Show Technology SM-8/2 Bedienungsanleitung

SM-8/2 V1

Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands

Ordercode: 50700

MANUAL

ENGLISH

Ordercode: 50700

SM-8/2

Table of contents

Warning ...............................................................................................................................................................................2

Unpacking Instructions.................................................................................................................................................2

Safety Instructions .........................................................................................................................................................2

Operating Determinations ..........................................................................................................................................3

Connection with the mains.........................................................................................................................................4

Return Procedure..........................................................................................................................................................4

Claims..............................................................................................................................................................................4

Description of the device.................................................................................................................................................5

Frontside..........................................................................................................................................................................5

Backside .........................................................................................................................................................................7

Installation...........................................................................................................................................................................8

Common Terms .............................................................................................................................................................8

Set Up and Operation .......................................................................................................................................................9

Resetting the System ....................................................................................................................................................9

Fixture Addressing .........................................................................................................................................................9

Physical Fader Assignment (optional setup) ...........................................................................................................9

Reverse Channel Output (optional setup) ............................................................................................................10

Fade Time Assignment (optional setup).................................................................................................................10

Programming....................................................................................................................................................................10

Entering Program Mode ............................................................................................................................................10

Create a Scene...........................................................................................................................................................10

Edit a Scene .................................................................................................................................................................11

Scene Copy .................................................................................................................................................................11

Delete Scene ...............................................................................................................................................................11

Delete All Scenes ........................................................................................................................................................11

Bank Copy....................................................................................................................................................................11

Bank Delete..................................................................................................................................................................12

Chase Programming.......................................................................................................................................................12

Create a Chase ..........................................................................................................................................................12

Copy Bank Into Chase...............................................................................................................................................12

Adding a Step To a Chase........................................................................................................................................12

Delete a Scene/Step In a Chase.............................................................................................................................12

Delete a Chase ...........................................................................................................................................................12

Delete All Chase Programs .......................................................................................................................................13

Playback (Scenes) ..........................................................................................................................................................13

Manual Run Scene .....................................................................................................................................................13

Running in Sound-Mode ............................................................................................................................................13

Running in Auto-Mode...............................................................................................................................................13

Blackout........................................................................................................................................................................13

Playback (Chases)..........................................................................................................................................................14

Manual Run Chases ...................................................................................................................................................14

Auto Run Chases.........................................................................................................................................................14

Music Run Chases .......................................................................................................................................................14

Running Sequential Chases ......................................................................................................................................14

Midi Operation .................................................................................................................................................................15

Maintenance....................................................................................................................................................................16

Troubleshooting ...............................................................................................................................................................16

Product Specifications....................................................................................................................................................17

Notes ..................................................................................................................................................................................18

Ordercode: 50700

SM-8/2

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure

that all parts are present, and have been received in good condition. Notify the dealer immediately and

retain packing material for inspection if any parts appear damaged from shipping or the carton itself

shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be

returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Your shipment includes:

Showtec SM-8/2

DC 9V, 300 mA power adapter (1,5 m)

User manual

Safety Instructions

Every person involved with the installation, operation and maintenance of this device has to:

be qualified

follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to

follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to

warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

Ordercode: 50700

SM-8/2

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-observance of

this manual or any unauthorized modification to the device.

Never let the power cord come into contact with other cables! Handle the power cord and all

connections with the mains with particular caution!

Never remove warning or informative labels from the unit.

Never use anything to cover the ground contact.

Never leave any cables lying around.

Do not insert objects into air vents.

Do not open the device and do not modify the device.

Do not connect this device to a dimmerpack.

Do not switch the device on and off in short intervals, as this would reduce the device’s life.

Do not shake the device. Avoid brute force when installing or operating the device.

Only use device indoor, avoid contact with water or other liquids.

Only operate the fixture after having checked that the housing is firmly closed and all screws are

tightly fastened.

Only operate the device after having familiarized with its functions.

Avoid flames and do not put close to flammable liquids or gases.

Always keep case closed while operating.

Always disconnect power from the mains, when device is not used or before cleaning! Only handle

the power cord by the plug. Never pull out the plug by tugging the power cord.

Make sure that the device is not exposed to extreme heat, moisture or dust.

Make sure that the available voltage is not higher than stated on the rear panel.

Make sure that the power cord is never crimped or damaged. Check the device and the power

cord from time to time.

If device is dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not

switch it on immediately. The arising condensation water might damage your device. Leave the

device switched off until it has reached room temperature.

If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

For adult use only. Device must be installed out of the reach of children. Never leave the unit running

unattended.

The user is responsible for correct positioning and operating of the SM-8/2. The manufacturer will not

accept liability for damages caused by the misuse or incorrect installation of this device.

This device falls under protection class I. Therefore it is essential to connect the yellow/green

conductor to earth.

Repairs, servicing and electric connection must be carried out by a qualified technician.

WARRANTY: Till one year after date of purchase.

Operating Determinations

This device is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

The minimum distance between light-output and the illuminated surface must be more than 1 meter.

