SilverStar Backpacker MV Bedienungsanleitung
www.silverstarmobility.com • www.pridemobility.com
(800) 800-8586 (U.S.) • (888) 570-1113 (Canada)
BACKPACKERMV-BR-10-17-08
www.silverstarmobility.com • www.pridemobility.com
(800) 800-8586 (U.S.) • (888) 570-1113 (Canada)
BackpackerBackpacker
®
MV
Base weight lift 191 lbs.1
Scooter/power chair overall
weight 350 lbs.
Maximum product width 27”
Maximum travel distance
from the ground 37”
Motor Sealed 12 volt DC
Overall platform length 44” (41” usable surface)
Maximum product
wheelbase 41”
Warranty 3-year
transferable
Optional battery pack 12 volt, on-board
Optional charger 110 volt
1Weight does not include any accessories
2Vehicle dependent
Can easily lift the following current Pride®Scooters2
• Celebrity®X 3 & 4
• Go-Go®Ultra X 3 & 4
• Go-Go Elite Traveller®/
LR 3 & 4
• Go-Go Elite Traveller®
Plus 3 & 4
• Go-Go Elite Traveller®
Plus HD 3 & 4
Can easily lift the following
current Pride®Power Chairs2
• Jazzy®600
• Jazzy®614/614 HD
• Jazzy®1113 ATS
• Jazzy Select®
• Jazzy Select®6
• Jazzy Select®6 Ultra
• Jazzy Select®Traveller
• JetTM 3 Ultra
Can easily lift the following
current Quantum®Power Chairs2
• Quantum®600/600 XL
• Quantum®610
• Quantum®614
• Quantum®1103 Ultra
• Quantum®1121
• Quantum®6000
• Quantum®6000 XL
• Quantum®6000Z
• Quantum®R4000
BackpackerBackpacker
®
MV
1Weight does not include any accessories
2Vehicle dependent
• Legend®3 & 4
• Maxima 3 & 4
• Rally®3 & 4
• Revo®3 & 4
• Sundancer®
• Victory® 10 3 & 4
Interior Lift
• Industry first
• Industry exclusive
• Charges the mobility
device from the lift
as you drive
NEW, OPTIONAL MULTI-PURPOSE BATTERY BOX
BackpackerBackpacker
®
MV
Backpacker®MV in lowest position.
Interior Lift
Now you can take your mobility on the road easily
in your Sport Utility Vehicle with the Backpacker®
MV from Silver Star Lifts and Ramps. It’s the
ultimate solution to lifting your powered mobility
device into your vehicle, engineered specifically
to be a perfect fit for a wide variety of popular
vehicles including SUVs. Like all Silver Star Lifts,
the Backpacker MV features all-steel construction
and a protective finish, along with an industrial
rated 12 volt motor and battery pack, and easy-
to-use controls to combine rugged durability with
safe, simple and reliable operation.
The information contained herein is correct at the time of publication; we reserve
the right to alter specifications without prior notice.
Note: The Backpacker®MV can lift all of the listed power chairs
with contoured, Synergy®or Specialty seating. Please call Customer
Service when requesting information about lifting with a power
positioning system. Can fit into most SUV’s and mini-vans with little
or no vehicle modification, full-size vans require modification.
BackpackerBackpacker
®
MV
• One piece, fully assembled drive-on/drive-off platform
• Removable, front drive panel for easier serviceability
• New, adjustable wheel chocks on the platform surface
• Single piece horizontal drive rail: Minimum welding
points for noise reduction, increased rigidity, and more
fluid movement
• New, angled, low-profile platform
• Easy-to-use 2 button hand control
• Can lift a wide range of Pride®Scooters and Power Chairs
and other manufacturers’ mobility devices
• 350 lbs. lifting capacity
• 3-year transferable warranty
• Fits into SUVs with a 31” opening height
• Manual override
• Improved micro switch protection
• False floor available for specified vehicles through
special order to preserve vehicle aesthetics
Backpacker®MV fully loaded.
