Silvan Selecta RP70N-S7 Bedienungsanleitung

Instruction Manual

MANRP50-4 REV I 20/04/20

RAKPAK PLUS 70L 12V SPRAYERS

RP70N-S7, RP70N-S10

VICTORIA (HEAD OFFICE)

Telephone: +61 (03) 9215 2700

Fax: +61 (03) 9215 2701

www.silvan.com.au

NEW ZEALAND

Hamilton, New Zealand

Telephone: +64 (07) 8496 033

Fax: +64 (07) 8496070

www.silvannz.co.nz

SILVAN AUSTRALIA PTY. LTD.

ABN 48 099 851 144

No liability can be accepted for any inaccuracies or

omissions in this publication, although due care has been

taken to make it as complete and accurate as possible.

The information, illustrations and technical data were

considered to be correct at the time of preparation.

In accordance with our policy of continuous development

Silvan Australia Pty. Ltd. reserves the right to make changes

at any time without notice.

YOUR SPRAYER DETAILS

Record the details of your Rakpak Sprayer here for future reference when

discussing service with your Silvan dealer, ordering service parts or making a

warranty claim.

DATE OF DELIVERY _____________________________

SELLING DEALER _____________________________

ADDRESS _____________________________

TELEPHONE NO. _____________________________

PRODUCT CODE _____________________________

SERIAL NUMBER _____________________________

INSTALLED BY _____________________________

Silvan Warranty

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensation for any other

reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or

replaced if the goods fail to be of acceptable quality and the failure does not amount to a major

failure.

We warrant our goods to be free from defects in materials and workmanship for the warranty period

of 12 months from the date the product is delivered to the consumer.

Silvan warrants its authorised Dealer, who in turn warrants the original purchaser (consumer) of each

new Silvan product that it will repair or replace the product, or, pay the cost of repair or replacement,

as determined by Silvan without charge for labour or any defective or malfunctioning parts in

accordance with the warranty limitations below.

This Warranty is in addition to any other rights and remedies available to consumers under the law

This Warranty Covers

Only conditions resulting directly from defects in workmanship or material under normal use and

service.

Warranty Exclusions

The Warranty does not cover:

•Conditions resulting from misuse, use of incompatible chemicals, exceeding machine

specifications including overloading, impact damage, negligence, accidental damage or failure to

perform recommended maintenance services as specified in the Owner/Operator Manual

applicable to the product.

•Damage caused by continued use of a product after initial failure

•Any product which has been repaired by other than an authorised Silvan service outlet in a way

which, in the sole and absolute judgment of Silvan, adversely affect its performance or reliability.

•The replacement of maintenance items such as diaphragms, batteries, V belts and ground

engaging components, etc.

How To Claim Warranty

Return the goods to the place of purchase at your cost and within the warranty period along with

evidence of the purchase date. If the original supplier cannot be contacted, then contact Silvan as

below and we can direct you on how to proceed with your warranty claim.

How Your Claim Will Be Managed

The repair of a defective product qualifying under this warranty will be performed by any authorised

Silvan service outlet within a reasonable time following the delivery of the product, at the cost of the

owner, to the service outlet’s place of business. The product will be repaired or replaced depending

on the extent of the problem at the discretion of Silvan and the Silvan dealer.

Warranty

Warning! This sprayer is designed and manufactured solely for the purpose of applying agricultural

chemicals to plants. Under no circumstances may it be used for any other purposes.

Warning! Prior to installing or using the sprayer all operators must have read and fully understood

the contents of this instruction manual and the safety decal fitted to the sprayer.

Warning! Never allow an inadequately trained person to install or operate the sprayer.

Warning! When installing the sprayer on a vehicle do not exceed the vehicle manufacturer’s

specified safe load and carrying capacity when the sprayer tank is full. Exercise extreme

care when operating in hilly or uneven terrain to ensure proper stability. Refer also to the

vehicle manufacturer’s operating and safety instructions.

Warning! Stability may be affected by water surging inside the spray tank.

Warning! Refer to the chemical manufacturer’s label for correct use and safe handling instructions

of chemicals before filling or using the sprayer. Always wear the recommended safety

clothing and equipment when handling chemicals and operating the sprayer. Ensure that

all operators and associated personnel are familiar with the legal regulations and codes

of practice that apply to the safe use, storage, and disposal of spray chemicals

Warning! Before carrying out maintenance work, wash the sprayer thoroughly to remove all toxic

chemicals that may contaminate the sprayer.

