Showline SL BEAM 300 FX Bedienungsanleitung

SL BEAM 300 FX

Showline Offices

Document Number: SL BEAM 300 FX QuickStart Guide

Version as of: 27th Jan, 2015

SL BEAM 300 FX QuickStart Guide

Dallas

10911 Petal Street

Dallas, TX 75238

Tel: +1 214-647-7880

Fax: +1 214-647-8030

Auckland

19-21 Kawana Street

Northcote, Auckland 0627

New Zealand

Tel: +64 9 481 0100

Fax: +64 9 481 0101

Asia

Unit C, 14/F, Roxy Industrial Centre

No. 41-49 Kwai Cheong Road

Kwai Chung, N.T., Hong Kong

Tel: +852 2796 9786

Fax: +852 2798 6545

Europe

Rondweg zuid 85

Winterswijk 7102 JD

The Netherlands

Tel: +31 (0) 543-542516

www.philips.com/showline

SL BEAM 300 FX QUICKSTART GUIDE

SL BEAM 300 FX QuickStart Guide

SL BEAM 300 FX

About Quickstart Guide

Included Items

Each SL BEAM 300 FX includes the following items:

Figure 1: Included Items

Warnings and Notices

When using electrical equipment, basic safety precautions should always be followed including the following:

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

D o n o t use outdoors.

D o n o t mount near gas or electric heaters.

E q u i p ment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized personnel.

T h e u se of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

D o n o t use this equipment for other than intended use.

R e f e r service to qualified personnel.

SAVE THIS DOCUMENT FOR FUTURE REFERENCE! READ COMPLETELY BEFORE INSTALLING AND USING PRODUCT!

WARNING: You must have access to a main circuit breaker or other power disconnect device before installing any wiring. Be sure that

power is disconnected by removing fuses or turning the main circuit breaker off before installation. Installing the device with power on may

expose you to dangerous voltages and damage the device. A qualified electrician must perform this installation.

WARNING: Refer to National Electrical Code® and local codes for cable specifications. Failure to use proper cable can result in damage to

equipment or danger to personnel.

WARNING: This equipment is intended for installation in accordance with the National Electric Code® and local regulations. It is also

intended for installation in indoor applications only. Before any electrical work is performed, disconnect power at the circuit breaker or

remove the fuse to avoid shock or damage to the control. It is recommended that a qualified electrician perform this installation.

Service and Maintenance

For all service and maintenance issues, please contact your local Showline office or an Authorized Service Center.

Power Requirements

The SL BEAM 300 FX operates on AC input voltages from 100 to 240 VAC.

SL BEAM 300 FX

QuickStart Guide

AC Input Cable 1.5M

Omega Mounts

(this document)

This Quickstart Guide is intended for a knowledgeable user to unpack, install, and use SL BEAM 300 FX in a short time period. For the complete

manual in PDF format, please visit our web site at : and click the user manual download link on the product page. The www.philips.com/showline

complete manual provides you all information related to accessories, menu structures, DMX channel mapping/modes,and care for your new luminaire.

SL BEAM 300 FX QUICKSTART GUIDE

QuickStart Guide

WARNING: This unit does not contain an ON/OFF switch. Always disconnect power input cable to completely remove power from unit when not in use.

Maximum amount of units that may be daisy-chained is (A) 10 units 100VAC (15 Amps) or (B) 20 units 240VAC (15 Amps). Refer to

Table1for detailed information at various voltages.

Note: For wiring of AC input connector, refer to . Connecting SL BEAM 300 FX to AC Power

Ta ble 1: SL BEAM 300 FX Voltage vs. Current

WARNING: *These figures are based on the Maximum Allowable Input Current of 15 Amps. Do not overload circuits!

IMPORTANT AC POWER CONNECTION NOTES:

DO NOT CONNECT OTHER TYPES OF LUMINAIRES OR DEVICES!

