SkyLink AM-100 Bedienungsanleitung

P/N. 101A365 JULY, 2005 PATENTED

Home Smart Center

www.skylinkhome.com

CUSTOMER SERVICE

17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3

Tel : (905) 456-8883

Fax : (905) 456-7819

Email : [email protected]

MODEL: AM-100

Home Smart Center

USER'S INSTRUCTIONS

English

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions should

always be followed to reduce the risk of fire, electric shock and injury to

persons, including the following:

1. Do not use this product near water, for example, near a bath tub, wash

bowl, kitchen sink or laundry tub, in a wet basement or near a swimming

pool.

2. Avoid using a telephone (other than a cordless type) during an

electrical storm. There may be a remote risk of electric shock from

lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not

dispose of batteries in a fire. They may explode. Check with local codes

for possible special disposal instructions.

5. Plug the adaptor to the socket-outlet that near the equipment and

shall be easily accessible.

SAVE THESE INSTRUCTIONS

–

Declaration of Conformity

Application of Council Directive(s) :

Radio Equipment and Telecommunication Terminal Equipment

Directive (1999/5/EC) - R&TTE

Standard(s) to which Conformity is Declared:

EMC:

EN 55022:1998+A1: 2000, EN 610000-3-2: 2000,

EN 61000-3.3: 1995 +A1:2001, EN 55024: 1998+A1: 2001,

EN 50130-4: 1995/A1: 1998, EN 300220-3: 2000,

EN 301489-3: 2002

Safety:

EN 60950-1: 2001, EN 50371: 2002

Telephony:

TBR 21: 1998

Manufacturer’s Name: Capital Prospect Limited

Manufacturer’sAddress: Room 3, 13/F, Block B, Veristrong Industrial Centre,

36 Au Pui Wan Street, Fo Tan, N.T., Hong Kong

Type of Equipment: Home Smart Center

Model No.: AM-001

Serial No.: Not Labelled

Year of Manufacture: 2005

I, the undersigned, hereby declare that the equipment specified above conforms to the above

Directive (s) and Standard(s).

Place: Hong Kong Joe Ng

Project Manager

Date: 21st July 2005

–

IC Statement

‘’This product meets the applicable Industry Canada technical

specifications.”

Before installing this equipment, users should ensure that it is permissible

to be connected to the facilities of the local telecommunications com-

pany. The equipment must also be installed using an acceptable method

of connection. In some cases, the company’s inside wiring associated

with a single line individual service may be extended by means of a

certified connector assembly (telephone extension cord). The customer

should be aware that compliance with the above conditions may not

prevent degradation of service in some situations.

Repairs to certified equipment should be made by an authorized Canadian

maintenance facility designated by the supplier. Any repairs or alterations

made by the user to this equipment, or equipment malfunctions, may give

the telecommunications company cause to request the user to disconnect

the equipment.

Users should ensure for their own protection that the electrical ground

connections of the power utility, telephone lines and internal metallic water

pipe system, if present, are connected together. This precaution may be

particularly important in rural areas.

Caution: Users should not attempt to make such connections themselves,

but should contact the appropriate electric inspection authority, or electri-

cian, as appropriate.

‘’The Ringer Equivalence Number is an indication of the maximum

number of terminals allowed to be connected to a telephone inter-

face. The termination on an interface may consist of any combination

of devices subject only to the requirement that the sum of the Ringer

Equivalence Numbers of all the devices does not exceed five.’’

g) Should you experience trouble with this equipment, please contact

Skylink Customer Support at 1-800-304-1187 for repair or warranty

information. If the equipment is causing harm to the telephone network,

the telephone company may request that you disconnect the equipment

until the problem is resolved.

h) Please follow instructions for repairing if any (e.g. battery replacement

section); otherwise do not alternate or repair any parts of device except

specified.

i) Connection to party line service is subject to state tariffs. Contact the

state public utility commission, public service commission or corporation

commission for information.

j) NOTICE: If your home has specially wired alarm equipment connected to

the telephone line, ensure the installation of this model AM-001 does not

disable your alarm equipment. If you have questions about what will

disable alarm equipment, consult your telephone company or a quali-

fied installer.

NOTICE: According to telephone company reports, AC electrical surges,

typically resulting from lightning strikes, are very destructive to telephone

equipment connected to AC power sources. To minimize damage from

these types of surges, a surge arrestor is recommended.