The maximum ambient temperature ta = 40°C must never be exceeded.

The relative humidity must not exceed 50 % with an ambient temperature of 40° C.

If this device is operated in any other way, than the one described in this manual, the product may

suffer damages and the warranty becomes void.

Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.

You endanger your own safety and the safety of others!

Ordercode: 50700

SM-8/2

Connection with the mains

Connect the device to the mains with the power-plug.

Always pay attention, that the right color cable is connected to the right place.

International

EU Cable

UK Cable

US Cable

BROWN

RED

YELLOW/COPPER

PHASE

BLUE

BLACK

SILVER

NEUTRAL

YELLOW/GREEN

GREEN

PROTECTIVE GROUND

Make sure that the device is always connected properly to the earth!

Improper installation can cause serious damage to people and property!

Return Procedure

Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.

Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned

without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.

Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.

Be prepared to provide the model number, serial number and a brief description of the cause for the

return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the

customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace

product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.

Note: If you are given an RMA number, please include the following information on a piece of paper

inside the box:

01) Your name.

02) Your address.

03) Your phone number.

04) A brief description of the symptoms.

Claims

The client has the obligation to check the delivered goods immediately upon delivery for any short-

comings and/or visible defects, or perform this check after our announcement that the goods are at their

disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be

reported to the carrier upon receipt of merchandise.

It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is

damaged due to shipping. Transportation damage has to be reported to us within one day after receipt

of the delivery.

Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with

a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless

otherwise agreed in writing.

Complaints against us must be made known in writing or by fax within 10 working days after receipt of the

invoice. After this period complaints will not be handled anymore.

Complaints will only then be considered if the client has so far complied with all parts of the agreement,

regardless of the agreement of which the obligation is resulting.

Ordercode: 50700

SM-8/2

Description of the device

Features

The SM-8/2 is a light controller from Showtec and is equipped with the following features:

•192 DMX channels; up to 12 intelligent fixtures with 16 channels each

•30 banks of 8 scenes, a maximum of 240 scenes

•6 sets of chases containing 240 scenes

•Fog & strobe control buttons

•Patch mode: each fixture has free assignable channels

•Programmable speed and fade time

•Reversible faders

•Sequential chase linking

•Re-assignable channels

•Sound-controlled, tap-sync and auto run

•Polarity selector

•Output connector: 3-pin/5-pin XLR female

•MIDI compatible

•9V, 300 mA DC power adapter

•Dimensions:

535 x 195 x 100 mm (LxWxH)

3HE (3U) 19" rack mount

•Weight: 2,9 kg

Frontside

Fig. 01

Ordercode: 50700

SM-8/2

01) Fixture buttons

Press the buttons to select scanners for setting, programming or recording.

02) Fixture indicator

The LEDs indicate the currently selected fixture.

03) Strobe button + LED

Press the button to control Showtec strobes.

04) Page A Indicator

The LED indicates CH1~8 range.

05) Page B Indicator

The LED indicates CH9~16 range.

06) Scene select buttons

Press the universal bump buttons to indicate scene location for storage and selection.

07) Channel faders

For adjusting DMX values, CH1~8 can be adjusted immediately, after pressing the respective scanner

select button. CH9~16 - after pressing the Page select button (18).

08) LCD display

09) Mode Indicator

The LEDs provide operating mode status, (manual, music or auto).

10) Midi/Add button

Press the button to activate MIDI external control or to confirm the record/save process.

11) Program button

Press the button to activate program mode.

12) Bank Up/Down button

Press the button to select one out of the 30 available banks.

13) Chase buttons

Chase memory 1~6; Press these buttons to activate the chase of programmed scenes.

14) Blackout button

Press this button to enable or disable the relevant DMX output. When its LED is lit, it means that the

relevant DMX output is disabled. If you press this button again, the LED will be OFF and the DMX

output is reactivated.

15) Fog button + Heat Ready LED

Press the button to control the fog machine. The relevant LED will show you the working state

(READY).

16) Reverse Channel LED

The LED indicates reverse channel programming mode.

17) Fade LED

The LED indicates fade programming mode.

18) Page select button

Press the button to select page, between Page A (1-8) and Page B (9-16).

19) Speed fader

Move the fader to adjust the hold time of a scene or a step within a chase (range from 0.1 second to

10 minutes).

20) Fade Time fader

Move the fader to adjust the fade time. Fade time is the amount of time it takes for a scanner (or

scanners) to move from one position to another, for the dimmer to fade in or fade out.

21) Auto/Del button

Press the button to activate music mode or to delete scenes or chases during programming.

22) Music/Bank Copy button

Press the button to activate music mode or to copy command, while programming.

23) Tapsync/Display button

Press the button to create a standard beat or to change the value mode between % and 0-255.

Ordercode: 50700

SM-8/2

Backside

Fig. 02

24) MIDI input port

Connect this input for external triggering of banks, scenes, chases, and blackout using a MIDI device.