Warning! Never point the spray gun at any person or any part of the human body.

Warning! Do not pump flamable liquids or operate the pump in an explosive environment.

The wording of the Safety decal is shown below. All operators must be made aware of the decal and

follow its instructions.

The decal must be fitted to the machine at all times in the location shown. If the decal is missing or

unreadable it should be replaced by ordering a new decal from your Silvan dealer under part

number, DEC 48.

Safety Instructions

Before attempting to operate or install the sprayer carefully read and take note of the

following safety warnings.

Failure to comply with these warnings may result in serious injury or death.

GENERAL

The Silvan 70 litre Rakpak Plus is a compact portable sprayer. Whether you are a commercial grower, or hobby

farmer, you will find many uses for this unit. The tank, pump and spray lance fittings are corrosion resistant

and suitable for applying weedicides, herbicides, insecticides, fungicides, organic and green formulations.

It has been solely designed for mounting on four-wheel ATV. The Rakpak is designed for spot spraying but may

be used in conjunction with a boom for boom spraying.

SPECIFICATIONS

PUMP AND CONTROLS

There are different models available. All feature

Viton Valves and Santoprene diaphragm with an

On-Off pressure sensing power switch

SPOT SPRAY PUMPS

•Aquatec 552 Series Smoothflo 12-volt DC

electric, 7 L/min open flow, Max 120psi on

demand electric pressure switch.

The 552 Series Smoothflo pump is designed with

adaptive pressure sensing technology that

prevents pressure spikes while maintaining

higher pressures and flows

BOOM SPRAY PUMPS

•Aquatec 555 Series 12-volt DC electric, 12

L/min open flow, Max 60psi on demand

electric pressure switch.

On-Off power switch mounted to the protective

pump cover for ease of use and are supplied with

3 metre power looms with alligator clamps for

connection to 12-volt battery and a rubberised

fuse holder on positive lead fitted with

automotive type 10-amp fuse.

DIMENSIONS

Length

800

Width

850

Height

390

Weight (dry)

12 kg

Nominal capacity

70 litres

TANK

•70 Litre translucent tank moulded from U.V.

stabilized and impact resistant polyethylene.

•135mm filler neck with screw on anti-spill

breather lid.

•Calibrated fill mark moulded into tank as well

as recesses for locating tie down straps and

spray lance for transport.

FILTRATION:

Wire mesh foot filter on suction line, removable

for cleaning.

DELIVERY HOSE: 6 metre length

SPRAY GUN Lightweight, 600mm Stainless steel

lance with adjustable nozzle.

IMPORTANT INFORMATION ABOUT SPOT SPRAYERS

To ensure long life of this spot sprayer please read the following.

This product features a positive displacement diaphragm pump with a pressure sensing switch. The pressure

switch interrupts power to the pump when the system pressure builds towards maximum and power is

resumed to the motor when the pressure falls. The pressure switch does not in any way substitute for a

pressure regulator.

When the spray lance trigger is depressed fluid is released and the pressure will drop allowing the pressure

switch to resume power to the pumps motor.

If the pump is subjected to rapid pulsation/cycling during normal operation, or for infrequent periods it may

reduce the life of the pump. Applications which exhibit rapid pulsation/cycling should have restrictions in the

nozzle minimized by fitting a larger (less restrictive nozzle) Pulsation can cause premature failure of the

pressure switch or pump; these failures are not as a result of the workmanship of the component.

Spotpak’s fitted with the Smoothflo model pump are designed not to pulsate and should stop pumping when

the valve or spray gun trigger is released. If the pump fails to stop pumping the pressure switch may require

re-adjustment to lower the max shut off pressure by a 1/16” Allen head screw on the head of the pump.

Specifications

FITTING TO A VEHICLE

Position the sprayer on the vehicle to minimise chemical contamination to the operator. Face the

pump away from the operator to minimize the risk of contamination due to hose failure.

The sprayer should be securely attached to any ATV or other type of vehicle that it is installed on.

The hold-down strap recesses moulded into the top of the tank can be used to positively locate tie

down straps, which should be firmly secured to approved attachment points on the ATV or other

vehicle.

