Slider Dynamic Bedienungsanleitung
1
Click on the orange text for the particular
section you would like to see.
To get back to this page, select the Slider
logo at the bottom of each page.
If you have further questions or need to
order any spare parts, please contact us:
US:
+1 (401) 247-7745i
560 Metacom Ave.
Warren, RI 02910
UK:
0208 749 2292
info@crokeruk.com
19 Acton Park Estate
The Vale, London, W3 7QE
©2014-2015 WaterRower
TABLE OF CONTENTS
Replacing the Chain 02-03
Replacing the Flywheel 04
Replacing the Idler Sprocket 05-06
Cleaning the Flywheel 07
Cleaning the Rails 08
Oiling the Chain 09
Tightening the Bungee 10
Replacing the Bungee 11-12
Replacing the Drive Sprocket 13
Rail Troubleshooting 14
Replacing the Rail Bracket 15
Replacing the Rail Wheels 16
Replacing the Sensor 17
Replacing the Seat Wheels 18
Replacing the Handle 19
Replacing the Foot Strap 20-21
SERVICE MANUAL
2
REQUIRED TOOLS:
ALLEN WRENCH TOOL SET
SCREWDRIVER
1. Unplug Monitor. Remove the monitor cover bolts (4)
using a 3mm allen tool.
BE CAREFUL NOT TO STRIP THE BOLTS, it is
recommended on older machines to use Liquid Wrench
or WD-40, apply pressure and slowly turn as to not strip.
2. Remove the 3mm bolts (6) securing the front cover.
3. Remove top 3mm bolts (2) holding the rear cover.
SLIDER CHAIN REPLACEMENT
4. Pull the bungee chain block pulley up above the
footplate and secure using a screwdriver.
5. Undo the bolt holding the connector end of the chain.
6. Remove the original chain.
7. Remove the chain from the handle end by undoing the
two socket inserts on the rower side of the handle.
8. Pull the U Bolt from the handle.
9. Undo one insert nut and slide the chain swivel end of
the chain off.
10. Attach the new chain.
11. Thread the insert nut and turn until it is equal with the
other side on the U bolt.
12. Insert the U bolt into the handle.
13. Secure the U bolt with the socket insert nuts.
14. Once attached to the handle, place the handle on the
top rails and straighten the chain out.
3
15. Insert the open end of the chain through the plastic
chain faring opening.
16. Thread the chain over the top sprocket, then down to
the second drive sprocket on the flywheel drive shaft.
17. Thread the chain over the large plastic pulley, then down
towards the footplate.
18. Insert the chain around the small pulley on the bungee/
chain block.
19. Thread the chain back up and over the small idler pulley
then back down to the chain/bungee block pulley.
20. Holding the chain, insert one chain clip into the two
end links on the chain. Insert the other chain clip in the
opposite direction of the same two links the first chain
clip is attached to.
21. Thread the bolt through the connector plate and tighten
the nut.
22. Pull the handle to make the bungee/chain block plate
move up, and remove the screwdriver that was securing
the block in place.
23. Check that the chain is running smoothly and correctly
around all sprockets and pulleys. Use the threading
procedure picture as a guide.
24. Replace all covers and reattach monitor cable.
SLIDER CHAIN REPLACEMENT
4
REPLACING THE FLYWHEEL
REQUIRED TOOLS:
17 MM WRENCH (2)
PHILIPS HEAD SCREWDRIVER
MALLET
1. Take screws (4) out of the Flywheel Cover, Remove Cover
2. Using both 17 mm wrenches, loosen the flywheel bolt.
3. Loosen flywheel nut, take off spacer and nut. and remove
flywheel. If the flywheel won’t come off, put the nut back
on the end of the shaft and tap the nut with the mallet.
This will loosen the flywheel, and allow you to remove it.
4. Replace with new flywheel. You may need to tap on the
opposite side of the shaft for it to slide on all the way.
Take the spacer and nut and put back on the shaft.
5. Tighten bolts on both sides of the shaft. Take a few
strokes to check that is not too tight. If it is too tight,
the chain won’t recoil properly.
6. Put flywheel cover back on and put the screws back in.
5
REPLACING THE IDLER SPROCKET ASSEMBLY
REQUIRED TOOLS:
(2) 4MM ALLEN KEYS
3MM ALLEN KEY
VICE GRIPS OR PLIERS
CLOTH
1. To release bungee pressure, stand the machine up and
unclip bungees from the axle. Clip on the safety bungee
bracket (or tie off so they don’t slip into the machine).
2. Use 4mm Allen wrench to remove plastic cover (4 bolts).
3. Take 3mm Allen wrench (you may need to tap with a
mallet) and loosen the bolts on the monitor cover and
the front cover. Be careful not to strip - turn slowly with
pressure or apply WD-40/ Liquid Wrench.
6
REPLACING THE IDLER SPROCKET ASSEMBLY
4. Take bungees and chain and move to the sides of the
body. (use a tool or cloth to keep it off your paint)
5. Use two 4mm Allen wrenches on either side of idler
sprocket assembly to loosen. Once loose, take the
assembly out.
6. Put replacement assembly in. Tighten with 4mm wrench
on either side of the axle.
7. Move bungees and chain back to pulley system and put
covers back on.
8. Tighten all the covers and clip bungees back to the
Bungee/Chain Block axle.
9. Oil chain to smooth out and quiet the new sprocket
system.
7
CLEANING THE FLYWHEEL
TOOLS NEEDED:
PHILLIPS SCREWDRIVER
VACUUM
1. Take screws (4) out of the Flywheel Cover.
2. Remove Flywheel Cover
3. Use a vacuum to clean out any dust and dirt.
4. Replace the cover and screws.
8
CLEANING THE RAILS
TOOLS NEEDED:
CLOTH
MULTI-PURPOSE CLEANER
1. With a mild, multi-purpose cleaner, clean tracks and
wheels inside the rails.
2. Clean seat wheels.
3. If machines are receiving excessive use, clean daily.
9
OILING THE CHAIN
TOOLS NEEDED:
CLOTH
OIL
1. Pull chain out to the finish position and slowly retract
back while oiling with cloth. Do this from under the
chain so it does not drip on the machine or your floor.
2. Oil the full length of the chain.
3. Row 250 meters to spread the oil out to the rest
of the chain.
4. This should be done only a few times a year based on
use (otherwise the oil can build up in the gears).
10
TIGHTENING THE BUNGEE
NO TOOLS NEEDED
1. Lock the Slider and stand it up.
2. Take one bungee clip off of the axle.
3. Pull bungee towards the larger opening in the keyhole to
loosen (or ‘unlock’). Pull 2 inches through, then tighten
towards the narrow keyhole to lock into place. Clip back on
bottom pulley axle (flat side to machine body).
Repeat steps for opposite side.
Make sure both clips are back on the axle.
Slowly lower machine, unlock the plate and row.
If it still feels loose repeat above steps.
4. You may need to cut off any excess bungee. If the
bungee appears frayed or does not give ample tension
after tightening, it is time to replace your bungee.
2. pull through
two inches
3. lock into place
1. pull down to unlock
