Sennheiser CX Plus True Wireless Bedienungsanleitung

CX Plus True Wireless

CX Plus SE True Wireless

CX 500BT True Wireless

True Wireless stereo earbuds

Model: CXPLUSTW1, CXPLUSTW1 R, CXPLUSTW1 L, CXPLUSTW1 C

Instruction manual

Use the search function, the navigation (left) or the following links:

Start

“Product overview”

“Getting started”

“Using the earbuds”

“FAQ/If a problem occurs ...”

“Specifications”

Sonova Consumer Hearing GmbH

Am Labor 1

30900 Wedemark

Germany

www.sennheiser-hearing.com

Version: 06/22 A02

Important safety instructions

2 | CX Plus True Wireless

Important safety instructions

▷Read this instruction manual carefully and completely before

using the product.

▷Always include this instruction manual when passing the product

on to third parties.

▷Do not use the product if it is obviously defective or makes loud,

unusual (whistling or beeping) noise.

▷Only use the product in environments where Bluetooth® wireless

transmission is permitted.

Preventing damage to health and accidents

▷Protect your hearing from high volume levels. Permanent

hearing damage may occur when headphones are used

at high volume levels for long periods of time. Head-

phones of the Sennheiser brand sound exceptionally good even at

low and medium volume levels.

▷Do not insert the earphones too deep into your ears and never

insert them without ear adapters. Always remove the earphones

slowly and carefully from your ears.

▷The product generates stronger permanent magnetic

fields that could cause interference with cardiac pace-

makers, implanted defibrillators (ICDs) and other

implants. Always maintain a distance of at least 3.94"/10 cm

between the product component containing the magnet (earbuds

and charging case) and the cardiac pacemaker, implanted

defibrillator, or other implant.

▷Keep the product, accessories and packaging parts out of reach

of children and pets to prevent accidents. Swallowing and chok-

ing hazard.

▷Do not use the product in an environment that requires your spe-

cial attention (e.g. in traffic). Especially the product’s active noise

cancellation can make ambient noise inaudible or drastically

change the perception of acoustic warning signals.

Preventing damage to the product and malfunctions

▷Always keep the product dry and do not expose it to extreme tem-

peratures (hairdryer, heater, extended exposure to sunlight, etc.)

to avoid corrosion or deformation. The normal operating tempera-

ture is from 0 °C to 40 °C/32 °F to 104 °F.

▷To avoid loud, unusual (whistling or beeping) noise and to ensure

proper noise cancellation, do not cover the microphone openings

of the active noise cancellation circuitry located on the outside of

the earbuds.

▷Use only attachments/accessories/spare parts supplied or rec-

ommended by Sonova Consumer Hearing.

▷Clean the product only with a soft, dry cloth.

Important safety instructions

CX Plus True Wireless | 3

Safety instructions for lithium-ion rechargeable batteries

Notes on the ingress protection rating of the earbuds

The earbuds feature an IPX4 ingress protection rating which means

they are protected from the ingress of water (protection class

according to International Protection Marking (IP code), IEC standard

60529, tested under laboratory conditions).

The earbuds can be used in the rain, for example. However, they are

not suitable for immersion in water or for wearing in the shower. In

case of permanent moisture/wetness, the ingress protection can be

reduced and the product can be damaged.

Do not charge wet earbuds. Completely dry wet earbuds with a dry

cloth before charging them.

WARNING

If abused or misused, rechargeable batteries may leak. In

extreme cases, they may even present a risk of:

•explosion,

• heat and fire development

•smokeorgasdevelopment

• damage to health and/or the environment

Only use rechargeable batteries and chargers

recommended by Sonova Consumer Hearing.

Do not leave the product / rechargeable batteries

unattended while charging.

Only charge the product / rechargeable batteries at

ambient temperatures between 10 °C and 40 °C/41 °F

and 95 °F and do not charge them near easily flammable

objects.

Do not heat the product / rechargeable batteries above

70 °C/158 °F. Avoid exposure to sunlight and do not

throw the product / rechargeable batteries into fire.

Switch rechargeable battery-powered products off after

use.

When not using the product / rechargeable batteries for

extended periods of time, charge them regularly (about

every three months).

This product contains coin rechargeable batteries. If you

think the product / a coin rechargeable battery has been

swallowed or is lodged in the body, seek medical

assistance immediately.

Avoid prolonged skin contact with the product,

rechargeable battery, charger or charging cable when

connected to a power source. These components can

heat up during charging and cause skin irritation.

Dispose of defective products with built-in rechargeable

batteries at special collection points or return them to

your specialist dealer to facilitate recycling.

Important safety instructions

4 | CX Plus True Wireless

The charging case is not splash waterproof. Always keep the

charging case dry.

Notes on data collection and processing and on firmware updates

This product stores individual settings such as the volume, the

sound profiles and the Bluetooth connection data of paired devices.

This data is required for the operation of the product and is not trans-

ferred to Sonova Consumer Hearing GmbH or companies commis-

sioned by Sonova Consumer Hearing GmbH and is not processed.

