Sharp FP-J30J-B Bedienungsanleitung

FP-J30J

“Plasmacluster” and “Device of a cluster of grapes” are

trademarks of Sharp Corporation.

* The number in this technology mark indicates an

approximate number of ions supplied into air of

1 cm3, which is measured around the center of a

room applicable oor area (at 1.2 m height above

the oor) when the product is placed close to a

wall at the MED mode setting.

AIR PURIFIER

OPERATION MANUAL

FP-J30J_2nd.indd 1FP-J30J_2nd.indd 1 2022/12/01 16:17:262022/12/01 16:17:26

HEPA Filter

Deodorizing Filter

Back Panel

The air purifier draws in room air through the air inlet, circulates it through a

Pre-Filter, a Deodorizing Filter and a HEPA Filter inside the main unit, and then

discharges it through the air outlet. The HEPA Filter can remove 99.97 % of dust

particles as small as 0.3 microns that pass through the filter and also helps absorb

odors. The Deodorizing Filter gradually absorbs odors as they pass through the filter.

Some odors absorbed by the filters will break down over time, causing additional

odors. Depending on usage conditions, and especially if the main unit is used in

environments significantly more severe than a normal household, these odors may

become noticeable sooner than expected. If these odors persist, replace the filters.

NOTE

• The air purier is designed to remove air-suspended dust and the odors.

The air purier is not designed to remove harmful gases such as carbon monoxide

contained in cigarette smoke.

The air purier may not completely remove an odor if the source of the odor is still present.

Please read before operating your new Air Purifier

This appliance is intended for indoor domestic use only.

FP-J30J_2nd.indd 2FP-J30J_2nd.indd 2 2022/12/01 16:17:262022/12/01 16:17:26

Thank you for purchasing this SHARP Air

Purifier.

Please read this manual carefully before

using the product.

This manual should be kept in a safe place

for handy reference.

CONTENTS

Unique Combination of Air Treatment

Technologies

Filtration System + Plasmacluster

TRAPS DUST*

Pre-filter traps dust and other large

airborne particles.

REDUCES ODORS

Deodorizing filter absorbs many common

household odors.

REDUCES POLLEN & MOLD*

HEPA filter traps 99.97 % of particles as

small as 0.3 microns.

FRESHENS

Plasmacluster treats the air similar to

the way nature cleans the environment

by emitting a balance of positive and

negative ions.

* When air is drawn through the filter

system.

FEATURES

IMPORTANT SAFETY INSTRUCTIONS ....2

CARE AND MAINTENANCE ......................4

REPLACEMENT .........................................5

PART NAMES .............................................6

FILTER INSTALLATION ............................. 7

OPERATION ...............................................8

TROUBLESHOOTING..............................10

SPECIFICATIONS..................................... 11

FP-J30J_2nd.indd 1FP-J30J_2nd.indd 1 2022/12/01 16:17:262022/12/01 16:17:26

IMPORTANT SAFETY INSTRUCTIONS

Always follow basic safety precautions when using electrical appliances,

including the following:

WARNING – Always observe the following to reduce the risk of electrical shock,

fire, or injury:

• Read all instructions before using the main unit.

• Use only a 220 - 240 volt outlet.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure they do not play with the appliance.

• If the power cord is damaged, it must be replaced by the manufacturer,

its service agent, a Sharp authorized Service Center or similarly qualified

persons in order to avoid a hazard. Contact the nearest Service Center for

any problems, adjustments, or repairs.

• Do not repair or disassemble the main unit yourself.

• Be sure to remove the power plug, before performing maintenance, when

removing and attaching and replacing the filter and when not using for a

long time. Failure to do so can cause a short circuit resulting in electrical

shock or fire.

• Do not use the main unit if the power cord or plug is damaged or if the connection

to the wall outlet is loose.

• Periodically remove dust from the plug.

• Do not insert fingers or foreign objects into the air inlet or air outlet.

• When removing the power plug, always hold the plug and never pull on the cord.

Failure to do so can cause a short circuit resulting in electrical shock or fire.

