SECO-LARM Enforcer EV-1223C12 Bedienungsanleitung

Technical Specifications:

SECO-LARM offers both Black & White and Color

Dome Cameras for use in those applications which

require an attractive, inconspicuous look.

SECO-LARM dome cameras offer high resolution

with low lux in a compact and durable enclosure.

1.949.261.2999 (CA& Int’l) 1.800.662.0800 Fax: 1.949.261.7326

Email: info@seco-larm.com Website: www.seco-larm.com

16842 Millikan Avenue, Irvine, CA 92606 BasicDomeCamsb.cdr

Model

EV-1223C12

EV-122C-2

EV-122B-4

4.3mm

2.9mm

4.3mm

78°

120°

78°

Lens Angle

Viewing angles are approximate

Type

Chip

Resolution

Pickup elements

Scanning system

Sync

Video output

Lens

Viewing Angle*

Minimum illumination

Gamma correction

S/N ratio

Shutter control

Backlight compensation

Gain control

White Balance

D/A Bits

Power source

Power consumption

Operating temperature

Dimensions

420 TV lines

512 x 492 pixels (NTSC / EIA)

2:1 interlace

Internal

1V pp composite output, 75 ohms

EV-1223C12 / EV-122B-4 (4.3mm)

EV-122C-2 (2.9mm)

EV-1223C12 / EV-122B-4 (78 )

EV-122C-2 (120 )

0.1 lux

0.45

>48dB (AGC off)

Auto Electronic Shutter (AES)

1/60~1/100,000 sec. (NTSC / EIA)

Auto & Manual

Auto

12VDC

14°~140° F (-10°~60° C)

3 /2” x 2 /4” (88 x 57 mm)

Color Cameras B/W Camera

IP67

Weatherproof

VDC

Sony

CCD

Low

Current

Drain 0

Lux

Day

Night

The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.

Dome Cameras

With Multi-Axis Gimbal Brackets*

Type

Color

B/W

1/3” CCD, Sony

1/3” CCD, A1 PROs

AWB N/A

110mA 100mA

For wall mounting. Remove the 2 screws and turn the

lens 90 clockwise until the wire harness is adjacent to the

support bracket, then replace the 2 screws to secure it.

*For ceiling or wall mounting

Wire

Harness

Support

Bracket

Screw Support

Bracket

Support

Bracket Wire

Harness

Screw

Lens