25) DMX polarity switch

Press the switch to change signal polarity.

26) DC input 9V, 300 mA

Power supply.

27) Strobe connector

Showtec Mono Strobe ¼” connector for the built-in strobe controller.

28) Fog connector

Showtec fog controller. ¼” jack.

29) Power switch ON/OFF

Press the switch to turn the device on or off.

30) 3-pin DMX output connector

31) 5-pin DMX output connector

Ordercode: 50700

SM-8/2

Installation

Remove all packing materials from the SM-8/2. Check if all foam and plastic padding is removed.

Connect all cables.

Do not supply power before the whole system is set up and connected properly.

Always disconnect from electric mains power supply before cleaning or servicing.

Damages caused by non-observance are not subject to warranty.

Common Terms

The following are common terms used in intelligent light programming.

Blackout is a state where all lighting fixtures’ light outputs are set to 0 or off, usually on a temporary basis.

DMX-512 is an industry standard digital communication protocol used in entertainment lighting

equipment. For more information, read sections “DMX Primer” and “DMX Control Mode” in the Appendix.

Fixture refers to your lighting instrument or other device such as a fogger or dimmer which you can

control.

Programs are a number of scenes arranged one after another. It can be programmed as either a single

scene or multiple scenes in sequence.

Scenes are static lighting states.

Sliders are also known as faders.

Chases can also be called programs. A chase consists of a number of scenes arranged one after

another.

Scanner refers to a lighting instrument with a pan and tilt mirror; however DMX controllers can use this

term to control any DMX-512 compatible device as a generic fixture.

MIDI is a standard for representing musical information in a digital format. A MIDI input would provide

external triggering of scenes using midi devices such as a MIDI keyboard.

Stand Alone refers to a fixture’s ability to function independently of an external controller and usually in

sync to music, due to a built in microphone.

Fade slider is used to adjust the fade time between scenes within a chase.

Speed slider affects the amount of time a scene will hold its state. It is also considered a wait time.

Shutter is a mechanical device in the lighting fixture that allows you to block the light’s path. It is often

used to decrease the intensity of the light output and to strobe.

Patching refers to the process of assigning faders to a DMX channel within a fixture.

Playbacks can be either scenes or chases that are directly called to execution by the user. A playback

can also be considered a program memory that can be recalled during a show.

Ordercode: 50700

SM-8/2

Set Up and Operation

Follow the directions below, as they pertain to your preferred operation mode.

Before plugging the unit in, always make sure that the power supply matches the product specification

voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

Connect the device to the main power supply. The device can be sound-controlled as it is equipped

with a built-in microphone.

Resetting the System

Warning: this will reset the controller to its factory defaults. This will erase all programs and settings.

01) Turn off the unit.

02) Press and hold down the BANK UP and AUTO/DEL buttons.

03) Switch the unit on (while still holding down the BANK UP and AUTO/DEL buttons).

04) All LEDs will blink to indicate a successful reset. This process may take up to 30 seconds.

Warning: This will reset the controller to its factory defaults.

This will erase all programs and settings.

Fixture Addressing

The SM-8/2 is programmed to control 16 DMX channels per fixture. Therefore, the fixtures you wish to

control with the corresponding FIXTURE buttons on the unit must be spaced 16 channels apart from each

other (check the respective fixture’s manual for how to enter the information into the fixture).

Note: failure to use these DMX assignments may cause a lack of control of the fixtures.

Physical Fader Assignment (optional setup)

Use this feature to combine or unify fixture control attributes for different fixtures. For example; if you were

controlling 4 moving mirrors and 4 moving yokes - the color, gobo and dimmer channels may not line up

ideally on the physical faders. Use this function to re-assign the dimmer, color and gobo channels to

faders 1, 2 and 3. From now on you will be able to control the same attributes on all fixtures using the

same fader location.

01) Press and hold down the PROGRAM & TAPSYNC buttons to access the channel assignment mode.

02) Press the SCANNER button that represents the fixture whose faders you would like to re-assign.

03) Move the SPEED fader until you arrive at controller channel (number).

04) Move the FADE TIME fader to select the DMX channel.

05) Press the MIDI/ADD button to confirm your setting.

06) Repeat steps 3-5 as often as necessary. If you wish to copy a scanner’s physical assignments to

another scanner, follow steps 7-13. If you do not wish to do this, press and hold down the PROGRAM

& TAPSYNC buttons twice, to exit mode.

Example: Copying Scanner 1 to Scanner 2

07) Press and hold down FIXTURE button # 1.

08) While holding down button # 1, press FIXTURE button # 2.

09) While holding FIXTURE buttons # 1 and # 2, press and hold down the MIDI/ADD button.

10) Release FIXTURE button # 1 first before releasing FIXTURE button # 2.

11) Release the MIDI/ADD button.

12) All FIXTURE LED indicators will flash to confirm successful copy.

13) Press and hold down the PROGRAM & TAPSYNC buttons twice, to exit mode.

Inhaltsverzeichnis

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