• Be careful not to damage the power cord.

Failure to do so can cause electric shock, heat generation, or fire.

• Do not remove the plug when your hands are wet.

• Do not use this main unit near gas appliances or fireplaces. When the main unit

is operated with gas appliances in same room, Ventilate a room periodically,

otherwise it may cause Carbon monoxide poisoning.

• Do not operate the main unit in rooms where aerosol insecticides are present. Do

not operate the main unit in rooms where there is oily residue, incense, sparks

from lit cigarettes, or chemical fumes in the air.

• Keep the main unit away from water.

Do not operate the main unit in places where it may get wet, such as a bathroom.

• Do not expose the main unit to water. Doing so can cause a short circuit or

electrical shock.

• Be cautious when cleaning the main unit. Strong corrosive cleansers can damage

the exterior.

NOTE – What to do if the main unit interferes with radio or TV reception

If the air purifier interferes with radio or television reception, try one or more of the

following measures:

FP-J30J_2nd.indd 2FP-J30J_2nd.indd 2 2022/12/01 16:17:262022/12/01 16:17:26

• Adjust or reposition the receiving antenna.

• Increase the distance between the main unit and the radio or TV.

• Connect the equipment into an outlet on a circuit different from that of the radio or

TV receiver.

• Consult the dealer or a qualified radio or TV technician.

CAUTIONS CONCERNING OPERATION

• Do not block the air inlet or air outlet.

• Do not place the main unit near or on hot objects, such as stoves or heaters, or

where it may come into contact with steam.

• Always operate the main unit in an upright position.

• Do not move the main unit when it is in operation.

• When moving the main unit, use the handle on the back of the main unit.

• If the main unit is on easily damaged flooring, an uneven surface, or thick-piled

carpet, lift it up when moving.

• Do not operate the main unit without the filters properly installed.

• Do not wash and reuse the HEPA filter and the Deodorizing filter.

Doing so will not improve filter performance and can also cause electric shock or

operating malfunctions.

• Clean the exterior with a soft cloth only. Do not use volatile fluids or detergents.

The main unit surface may be damaged or cracked with Benzine, paint thinner or

polishing powder.

• Do not scrub the Back Panel hard during its maintenance.

INSTALLATION GUIDELINES

• Avoid locations where furniture, fabrics, or other objects can come in contact with

the main unit and interfere with the intake and outtake of air.

• Avoid locations where the main unit is exposed to condensation or drastic changes

in temperature. Appropriate room temperature is between 0 – 35 ºC.

• Place the main unit on a level and stable surface with sufficient air circulation.

When placed on heavy carpet, the main unit may vibrate slightly.

• Avoid locations that generate grease or oily smoke.

Doing so can cause the main unit exterior to crack.

• The dust collecting ability of the main unit is effective even when the main unit is

as close to 3 cm from the wall,the surrounding walls and floor may get dirty. Please

place the main unit at a distance from the wall.

The wall directly behind the air outlet may become dirty over time. When using the

main unit for an extended period of time at the same location, periodically clean

the walls adjacent to it.

FILTER GUIDELINES

• Follow the instructions in this manual for proper filter care and maintenance.

(Page 4)

FP-J30J_2nd.indd 3FP-J30J_2nd.indd 3 2022/12/01 16:17:272022/12/01 16:17:27

To maintain optimum performance of this air purifier, please clean the main unit including the

filter periodically.

Be sure to disconnect the power cord from the wall outlet before performing any maintenance.

CARE AND MAINTENANCE

NOTE How to clean hard to remove dirt

Gently remove dust from the Back Panel by using a

vacuum cleaner attachment or similar tool.

Back Panel (Pre-filter)

Back Panel

Main Unit Wipe with a dry, soft cloth

For stubborn stains or dirt, use a soft cloth dampened with warm water.

• Do not use volatile fluids

Benzene, paint thinner, polishing powder, etc. , may damage the surface.

• Do not use detergents

Detergent ingredients may damage the main unit.