–

CONTENT

Introduction..........................................................................................................................4

Overview........................................................................................................................4

Installation...........................................................................................................................7

InstallingtheConsole.................................................................................................7

ProgrammingPasswords..........................................................................................9

PhoneNumberProgramming..................................................................................10

InstallingDoor/WindowSensors.............................................................................12

InstallingMotionSensor...........................................................................................13

Operation..............................................................................................................................15

Alertmode...................................................................................................................15

Mute....................................................................................................................................16

SystemStatus..............................................................................................................17

ArmingTheSystem.....................................................................................................17

Disarmingthesystem...............................................................................................18

Disarming a triggered control panel.....................................................................19

DisarmingunderDuress..........................................................................................19

Panic...................................................................................................................................20

SystemFailure............................................................................................................20

PhoneLineFailure............................................................................................20

SensorFailure.....................................................................................................21

LowBattery...........................................................................................................21

Coummunication.............................................................................................................23

Receivingan emergencycall..................................................................................23

Remote Operation by Telephone...........................................................................24

Toaccess thecontrolpanelawayfromhome......................................................24

AdvancedProgramming.................................................................................................26

Zone Dependent Setting – Beep / Alarm..............................................................26

Zone Dependent Setting – Auto Mute....................................................................29

ZoneDependent Setting– AlertZone (Bypasszone).........................................30

LearnKeychain/KeypadRemotes........................................................................32

EraseKeychain/KeypadRemotes........................................................................33

LearnSensors..............................................................................................................34

SensorLocationSelectionGuide.............................................................................34

EraseSensors...........................................................................................................36

HomeAutomation.............................................................................................................37

Learn Control Modules............................................................................................37

EraseControlModules............................................................................................40

Event Trigger..............................................................................................................42

TroubleShooting..............................................................................................................44

Accessories......................................................................................................................46

System Configuration.....................................................................................................49

FCCInformation................................................................................................................50

CE........................................................................................................................................52

FCC Information

Consumer Information:

a) This equipment complies with Part 68 of the FCC rules and the require-

ments adopted by the ACTA. On the bottom of this equipment is a label

that contains, among other information, a product identifier in the format

US:AAAEQ##TXXXX. If requested, this number must be provided to the

telephone company.

b) An applicable certification jacks Universal Service Order Codes (USOC)

for the equipment is provided (i.e., RJ11C) in the packaging with each

piece of approved terminal equipment.

c) A plug and jack used to connect this equipment to the premises wiring

and telephone network must comply with the applicable FCC Part 68

rules and requirements adopted by the ACTA. A compliant telephone

cord and modular plug is provided with this product. It is designed to be

connected to a compatible modular jack that is also compliant. See

installation instructions for details.

d) The REN is used to determine the number of devices that may be con-

nected to a telephone line. Excessive RENs on a telephone line may

result in the devices not ringing in response to an incoming call. In most

but not all areas, the sum of RENs should not exceed five (5.0). To be

certain of the number of devices that may be connected to a line, as

determined by the total RENs, contact the local telephone company. [For

products approved after July 23, 2001, the REN for this product is part of

the product identifier that has the format US:AAAEQ##TXXXX. The digits

represented by ## are the REN without a decimal point (e.g., 03 is a

REN of 0.3). For earlier products, the REN is separately shown on the label.]

e) If this equipmentAM-001 causes harm to the telephone network, the

telephone company will notify you in advance that temporary discontinu-

ance of service may be required. But if advance notice isn’t practical, the

telephone company will notify the customer as soon as possible. Also,

you will be advised of your right to file a complaint with the FCC if you

believe it is necessary.

f) The telephone company may make changes in its facilities, equipment,

operations or procedures that could affect the operation of the equipment.

If this happens the telephone company will provide advance notice in

order for you to make necessary modifications to maintain uninterrupted

service. –50–

–

INTRODUCTION

Overview

Congratulations on your purchase of a Skylink Home Smart Center. This is a

complete wireless system which not only functions as a security system, but

also monitors your premises by giving you alert notification when the system is

not armed. It is also a home automation center, which allows you to remotely

control household appliances and lights, even when you are away from home.

It can be controlled by dialing in from any touch tone phone, which makes it

even more convenient and powerful. Additional accessories such as different

kinds of sensors and controllers can be added to suit your specific needs.

This user instructions will guide you through the whole setup procedure as well

as all the programming instructions. Please follow the instructions closely, you

should find it very easy to set up the system.

