Smeg FAB50ULCR3 Bedienungsanleitung

IMPORTANT SAFETY INSTRUCTIONS - 391477A034/A

IMPORTANT SAFETY INSTRUCTIONS 3

How to read the User Manual 3

For this appliance 8

Purpose of the appliance 9

Disposal 9

This user manual 10

Manufacturer’s liability 10

Identification plate 10

Energy label 10

To save energy 10

Light sources 10

DESCRIPTION 11

General description 11

Control panel 11

Accessories 12

USE 13

Preliminary operations 13

First use 13

Temperature setting 13

Temperature format 14

Super cold function 14

Alarm for door open 14

Using the accessories 14

Ventilation 15

Using the refrigerator compartment 15

Using the freezer compartment 16

Noises during operation 16

Heated front surface 16

Turning the appliance off 16

Storage advice 17

CLEANING AND MAINTENANCE 17

Cleaning the appliance 17

Defrosting 17

Interior lighting 17

What to do if... 18

INSTALLATION 18

Electrical connection 18

Hydraulic connection 19

Positioning 21

We advise you to read this manual carefully, which contains all the instructions for maintaining the

appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com

IMPORTANT SAFETY INSTRUCTIONS

How to read the User Manual

This User Manual uses the following definitions

of terms:

WARNING: If the instructions in this manual are not carefully

followed, fire or explosion may occur resulting in property

damage, personal injury or death.

DANGER

• failure to follow instructions immediately

may result in death or serious injury.

WARNING

• failure to follow instructions may result in

death or serious injury.

PRECAUTION

• indicates a potentially hazardous situation

which, if not avoided, may result in minor to

moderate injury.

NOTE: important information

4 - IMPORTANT SAFETY INSTRUCTIONS 91477A034/A

Notice: Proposition 65 of the State of

California

Injury to persons

• Read all instructions.

• This appliance is not intended

for use by persons (including

children) with reduced

physical, sensory or mental

capabilities, or lack of

experience and knowledge,

unless they have been given

supervision or instruction

concerning use of the

appliance by a person

responsible for their safety.

• Do not leave children

unattended: Children should

not be left alone or unattended

in the area where the

appliance is used.

• Never allow children to sit or

stand on any part of the

appliance.

• Never allow children to play

with the refrigerator and have

them use the drawers, shelves

and other parts of the

appliance only as described in

this manual.

• Never attempt to extinguish

flames/fire with water. Turn off

the appliance and cover the

flame with a fire-proof blanket

or a dry or foam

fire-extinguisher.

• Do not attempt to repair,

disassemble, or modify the

appliance yourself.

• Do not damage the coolant

circuit.

• Do not use this appliance if the

power plug or cord are

damaged.

• CAUTION: do not use

electrical equipment inside the

food storage compartments of

the appliance unless it is of the

type recommended by the

manufacturer.

• Use a non-flammable cleaner.

• Do not climb, stand or stick to

refrigerator shelves. This could

result in serious injury or

damage to the appliance.

• Cleaning and maintenance

operations to be performed by

the operator should not be

carried out by children without

supervision.

• Do not modify the appliance.

• Do not insert sharp metal

objects (knives and utensils) into

the slots.

• Do not touch (especially with

wet hands) or place in your

mouth a frozen product taken

directly from the freezer. This

can cause burns due to very

low temperatures.

• Do not store explosive or

This product may expose you to

chemicals including vinyl chloride,

which is known to the State of California

to cause cancer and prenatal defects or

other reproductive harm. See

www.P65Warnings.ca.gov for more

information.

WARNING

IMPORTANT SAFETY INSTRUCTIONS - 591477A034/A

flammable substances, such as

petrol, in or near this

refrigerator or use petrol or

other flammable vapors or

liquids in the vicinity of this or

any other appliance.

• Do not store or use gasoline or

other flammable vapors,

liquids, or materials near this or

any other appliance.

• Bottles with high alcohol

content should be tightly closed

and upright.

• Organic, acidic substances

and ethereal oils can corrode

plastic surfaces and seals if in

contact for a long time.

• Before cleaning or servicing,

turn off the appliance and

disconnect it from the power

supply.

• Do not insert the plug into the

electrical outlet with wet hands.

• Do not pull the cable to remove

the plug.

Damage to the appliance

• While in use, do not place

metal objects on the appliance,

such as knives, forks, spoons

and lids.