1. Add a small amount of kitchen detergent to water and

soak for about 10 minutes.

2. Rinse off the kitchen detergent with clean water.

3. Completely dry the filter in a well-ventilated area.

Do not apply excessive pressure when

scrubbing the Back Panel.

Gently remove dust from the HEPA FILTER and Deodorizeing Filter

with a vacuum cleaner attachment or similar tool.

Filters

Tag

HEPA Filter

Deodorizing Filter

Do not WASH in water and DRY in the sun.

The filters are fragile, be careful not to apply too much force.

• HEPA Filter

Apply the maintenance only on the side with the tag.

Do not clean the opposite side; otherwise, the filter will be damaged.

• Deodorizing Filter

The maintenance can be applied to the both sides.

CAUTION

Always be sure to remove the

power plug from the wall outlet.

FP-J30J_2nd.indd 4FP-J30J_2nd.indd 4 2022/12/01 16:17:292022/12/01 16:17:29

Deodorizing Filter

REPLACEMENT

Disposal of Filter

Please dispose of the replaced filter according

to the local disposal laws and regulations.

When Replace Filter Indicator light turn on*

Replacement timing

HEPA Filter

• Filter : Polypropylene

• Frame : Polyester

Filters

Replace the Filter according to the instructions

provided with the replacement filter.

After the exchange, insert the plug in socket and

press the POWER button, and OFF TIMER button

3 seconds.

Deodorizing Filter

• Polypropylene

• Polyester

• Activated charcoal

HEPA Filter

Deodorizing

Filter

Model : FZ-F30HFE

Model : FZ-F30DFE

HEPA Filter

Do not wash and reuse the filter

The filter life and replacement period are based

on the condition of smoking 5 cigarettes per day

and the dust collection power is reduced by half

compared with that of new filter.

Filter life varies depending on the room

environment, usage, and location of the main unit.

We recommend to replace the filter more

frequently if the product is used in a condition

significantly severer than normal household use.

• Please consult your dealer for purchase of

replacement lter.

• Use only lter designed for this product.

* The Replace Filter indicator light will turn on after

approximately 17,500 hours in Sleep mode.

( 2 years × 24 hours = 17,500)

Filter life varies depend on the operation mode.

Always be sure to remove the

power plug from the wall outlet.

FP-J30J_2nd.indd 5FP-J30J_2nd.indd 5 2022/12/01 16:17:312022/12/01 16:17:31

PART NAMES

1Main Unit

MODE Button, Indicator Light (green)

(Press 3 sec.)

Plasmacluster Ion ON/OFF Button

2Air Outlet

OFF TIMER Button, Indicator Light (green)

(Press 3 sec.) Filter Reset Button

9HEPA Filter

10 Deodorizing Filter

4Replace Filter Indicator Light (orange) 11 Back Panel (Pre-Filter)

5Plasmacluster Ion Indicator Light (blue) 12 Bottom Tabs

6POWER ON/OFF Button 13 Handle

Clean Ion Shower Button,

Indicator Light (green)

(Press 3 sec.) LIGHT ON/OFF Button

14 Power Cord

15 Plug

16 Air Inlet

FRONT

BACK

FP-J30J_2nd.indd 6FP-J30J_2nd.indd 6 2022/12/01 16:17:312022/12/01 16:17:31

3Place the Filter within the Main

Unit.

Do not install the filter backwards or the

main unit will not operate properly.

4Replace the Back Panel to the

main unit.

FILTER INSTALLATION

To maintain the quality of the filter, it is installed in the main unit and packed in plastic bag.

Be sure to remove the filter from the plastic bag before using the main unit.

• Do not operate the main unit without

the ﬁ lter.

1Remove the Back Panel.

Pull the Back Panel while holding down

the Main Unit.

2Remove the plastic bag from

the Filter.

Push

Bottom Tabs

Pull

Always be sure to remove the

power plug from the wall outlet.

FP-J30J_2nd.indd 7FP-J30J_2nd.indd 7 2022/12/01 16:17:342022/12/01 16:17:34

OPERATION

MED MAX SLEEP

CLEAN AIR

START STOP

• Select the desired fan speed.

