Fastening Solutions™

FramePro®602 Full Round Head Nailer

Compressor Combo Kit – Model PC0962

NEW FRAMING KIT!

Everything to get you started on the job is included in

this one package and at a price that creates an

excellent value.

The FramePro 602 Full Round Head Nailer is easy to

handle and has excellent line of sight. This powerful

framer drives 2” to 31/2” nails in gauges from .113 to

.148.

The SENCO PC0967 Compressor is a 2 HP, 4 gallon,

oil-splash portable air compressor. Its' rugged design

will satisfy the needs of the pro!

Applications:

Framing, truss building, subflooring, sheathing,

decking, siding, fencing, pallets and crate assembly

Kit Contents:

• FramePro 602 FRH Nailer

• 2 HP, 4 gallon compressor

• 3/8” x 25’ rubber hose

• Compressor oil

• Tool oil

• Safety glasses

• All necessary air fittings

• Tool wrenches

• Manuals

PC0967 Compressor Features and Benefits:

• 2 hp, oil-splash motor for improved life

• 4 gallon capacity, twin stacked tanks

• 15 amps @ 115V, 125 PSI max output

• 3/8" quick disconnect coupler and regulator

• Individual gauges for tank and regulated output

pressure

• Hand carry – cushioned grip handle, compact,

rugged and designed for the pro

• One full year limited warranty

FramePro® 602 Features and Benefits:

• Sawtooth safety for precision toenailing

• In-line magazine for superior balance and line of

sight

• Adjustable exhaust

• Lightweight and powerful

• Adjustable depth-of-drive control

• Soft comfort grip handle reduces fatigue

• One year warranty

Fastener Specifications:

The FramePro 602 FRH nailer drives ring and smooth

shank nails in four gauges (.113 – .148) from 2" to

31/2" shank nails. Shank diameters include.113, .120,

and .131.

.148

.113

.120

.131 (For soft wood applications only with)

31/4

inches 2

mm 50

21/4

57 23/8

21/2

31/2

Fastening Solutions™

For additional information on how SENCO Power Fastening Systems will save you time, reduce costs, and increase quality, call our

toll-free Action Line: 1-800-543-4596 to find your nearest Authorized Senco Dealer or Distributor . Visit our web site at: www.senco.com

Stainless Steel

Braided Discharge

Hose

15 amps @ 115V

4 gal Twin

Stacked Tanks

3/8" Quick

Disconnect Coupler

Tank Pressure Gauge

Regulator & Outlet

Pressure Gauge

125 PSI Max Output

Rugged -

Designed

for the Pro

Easy Grip

Rubber Handle

Ergonomic Design

Superb balance

for use all day

Proven design for

long trouble-free

operation

Adjustable

Depth-of-Drive

Comes with

No-Mar Pad over

Toenail Safety

Adjustable Exhaust

Full Comfort Grip

Rear Two-Step

In-line Magazine for

superior line of sight

Dry Fire Lockout

FramePro 602 Full Round Head Nailer

PC0967 2hp, 4 gal, Oil-Splash Compressor

2 hp, Oil-Splash Motor

for Improved Life

Specifications:

Power: 869 in-lbs

Tool Weight: 8.1 lbs (3.7 kg)

Height: 13.2" (335 mm)

Length: 20.1" (511 mm)

Nail Capacity: 61

Reg. Operating Pressure: 70-120 psig

Specifications:

Power source: Electric

Max. amp: 15 amps @115V

Horsepower: 2.0

Pump: Oil-splash

SCFM @ 90 psi: 4.8

Pump-up time: 0 - 125 psi 46 seconds

Recovery time: 95 - 125 psi 12 seconds

Max pressure: 125 psi

Tank storage: 4.0 gallon

Weight: 63 lbs.

Dimensions: length 19", height 16.5",

width 17"

FramePro®602 Full Round Head Nailer

Compressor Combo Kit – Model PC0962
