1. General Information
1.3. Environment
Redundant electronic products are classied as
hazardous waste under the WEEE regulations
(Waste Electrical and Electronic Equipment).
Electronic parts must be disposed by an authorised
and licensed recycler. They must not be disposed
of in household waste or ‘general waste’ skips.
If recycling facilities are not locally available,
contact SE Controls who can arrange for recycling
and disposal of old electronic products.
1.4. User Responsibilities
United Kingdom Only: BS 7346-8:2013 is
a British Standard code of practice for the
planning, design, installation, commissioning and
maintenance of smoke control systems. Section
9 of the standard (Maintenance and Servicing)
states that frequent inspection of the system
should be undertaken by a named suitably-trained
member of the premises management team.
Routine inspection of the system should be carried
out in accordance with BS 9999:2008, Annex V.
For countries outside the United Kingdom:
Please check with the local the re authority in
your area regarding smoke control legislation,
dierent user responsibilities may apply.
Smoke control equipment should
only be maintained by a competent
person with specialist knowledge of
smoke control systems and sucient
information regarding the system.
1.1. General Safety Information
Read and observe the information
contained in these instructions.
Please keep these safety instructions for
future reference and maintenance. Reliable
operation and the prevention of damage
and risks are only assured if the equipment
is assembled carefully and the settings are
carried out according to these instructions and
to the operating instructions of the drives.
Please observe the exact terminal assignment,
the minimum and maximum power ratings (see
technical data) and the installation instructions.
1.2. Health and Safety
Electrical Safety: Warning 230 Vac or 400
Vac mains supply can cause death, serious
injury or considerable material damage.
Competence: This equipment is designed for
professional installation only by qualied, trained
and safety conscious electricians or skilled and
trained sta with considerable knowledge of
electrical equipment installation. These instructions
must be followed and retained for future reference.
Application: this equipment is
designed exclusively for the purposes
of controlling automatically smoke and
natural ventilation equipment.
Personal Protective Equipment: It is
recommended that suitable PPE is worn
at all times during the installation and
connection of products in accordance with
a recommended safe system of work.
Handling and storage: This equipment is
heavy. Care must be taken in transportation to
the installation location and during tting. The
equipment must not be dropped, impacted,
allowed to get wet or abused in any other way.
The panel should be kept in an upright position
at all times and should not be stacked more than
one high during shipping or storage.
Mishandling can result in serious damage to
the housing and the components therein.
Risk of crushing: this equipment can
automatically close windows and other
appliances without warning. Risk of serious
injury from crushing of hands or ngers.
