Sharp FU-A80A Bedienungsanleitung
Device of this mark is a trademark of Sharp Corporation.
Plasmacluster is a registered trademark or a trademark
of Sharp Corporation.
AIR PURIFIER
OPERATION MANUAL
FU-A80A
Free standing type
䠧ㄶ㏫✤⹐
㽡揅⟆⤥
䉫䣊
ENGLISH
Ĺ⛢
⿾ⷣ掂䇂恀傢Ŕ5JCTR⫏⤵䗰䇂ⷣ뺔
2NCUOCENWUVGTŔ5JCTR⫏⤵䗰䇂拞رⷣⅾⷣ뺔
OP_FU-A80A-EN+HK.indb 1OP_FU-A80A-EN+HK.indb 1 9/21/11 2:42:54 PM9/21/11 2:42:54 PM
Please read before operating your new Air Purifier
Some odor ingredients absorbed by the filters may become separated and may be
discharged through the air outlet and result in additional odor. Depending on the
usage environment, especially when the product is used in a condition significantly
more severe than household use, this odor may become strong in a shorter period
than expected.
The air purifier is designed to remove air-suspended dust and odor, but not harmful
gases (for example, carbon monoxide contained in cigarette smoke). If the odor
sources still exist, it cannot completely remove the odor (for example, odor from
construction materials and pet odor).
It is suggested to open the window a bit when you are smoking in order to facilitate
ventilation.
In this case we recommend purchasing the optional replacement filters.
HEPA Filter (white)
Active Carbon
Deodorizing Filter (black)
Dust Removal
pollen, dust, particles of cigarette
smoke, pet dander
Odor Removal
cigarette smoke odor, household odor
OP_FU-A80A-EN+HK.indb 2OP_FU-A80A-EN+HK.indb 2 9/21/11 2:42:57 PM9/21/11 2:42:57 PM
E-1
ENGLISH
ENGLISH
FEATURES
EXCLUSIVE AIR PURIFYING
TECHNOLOGY
Filtration System + Plasmacluster Ion
REMOVE ODOR
Active Carbon Deodorizing Filter absorbs
many common household odors.
REMOVE DUST, POLLEN, DANDER &
MOULD*
HEPA filter traps 99.97% of particles as
small as 0.3 microns.*
REFRESH AIR
Plasmacluster refreshes the air similar to
the way nature cleans the environment by
emitting a balance of positive and negative
ions.
*From that air is drawn through the filter
system.
Applicable area : 62m2
Thank you for purchasing the SHARP Air
Purifier. Please read this manual carefully.
Before using this product, be sure to read
the section: “Important Safety Instructions.”
After reading this manual, keep it in a
convenient location for future reference.
For your reference, we recommend to keep
this manual in the place where you can read
at any time.
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
.....E-2
PART NAMES ...........................................E-4
FILTER INSTALLATION ...........................E-6
OPERATION .............................................E-7
MAINTENANCE........................................E-8
TROUBLESHOOTING............................E-10
SPECIFICATIONS...................................E-11
OP_FU-A80A-EN+HK.indb 1OP_FU-A80A-EN+HK.indb 1 9/21/11 2:42:58 PM9/21/11 2:42:58 PM
E-2
Read all instructions before using the unit.
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING - To reduce the risk of electric shock, fire or injury to persons:
•Connect the power plug to a dedicated electrical outlet for 220V, 50Hz.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet is
loosened.
•Periodically remove dust from the power plug.
•Do not use an extension cord.
•Do not insert fingers or any objects into the air inlet or air outlet.
•Do not unplug by pulling on cord. To unplug, grasp the plug.
•Do not handle plug or unit with wet hands.
•Unplug the electrical cord before performing any maintenance.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, a Sharp
authorized Service Centre or qualified person in order to avoid a hazard.
•Do not use near flammable gases and material such as insecticides, fragrances, and lit cigarettes.
•Do not use in humid place such as bathrooms.
•Contact the nearest Sharp Approved Service Centre for any problems, adjustments, or repairs.
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not play with the appliance.
NOTE - Radio or TV Interference
If this air purifier causes interference to radio or television reception, try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the unit and radio/TV receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Contact the dealer or an experienced radio/TV technician for help.
