SignaMax 065-7707 Bedienungsanleitung

User‘s Guide

8-Port 10/100/ BaseT/TX +

Model: 065-7707

User‘s Manual

Revision A1

Table of Contents

CHAPTER 1 About this User’s Guide................................................................. 4

1.1 Usage.................................................................................................................4

1.2 Overview of this User’s Guide .........................................................................4

CHAPTER 2 Introduction............................................................................................. 5

2.1 Overview of the product ...................................................................................5

2.2 Features and Specification ................................................................................5

2.2.1 Features...................................................................................................5

2.2.2 Specification ...........................................................................................6

CHAPTER 3 Installation Guide............................................................................. 7

3.1 Installation.........................................................................................................7

3.1.1 Hardware Installation on the desktop ..................................................7

3.1.2 Hardware Installation on the Rack.......................................................7

3.1.3 Power Supply.......................................................................................7

3.2 Appearance of the Switch ..............................................................................8

3.2.1 Front panel ...........................................................................................8

3.2.2 Back Panel ...........................................................................................8

3.3 Notice.............................................................................................................9

CHAPTER 4 WEB Management...........................................................................10

4.1 Summarization .............................................................................................10

4.2 Connection of WEB Management ...............................................................10

4.2.1 Preparation .........................................................................................10

4.2.2 Connection .......................................................................................14

4.3 WEB Management Interface and Operation................................................15

4.3.1 System................................................................................................16

4.3.2 Port.....................................................................................................19

4.3.3 Mac Forward......................................................................................25

4.3.4 VLAN ..............................................................................................27

4.3.5 Trunk................................................................................................28

4.3.6 QoS ..................................................................................................29

CHAPTER 5 Out-of-Band Management....................................................... 33

5.1 Introduction..................................................................................................33

5.2 Out-of-Band Connection..............................................................................33

5.3 The interface and operating way of TELNET/Out-of-Band........................34

5.4 Cli command and assist of use........................................................34

5.4.1 Phrase Help ........................................................................................34

5.4.2 Command Usage Illumination ..............................................................35

5.4.3 General command .................................................................................35

CHAPTER 6 Telnet Management..................................................................... 38

6.1 Summarization .............................................................................................38

6.2 Telnet connection method ............................................................................38

6.3 Connection ...................................................................................................40

CHECKLIST

The following contents should be in your box:

One Switch

One AC power cable

One Serial cable

One user’s Guide

L-type Brackets

Note: If any of the listed contents are damaged or missig, please contact the retailer from whom

you purchased the Switch for assistance.

CHAPTER 1

ABOUT THIS USET’S GUIDE

Thank you for the purchase of 8-Port Fast Ethernet management switch. The

switches provide a full range of management capabilities, superior performance, simple to use, is a

working group to enhance your performance ideal.

1.1 Usage111111111111111111111111111111111111111111111111111111111

This User’s Guide tells you how to use 065-7707 management switch.

1.2 Overview of this User’s Guide1111111111111111111111111111111111

Chapter 1 About the User’s Guide

Chapter 2 Introduction Describes the switch and its features

Chapter 3 Installation Help you to get started with the basic installation of the switch

Chapter 4 General conception of Switch

Chapter 5 WEB Management

Chapter 6 Out-of-Band Management Describes how to management

Chapter 7 Telnet Management

CHAPTER 2

INTRODUCTION

2.1 Overview of the product111111111111111111111111111111111111111

065-7707 8-Port Fast Ethernet management switch fully complies with IEEE802.3

Ethernet standard, its intelligent management make it suitable for small, middle and large

networks solution.

065-7707 8-Port Fast Ethernet management switch provides powful management

functions including the system, port, network, VLAN, Truck, priority and security management

etc.

You can manage the switch through WEB browser and you can also check the system

configuration, modify IP network parameter, and modify login password through the RS232 serial

port.