The sprayer should be mounted centrally and

as near to the centre of gravity of an ATV as

possible. It should not protrude so as to cause

an obstruction. Refer to the manufacturer’s

instructions for appropriate load limits and

fitting positions.

Never fill the spray tank to a capacity beyond

the specified overall weight limit set by your

vehicle manufacturer.

Note: 1 litre of water = 1 kg.

Warning! Do not exceed the the vehicle

manufacturer’s specified safe load and

carrying capacity.

CONNECTING TO 12 VOLT DC SUPPLY

The sprayer requires a 12 volt DC power source

to operate the pump, such as the vehicle

battery. The wiring loom is fitted with alligator

clamps to facilitate connection to a normal

vehicle battery The red clamp should be

connected to the positive terminal and the

black clamp to the negative terminal.

If you need to extend the wiring loom use wire

of the same gauge or thicker.

SAFETY FUSE

The positive (red) lead incorporates a 10-amp

automotive type fuse in a rubberised holder.

This protects the pump and vehicle electrical system from damage should a short circuit occur. If a

fuse should blow determine the cause of the short circuit before replacing the fuse.

ON/OFF SWITCH

The on/off switch mounted on the metal cover operates the pump. It should be switched off when

the pump is not in use or when the tank is empty to prevent unnecessary drain of power and

overheating and damage to the pump.

Installation

10-amp

fuse

Positive (red)

Negative (black)

On/off

switch

Hold-down strap recesses

SETUP AND TESTING

It is always recommended that you first test all spray equipment thoroughly with clean water. Silvan

Rakpack’s are supplied with a blue adjustable nozzle containing a large orifice, which when twisting

the tip can allow for a greater flow of liquid. It is recommended that the adjustable nozzle is used

first with the spray gun and can be changed later if you require.

Release the elastic straps that secure the spray hose to the tank and remove the lance and hose

from the transport recesses on the tank.

1. Be sure to wear safety equipment as recommended by the chemical manufacturer before

adding chemical to the sprayer

2. Check the suction line foot filter is clean and undamaged (see Maintenance section).

3. Fill the tank with clean water.

4. With the 12-volt supply connected and the 6-meter spray hose and spray lance connected. Fit

the blue adjustable nozzle or any large orifice nozzle you may wish to use.

5. Check all hoses, hose clamps and connections for leaks or damage.

6. Switch the pump ON.

7. Depress the spray lance trigger. The pump is self-priming and will start spraying within 30

seconds.

8. Check the hose connections for leaks, if any are found stop the pump and rectify the problem

before continuing.

9. By twisting the tip of the nozzle to the coarsest droplet size, the restriction to flow is minimized

and pump pulsation will not occur.

10. Slowly twist the tip of the nozzle from a course droplet size to a fine droplet to your preference.

If the pump begins to pulsate/cycle you may require a different nozzle that is rated to allow for

higher flow rates at your selected droplet size at approximately.

11. Once the nozzle is set and the pump operates free of pulsation/cycling, the spot sprayer is ready

to be utilized for spot spraying of chemical.

•Chemical solution may now be added to the tank.

•Follow the mixing instructions and safety precautions provided by the chemical manufacturer.

Before adding concentrated chemicals, partially fill the tank with water then add the chemical

and complete filling with water.

•Wear all the safety equipment recommended by the chemical manufacturer before adding

chemical to the sprayer and whilst conducting spraying operations.

For safety, the spray gun has a catch that can be used to lock the lever closed to prevent accidental

spraying. The catch can also be used to lock the lever open for continuous spraying. This should only

be done when safe to operate in this manner and where there is no likelihood of inadvertently

spraying any person or property that may suffer damage.

Operation

Turn nozzle to adjust

spray pattern

Depress lever to spray

Move red catch back to lock

lever in ‘on’ or ‘off”

position. Only if safe to do

so.

After spraying is completed, drain unused chemicals from the tank. Rinse the tank with clean water

then operate the sprayer with clean water in the tank to clean out the pump, hose and spray lance.

Do not leave chemicals in the tank as they may settle and form solids that may block the filter.

If heavy frosts are experienced, run the sprayer until the pump and spray lines are dry. This will

prevent water freezing in the pump or spray lines and damaging the sprayer.

