SHOWERFORCE 911-M Montageanleitung

NewTeam Ltd.

Customer Service Dept.

Brunel Road

Earlstrees Industrial Estate

Corby

Northants

NN17 4JW

1st Fold

2nd Fold

3rd Fold

✁

Please tape down

Affix

Stamp

Installation Instructions

and User Guide

PLEASE KEEP THIS BOOKLET

FOR FUTURE REFERENCE

SHOWERFORCE 911-M

MANUAL MIXER SHOWER

DEAR INSTALLER WHEN YOU HAVE READ THESE INSTRUCTIONS

PLEASE ENSURE YOU LEAVE THEM WITH THE USER

IN THE EVENT OF ANY QUERY PLEASE CONTACT

THE NEWTEAM CUSTOMER HELPLINE

Tel : 01536 264 012

Product Features

1SHOWERFORCE 911-M SHOWER VALVE

ShowerForce 911-M

Contents

SHOWERFORCE 911-M SHOWER VALVE

Please read this booklet carefully and ensure a competent person undertakes the

installation.

Note: Following the headings in sequence will guide you through the installation

and operation of your ShowerForce 911-M Mixer Shower

PLANNING YOUR INSTALLATION

FITTING YOUR SHOWER

• Plumbing

• Surface Mounted Fixing

• Recessed Fixing

USER INSTRUCTIONS

ADJUSTING MAXIMUM TEMPERATURE

COMMISSIONING

Refer to back cover for Guarantee, Customer Service and Replacement Parts Policy.

In the event of any query regarding installation please contact the NewTeam Customer

Service Department

Tel: 01536 264 012 • Fax: 01536 409 201

E-mail: [email protected] • E-mail: [email protected]

In line with our policy of continual product development the specifications may be

varied and product design altered. We reserve the right to depart from the details

given in this manual without prior notice.

Pages

Installation and Operating Instructions

for ShowerForce Manual Mixer Shower

• 911-M

SPARE PARTS 8

GUARANTEE 10

FIXING YOUR SHOWER 6

Planning Your Installation

3SHOWERFORCE 911-M SHOWER VALVE

911-M

• Make your connection into the hot water supply from the cylinder ensuring

that it is the first draw off below the expansion pipe tee. (Fig. 1).

• If this is not possible, a direct connection must be made from the hot water

cylinder with an Essex flange.

• The cold water should be taken directly from the cold water storage tank

and must be positioned 60mm below the cold connection to the hot water

cylinder, Fig 1.

• It is recommended that non restrictive isolating valves are incorporated

into the shower supply pipework.

• The temperature of your stored water must not exceed 65ºC. A stored

water temperature of 60ºC is considered sufficient to meet all normal

requirements in line with the British Standard 6700.

General

Hot Water Tank

Cold Water Storage Tank

1m. (39”) min.

Fig 1 - Typical Installation Diagram

Mixer

1 Metre

Min.

60mm

Cold Hot

Mains

Water

Supply

Fitting Your Shower

SHOWERFORCE 911-M SHOWER VALVE

Fitting your Shower

• Determine the position at which the mixer valve is to be installed. This is normally

chest height, - approximately 1 - metre above the bath base or shower tray.

• If the pipework is to be concealed, or the valve is to be recessed, the pipes should

be installed at this time.

• If surface mounting the valve with concealed pipework, the pipes must terminate

15mm above the finished wall surface.

• If the valve is to be recessed, a channel must be prepared for the valve and

pipework, approximately 140 mm wide and between 40 and 60 mm deep, with

the pipework terminating at 96 mm centres.

• In all cases the pipes should be installed with the hot supply on the right hand

side viewed from the front. If the pipework is reversed, a "reverse indice" may be

obtained from Showerforce Customer Service department.

• Before commencing installation, remove the retaining ring and shroud, and

identify all components using the illustration and parts list.

Plumbing

Surface Mounted Fixing - Fig 2

• Remove the inlet elbows (1) from the valve body (2) and, using a few turns of PTFE tape

to seal, refit in the final position for the required pipework entry, i.e. top, bottom or rear.

Using PTFE tape to seal, screw the shorter (chamfered) end of the outlet nipple (3) into

the valve body.

• Position the wall bracket (4) against the wall and mark the two upper fixing holes on

the wall. Drill the wall at the marked positions, and insert the wall plugs supplied. Fix

the wall bracket and valve using the screws supplied.

NOTE.