Using the “Sennheiser Smart Control” app, you can update the firm-

ware of the product for free via an Internet connection. If the device

on which the app is installed is connected to the Internet, the follow-

ing data is automatically transferred to and processed by Sonova

Consumer Hearing GmbH servers in order to provide and transfer

suitable firmware updates: hardware identifier, hardware revision

number, firmware version of the product, operating system type

(Android, iOS) and version, version of the app. The data will only be

used as specified and will not be stored permanently.

If you do not want this data to be transferred and processed, do not

connect to the Internet.

Intended use/Liability

These headphones have been designed as an accessory for Blue-

tooth compliant devices. They are intended for wireless audio com-

munication such as music playback and phone calls via Bluetooth

wireless technology.

It is considered improper use when the product is used for any appli-

cation not named in the corresponding product documentation.

Sonova Consumer Hearing GmbH does not accept liability for

damage arising from misuse or improper use of the product and its

attachments/accessories.

Sonova Consumer Hearing GmbH is not liable for damages to USB

devices that are not consistent with the USB specifications.

Sonova Consumer Hearing GmbH is not liable for damages resulting

from the loss of connection due to flat or overaged rechargeable bat-

teries or exceeding the Bluetooth transmission range.

Before putting the product into operation, please observe the

respective country-specific regulations.

Package contents

CX Plus True Wireless | 5

Package contents

Online you can find:

• this detailed instruction manual and additional information

(www.sennheiser-hearing.com/download)

• the Sennheiser Smart Control app for configuring the head-

phones and for additional functions

(www.sennheiser-hearing.com/smartcontrol)

Earbud R for right ear (model: CXPLUSTW1 R) and

earbud L for left ear (model: CXPLUSTW1 L)

Charging case (model: CXPLUSTW1 C) with built-in

rechargeable battery for the earbuds

USB charging cable with USB-C and USB-A connec-

tor, length approx. 0.25 m

Silicone ear adapters (size XS, S, M (pre-mounted to

the earbuds) and L)

Quick guide

Safety guide

A list of accessories can be found on the CX Plus True Wireless

product page at www.sennheiser-hearing.com.

Contact your local Sonova Consumer Hearing partner:

www.sennheiser-hearing.com/service-support.

Product overview

6 | CX Plus True Wireless

Product overview

Charging case

Model: CXPLUSTW1 C

LED

displays the charging process/charge status of the

rechargeable battery of the charging case or of the

earbuds (when inserted into the charging case)

Input for USB-C connector

for charging the rechargeable batteries

Built-in rechargeable battery for charging the earbuds on

the go

Type plate

Charging compartment for the left earbud L

Magnetic holders

Charging compartment for the right earbud R

Charging contacts

234

Product overview

CX Plus True Wireless | 7

Earbuds

Model: CXPLUSTW1 R and CXPLUSTW1 L

Touch control panel

Changeable silicone ear adapters

Left earbud L

Status LED

Infra-red carrying senor

Magnetic holders

Charging contacts

Microphones for the active noise cancellation ANC, for the

perception of ambient noise (“Transparency Mode”) and

for phone calls

Right earbud R

Built-in rechargeable battery

CXPLUSTW1 RCXPLUSTW1 L

I I

Product overview

8 | CX Plus True Wireless

Overview of the LED indications of the

charging case

When a USB cable is connected, the LED of the charging case per-

manently displays the charging process:

If you open the lid of the charging case and no USB cable is con-

nected, the LED of the charging case displays the battery charge

status or the charging process of the earbuds. If you close the lid of

the charging case, the LED will go off after 5 seconds.

LED Charging case WITH

earbuds inserted

Charging case

WITHOUT earbuds

inserted

pulses

yellow

... earbuds and

charging case are

being charged

... charging case is

being charged

lights up

green

... earbuds and

charging case are

fully charged

... charging case is

fully charged

flashes

red

... a charging error/

battery error has

been detected in at

least one earbud (>

33)

... a charging error/

battery error has

been detected in the

charging case (> 33)

Product overview

CX Plus True Wireless | 9

Overview of the LED indications of the

earbuds

LED Charging case WITH

earbuds inserted

Charging case

WITHOUT earbuds

inserted

lights up

green

... earbuds are fully

charged and the

charging case can

still charge at least

one complete cycle

... charging case is

fully charged

pulses

yellow

... earbuds are being

charged via the

rechargeable bat-

tery of the charging

case

–

lights up

yellow

... earbuds are fully

charged, the

charging case

cannot charge

another complete

cycle

... charging case is

charged less than

50 %

lights up

red

... rechargeable bat-

teries of the earbuds

and the charging

case are empty

... rechargeable bat-

tery of the charging

case is empty

flashes

red

... a charging error/

battery error has

been detected in at

least one earbud (>

33)

... a charging error/

battery error has

been detected in the

charging case (> 33)

If the LED does not light up:

• Clean the contacts on the earbuds and in the charging case

(> 32).

• Charge the rechargeable batteries of the earbuds and the

charging case until the LED lights up again (> 14).