Warning! Dispose of unused chemical and water used for rinsing in a manner that will not endanger

people, animals or the environment in accordance with local regulations and the handling and

disposal information available from the Chemical manufacturer.

CLEANING THE FILTER

To check the filter, remove the filler cap and hook the suction hose out with a bent piece of wire.

To avoid chemical contamination do not put bare hands in the tank to remove the filter. Appropriate

protective equipment including gloves should be used whenever maintenance is carried out. Clean

the filter with a bristle brush, do not use a wire brush or sharp object as this may damage the mesh.

The filter can be pulled from the suction hose if necessary, for cleaning. When reinstalling the filter

in the tank press the suction hose into the recess to keep the filter on the bottom of the tank so

that it will fully empty.

Operation (cont.)

Maintenance

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Silvan Selecta Spritzpistole Handbücher

Silvan Selecta

Silvan Selecta 190545 Bedienungsanleitung

Silvan Selecta

Silvan Selecta TR25-S7 Bedienungsanleitung

Silvan Selecta

Silvan Selecta TR25-2 Bedienungsanleitung

Silvan Selecta

Silvan Selecta Spotpak 50L Bedienungsanleitung

Silvan Selecta

Silvan Selecta WP12-1 Bedienungsanleitung

Silvan Selecta

Silvan Selecta UP100-S7 Bedienungsanleitung

Silvan Selecta

Silvan Selecta SPOTPAK SP50-S7 Bedienungsanleitung

Silvan Selecta

Silvan Selecta DEC101213P Bedienungsanleitung

Silvan Selecta

Silvan Selecta WP16-6 Bedienungsanleitung

Silvan Selecta

Silvan Selecta 200 litres Bedienungsanleitung

Silvan Selecta

Silvan Selecta Utepak 100L Bedienungsanleitung

Silvan Selecta

Silvan Selecta TGS Bedienungsanleitung

Silvan Selecta

Silvan Selecta Supaflo 2000L Bedienungsanleitung

Silvan Selecta

Silvan Selecta Supaflo 3500 Bedienungsanleitung

Silvan Selecta

Silvan Selecta Super 400L Series Bedienungsanleitung

Silvan Selecta

Silvan Selecta 190547 Bedienungsanleitung

Silvan Selecta

Silvan Selecta TR13-1 Bedienungsanleitung

Silvan Selecta

Silvan Selecta REDLINE SPOTPAK Series Bedienungsanleitung

Silvan Selecta

Silvan Selecta Oktopus 500L Bedienungsanleitung

Silvan Selecta

Silvan Selecta TR12-2 Bedienungsanleitung

Silvan Selecta

Silvan Selecta LT30-S8 Bedienungsanleitung

Silvan Selecta

Silvan Selecta WP16-6 Bedienungsanleitung

Silvan Selecta

Silvan Selecta RP50-P1 Bedienungsanleitung

Silvan Selecta

Silvan Selecta K02A Bedienungsanleitung

Beliebte Spritzpistole Handbücher anderer Marken

SNOWJOE

SNOWJOE Sunjoe 24V-GS-LTW-RM Bedienungsanleitung

Graco

Graco 246737 Gebrauchs- und Pflegehandbuch

Binks

Binks SV100 Bedienungsanleitung

Fimco

Fimco LG-4-3-1 Bedienungsanleitung

AG SPRAY

AG SPRAY FS-ATV-25BL Bedienungsanleitung

Nordson

Nordson MicroMax 2 Bedienungsanleitung

Bonide

Bonide 051 Bedienungsanleitung

zogics

zogics Z-DAS Bedienungsanleitung

KISANKRAFT

KISANKRAFT KK-KBS-165 Bedienungsanleitung

Matrix

Matrix SG 650 Bedienungsanleitung

Anest Iwata

Anest Iwata SGA-3 Kurzanleitung

paasche

paasche VV Datenblatt

Carlisle

Carlisle DeVilbiss JGA-510 Bedienungsanleitung

Gardena

Gardena 11120 Bedienungsanleitung

Conrad

Conrad Hobby Airbrush K3 Bedienungsanleitung

wiwa

wiwa 14025 R/F Bedienungsanleitung

Graco

Graco EM 390 Bedienungsanleitung

DeVilbiss

DeVilbiss LUNA2i Bedienungsanleitung