Connecting Power

Units can be powered in one of two ways:

D i r e c t connection to a AC power source using an AC input cable. For wiring of AC input connector, refer to Connecting SL BEAM 300 FX

to AC Power.

C o n n e ction from the AC output of another SL BEAM 300 FX. When using this method, it is very important not to

connect any other type of equipment.

Connecting SL BEAM 100 RGBWLED Luminaires to AC Power

Table 2: AC Input Connections

Wire Color

WARNING:

Purpose

WARNING: Only connect other SL BEAM 300 FXs to the AC Output (Thru) connector of a SL BEAM 300 FX.

Table 2, AC Input Connections describes how to connect power to your SL BEAM 300 FX. Field wiring of the SL BEAM 300 FX is

straight forward. A total of 3 wires/conductors is supplied to this unit.

100 1803.50 1.954 7

4 8

5 9

6 9

6 10

5 8

110 1903.18 1.84

160 2402.19 1.46

150 2302.34 1.52

140 2202.50 1.59

130 2102.69 1.67

120 2002.92 1.75

170 2.06

Only use approved cable types.

When using the daisy-chain connection method, only connect SL BEAM 300 FX to AC Output Connection of SL BEAM 300 FX.

Do not overload circuits!

Do not connect SL BEAM 300 FX to dimmed circuits.

Black

White

Green

Main/Line(100 to 240 VAC)

Neutral

Ground(Earth)

SL BEAM 300 FX

SL BEAM 300 FX QUICKSTART GUIDE

QuickStart Guide

AC Power Operation

When connected to an AC source, the unit operates on 100 to 240 volts AC (+/- 10%, auto-ranging). The luminaire contains an auto-ranging power supply.

Each luminaire can draw up to 350 Watts.

Voltage

(AC)

Voltage

(AC)

Total

Current(A)

Total

Current(A)

Maximum

number of units

that can be linked

together*

Maximum

number of units

that can be linked

together*

AC Input and Output Connections

4. Mounting Luminaire

Back of Unit

AC Input AC Output

Truss / Hanging Applications

The SL BEAM 300 FX is provided with the ability to hang via truss hooks, clamps, etc. (sold separately).

Figure 2: AC Input connection

Figure 3: Hanging Application

The SL BEAM 300 FX will be equipped with a 1m power cord with bare end for power input and a white 3pin terminal for power

output. For DMX input and output, 2 DMX plugs are installed.

4SL BEAM 300 FX QUICKSTART GUIDE

SL BEAM 300 FX

QuickStart Guide

SAFETY CABLE: Is sold separately and recommended

for all hanging installation and may be required by

national and local codes. Use enclosure handles for

safety cable anchor points for this fixture.

LCD Display and Menu System

The SL BEAM 300 FX’s LCD Display and Menu System provides local control for accessing the following fixture’s settings:

Presets (Standard and User Defined)

Color Filter

Effects (Chases - preloaded and user defined)

Strobe / Timing

Settings

Lock Fixture (to prevent changes)

Password

Status

Note: If there are multiple luminaires in a system, changes would need to be made at each LCD Menu as desired. For

Upon power up, the LCD will display the main screen showing the product type/name. If DMX is enabled, the

programmed address will appear after power up.

SL BEAM 300 FX

Home (menu settings)

Edit a Preset Edit a Chase

DMX512 Addressing

Return to Main Screen

LEFT Arrow Button UP Arrow Button

OK (Check Mark) Button

DOWN Arrow Button

RIGHT Arrow Button

LCD Display

NOTE: Menu rotates with orientation of Luminaire and

menu buttons are always in the same position (with

rotation of menu)

To rotate menu 180 degrees manually from current

orientation, press and hold the two center buttons for 2

seconds.

Figure 4: Menu System

SL BEAM 300 FX

SL BEAM 300 FX menu structure, please refer to the complete user manual

5 SL BEAM 300 FX QUICKSTART GUIDE

SL BEAM 300 FX QuickStart Guide

EditaPreset

M12%

R0%

G0%

B0%

W0%

OFF AllPixel

Edit a Preset

To edit and save a DMX address:

EditaChase

UserChase:2

MasterIntensity 39%

TotalSteps 3

EditUserChase

Fade 100%

Speed 1S

Edit a Chase

Address

Step 1. Press Edit a Preset button. Current preset will be shown.

