SinoCastel IDD-213T Bedienungsanleitung

IDD-213T User Manual

(Rev. 1.5)

Sinocastel Co., Ltd.

September, 2014

IDD-213T User Manual

Contents

1. Introduction......................................................................................................................................................................2

2. Specifications...................................................................................................................................................................3

2.1 External Interface....................................................................................................................................................3

2.2 Status Indicator .......................................................................................................................................................4

2.3 Technical Parameters............................................................................................................................................5

3. Device Configuration....................................................................................................................................................7

3.1 PC Tool .......................................................................................................................................................................7

3.2 SMS Instructions.....................................................................................................................................................7

4. Installation Instruction..................................................................................................................................................9

4.1 SIM Card Installation.............................................................................................................................................9

4.2 OBD Port................................................................................................................................................................. 10

4.3 Device Installation............................................................................................................................................... 11

5. Functions ........................................................................................................................................................................ 14

5.1 Location Inquiry ................................................................................................................................................... 14

5.2 Regular GPS data reporting............................................................................................................................. 14

5.3 Regular G-Sensor Data Reporting ................................................................................................................ 14

5.4 Cell ID Reporting ................................................................................................................................................. 15

5.5 GPS Data Reporting in Sleep Mode............................................................................................................. 15

5.6 Data storage/Supplementary Report in Dead zones............................................................................. 15

5.7 Trip Mileage........................................................................................................................................................... 15

5.8 Alarms and Events Reporting ......................................................................................................................... 15

5.9 Intelligent Power Saving................................................................................................................................... 16

5.10 GPS/Cellular Timer............................................................................................................................................ 16

5.11 SMS Alert.............................................................................................................................................................. 16

5.12 Google Map Link............................................................................................................................................... 16

5.13 Remote Configuration .................................................................................................................................... 16

5.14 SMS Configuration ........................................................................................................................................... 16

5.15 PC Tool Configuration..................................................................................................................................... 16

6. Disclaimer....................................................................................................................................................................... 17

7. Warranty......................................................................................................................................................................... 18

8. Statement....................................................................................................................................................................... 19

IDD-213T User Manual

1. Introduction

IDD-213T is a plug-and-play GPS tracker with standard OBD II interface, it monitors

and records trip info including engine start/off time, real-time location, vehicle speed,

various alarms and events, it supports GPRS and SMS channel.

Packing List

Parts name

Quantity

Note

IDD-213T OBD Dongle

●

USB Configuration

Cable

○

OBD II extension cable

○

9-Pin deutsch wiring harness

○

6-Pin deutsch Wiring harness

○

Power cable (including 3A Fuse)

○

SOS button

○

Note: ● Standard configuration ○ Optional configuration

(Optional accessories will not be included if there is no indication in the order)

IDD-213T User Manual

2. Specifications

2.1 External Interface

Product appearance as follows：

SOS Button

Interface

GPS LED

Cellular LED

Power/OBD LED SIM Card Slot

OBD Connector

USB Interface

1. Standard OBD Connector

Connect to the 16 pin on-board Diagnostic Link Connector (DLC).

2. Mini USB interface

Connect to PC through USB configuration cable.

3. SOS button Interface

This is a SOS button interface, to connect the SOS button for emergency, interface

type is MMCX.

4. SIM Card slot

IDD-213T User Manual

2.2 Status Indicator

Indicator

Color

Status

OBD LED

Red

Solid off

Cellular LED

Orange-red

Fast blinking (on 0.5s, off 0.5s) - No SIM card or

network searching

Slow blinking (on 0.5s, off 2.5s) - Registered network

Solid on - Logged into the server

Solid off - Cellular off

GPS LED

Green

Blinking (on 1s, off 1s) - GPS signal is good

Solid on - Searching for GPS signal

Solid off - GPS off

Buzzer

Beep

One beep - Power on

Three beeps - Successful log in

Four beeps - Trip end

Five beeps - Power off

Six beeps –Trip Start

Five beeps (short beep) - Alarm indication

IDD-213T User Manual

2.3 Technical Parameters

Mechanical

Dimension

63mm (L) x 48mm (W) x 28mm (H)