In the package, you should find the following items:

•One Control Panel

•One Motion Sensor

•Two Door / Window Sensors

•One Keychain Remote

Alert

When Home (System Not Armed)

Beep Beep

Alarm

Not Home (System Armed)

Alarm

Automation

Communicator

AM-001

PS-101

WD-101

4B-101

Master Password ____________________

Secondary Password ____________________

Duress Password ____________________

ZONE SENSOR 1 SENSOR 2 BEEP / ALARM AUTO MUTE EVENT TRIGGER ALERT

Example Front Door Front Window Beep / Alarm Y / N Disabled / On / Off Y / N

Sensor locations and settings

Phone number settings

PHONE MEMORY PHONE NUMBER REDIAL COUNT REPEAT COUNT

Example 321-123-4567 5 5

Keychain / Keypad Remotes settings

KEYCHAIN / KEYPAD LOCATIONS OWNER (KEYCHAIN) / LOCATION (KEYPAD)

Example Keychain Owner - John

Control Modules settings

CONTROL MODULES LOCATIONS / APPLIANCES

Example Family room lighting

SYSTEM CONFIGURATION

–

INTRODUCTION

–

•OneACadapter

•One telephone cord

•Batteries for all sensors

- 1 PC 9V Alkaline Battery (PS-101)

- 1 PC 12V Alkaline Battery Type 23A

(4B-101 -installed)

- 2 PCS 3V Lithium Battery CR-2032

(WD-101 -installed)

•Four AAA backup batteries for Control Panel

•Mounting hardware

Basic installation involves the following procedures:

1. Install Control Panel AM-001

2. Program Passwords

3. Program Phone Numbers

4. Install Door / Window Sensors WD-101

5. Install Motion Sensor PS-101

Mounting

Plate

Ball-head

joint

Screws

Pack

Control Module SW-100

(US and Canada)

- To turn home appliances / lights on / off

- Max rating: 960W (Resistive)

Control Module SW-101U (UK), SW-101F

(French), SW-101G (German)

(3 models for 3 countries)

Emergency Dialer (AD-433S)

- External dialer with user programmable voice

message

- Calls up to 9 phone numbers

- One personal voice recording up to 40 seconds

- Can be installed anywhere within 100 feet from

the control panel, with a phone socket

Swing door opener (DM-100)

- Remotely open / close a swing door

- Fits most interior doors

ACCESSORIES

905-608-9223

AD-433

–

INTRODUCTION

]

1615

1. Zone LEDs

2. Numeric Keypad

3. Arm button

4. Status button

5. Mute button

6. Panic button

7. Power LED

8. Arm LED

9. Program LED

10. System Low Battery LED

11. Built-in Siren and Speaker

12.Antenna

13. Programming button

14. Buzzer Mode Selector

15. Phone Jack for external phone

16. Line Jack for telephone line

17.Adaptersocket

18. Battery Compartment

19. Language Selector (only available for

models with multiple languages)

–

3 4 5 6

ACCESSORIES

Audio Sensor (AS-101)

- When audio level exceeds preset limit, it will trigger the

alarm

- Place beside smoke detector, CO detector, so when these

detectors are triggered, the control panel will be triggered

Remote Control (4B-101)

- Additional keychain remotes for other family members

- To arm, disarm or trigger the panic alarm with this remote

Keypad Control (KP-434)

- External keypad control

- To arm, disarm or trigger the the panic alarm with this

remote

- Ideal mounting locations include upper floor, backdoor, or

garage

Wrist Watch Style Panic Remote (HW-434)

- Activate the panic alarm instantly with this remote

- Wear it as a watch

- Splashproof design, can be worn during showering

Panic Transmitter (PT-434)

- Activate the panic alarm instantly with this remote

- Wear it as a pendant

- Splashproof design, can be worn during showering

Audio Alarm (AA-433)

- External Siren

- Powered by AC adapter with backup battery

-43

–

INSTALLATION

Installing the Console

You must first determine where the control panel will be located. Please follow

the criteria below to select the ideal location for the control panel.

- Place it within a few feet of an electrical outlet and phone jack

- Place it where it is easily accessible by you and other users

- Place it away from any doors or windows which could be accessed by non-

intended users

- Place it away from extreme temperature sources such as oven, stove and

away from large metal objects which could affect the wireless performance

After you have selected a location for the control panel, you are now ready to

connect all the necessary wires and ready to power up the unit.

1.Plug in theAC adapter to a nearbyelectrical

outlet and plug the other end to the socket

labeled “DC 12V” on the back of the control

Panel. You should hear 3 beeps and

“System Phone Failure” indicating the

phone line is not connected. PWR, ARM

and PROG LEDs should be flashing, LO

BATT LED should be on.

2. Remove the battery cover on the bottom

of the control panel with a Phillips screw

driver, and insert 4 AAA alkaline batteries

into the battery holder (note the polarity).