• The wall bracket is used for top, bottom or concealed (rear) pipe connection. The two

inlet caps should be pulled off the bracket for top and bottom feed – the illustration

shows the position for bottom feed, it must be turned through 180 degrees for top

feed. For concealed entry, the inlet caps should be left in position as received, and the

bracket fixed to the wall as for bottom pipe entry.

• Bring the inlet pipework to the valve. Flush out the pipework and connect using the

15mm compression nuts and olives supplied.

• Place the shroud (5) over the valve with the apertures in appropriate positions to

accommodate the inlet pipework and outlet nipple. If the valve has concealed inlet

pipes, ensure that the pegs on the inlet caps locate correctly in the holes in the shroud.

• With the shroud in place, screw the retaining ring (6) onto the valve body, fit the handle

(7) to the shaft, and secure using the screw supplied (8).

• Insert the indice (9) into the recess in the handle and press into place.

• Fit the outlet cap into the hole in the top of the shroud. The wide, raised slot in the

cap fits into the rear (wall side) slot in the shroud hole.

Fig. 2 - Diagram of Surface Mounted

Mixer Valve

5SHOWERFORCE 911-M SHOWER VALVE

Fitting Your Shower

Recessed Fitting - Fig 3

• It is essential that when installing a recessed mixer valve, full access to the

valve can be achieved for servicing purposes. Rear access to the mixing valve is

always preferred wherever possible, (e.g. airing cupboard or panelled wall)

as this removes the need to disturb any tiling or decorative features at the front

of the valve. Isolation valves should be fitted on both supplies and ensure that they are

accessible and maintained.

• Position the valve body (2) in the recess and mark the fixing screw positions on the wall,

drill the wall and insert the wall plugs supplied.

• Remove the inlet elbows (1) from the valve body and, using a few turns of PTFE tape

to seal, refit in the final position for the required pipework entry, i.e. top, bottom or rear.

Using PTFE tape to seal, screw the longer, flat end of the outlet nipple into the valve

body. Fix the valve to the wall, flush out the pipework and connect using the 15mm nuts

and olives supplied.

• Determine the position for the shower union elbow (3), and using a length of 15mm

pipe and suitable fittings, connect to the valve outlet nipple. The union elbow requires

a 1/2” BSP female FI connection.

• If conditions permit, it may be possible to make

the connections prior to finally fitting the valve to

the wall.

• Make good the wall as necessary, and fit the recessed

cover (4) over the valve body and secure using the

2 x 35mm screws supplied.

• Fit the handle and indice as described in the surface

mounted instructions (above).

Fig. 3 - Diagram of Recessed Mixer Valve

Commissioning

• Ensure the mixer valve is in the "off" position (see User Instructions), but do not

connect the handset. Turn on the cold isolating valve, and run the shower on the

cold setting for 2-3 minutes to clear any debris from the pipework.

• Attach the handset to the hose, and turn on the hot water isolating valve. Run the

shower in the full flow position, and starting with the handle full left (max. cold),

gradually turn the handle clockwise to the full right extreme (max. hot), noting the

temperature rise.

• If the temperature does not rise, suspect supplies are connected the wrong way

round, check and either correct, or obtain a reverse indice from Showerforce

Customer Service.

• If the temperature is too hot on the full hot position, it is necessary to either adjust

the hot water temperature, or set the temperature limit stop.

SHOWERFORCE 911-M SHOWER VALVE

Before proceeding with fitting the rail, identify each of the items

supplied using the illustration.

The slider need not be removed from the rail during fitting. The top of

the slider has a smooth profile, whereas the underside has a recess

revealing the grooves on the handset holder.

Fit the hose retainer onto the bottom end of the rail and secure using

the small screw from the kit.

Position the rail on the wall, bearing in mind the heights of people

likely to use the shower, and the length of the hose when connected to

the shower and passed through the hole in the hose retainer. Mark the

wall to indicate the upper fixing screw position. Screw centres are 605

mm (approx. 23 inches,) apart.

Drill the wall at the marked fixing position using a 6 mm drill, and

loosely fix the rail end, checking that the rail is hanging vertically using

the spirit level incorporated into the top end of the rail. The bubble

should be exactly between the two lines on the spirit level body. Mark

the position for the lower fixing screw, move the rail to one side, drill

the wall, and fix the lower end of the rail.

Check that the rail is vertical and tighten both fixing screws.