Weight

50g

Interface

OBD interface: 16 pin standard OBD II

Configuration interface: Mini USB

SOS button interface: MMCX

SIM card interface: Push-Push Type

Storage

2MB FLASH, can store up to 24000 GPS data

Data Transmission

GPRS/SMS

Positioning Mode

GPS/A-GPS

Power

Working Voltage

9-36VDC

Working Currency

Average Currency: <150mA@13.8/27.6VDC

Max. Currency: <2[email protected]/27.6VDC

Sleep Currency: <10mA@12/24VDC

Internal Battery

3.7V/160mA Lithium battery

3-axis Accelerometer

+/-2g, +/-4g, +/-8g, +/-16g

GPS

Channels: 50

Sensitivity: -160dBm

Accuracy: 5m CEP

Cold start: <32s

Warm start: <32s

Hot start: <1s

Cellular

Frequency: Quad-band 850/900/1800/1900MHz

Protocol: TCP/IP

Sensitivity: -107dBm@850/900MHz

-106dBm@1800/1900MHz

Output Power: Class 4 (2W)@850/900MHz

Class 1 (1W)@1800/1900MHz

LED Indicator

Power/Cellular/GPS

Buzzer

System status/Alarm indication

Antenna

Cellular Antenna

Built-in

GPS Antenna

Built-in

Certification

E-Mark (Pending)

IDD-213T User Manual

Environment

Working

Temperature

-30℃ ~ +70℃

Storage

Temperature

-40℃ ~ +85℃

Humidity

5%～95%（no frog）

IDD-213T User Manual

3. Device Configuration

3.1 PC Tool

Download USB driver and PC Tool at http://www.sinocastel.com/en/Downloads/.

Install the USB driver and PC Tool on your PC.

Connect device to PC through USB configuration cable, open the OBD PC Tool, click

on “Help->User manual” for configuration reference.

3.2 SMS Instructions

SMS command is mainly for remote maintenance. The message content is text format.

Default secret key is the last 6 digits of the device ID. The key can only be changed

through PC Tool. SMS format is defined as follows:

3.2.1 Set IP parameters

Send SMS *SecretKey#set gprs#APN,User,Password,IP,Port*, device will reply *set

gprs#ok* or *set gprs#fail*.

e.g.: *123456#set gprs#cmnet,,,113.98.241.66,11088*

3.2.2 Read IP parameters

Send SMS *SecretKey#get gprs#*, device will reply *get gprs#APN,User,Password,

IP,Port*.

e.g.: *123456#get gprs#*

3.2.3 Set domain parameters

Send SMS *SecretKey#set domain #APN,User,Password,IP,Port*, device will reply *set

domain#ok* or *set domain#fail*.

e.g.: *123456#set domain# cmnet,,,obd.livetelematics.com,11088*

3.2.4 Read domain parameters

Send SMS *SecretKey#get domain#*, device will reply *get domain#APN,User,

Password,domain,Port*.

e.g.: *123456#get domain#*

3.2.5 Get current location

IDD-213T User Manual

Send SMS *SecretKey#position#*, device will reply

*position#http://maps.google.com /?q=latitude,longitude*.

e.g.: *123456#position#*http://maps.google.com/?q=22.536934,114.021425*

IDD-213T User Manual

4. Installation Instruction

4.1 SIM Card Installation

1. Remove the SIM card cover.

2. Insert the SIM card and press gently, a click will be heard upon successfully placing

the SIM card in its place, please follow the insertion direction marked on the SIM

card cover.

3. Put the SIM card cover back.

Note:

There is a backup battery in the device, please make sure all lights are off before inserting or

removing SIM card.