Step 2. Use LEFT and RIGHT arrow buttons to scroll through all presets.

Step 3. Once at desired preset, use UP and DOWN arrows to access (highlight) preset parameters. Once in

desired parameter, use LEFT and RIGHT arrow buttons to adjust parameter value as desired.

Step 4. Once all values are adjusted as desired, press OK (Check Mark) button.

Step 5. Save preset menu option will appear. Use LEFT and RIGHT arrow buttons to select preset number.

Step 6. If saving preset, press OK (Check Mark) button. Confirm choice.

Step 7. Preset is now saved.

Step 3. Once at desired Chase, use UP and DOWN arrows to access (highlight) Chase parameters. Once in

desired parameter, use LEFT and RIGHT arrow buttons to adjust parameter value as desired.

Step 4. Once all values are adjusted as desired, press OK (Check Mark) button.

Step 5. Save Chase menu option will appear. Use LEFT and RIGHT arrow buttons to select Chase number.

Step 6. If saving Chase, press OK (Check Mark) button. Confirm choice.

Step 7. Chase is now saved.

Step 1. Press Edit a Chase button. Current chase will be shown.

Step 2. Use LEFT and RIGHT arrow buttons to scroll through all chases (Built In and User Chases).

Step 1. Press DMX Address button. Current DMX Address will be shown.

Step 2. Press OK (Check Mark) button to highlight a digit in the DMX address.

Step 3. Use LEFT and RIGHT arrow buttons to scroll through all digits.

Step 4. Once at desired dight, use UP and DOWN arrows to change highlighted digit. Once digit is set, use

LEFT and RIGHT arrow buttons to set other digits in DMX address.

Step 5. Once all digits are set in DMX address, press OK (Check Mark) button.

Step 6. DMX will display and is saved.

The LCD Display Menu system consists of several categories. Use the Menu Buttons to access and make changes to the menu items. When the

desired menuitems is reached, press the desired Menu Button to display the menu options and to navigate and configure the menu options as required.

LCD Display and Menu System Operation

Quick Selection Buttons

Edit a Preset Button

Edit a Chase Button

DMX Address Button

To navigate and access menu settings/selections:

Step 1. Make sure unit is powered on.

Step 2. Press the desired button ( as shown in ) to access menu categories.Figure 4

Step 3. Use UP/DOWN/LEFT/RIGHT buttons to navigate through the various options and settings.

Step 4. Make changes as desired.

Step 5. Press CHECK MARK (OK) button to accept changes.

When in Manual Mode, the SL BEAM 300 FX features can be accessed via the on-board LCD menu system or via three quick select buttons:

Edit a Preset Button

Edit a Chase Button

DMX Address Button

To edit and save a preset:

To edit and save a Chase:

Note: for Built In Chases, only the Speed and Fade farameters may be changed and saved. For User Chases, Chase

Number, Total Steps, Speed, and Fade Parameters may be changed and saved.

SL BEAM 300 FX QUICKSTART GUIDE

SL BEAM 300 FX

QuickStart Guide

Dallas

10911 Petal Street

Dalls, TX 75238

Tel: +1 214-647-7880

Fax: +1214-647-8031

Asia

Unit C, 14/F, Roxy Industrial Centre

No. 41-49 Kwai Cheong Road

Kwai Chung, N.T., Hong Kong

Tel: +852 2796 9786

Fax: +852 2798 6545

Auckland

19-21 Kawana Street

Northcote, Auckland 0627

New Zealand

Tel: +64 9 481 0100

Fax: +64 9 481 0101

Europe

Rondweg zuid 85

Winterswijk 7012 JD

The Netherlands

Tel: +31 (0) 543-542516

2015 Philips Group