• Unless the power cord has been unplugged,

the operation starts in the previous mode it

was operated in.

Releases high density Plasmacluster ions and discharges strong air flow for 60 minutes.

CLEAN ION SHOWER

START

• When the operation nishes, the main unit will return to the

prior operation mode.

It is able to change the other mode and during this

mode.

• If Plasmacluster Ion is OFF, Plasmacluster Ion will not be

released.

NOTE

FAN SPEED

SLEEP

• The main unit will operate very quietly with low fan

speed.

Plasmacluster Ion Indicator goes o󰀨 automatically.

Even though the indicator is o󰀨, Plasmacluster Ion is

dispersed into air unless Plasmacluster Ion is turned o󰀨

by .

NOTE

FP-J30J_2nd.indd 8FP-J30J_2nd.indd 8 2022/12/01 16:17:372022/12/01 16:17:37

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Sharp Luftreiniger Handbücher

Sharp

Sharp FP-JM40B Bedienungsanleitung

Sharp

Sharp KI-N50TA Bedienungsanleitung

Sharp

Sharp FP-JM30E Bedienungsanleitung

Sharp

Sharp FP-F40E Bedienungsanleitung

Sharp

Sharp FX-S120 Bedienungsanleitung

Sharp

Sharp Plasmacluster KC-860U Bedienungsanleitung

Sharp

Sharp FU-60SE Bedienungsanleitung

Sharp

Sharp Plasmacluster FP-J80M Bedienungsanleitung

Sharp

Sharp Plasmacluster KC-840E Bedienungsanleitung

Sharp

Sharp FU-28H-S Bedienungsanleitung

Sharp

Sharp FU-S25E Bedienungsanleitung

Sharp

Sharp FP-GM50Y Bedienungsanleitung

Sharp

Sharp FP-K50U Bedienungsanleitung

Sharp

Sharp FU-A28E Bedienungsanleitung

Sharp

Sharp Plasmacluster KC-830U Bedienungsanleitung

Sharp

Sharp FP-J30TA Bedienungsanleitung

Sharp

Sharp QNET ZENsational KC-G60M-W Bedienungsanleitung

Sharp

Sharp Plasmacluster IG-A10J-B Bedienungsanleitung

Sharp

Sharp FP-R30CX Bedienungsanleitung

Sharp

Sharp UA-KCP100U-W Bedienungsanleitung

Sharp

Sharp FU-W28J Bedienungsanleitung

Sharp

Sharp KC-D60E Bedienungsanleitung

Sharp

Sharp FP-P35CX - HEPA Air Purifier Bedienungsanleitung

Sharp

Sharp KC-F30Y Bedienungsanleitung

Beliebte Luftreiniger Handbücher anderer Marken

IKEA

IKEA UPPÅTVIND Bedienungsanleitung

Nash

Nash AP-1 PureSmart Bedienungsanleitung

LG PH-U450 Series Bedienungsanleitung

DeLonghi

DeLonghi DDSX 220WFA Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Bedienungsanleitung

Philips

Philips AC2721 Bedienungsanleitung

Hitachi

Hitachi EP-A3000 Bedienungsanleitung

TruSens

TruSens Z-2000 Bedienungsanleitung

Motorola

Motorola MBP87SN Bedienungsanleitung

Beko

Beko ATP 7100I Bedienungsanleitung

Carrier

Carrier INFINITY 1620 Bedienungsanleitung

AtmosAir

AtmosAir P2002 Bedienungsanleitung

Winix

Winix NK300 Bedienungsanleitung

Friedrich

Friedrich C-90A Bedienungs- und Montageanleitung

Surgically Clean Air

Surgically Clean Air JADE2.0 Bedienungsanleitung

Base aire

Base aire 555 Pro Bedienungsanleitung

Champion

Champion CP25 Bedienungsanleitung

vollara

vollara Air & Surface Pro+ Bedienungsanleitung