• Do not use abrasive or

corrosive detergents on the

glass parts (e.g. powder

products, stain removers or

metal scouring pads).

• Do not sit on the appliance.

• Do not lean or sit on the door

or on open drawers.

• Do not use steam jets to clean

the appliance.

• CAUTION: do not defrost or

clean the appliance with a

steam cleaner.

• WARNING: do not use

electrical appliances (e.g., hair

dryers, etc.) or defrosting

sprays to accelerate defrosting,

as they may deform plastic

parts, unless they are

recommended by the

manufacturer.

• Do not store liquids in cans or

glass containers in the freezer.

• Do not remove ice or frost with

sharp objects to avoid damage

to the walls of the appliance.

• CAUTION: Do not place

portable power strips or

portable power supplies in the

rear of the appliance.

• Do not place heavy objects on

top of the appliance.

• For safety reasons and to

prevent damage to the

appliance, never sit, stand or

lean on the refrigerator door.

• CAUTION: never cover or

block any ventilation openings

on the appliance.

• Do not refreeze frozen foods

that have partially or

completely thawed.

• Do not strike or press too hard

WARNING

PRECAUTION

6 - IMPORTANT SAFETY INSTRUCTIONS 91477A034/A

on glass surfaces.

• Do not pry open the door or

handle to move the appliance.

• Under no circumstances should

the appliance be used to cool

the room.

• Wear appropriate clothing.

Never wear loose or dangling

clothing when using the

appliance.

• Comply with maximum storage

times and expiration dates for

frozen products.

Installation and maintenance

• It takes two or more people to

move and install this appliance.

• This appliance is heavy and must

be secured during transport and

installation.

• Do not place the appliance

outdoors.

• CAUTION: When positioning the

appliance, make sure the power

cord is not caught or damaged.

• To prevent instability of the

appliance, install and secure it

properly according to the

instructions in this manual.

• Do not install this appliance in

prefab (mobile) homes,

recreational vehicles (RV), or

boats.

• Do not install this appliance in a

room where there is a risk of

freezing.

• The appliance should not be

exposed to sunlight.

• The appliance should not be

placed near any heat sources or

flammable materials. If this is not

possible, a suitable insulation

panel should be used.

• Always place the appliance in a

dry, well-ventilated room.

• If installed near another

refrigerator or freezer, maintain a

minimum clearance of 2 cm - 3/

4".

• Depending on the climate class to

which it belongs, the appliance

can be used in different

temperature conditions. The

climate class is specified on the

appliance nameplate.

• Observe all applicable

regulations and ordinances.

• The ground connection must be

completed in the manner

indicated in the regulations on

electric installations.

• Insert the plug into a 3-pin

grounded outlet.

• Do not remove the grounding pin.

• Do not use an adapter plug.

• Do not use an extension cord.

• Do not twist or tie the power cord.

• Do not pull or bend the power

cord.

• Do not damage the power cord

when moving the appliance.

• To avoid any danger, if the power

supply cable is damaged, contact

the technical assistance service

immediately, that will replace the

cable to prevent any risk.

• Never unplug an appliance

device by pulling on the power

cord. Always grasp the plug firmly

when pulling it out of the outlet to

avoid damaging the power cord.

WARNING

IMPORTANT SAFETY INSTRUCTIONS - 791477A034/A

• Always disconnect the appliance

from the power supply when

troubleshooting, servicing,

replacing bulbs, or cleaning.

• Have a qualified electrician

check the wall outlet and circuit to

make sure the outlet is properly

grounded.

• Qualified personnel should carry

out the installation and servicing in

compliance with existing

regulations. Service personnel

should disconnect power before

working on this appliance.

• A qualified technician must

complete the electrical

connection.

• Before any operation on the

appliance (installation,

maintenance, positioning or

movement) always wear PPE.

• Do not attempt to repair or

replace any part of this appliance

unless specifically recommended

in this manual. Any other

maintenance must be performed

by a qualified technician.

• Do not damage or drill the

coolant pipes.

• Do not damage the coolant

circuit.

• Do not use sharp instruments,

alcohol, flammable liquids, or

abrasive cleaners to remove tape

glue. Clean only with warm

water.

• WARNING: Keep ventilation

openings in the appliance

enclosure or built-in structure free

from obstructions.