2.2 Features and Specification 1111111111111111111111111111111111111

2.2.1 Features1111111111111111111111111111111111111111111111111111111111111111

●Fully comply with IEEE 802.3,IEEE 802.3u

●Support IEEE 802.3x flow control for full-duplex mode and collision-based

backpressre for half-duplex mode

●065-7707 support 8 10/100M Auto-Negotiation RJ45 ports

●Support RJ-45 port Auto MDI/MDIX

●Provide one DTE equipment configuration serial port.

●Support 8 Port VLAN, 256 IEEE 802.1 Q Tag VLAN

●Support MTU VLAN group.

●Support MAC address binding

●Support port trunk function

●Support Port Mirror

●Support port priority, TOS priority, IEEE 802.1 p priority protocol mode

●Support IEEE 802.1p priority mapping

●Support broadcast storm control, it can reduce and divide broadcast storm

●support Port-based bandwidth restrictions

●Support WEB management interface, local Xmodem and telnet TFTP upgrade

●Support the passage of the TFTP configuration file import and export

●Support the static IP address setting and from the DHCP server to obtain IP

address switch dynamicly

●Support of the Super Terminal, Telnet, and so on a variety of management

●Dynamic LED indicator, provide simple work state indication and malfunction obviation

●Internal excellent power supply, high stability and reliability

2.2.2 Specification 11111111111111111111111111111111111111111111111111111111111

Model 065-7707

Standards and Protocols IEEE802.3 、IEEE 802.3u、IEEE 802.3x

Port No. 8

Network Medium 10Base-T：UTP category 3 or above；100Base-TX：UTP category 5；

MAC Address table 4K

Backboard bandwidth 1.6G

Filter and Transfer

Rates 10Mbps：14880pps；100Mbps：148800pps；

10/100M Link/ActLED

Indicator Other Power

Dimension(L×W×H)

(mm) 230×147×44

Environment

Operating Temperature

：0℃～40℃；Operating Humidity 10％～90％non-condensing;

Storage Temperature：-40℃～70℃；Storage Humidity 5％～90％

non-condensing

Input Input：180-260VAC，50-60Hz；

Fig 2-1 065-7707 specification table

CHAPTER 3

INSTALLATION GUIDE

3.1 Installation1111111111111111111111111111111111111111111111111111

Follow these steps to install the switch:

The surface must support at least 5kg

The power source must be within 1.5m

¾Make sure the power cable has connected to the power socket in the back panel of the switch

and the power supply slot.

¾Make sure the switch is in a breezy environment and good for cooling the switch. Don’t put

heavy things on the switch.

3.1.1 Hardware Installation on the desktop 1111111111111111111111111111111111

1.Put the switch upside-down on a steady and big enough desk

2.Tear off the protective paste on the 4 pads, and paste them in the 4 circular slots in the

underside of the switch.

3.Turn the switch over, and put it on the desktop.

3.1.2 Hardware Installation on the Rack1111111111111111111111111111111111111

The dimension of the switch is compliant with the EIA(Electronic Industries Association)

standard 19 in rack.

1. Fix up the 2 L-type Brackets on the two lateral side of the switch. (The accessories contain the

bolts)

2. Put the switch on the shelf.

3. Fix up the switch (bolts is provided by the user.)

Fig 3-1 L-type Brackets installation

3.1.3 Power Supply111111111111111111111111111111111111111111111111111111111

The power supply input of the switch is AC 180-260V(50-60Hz), the internal power system

of the switch can auto-regulate the working power according to the actual input power. When

the switch is power on, the Power indicator light on the front panel of the switch shines.

Notice：

When the power supply is off, to make sure the switch won’t be damaged by sudden great

power, please pull off the power cable from the power supply socket. And plug in when the power

supply is well balanced.

3.2 Appearance of the Switch111111111111111111111111111111111111

Describe the front panel and back panel of the switch in details.

3.2.1 Front panel11111111111111111111111111111111111111111111111111111111111

065-7707 front panel is made up of 8 10／100Mbps ports, 1 Console port （RS232 serial

port）and LED indicators, as the following:

Fig 3-2 065-7707 Front Panel

●Serial Port

Serial Port (Console port or RS232 port) is on the right of the front panel. It’s the port for

connecting to the computer when use the Out-of -band Management. You can configure the

system information, network parameter and security management through CLI.