Slide the end cap into position on the top end of the rail, and fit the

screw cover into the recess in the hose retainer.

When fitting the hose, it should pass through the hole in the hose retainer.

Hose connections should be handtightened only.

NOTE: The hose nut, and not the handset handle, fits into the slider,

and the slider moves more freely on the rail if gripped next to the rail,

rather than at the handset.

Spirit Rail Kit

No Part Description

1Rail end cap

2Spirit level

3-4 Rail with slider attached

5Hose retainer & Gel Hook

6Screw cap

7Hose retainer fixing screw

Rail fixing screws &

wall plugs

Fig 4 - Riser Rail

Fitting Your Shower Rail

Adjusting Maximum Temperature

7SHOWERFORCE 911-M SHOWER VALVE

The mixer valve allows the showering temperature to be set at a safe level, preventing

accidental selection of high temperatures. This setting should be made during

commissioning and will require that the hot water cylinder is at its normal operating

temperature.

Procedure:

Refer to Fig 5 & Fig 6

• Prise out the indice (1) from the recess in the handle, and remove the handle

fixing screw (2).

• Remove the handle (3) and retaining ring (4).

• Prise off the clear temperature limit ring (5), and the green flow selector (6).

• Refit the handle to the mixer shaft, turn on the shower, and adjust the

temperature to approximately 5ºC above the comfortable showering level.

• Turn off the shower but retain the temperature setting. Refit the temperature limit

ring with the limit stop (7) touching the lower side of the pin (8) through the mixer

shaft.

• Refit the handle and check that the temperature is acceptable. Adjust as

necessary as above.

• Refit the flow selector with the "Max" slot in the 6 o’clock position.

• Refit the handle, insert the handle fixing screw and fit the indice.

User Instructions

• Pull the valve handle towards you (Fig 5) water will begin to flow from the handset.

• To regulate the water flow and pressure of your shower gently move the valve

handle (3) to and from the ‘off’ position.

Fig 6

Fig 5

Spare Parts

SHOWERFORCE 911-M SHOWER VALVE

1. SP-075-0016 Lever Fixing Cover

2. SP-075-0015-WT Handle

3. SP-075-0017-WT Recess Shroud

4. SP-075-0018-WT Surface Shroud Front

5. SP-075-0012-WT Retaining Sleeve - C/Mix-T

6. SP-075-0019-WT Surface Shroud Rear

7. SP-075-0020-WT Outlet Cap (Not Shown)

8. SP-075-0021-WT LH Inlet Cap (Not Shown)

9. SP-075-0022-WT RH Inlet Cap (Not Shown)

10. SP-088-0321 Laser Insert Prntd Showerforce

11. SP-075-0024 Recess Shroud Surface Seal (Not Shown)

12. SP-075-0025 Recess Shroud Collar Seal (Not Shown)

13. SP-280-0500-WT Spirit Rail & Slider Assembly (Not Shown)

14. SP-280-0032 Hose Retainer & Gel Hook (Not Shown)

15. SP-285-0820-WT Hose (Not Shown)

16. SP-168-0211-WT Handset (Not Shown)

Inhaltsverzeichnis

Beliebte Sanitärprodukte Handbücher anderer Marken

Weka

Weka 506.2020.00E Betriebsanleitung

Kohler

Kohler K-6228 Montageanleitung

UBERHAUS DESIGN

UBERHAUS DESIGN 75175017 Bedienungsanleitung

American Standard

American Standard DetectLink 6072121 Bedienungsanleitung

Uponor

Uponor Contec TS Bedienungsanleitung

Pfister

Pfister Selia 49-SL Bedienungsanleitung

Fortis

Fortis VITRINA 6068700 Bedienungsanleitung

Fortis

Fortis MILANO 78211JS Bedienungsanleitung

Kohler

Kohler K-12183 Montageanleitung

Maxxus

Maxxus MX-M206-01 Bedienungsanleitung

Moen

Moen 5922 Series Bedienungsanleitung

Viega

Viega Prevista Pure 8512 Bedienungsanleitung

Kohler

Kohler Centerset K-15240 Montageanleitung

Viega

Viega Prevista Dry 8522.33 Bedienungsanleitung

Sanela

Sanela Lema SLP 59RB Bedienungsanleitung

Elkay

Elkay EDF15AC Installationshandbuch

Hans Grohe

Hans Grohe AXOR Citterio E 36702000 Handbuch

baliv

baliv WT-140 Bedienungsanleitung
