MODEL CG-590

COMMERCIAL GRADE

SEWING MACHINE

WORKBOOK

Congratulations on the purchase of your new SINGER®

Sewing Machine! This commercial grade sewing machine

is ideal for all types of sewing, including fashion sewing,

home decorating, quilting and crafts. Your machine is

designed to deliver the ultimate combination of power,

performance and durability.

This workbook has been created as a tool for learning

various sewing techniques, which you can apply to your

own projects. We are certain that your creativity will be

inspired, and that you will have many hours of sewing

enjoyment with this easy-to-use machine, feature-packed

machine!

Enjoy!

The SINGER®Education Department

SINGER®is a registered trademark of the Singer Company Ltd.

Part # 640 5052550GM

Straight Stitch 1

Straight Stitch for Topstitching 2

Create Quilted Fabric 3

Speed Basting 4

Making Piping 5

Attaching Purchased Piping 6

Centered Zippers 7

Satin Stitch Applique 9

Lace Insertion 11

Button Sewing 13

Four-Step Buttonholes 15

Free-Motion Monogramming 17

Free-Motion Embroidery 19

Blindstitch Hem 21

Attaching Beaded Trims 23

Mending with Multi-Stitch Zigzag 24

Crazy Quilting 25

Straight Stretch Stitch for Woven Fabrics 26

Straight Stretch Stitch for Stretch Fabrics 27

Ribbing Application 28

Overedge Stitching 29

Seam Allowence with Stretch Overedge Seam Stitch 30

Attaching Elastic 31

Sewing with a Wing Needle 32

Twin Needle Sewing 33

Applying Ribbon with a Twin Needle 34

Sewing on Leather 35

Decorative Stitching 36

Joining Fabric with Herringbone Stitch 37

Decorative Stippling 38

Scallop Edges 39

NarrowHem 40

Gathering with the Cording Foot 41

Applying Trims, Cords & Braids 42

Shirring with the Gathering Foot 43

Using the Even Feed Foot to Sew Multiple Fabric Layers 45

Using the Even Feed Foot to Sew Plaid Fabrics 46

Using the Even Feed Foot to Sew Pile Fabrics 47

Sewing with the Side Cutter 48

Sewing with the Ruffler 50

Heavy Duty Commercial Grade

CG-590

Up to 1100 Stitches-Per-

Minute Sewing Speed

Machine sews faster than a standard sewing machine.

Electronic Foot Control Guarantees consistent speed with no jump starts.

Includes a regulating dial that allows for slower speeds,

regardless of the pressure applied.

60% Stronger Motor The motor is stronger than a standard sewing machine

motor, which means it can sew heavyweight fabrics with

ease.

Steel Plate on Machine

Bed

Sewing pins won’t damage the steel surface of the

machine free arm. This feature is particularly beneficial

for quilting.

Duratec™ Frame A SINGER® Exclusive. This provides rigid support and

helps prevent rusting.

Double Insulated Double insulation protects against electric shock by

creating a non-conducting barrier between the operator

and the electrical components inside.

Finger Guard Provides additional protection to keep fingers from

getting too close to the needle area. This is especially

helpful and desirable for high speed sewing.

Free Arm Provides professional results and easy access to cuffs,

collars, pant hems and other difficult-to-reach areas.

Automatic Needle

Threader

Effortless threading of the machine, including the eye of

the needle.

Drop Feed By moving the drop feed lever, conveniently located in

the front of the machine, the feed dogs lower for free

motion embroidery, stippling, or attaching a button. No

plates or covers required, just push a lever.

Utility Stitches A variety of stitches for fashion sewing, home dec and

quilting.

Stretch Stitches Specially designed stitches that add strength and

flexibility to seams, especially useful when sewing on

knitwear and super-stretch fabrics.

Additional Decorative and

Stretch Stitches

An extensive variety of stitches for fabric

embellishment, quilting, and more.

6mm Stitch Width Most stitches can be set for a maximum width of 6mm.

Automatic Built-In Four

Step Buttonhole

Buttonhole sewing is a 4-step simple process that

provides reliable results.

Balance Adjustment Dial Guarantees control for even stitching of buttonholes

and stretch stitches, even on difficult fabrics.