●8 10Base-T/100Base-TX RJ-45 port

They support 10Mbps or 100Mbps bandwidth joint equipment, and they all support

auto-negotiation. Each port has 2 LED indicators, Link/Act indicator, and Speed indicator.

Indicators

●System indicator

Indicators are on the left of the panel.

1. Link/Act indicator

When a port is connected to 100Mbps equipment, the relative LED shines green light, and

when there is data transferring, the LED blinks.

2. Speed indicator

When a port is connected to 100Mbps equipment, the relative LED shines green light.

3. Power indicator

It’s on the left. When the switch power supply is on, the indicator shines red light. If the

indicator doesn’t shine, check if the power supply is connected.

3.2.2 Back Panel111111111111111111111111111111111111111111111111111111111111

There is a power supply socket in the back panel of the switch. The power input

is :180-260V～50Hz-60Hz。

Fig 3-3 065-7707 Back Panel

Power supply socket

This is a two-circuit three-phase Power supply socket. Plug the cathode pin of the power

cable in this socket, and plug the anode pin in the AC power supply.

3.3 Notice1111111111111111111111111111111111111111111111111111111

1) When moving the switch, be careful and keep steady. If the switch falls down, it may suffer

serious damage.

2) The switch requires normal power supply for working at normal, please check if the power

supply is compliant with the power requirement of the switch.

3) To reduce electric shock dangerous, don’t open the case of the switch when it’s working, and

don’t try to open it yourself even when power off.

4) If the switch is connected to the workstation, server, HUB or other switch by UTP cable, the

UTP cable should be not longer than 100m.

¾For 10Base-T Ethernet, the cable used should be UTP category 3 or above.

¾For 100Bas-TX Ethernet, the cable used should be UTP category 5 or above.

¾You can plug in or pull out the cable when the switch is working. It won’t disturb the

switch.

¾If you want to clean the switch, please pull out the power pin first, and use wet cloth to

clean, don’t use liquid.

¾Don’t put the switch near water or wet environment, to avoid that the water or moisture

gets in the switch.

¾Please avoid the dusty environment and environment with strong Electromagnetic

Interference.

Inhaltsverzeichnis

Andere SignaMax Schalten Handbücher

SignaMax

SignaMax C-300 Series Bedienungsanleitung

SignaMax

SignaMax 065-7910HPOEP Bedienungsanleitung

SignaMax

SignaMax SC30010 Bedienungsanleitung

SignaMax

SignaMax 065-7006 Bedienungsanleitung

SignaMax

SignaMax FO-065-7030Q Bedienungsanleitung

SignaMax

SignaMax 065-7726SPOE Bedienungsanleitung

SignaMax

SignaMax SC10010 Bedienungsanleitung

SignaMax

SignaMax 098-8026 Bedienungsanleitung

SignaMax

SignaMax 065-7940B-WS Bedienungsanleitung

SignaMax

SignaMax I-100 Series Bedienungsanleitung

SignaMax

SignaMax C-310 Series Bedienungsanleitung

SignaMax

SignaMax C-600 Series Bedienungsanleitung

SignaMax

SignaMax 065-7727S Bedienungsanleitung

SignaMax

SignaMax FO-065-7732AF Bedienungsanleitung

SignaMax

SignaMax 098-8280 Bedienungsanleitung

SignaMax

SignaMax 065-7931 Bedienungsanleitung

SignaMax

SignaMax 065-7434 Bedienungsanleitung

SignaMax

SignaMax C-300 Series Bedienungsanleitung

SignaMax

SignaMax 065-7310F Series Bedienungsanleitung

SignaMax

SignaMax 065-7508 Bedienungsanleitung

SignaMax

SignaMax 065-7520 Bedienungsanleitung

SignaMax

SignaMax CommandView 098-8025 Bedienungsanleitung

SignaMax

SignaMax C-100 Series Bedienungsanleitung

SignaMax

SignaMax FO-065-7732A Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