Product overview

10 | CX Plus True Wireless

Notes on voice prompts

The earbuds output voice prompts for events (the table gives some

examples). Using the Smart Control app, you can change the lan-

guage of the voice prompts, choose between voice prompts and

beep sounds, or deactivate the status messages with a few excep-

tions (e.g. rechargeable battery is empty).

LED Meaning; the earbuds...

flashes red-blue

for approx.

1minute

... are in Bluetooth pairing mode

flashes blue 3x ... Bluetooth pairing or earbud pair-

ing successful

flashes red 3x ... Bluetooth pairing or earbud pair-

ing failed

lights up blue ... are connected to a device via

Bluetooth

lights up red

... are not connected to a device via

Bluetooth or the connection has

been lost

flashes red

quickly

... rechargeable battery is almost

empty

flashes red

slowly

... system error – perform a reset (>

34)

flashes red-

green for

approx. 1 minute

... are in earbud pairing mode (to pair

the right and left earbud)

When you insert the earbuds into your ears, the LEDs of the

earbuds automatically go off.

Voice prompt Meaning/earbuds...

“Power on” ... are switched on

“Power off” ... switch off

“Connected” ... connected via Bluetooth

“No connection” ... not connected via Bluetooth

“Pairing” ... in Bluetooth pairing mode

“Pairing cancelled” ... Bluetooth pairing cancelled

“Pairing successful” ... Bluetooth pairing successful

“Pairing failed” ... Bluetooth pairing not successful

“Recharge headset” ... Rechargeable battery is almost

empty. Recharge the rechargeable

battery.

“Call rejected” ... incoming call rejected

“Call ended” ... call ended

“Volume min” ... volume set to minimum

“Volume max” ... volume set to maximum

Inhaltsverzeichnis

Andere Sennheiser Kopfhörer Handbücher

Sennheiser

Sennheiser CX 980I Bedienungsanleitung

Sennheiser

Sennheiser HD 424 Bedienungsanleitung

Sennheiser

Sennheiser SPORT True Wireless Bedienungsanleitung

Sennheiser

Sennheiser Quickguide RS 4200 Bedienerhandbuch

Sennheiser

Sennheiser MM MM 50 Nokia Bedienungsanleitung

Sennheiser

Sennheiser UNIPOLAR 2002 Bedienungsanleitung

Sennheiser

Sennheiser OCX 686i Installations- und Betriebsanleitung

Sennheiser

Sennheiser RS195 Bedienungsanleitung

Sennheiser

Sennheiser URBANITE XL Bedienungsanleitung

Sennheiser

Sennheiser CX 400BT True Wireless Bedienungsanleitung

Sennheiser

Sennheiser IE 200 Bedienungsanleitung

Sennheiser

Sennheiser CX 686G SPORTS Bedienungsanleitung

Sennheiser

Sennheiser MOMENTUM Wireless Bedienungsanleitung

Sennheiser

Sennheiser PXC 350 Bedienungsanleitung

Sennheiser

Sennheiser NoiseGard HMDC 322 Bedienungsanleitung

Sennheiser

Sennheiser M2 OEG Bedienungsanleitung

Sennheiser

Sennheiser TVS 200 Bedienungsanleitung

Sennheiser

Sennheiser GP 03-M Gebrauchsanweisung

Sennheiser

Sennheiser MM 450-X TRAVEL Bedienungsanleitung

Sennheiser

Sennheiser MX 70 Sport Bedienungsanleitung

Sennheiser

Sennheiser HME 95 Bedienungsanleitung

Sennheiser

Sennheiser HDA 280 Bedienungsanleitung

Sennheiser

Sennheiser HD HD 218i Bedienungsanleitung

Sennheiser

Sennheiser MM 450 TRAVEL Bedienungsanleitung

Beliebte Kopfhörer Handbücher anderer Marken

Sony

Sony MDR-NC8 Bedienungsanleitung

AUSounds

AUSounds AU-Stream Bedienungsanleitung

ENERGY SISTEM

ENERGY SISTEM Style 7 Bedienungsanleitung

Philips

Philips SHE3622 Bedienungsanleitung

Insignia

Insignia NS-CAHBTSPORT Bedienungsanleitung

Movie Vision

Movie Vision HP-400 Bedienungsanleitung

MobiFren

MobiFren SM Pro Bedienungsanleitung

Motorola solutions

Motorola solutions PMLN8120 Bedienungsanleitung

Jaybird

Jaybird freedom Installationsanleitung

Sony

Sony MDR-ED12LP Bedienungsanleitung

HiFuture

HiFuture Tidy Buds Pro Bedienungsanleitung

Creative

Creative CB2530 Bedienungsanleitung

Renkforce

Renkforce RF FTVK-100 Bedienungsanleitung

Philips

Philips SHQ3000 Bedienungsanleitung

Califone

Califone 2924AV Bedienungsanleitung

Philips

Philips EARGEAR HE205 Series Bedienungsanleitung

Technics

Technics EAH-AZ80 Bedienungsanleitung

Bose

Bose On-Ear Headphone Gebrauchs- und Wartungshandbuch