IMPORTANT SAFETY INSTRUCTIONS
OP_FU-A80A-EN+HK.indb 2OP_FU-A80A-EN+HK.indb 2 9/21/11 2:43:00 PM9/21/11 2:43:00 PM
E-3
ENGLISH
CAUTIONS CONCERNING OPERATION
•Do not block the air inlet and air outlet.
•Do not use the unit near or on hot objects, such as stoves or heaters or radiators.
•Do not lay the unit down when using.
• Always hold the handle on both sides of the unit when moving it.
Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting
in bodily injury.
• Do not use without filters inside the unit.
• Do not wash and reuse the filter.
Not only does it not improve filter performance, but also may cause electric shock or malfunction.
• Clean the exterior with a soft cloth only.
Do not use corrosive cleansers, volatile fluids and/or detergents when cleaning the unit.
Otherwise, the unit surface may be damaged or cracked.
In addition, the sensor may malfunction as a result.
INSTALLATION GUIDELINES
• Avoid locations where curtains, etc., come into contact with air inlet or air outlet.
It may become dirty or a malfunction may occur.
• Avoid locations where the unit is exposed to condensation, due to rapid temperature changes.
(Use under appropriate conditions between 0 - 35˚C room temperature.)
• Place on a stable surface with sufficient air circulation.
When placing the unit on a heavily carpeted area, it may cause the unit to vibrate slightly.
• Do not use in locations where greasy or oily smoke is generated (such as in a kitchen, etc.).
The unit surface may crack or the sensor may malfunction as a result.
FILTER GUIDELINES
• Follow the instructions to handle carefully and keep
maintenance.
Do not install any other type of filters.
Distance from wall
far away
as possible
far away
as possible
60cm or more
OP_FU-A80A-EN+HK.indb 3OP_FU-A80A-EN+HK.indb 3 9/21/11 2:43:01 PM9/21/11 2:43:01 PM
E-4
PART NAMES
ILLUSTRATIVE DIAGRAM
BACK
1
3
4
2
7
5
6
8
9
10
1 Air Outlet
2 Air Inlet
3 Handle
4 Main Unit
5 HEPA Filter
6
Active Carbon Deodorizing Filter
7 Dust Sensor
8 Date Label
9 Power Cord
10 Plug
OP_FU-A80A-EN+HK.indb 4OP_FU-A80A-EN+HK.indb 4 9/21/11 2:43:03 PM9/21/11 2:43:03 PM
E-5
ENGLISH
CONTROL PANEL
11 12 14 15 16 17 18
11 SHOWER Button /
SHOWER Indicator Light (green)
12 Plasmacluster ON / OFF Button /
Plasmacluster ON / OFF Indicator Light (green)
13 CHILD LOCK Button /
CHILD LOCK Indicator Light (green)
14 CLEAN SIGN
The colour changes according to the air condition.
15 Plasmacluster Indicator Light (blue)
16 FAN SPEED Indicator Light (green)
17 FAN SPEED Button
18 POWER Button
Green Yellow Red
Clean Dirty
13
OP_FU-A80A-EN+HK.indb 5OP_FU-A80A-EN+HK.indb 5 9/21/11 2:43:05 PM9/21/11 2:43:05 PM
E-6
FILTER INSTALLATION
Unplug the electrical cord before
installation.
To maintain the quality of the filters, they are packed in plastic bags and installed in the
main unit. Be sure to remove the filters from the plastic bags before operating the unit.
1
Remove the front Panel.
Gently grip the bottom of the front panel
and remove it by pulling the bottom gently
towards you. Then move upward to
remove the front panel.
2
Remove the plastic bags.
3
Place the filters accordingly.
Follow below picture, install the filters in order.
4
Fix the Front Panel.
Fix the Front Panel by hooking it into
the top of the unit. Swing panel in by
pushing gently until the panel snaps
into place.
5
Record the date when you
start or replace the filters.
HEPA Filter (white)
Active Carbon Deodorizing Filter (black)
OP_FU-A80A-EN+HK.indb 6OP_FU-A80A-EN+HK.indb 6 9/21/11 2:43:05 PM9/21/11 2:43:05 PM
E-7
ENGLISH
OPERATION
1
Press to start / stop.