Infinitely Variable Stitch

Length and Width

Adjustment

Settings for length and width can be adjusted as

desired, to suit any project.

Multiple Needle Positions Needle position can be changed for individual

projects, such as inserting zippers or cording and

topstitching.

Jam-Resistant Bobbin System This is a system in which the bobbin case actually

floats above the hook, precluding thread jams. The

machine will not jam, even when sewing on sheer

fabric or no fabric at all!

Top-Loading Drop-In Bobbin The bobbin conveniently inserts-no bobbin cases to

remove or adjust. It is easy to monitor the thread

supply.

Extra-High Presser Foot Lifter There are 2 heights to the presser foot lifter. The

second height offers ¼” more clearance, which is

needed when placing multiple layers of bulky fabric

under the presser foot.

Thread Cutter Located for precise thread cutting, eliminating the

extra step of cutting thread with scissors.

Automatic Pressure System This feature automatically adjusts the pressure for

sewing on fabrics from the lightest weight tricots to

the heaviest denim, to maximize feed accuracy.

Twin Needle Capable Stitches are automatically adjusted for twin needle

sewing by just moving a lever.

Suction Cup Machine Base Holds the machine securely to the table, even when

sewing at maximum speed.

Built In Accessory Storage A back panel storage area for accessories is

conveniently located in the freearm extension bed.

Accessories Special Purpose Presser Foot

Buttonhole Presser Foot

Blindstitch Hem Presser Foot

Zipper Foot

General Purpose Foot

Finger Guard

Needle Pack

Bobbins

Touch-N-Wind™ Declutch

Bobbin Winder

Needle bar easily disengages for winding the bobbin.

SINGER®is a registered trademark of the Singer Company Ltd.

Self-Lubricating Because the machine is permanently lubricated, there is

no need to oil the machine, and no oil gets on fabric.

25 Year Limited Commercial,

School and Home Warranty

Peace of mind knowing the machine has a 25 year

limited warranty.

Portable Machine has a built-in carry handle, making it easy to

transport the machine.

Cabinet Mountable Machine can be mounted into a cabinet.

Straight Stitching

The Straight Stitch is generally used to join seams or do topstitching. It is the

most basic of the stitches and is the most commonly used. For a longer stitch

or for thicker fabrics, lengthen the Stitch Length.

Machine Set-Up:

Stitch: Straight Stitch

Pattern Selector: A

Stitch Width: 1, no width

Stitch Length: 3-4

Presser Foot: General Purpose Foot

Needle Position: Center

Materials:

(2) 4” x 4” pieces of cotton, right sides together

Procedure:

Place fabrics under the foot, matching the raw

edges with the ⅝” seam guide.

Sew the length of the fabric.

Use the Reverse Button to reinforce the seam.

Straight Stitch for Topstitching

The Straight Stitch can be sewn “on top” of the fabric so that the stitches are

visible. This is different from using the straight stitch to join a seam hidden

inside the project. A topstitch provides a decorative touch while holding the

seam allowances flat. It is also sturdy and durable.

Machine Set-Up:

Stitch: Straight Stitch

Pattern Selector: A

Stitch Width: 1, no width

Stitch Length: 3-4

Presser Foot: General Purpose Foot

Needle Position: Center

Materials:

(1) 5” x 5” piece of cotton

Procedure:

Press a 1” hem on one side of the edge.

Align the folded edge to the edge of the foot.

Sew.

Use the Reverse Button to reinforce the seam.

Create Quilted Fabric

Create your own quilted fabric with the Straight Stitch. Texture can be added to

plain fabric by just adding consecutive rows of straight stitches!

Machine Set-Up:

Stitch: Straight Stitch

Pattern Selector: A

Stitch Width: 1, no width

Stitch Length: 3-4

Presser Foot: General Purpose Foot

Needle Position: Center

Materials:

(2) 5” x 5” pieces of cotton with batting between the two fabrics,

creating a quilt-type sample

Procedure:

Sew diagonally from the top left corner to the bottom right corner.

Use the Reverse Lever to reinforce the seam.

Position the foot’s edge so that it rides on the previous row of stitching.

Sew successive rows using the edge of the foot to ensure even spacing and

straight lines.

Change the direction, sew diagonally from the top right corner to the

bottom left corner.