After inserting the batteries, the LO BATT

LED should be off.

3.Connect the phone line from the telephone

jack to the back of the control panel where

it marks “LINE”. PWR will stay on and

PROG LED will stop flashing.

4. [OPTIONAL] If you have another telephone

that will be using the same telephone jack,

you may connect this telephone to "PHONE"

outlet of the the control panel by a phone

cord. (not provided).

5. Rotate the antenna to the upright position to

ensure the best signal reception.

–

Door/Window Sensor (WD-101)

- Magnetic Contact Sensor

- For all doors or windows

- Batteries included

Repeater (RP-434)

- Extend the operation range between 2 wireless devices,

such as any sensors and control panel

- Doubles the operation range automatically between

sensors and control panel

Water Sensor (FS-101)

- Alerts you when water is detected

- Ideal for water detection in basement, under the sink, even

bathroom

Garage Door MonitorTM Sensor (GS-101)

(Available in US and Canada)

- Monitors your garage door

- Alerts you when the garage door is left open

Garage Door MonitorTM Sensor (GS-102)

(Available outside US and Canada)

- Monitors your garage door

- Alerts you when the garage door is left open

Indoor/Outdoor Motion Sensor (PS-101)

- Monitors area in a 110 degree ARC and up to 40 feet away

from the sensor

ACCESSORIES

Additional sensors and transmitters as wellas add on accessories are available

to work with your system.

–

6. For models with multiple languages,

select the desired language based

on the setting below.

[1]-German

[2]-Spanish

[3]-French

[4]-English

Language

selector

INSTALLATION

–

After mounting the door sensor, it - Please ensure the magnet is aligned with

doesn’t work anymore. the red marking on the transmitter.

- If you are mounting the sensor on to a

metal door or window, a spacer may be

required to avoid magnetic interference

caused by the metal door / window.

- Make surethe sensor is within the operation

range of the control panel by bringing it

closer to the control panel.

My motion sensor is not very The motion sensor is designed to detect the

responsive, sometimes when I walk “First Motion”. First Motion means no motion

by it, the control panel doesn’t respond, is detected within the past 20 seconds,

but sometimes it does. and if a motion is then detected, that is the

“First Motion”. So if you continue to walk

in front of the motion sensor, it will only

pick up the first motion. Unless you wait

for 20 seconds, then walk again, the control

panel will respond. Otherwise, the control

will only respond to the first motion.

TROUBLE SHOOTING

–

When a sensor is triggered, the - Make sure the battery in the sensor is

control panel doesn’t respond at all, installed properly, pay attention to the

what is the problem? polarity.

- Make sure the sensor is learned to the

control panel. Follow instructions on

page 34 on how to learn a sensor.

- You may try to bring the sensor closer to

the control panel, ensure it is not out of

the operation range.

My motion sensor sometimes gets Ensure the motion sensor is not facing

triggered by itself, how can I prevent direct sunlight, nor any A/C or furnace

that? vents. You may also reduce the sensitivity

to low. If your motion sensor is located

outdoors, you may want to relocate it.

Sensors

Inhaltsverzeichnis

Andere SkyLink Steuerungssystem Handbücher

SkyLink

SkyLink SK-100 Bedienungsanleitung

Beliebte Steuerungssystem Handbücher anderer Marken

Pentair Pool Products

Pentair Pool Products Compool Bedienungsanleitung

ComfortNET

ComfortNET CTK04 Bedienungsanleitung

Fireye

Fireye InSight II 95DSS3 Bedienungsanleitung

CAME

CAME G3000 Bedienungsanleitung

Idemia

Idemia MorphoAccess VP MD Bedienungsanleitung

Axis

Axis P1445-LE-3 Bedienungsanleitung

HEIDENHAIN

HEIDENHAIN TNC 150 B Bedienungsanleitung

CNC-Step

CNC-Step High-Z T-Series Bedienungsanleitung

Doosan

Doosan DVF Series Bedienungsanleitung

Honeywell

Honeywell KAP 140 Bedienungsanleitung

Honeywell

Honeywell vk41 series Bedienungsanleitung

AirBench

AirBench FPW Installationsanleitung

Cypress

Cypress HHR-3160 Bedienungsanleitung

CAME

CAME GLT40AOS Bedienungsanleitung

Zonex

Zonex GEN II -VVT Benutzerhandbuch

Altronics

Altronics K 9650 Bedienungsanleitung

micro-trak

micro-trak RoadMaster Bedienungsanleitung

micro-trak

micro-trak Calc-An-Acre II Bedienungsanleitung
