Seiko Pulsar Y182 Bedienungsanleitung
CAL. Y182, 7T32
ALARM CHRONOGRAPH
ENGLISH
TIME/CALENDAR
Hour & minute hands with small second hand
Date displayed in numerals
ALARM
Can be set on a 12-hour basis with small alarm hands.
STOPWATCH
Measures up to 30 minutes in 1/5 second increments.
TACHYMETER
For models with tachymeter scale
English
2
B
Second hand
(MAIN TIME)
Hour hand
(MAIN TIME)
C
There are three buttons and two crowns.
STOPWATCH
minute hand
a: Normal position c: Second click
A
Minute hand
(MAIN TIME)
a b c
a b c
CROWN 1
CROWN 2
Date
b: First click
STOPWATCH
1/5-second hand
ALARM minute hand
ALARM hour hand
DISPLAY AND CROWNS/BUTTONS
English
3
SCREW DOWN CROWN
[for models with screw down crown]
Unlocking the crown
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2TurnCrownclockwisewhilepressingitlightly
until tight.
English
4
DATE SETTING
2
Date
3
➠
➠
4
6
5
1
➠
CROWN 1
1Pull out to first click.
2Turn clockwise until the date for
the previous day appears.
3Pull out to second click and turn
until the desired date appears.
4Push back in to normal position.
CROWN 1
▲
▲
▲
English
5
TIME SETTING
Minute
hand
CROWN 1
Hour
hand
Second hand
1
➠
2
➠
3
1Pull out to second click when
Second hand is at the 12 o’clock
position.
2Turn to set Hour and Minute
hands.
3Push back in to normal position
in accordance with a time signal.
CROWN 1
▲
▲
English
6
Alarm time is set on a 12-hour basis and indicated by ALARM hour and minute hands
that move independently of MAIN TIME hands.
ALARM SETTING
1 Adjustment of ALARM hands
After the main time is adjusted, follow the procedure below, and then set the alarm.
* The following procedure is necessary only after the main time is adjusted.
ALARM
CROWN 2
Minute hand
(MAIN TIME)
2
➠
1
➠
3
Hour hand
(MAIN TIME)
1Pull out to second click.
2Turn to set ALARM
hands to the current
time (MAIN TIME).
3Push back in to normal
position.
CROWN 2
▲
ALARM hands
▲
English
7
2 Alarm time setting
* Once ALARM hands are adjusted to the main time, alarm time setting can be made only
by following the procedure below.
C
CROWN 2
➠
➠
Pull out to first click.
CPress repeatedly to set
ALARM hands to the
desired alarm time.
CROWN 2
▲
▲
Push back in to normal
position.
CROWN 2
English
8
1 Alarm engagement 2 Alarm disengagement
Pull out to first click. Push back in to normal
position.
CROWN 2 CROWN 2
ALARM ENGAGEMENT/DISENGAGEMENT
➠
Designated
alarm time
Current time
➠
●
Alarm rings at the designated time for 20 seconds.
* To stop it manually, press Button A, B or C, or push CROWN 2 back in to normal
position.
English
9
Stopwatch measures up to 30 minutes in 1/5 second increments.
After 30 minutes, it will start counting again from “0” repeatedly up to 6 hours.
STOPWATCH OPERATION
STOPWATCH
1/5-second hand
A
B
CROWN 1
CROWN 2
STOPWATCH minute hand
STOPWATCH
Start / Stop / Restart
Reset /
Split /Split release
●Before using the stopwatch:
1Check that CROWNS 1 and 2 are set at normal position.
2Press Button B to reset STOPWATCH hands to “0” position.
* If the hands do not return to “0” position, follow the procedure in “ADJUSTING
THE HAND POSITION” (page 12).
English
10
TACHYMETER
[for models with tachymeter scale on the dial]
Tachymeter scale can be used only when the time required is less than 60 seconds.
Ex. 2: If the measuring distance is extended to 2 km or miles or shortened to 0.5 km
or miles and STOPWATCH second hand indicates “90” on tachymeter scale:
To measure the hourly average speed of a vehicle
Ex. 1
STOPWATCH
second
hand:
40 seconds
Tachymeter
scale: “90”
“90” (tachymeter scale figure) x
1 (km or mile) = 90 km/h or mph
1Usethestopwatchtodetermine
how many seconds it takes to
go 1 km or 1 mile.
2Tachymeter scale indicated by
STOPWATCH second hand
gives the average speed per
hour.
▲