Unless the power cord has been unplugged,
the operation starts in the previous mode it
was operated in.
MAX
2
Press to select fan speed.
3
Press to turn Plasmacluster
Ion Mode ON and OFF.
Press to start SHOWER Mode..
The unit will operate at HIGH fan speed
for one hour, then will return to the prior
operation.
"SHOWER" mode is effective when you
would like to clean quickly.
Yellow Red
Clean
ON OFF
321
SHOWER Operation
Light Control
Press for 3 seconds to select
ON/OFF of the Plusmacluster
Indicator Light and the CLEAN SIGN.
AUTO mode
*The air purifier operates the airflow speed
automatically according to the indoor air
quality detected by the sensor.
CHILD LOCK
Press for 3 seconds to select
CHILD LOCK.
Operation of the unit display will be
locked.
To cancel the CHILD LOCK mode,
press again for 3 seconds.
CLEAN SIGN
Green
Dirty
The Dust sensor automatically monitors
indoor air quality.The CLEAN SIGN
light will change accordingly.
OP_FU-A80A-EN+HK.indb 7OP_FU-A80A-EN+HK.indb 7 9/21/11 2:43:09 PM9/21/11 2:43:09 PM
E-8
CLEANING THE FILTERS
1
Turn off the unit, and unplug the
power cord.
2
Remove the Front Panel.
(Refer to E-6)
3
Clean the filter and Dust sensor.
Gently remove dust from the filter, using a
vacuum cleaner with attachment or similar tool.
Dust Sensor
Remove the Sensor cover, and remove the
dust on the Sensor filter.
If it is very dirty, wash it with water and dry it
thoroughly.
CLEANING THE UNIT
Dust sensor
Active Carbon Deodorizing Filter
Sensor cover
Sensor filter
MAINTENANCE
Wipe with a dry, soft cloth.
For stubborn stains or dirt, use a soft cloth
dampened with warm water.
Do not use volatile fluids and
detergents.
Benzene, paint thinner, polishing powder,
detergent ingredients etc., may damage
the unit.
Care Cycle :
Whenever dust accumulates on the unit or every 1 month.
OP_FU-A80A-EN+HK.indb 8OP_FU-A80A-EN+HK.indb 8 9/21/11 2:43:11 PM9/21/11 2:43:11 PM
Inhaltsverzeichnis
Andere Sharp Luftreiniger Handbücher
Sharp
Sharp FP-J80E Bedienungsanleitung
Sharp
Sharp FU-40SE Bedienungsanleitung
Sharp
Sharp FZ-60SEF Bedienungsanleitung
Sharp
Sharp KC-F30Y Bedienungsanleitung
Sharp
Sharp FU-A28TA Bedienungsanleitung
Sharp
Sharp Plasmacluster FP-P60CX Bedienungsanleitung
Sharp
Sharp FP-R30CX Bedienungsanleitung
Sharp
Sharp FU-D40A Bedienungsanleitung
Sharp
Sharp IG-BC2UB Bedienungsanleitung
Sharp
Sharp FP-F30U Bedienungsanleitung
Sharp
Sharp FU-888SV Bedienungsanleitung
Sharp
Sharp FP-J80Y Bedienungsanleitung
Sharp
Sharp KC-F30E Bedienungsanleitung
Sharp
Sharp UA-PE30E Bedienungsanleitung
Sharp
Sharp Plasmacluster FP-A40C Bedienungsanleitung
Sharp
Sharp FU-E30A-W Bedienungsanleitung
Sharp
Sharp FP-GM50Y Bedienungsanleitung
Sharp
Sharp FZ-C150DFE Bedienungsanleitung
Sharp
Sharp FU-S51A Bedienungsanleitung
Sharp
Sharp FP-J30M Bedienungsanleitung
Beliebte Luftreiniger Handbücher anderer Marken
Winix
Winix NK300 Bedienungsanleitung
Friedrich
Friedrich C-90A Bedienungs- und Montageanleitung
Surgically Clean Air
Surgically Clean Air JADE2.0 Bedienungsanleitung
Base aire
Base aire 555 Pro Bedienungsanleitung
Champion
Champion CP25 Bedienungsanleitung
vollara
vollara Air & Surface Pro+ Bedienungsanleitung
