SIRETTA QUARTZ-ONYX Kurzanleitung
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
2
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
Table of Contents
Page
Introduction 3
About Siretta 4
General Description 5
Typical Installation 6
Features 7
Specifications 10
Ordering Information 16
Radio Characteristics 17
WiFi Characteristics 17
Cellular Characteristics 19
GPS Characteristics 22
Dimensions 23
Wall Mount Bracket 24
QUARTZ-ONYX Images 25
Status LEDs 27
Interfaces 29
LAN / WAN Port 30
RS232 Interface 31
GPIO 33
Earth Point 35
Reset 36
SIM Socket 37
Antenna Connectors 38
Cellular Antenna Connector 38
GPS Antenna Connector 40
WiFi Antenna Connector 42
Power 43
Copyright Information 44
Copyright Declarations 44
Trademarks 44
Approvals 45
Disclaimer 46
Definitions 47
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
3
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
This document covers all the electrical and mechanical aspects of the QUARTZ-
ONYX 5G NR router. For programming and use of this product in a computer
network, please refer to the QUARTZ-ONYX Software Manual.
This manual is intended to guide on how to connect the QUARTZ-ONYX 5G NR
router into a computer network so that it may be used as the gateway router either to
a WAN or the 5G NR cellular network, with the option of automatic fallback between
the two. For complete network conguration, it is necessary to set up the network
using the built-in web server for which reference to the companion software manual is
required.
Introduction
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
4
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
Siretta is a wireless communications company located in Reading, United Kingdom
and has been manufacturing & supplying industrial IoT products since the early
2000s.
The product portfolio is made up of:
»Antennas, plus their associated Cable Assemblies & Adapters,
»Cellular Network Analysers
»Industrial Modems
»Industrial Routers
»Associated Cloud Management
We supply our products directly and via a worldwide network of distributors, into
numerous markets and applications across the globe.
Siretta’s distribution partners range from industrial IoT specialists through to global
catalogue organisations.
Whether you require an “off the shelf” or custom solution, Siretta has a wide portfolio
of products to t your application.
Our extensive knowledge and experience in the wireless market allows us to support
a wide range of customer applications, focusing on frequencies between 150 MHz to
6 GHz. These encompass modems, routers and antennas for:
»Cellular technologies: GSM/GPRS/3G/UMTS/4G/LTE & 5G NR, plus LTE CAT 1,
LTE CAT M & LTE CAT NBIoT
»Global positioning: GPS/GNSS
»WLAN/Wi-Fi
Whilst providing the above products for the industrial cellular market, Siretta also has
a number of antennas to cover applications for:
»Bluetooth, Zigbee, ISM band, LoRa and Sigfox
With a heavy emphasis on design, we have a team of dedicated Engineers and
Product Managers, who specialise in wireless applications.
We continually make signicant investment in R&D in our endeavour to provide
customers with market leading, future-proofed wireless solutions and work closely
with many technology partners to stay at the forefront of industrial IoT.
About Siretta
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
5
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
The QUARTZ-ONYX uses a Mediatek 880 MHz MIPS dual-core processor with
256 Mb ash and 2 Gb of DDR3 RAM. This processor runs a proprietary Operating
System based on Linux which controls the web interface and routing functionality
of the router. VPN throughput is enhanced with a hardware IPSec crypto engine
onboard the MIPS processor. The processing system is augmented with an STM32
ARM Cortex coprocessor which controls the operation of the GPIO and serial
interfaces.
The cellular capabilities of the QUARTZ-ONYX are powered by the Quectel RM500
QAE Module which uses the Qualcomm Snapdragon X55 5G Modem and is
manufactured on a leading edge 7 nm semiconductor fabrication process. Dual SIM
operation provides cellular network resilience when there may be connectivity issues.
As well as offering four Gigabit Ethernet interfaces, the QUARTZ-ONYX also offers
RS232 and RS485 interfaces that may be used to connect serial ports on products
such as door access controllers and alarm panels to the Internet.
Further peripheral connectivity is provided by an intelligent GPIO interface that can
send SMS messages on change of input state, and control outputs based on input
state or SMS messages received.
WiFi 5 comes as standard, and the QUARTZ-ONYX also optionally supports GPS
using a 56-channel u-blox 7 engine for asset tracking applications.
Three modes of networking operation are possible:
1. 5G NR cellular router where the WAN connection of the router is the 5G NR
cellular interface. In this mode all Ethernet interfaces are for LAN use. Internet
connectivity comes from the internal cellular interface.
2. WAN router where one of the Ethernet ports of the router is used as the WAN
connection. The WAN port in this case would normally be connected to a cable
or ADSL modem to obtain Internet connectivity.
3. Backup router which combines the two above modes. The router can switch
between the cellular and WAN connections automatically to maintain Internet
connectivity should one path fail. The preferred route can be set to cellular or
WAN.
General Description
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
6
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
This section explains the interfaces on the QUARTZ-ONYX and how to
connect to them. It is recommended that the SIM card necessary for Cellular
operation into the QUARTZ-ONYX be inserted rst and power applied last.
