Sennheiser Evolution E 606 Bedienungsanleitung
606
Bedienungsanleitung
Instructions for use
Notice d‘emploi
Istruzioni per l‘uso
Instrucciones para el uso
Gebruiksaanwijzing
e606.book Seite 1 Donnerstag, 16. Dezember 2004 8:41 08
Bedienungsanleitung..............................................................3
Instructions for use.................................................................9
Notice d’emploi......................................................................15
Istruzioni per l’uso.................................................................21
Instrucciones para el uso......................................................27
Gebruiksaanwijzing...............................................................33
e606.book Seite 2 Donnerstag, 16. Dezember 2004 8:41 08
9
606
The 606 is a dynamic microphone with
super-cardioid
pick-up pattern
, offering a particularly direct sound when
miking guitars amps. The lightweight voice coil
construction and rigid dome provide an extended high
frequency performance.
Its laterally mounted capsule has been specially
developed for miking guitars amps face-on and and
extremely close to the signal source. The super-cardioid
pick-up pattern provides good isolation from other on-
stage signals.
Due to its flat design, the 606 is easy to position.
Features
y
Rugged metal body
y
Shock-mounted capsule
y
Super-cardioid pick-up pattern
y
Hum compensating coil
Delivery includes
y
606 microphone
y
Pouch
y
Instructions for use
y
Warranty Certificate
e606.book Seite 9 Donnerstag, 16. Dezember 2004 8:41 08
10
Positioning the microphone
Loudspeaker of a guitar amplifier
In order to prevent interference due to crosstalk between
adjacentsoundsources,trytopositionthemicrophoneso
that the interfering sound source is located in the angle
area of the highest cancellation of the microphone
(approx. 135°; see polar diagram)
Position Resulting sound Commentary
Many trebles,
aggressive sound Microphone directed
towards the dome of
the loudspeaker.
Less trebles, more
lower mids,
smoother sound
Balanced, natural
sound
Good starting position:
Microphone directed
towards the middle
between dome and
edge of the loud-
speaker. If necessary,
turnthemicrophoneby
approx. 30° towards
the edge.
Less trebles, more
lower mids,
smoother sound
Microphone directed
towards the edge of
the loudspeaker.
e606.book Seite 10 Donnerstag, 16. Dezember 2004 8:41 08
11
Polar diagram
Frequency response curve
°
5
1
0
1
5
20
2
5
dB
30
°
60
°
90
°
30
°
60
°
90
°
12
0
°
1
50
°
1
80
°
1
50
°
12
0
°
2
000
H
z
4
000
H
z
8000
H
z
1
6000
H
z
12
5
H
z
2
50
H
z
500
H
z
1
000
Hz
-
50
-
60
- 7
0
-
80
-
90
2
0
50
1
00
2
00
500
1
000
2
000
5000
1
0000
2
0000
Hz
0
°
,
1
m
0
°
,
5 c
m
- 4
0
d
B
v
e606.book Seite 11 Donnerstag, 16. Dezember 2004 8:41 08
12
Specifications
Transducer principle dynamic
Frequency response 40.....15,000 Hz
Pick-up pattern super-cardioid
Sensitivity
(free field, no load at 1 kHz) 1.5 mV/Pa
Nominal impedance (at 1 kHz) 350 Ω
Min. terminating impedance 1 kΩ
Connector XLR-3
Dimensions 55 mm
x 34 mm
x 134 mm
Weight 140 g
Pin assignment of XLR-3 connector
12 3
12
3
++
12 3
XLR
+
XLRXLR
+
e606.book Seite 12 Donnerstag, 16. Dezember 2004 8:41 08
13
Overview of microphone applications
Variant
Application
e602
e604
e606
e608
e614
e815
e825
e835
e840
e845
e865
Vocals xxxxxx
Choirs x
Studio,
acoustic instruments x
Orchestra x
Brass / Saxophone xx x
Acoustic guitar x
Acoustic bass x
Guitar amplifiers x
Bass amplifiers x
Leslie xxx
Piano, grand piano x
Kick drums x
Snare drums xxx
Rack toms xxx
Floor toms xxx
Congas xxx
Cymbals x
Percussion xxxx
Overheads x
e606.book Seite 13 Donnerstag, 16. Dezember 2004 8:41 08
14
e606.book Seite 14 Donnerstag, 16. Dezember 2004 8:41 08
Konformitätserklärung
Sennheiser electronic GmbH& Co. KG erklären, dass dieses Gerät
die anwendbaren CE-Normen und Vorschriften erfüllt.
Approval
Sennheiser electronic GmbH & Co. KG declare that this device is
in compliance with the applicable CE standards and regulations.
Certification
Sennheiser electronic GmbH & Co. KG déclarons que cet appareil
est en conformité avec les normes CE.
Certificazione
SennheiserelectronicGmbH&Co.KGdiachiarachequestoappa-
recchio risponde alle normative e alle prescrizioni CE applicabili.
Autorizacion
Sennheiser electronic GmbH & Co. KG declara que este aparato
cumple las normas y directrices de la CE aplicables.
Vergunning
Sennheiser electronic GmbH & Co. KG verklaren, dat dit toestel
voldoet aan de toepasselijke CE-normen en voorschriften.
Diese Service-Nummer gilt nur für Deutschland
e606.book Seite 1 Donnerstag, 16. Dezember 2004 8:41 08
Sennheiser electronic GmbH & Co. KG
30900 Wedemark, Germany
Phone +49 (5130) 600 0
Fax +49 (5130) 600 300
www.sennheiser.com
PrintedinGermany Publ. 09/04 511651/01
