9 mm
Travel: 160 mm F & R
Shock Length: 205 mm E2E
Shock Stroke: 60 mm
Hardware M/Frame: Trunnion
Hardware Linkage: 17 x 10 mm
Chainring Max: 38 T
Chain Line: 52 mm
Tyre Width Max: 2.6”
Max / Min Rotor: 203 Only
(no special mount)
Tyre sizes often vary from brand
to brand. Always ensure the frame,
linkage & swingarm tyre clearance
is adequate when replacing the
rear tyre.
For the full installation of the motor,
wiring, and frame parts please only take
your bike to an Authorised Scott Dealer
for assistance.
3
ENGLISH / PATRON TECH MANUAL
MY22 Patron eRIDE
Small Medium Large X/Large
A HEAD TUBE ANGLE 64.5° 65° 65° 65°
B HEAD TUBE LENGTH 120 mm 125 mm 135 mm 145 mm
C TOP TUBE HORIZONTAL 579.4 mm 595 mm 625.6 mm 656.4 mm
D STANDOVER HEIGHT 766 mm 766 mm 766 mm 766 mm
E BB OFFSET -30.0 mm -30.0 mm -30.0 mm -30.0 mm
F BB HEIGHT 347 mm 347 mm 347 mm 347 mm
G WHEEL BASE 1221.7 mm 1231.7 mm 1263.7 mm 1295.4 mm
I BB CENTER TO TOP OF SEATTUBE 410.5 mm 440.5 mm 470.4 mm 500.4 mm
J SEAT ANGLE 77° 76.9° 76.9° 76.8°
K CHAINSTAY 454.0 mm 454.0 mm 454.0 mm 454.0 mm
L REACH 432.7 mm 445.8 mm 473.6 mm 501.2 mm
MSTACK 634.8 mm 642.2 mm 651.3 mm 660.4 mm
N STEM LENGTH 50 mm 50 mm 60 mm 60 mm
P FORK LENGTH 567.1 mm 567.1 mm 567.1 mm 567.1 mm
Q MAX POST INSERTION 245 mm 265 mm 300 mm 320 mm
CRANK LENGTH 165 mm 165 mm 165 mm 165 mm
TRAIL 133.3 mm 129.5 mm 129.5 mm 129.5 mm
Geometry:
N
Q
P
4ENGLISH / PATRON TECH MANUAL
EASY TECHNICAL STEP
IMPORTANT TECHNICAL STEP
(Take your time, get it right)
WARNING/CAUTION
THREADLOC
NO GREASE
WITH GREASE
BEARING FIT
TORQUE CHECK
PLEASE TAKE NOTE OF THE BELOW
ICONS THROUGHOUT THIS MANUAL
FOR SAFE PRACTISE
5
ENGLISH / PATRON TECH MANUAL
Hangers & Axles:
Fenders & Carriers:
The Patron can be equipped with a kickstand, rear fender and rear rack.
265597 SYN Kickstand Fully E-MTB 2 bolts
288545 SCO Rear rack AXIS eRide Evo SnapIt 2.0
280312 SCO Rear fender stays Strike/AXIS ER Evo
280311 SCO Rear fender Strike /AXIS E-Ride Evo
(front fender not possible to mount to fork arch)
The Patron has only one rear hanger, this is the SRAM UDH.
This is available from your SRAM supplier, it is only available via Scott if you do not
have a supplier in your region.
286000 - SCO Dropout Sram UDH 21
The UDH must be assembled without grease to a torque of 25Nm
reverse thread
6ENGLISH / PATRON TECH MANUAL
The Axle must be assembled with grease, and torqued
to 10Nm.
The rear axle contains a “plug in“ tool T30/T25 and M6 Hex key:
290016 - SCO Axle RWS Rear 148x12 Spark Plug 22
7
ENGLISH / PATRON TECH MANUAL
Maximum Seatpost Insertion:
The same for both carbon and alloy front triangles.
S= 245mm
M=265mm
L=300mm
XL=315mm
8ENGLISH / PATRON TECH MANUAL
Cockpit:
The Patron has the new E-bike specific Hixon Handlebar with integrated cable
routing:
292623 SCO eRIDE Bar SY Hixon IC Patron Wty 22
The Patron Headset will be:
288252 SYN Headset ZS66/28.6 – ZS66/46
There is a new spacer kit for the Patron Stem and handlebar:
Spacer kit will include Stem and Top cover, headtube cover and 2pcs of 5mm and
3pcs of 10mm spacers. Not cross compatible with the New Spark.
292642 SCO Stem spacer kit Patron 22
There will be a new Koix holder for the MY22 Hixon IC eRIDE handlebar:
292691 SCO eRIDE Kiox mount Hixon IC 22
9
ENGLISH / PATRON TECH MANUAL
Cable Guides & Covers:
The Patron cable routing is internal, the following guides and covers are available:
Chainstay Protector:
292692 SCO eRIDE CST protector Patron 22
Main Pivot cover:
292633 SCO eRIDE M/P cover Patron 22
Cable Guide Kit & Chain Guide.
294279 SCO eRIDE cableguide set
Patron 22
294278 SCO eRIDE Chainguide
Patron 22
10 ENGLISH / PATRON TECH MANUAL
The Patron Features the new thinner cable housings from Jagwire.
294433 SCO Cable kit Spark 22
seatpost / shock / fork, 3mm / outer x3 1.8m / 1mm inner x4 1.5m plus end caps
The shock covers will be dierent for alloy and carbon front triangles.
The shock cover kit will include all the fixings and brackets.
292628 SCO Shock Cover Patron CB 22
282627 SCO Shock Cover Patron AL 22
The plug cover for the drive unit is also available:
292634 SCO eRIDE Plug cover/ bridge Patron 22