A typical installation will look like this:
Typical Installation
Figure 1. Typical system diagram
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
7
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
»4x Gigabit RJ-45 Ethernet Interfaces
»2x SIM Slots
»1x DC Power Interface (7.5 to 32 V dc)
»5x SMA Cellular antenna Interface (4x cellular, 1x GPS on
models supporting GPS)
»2x RP-SMA Wi-Fi Interface
»Serial interface that may be congured as 2x RS232 or 1x
RS485/Modbus
»2x Digital Inputs, with programmable noise lter
»2x Digital Outputs that can be set high, low or to pulse when
activated
Physical Interfaces
Features
WiFi Features
»IEEE 802.11n/ac radio supporting IEEE 802.11a/b/g/n/ac
wireless standards
»Concurrently operates in 2.4 and 5 GHz bands
»Standard Reverse Polarity SMA antenna interface
»Access point, Client, and Ethernet bridge modes of operation
»20/40/80 MHz channel width
LAN/WAN Features
»3x Gigabit LAN & 1x Gigabit LAN/WAN (user congurable)
»Hardware NAT capable of 2 Gbps wire speed
»Auto-MDI/MDIX
Cellular Features
»Support for 5G NR (NSA & SA), LTE (4G) and WCDMA (3G)
networks
»Dual SIM operation with failover and backup modes
»Network locking
»Network disconnection checking
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
8
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
5G NR Features
»Supports 3GPP Release 15 features
»Supports NSA (Non-Standalone Architecture) and SA (Standalone Architecture) modes of operation
»Supports FDD and TDD modes
»Supports Frequency Range 1 bands (Sub 6 GHz bands)
»MIMO support
»Maximum downlink speed 2.1 Gbps (SA mode); 2.5 Gbps (NSA mode)
»Maximum uplink speed 900 Mbps (SA mode, band n41); 650 Mbps (NSA mode)
LTE (4G) Features
»Supports Cat 16 download and Cat 18 upload speeds
»Supports FDD and TDD modes
»Supports MIMO in download direction
»Maximum downlink speed 1.0 Gbps
»Maximum uplink speed 200 Mbps
WCDMA (3G) Features
»Supports GPS constellation
»Client and server modes of operation
»10 Hz update rate
»NMEA 0183 & proprietary M2M format supported
»Cold start time to rst x typically 29 seconds
»TCXO oscillator for high performance
»Active antenna support
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
9
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
»Supports GPS constellation
»Client and server modes of operation
»10 Hz update rate
»NMEA 0183 & proprietary M2M format supported
»Cold start time to rst x typically 29 seconds
»TCXO oscillator for high performance
»Active antenna support
GPS Features
»Hardware Crypto Engine delivering 400~500 Mbps IPSec throughput
VPN Features
»Power – Power applied
»Cellular Signal – signal quality & connection status
»LAN – connection status and activity
»WAN – connection status and activity
»WLAN – connection status and activity
»Error – Cellular online/ofine status
LED Indication
»Galvanised steel box with grounding point
»Wide operating temperature range
»Supplied with DIN rail adapter (with accessories version only)
»Supplied with mounting plate to attach to a at surface such as a wall or
cabinet (with accessories version only)
Physical
Registered in England No. 08405712
VAT Registration No. GB163 04 0349
Siretta Ltd
Basingstoke Road
Spencers Wood
Reading
Berkshire RG7 1PW
sales
email
web
+44(0)118 976 9000
www.siretta.com
10
QUARTZ-ONYX
Hardware Manual
Download Latest Edition
Parameter Value
Operating Temperature -30 to +75°C
Storage Temperature -40 to +85°C
Humidity Range 0 to 95% RH non-condensing
Table 1. Environmental Characteristics
Physical
Specifications
Environmental
Mechanical
Table 2. Mechanical Characteristics
Parameter Value
Dimensions 132 mm x 112 mm x 44 mm (excluding protruding connectors)
Weight 472g (excluding antennas, SIM card, connectors and packaging)
IP Rating 30
Power Supply Requirements
Table 3. Power Supply Requirements
Parameter Value
Input supply voltage 7.5 – 32 V
Minimum power supply rating 24 W
Recommended Power Supply 12 V @ 2.0 A
Power
Andere Handbücher für QUARTZ-ONYX
1
Dieses Handbuch passt für folgende Modelle
4
Inhaltsverzeichnis
Andere SIRETTA Netzwerk-Router Handbücher
SIRETTA
SIRETTA QUARTZ-GOLD-W21-5G Kurzanleitung
SIRETTA
SIRETTA QUARTZ-COMPACT-UMTS Kurzanleitung
SIRETTA
SIRETTA QUARTZ-GOLD-5G Kurzanleitung
SIRETTA
SIRETTA QUARTZ Bedienungsanleitung
SIRETTA
SIRETTA QUARTZ-W22-UMTS(EU) Bedienungsanleitung
SIRETTA
SIRETTA QUARTZ-ONYX Bedienungsanleitung
SIRETTA
SIRETTA routeCONNECT MICA LTE Kurzanleitung
SIRETTA
SIRETTA QUARTZ-GOLD 5G NR Bedienungsanleitung
SIRETTA
SIRETTA QUARTZ-GOLD Kurzanleitung
SIRETTA
SIRETTA QUARTZ Series Kurzanleitung
Beliebte Netzwerk-Router Handbücher anderer Marken
NETGEAR
NETGEAR FS526T - Switch Bedienungsanleitung
Korenix
Korenix JetNet 5710G Series Bedienungsanleitung
Automated Logic
Automated Logic ZN551 Betriebsanleitung
Cisco
Cisco ASR 1000 Series Bedienerhandbuch
EnGenius
EnGenius ESR-9710 Bedienungsanleitung
Cisco
Cisco 805 Series Bedienungs- und Sicherheitshinweise