• WARNING: Do not use

mechanical, electrical, or

chemical products other than

those recommended by the

manufacturer to speed up the

defrosting process.

• Do not dispose of packaging

material. Separate the various

scraps by type and consign them

to the nearest separate waste

collection center.

• Before turning on the appliance

for the first time, leave it in the

upright position for at least 2

hours.

• Leave enough space around the

appliance and install it on a flat

surface.

• Do not use the open door as a

lever to move the appliance into

place.

• Do not apply excessive pressure

to the door when it is open.

• When installing the appliance be

careful not to scratch or damage

the floor.

• Do not move back and forth or

drag the appliance when trying to

move it, as you may damage the

floor.

• Never cover or block any

ventilation openings on the

appliance.

• This equipment can be used up

to a maximum height of 2000

meters/6562 feet above sea

level.

PRECAUTION

8 - IMPORTANT SAFETY INSTRUCTIONS 91477A034/A

For this appliance

• The appliance contains a small

amount of isobutane (R600a),

take care during transport,

assembly or cleaning not to

damage the refrigeration

circuit.

• In case of damage to the

refrigeration circuit, avoid using

open flames and ventilate the

room appropriately.

• Do not operate the equipment

or any part of it other than as

specified in this manual.

• Caution: Fire hazard/

flammable materials.

•Openingthedoor for long

periods of time can cause a

significant temperature increase

in the appliance compartments.

• Regularly clean surfaces that

may come in contact with food

and accessible drainage

systems.

• Store raw meat and fish in

suitable containers in the

refrigerator so that it does not

come in contact with other

foods or drips on them.

• If the appliance is left empty for

long periods, turn it off, defrost,

clean, dry, and leave the door

open to prevent the

development of mold inside.

• Connections to the water inlet,

filter, and reservoir should be

made by qualified personnel.

• Disconnect the product and

water pump, if available, when

connecting.

• CAUTION: connect only to

drinking water supply.

• After opening the tap, check

that there are no water leaks

anywhere on the water pipe. In

the event of a leak, close the

valve and tighten all

connections using pliers or a

wrench.

• Do not attach the filter to the

product.

• The appliance's water system

must only be connected to the

cold water line. Do not connect

to hot water line.

• The ice storage box is

designed solely to hold ice. Do

not fill with water. This may

cause it to break.

• Use only the hoses supplied

with the appliance. Any existing

old hoses should not be used

or readapted with this unit.

• The cold water inlet pressure

shall be a minimum of 21 psi

(147 kPa) and a maximum of

121 psi (834 kPa).

PRECAUTION

IMPORTANT SAFETY INSTRUCTIONS - 991477A034/A

Purpose of the appliance

• This appliance is not intended

for use as a built-in appliance.

• The appliance is not intended

for professional and

commercial use.

• This appliance is designed for

cooling or preserving fresh and

frozen food at home. Any other

use is inappropriate.

• This appliance is intended for

use in household and similar

applications such as:

- The kitchen area intended for

staff in stores, offices and

other work environments;

- farmhouses, holiday farms

and by customers in hotels,

motels and other residential

settings;

- bed and breakfasts;

- catering services and similar

non-retail applications.

• This appliance is not designed

to work with external timers or

remote control systems.

Disposal

• Entrapment risk for children.

Before you throw away an old

refrigerator/freezer:

- Remove the doors.

- Leave the shelves positioned

so that children cannot easily

climb inside.

• Destroy or recycle cardboard,

plastic bags, and any outer

packaging material

immediately after unpacking

the refrigerator. Children should

NEVER use these items for play.

They can cause suffocation and

death.

• Take the appliance to a

suitable recycling center for

electric and electronic waste,

or return it to the dealer when

purchasing an equivalent

product, as a one-on-one

exchange.

Before you throw away an old

refrigerator/freezer:

• Unplug the power cord plug.

• Cut the power cord.

• Have the coolant removed and

disposed of by a qualified

technician.

• Do not let children climb, stand

or stick to refrigerator shelves.

• Do not allow children to play

with the refrigerator.

PRECAUTION

DANGER

WARNING

10 - IMPORTANT SAFETY INSTRUCTIONS 91477A034/A

This user manual

• This user manual is an integral part of the

appliance and must therefore be kept in its

entirety and within the user's reach for the

whole working life of the appliance.

• Read this user manual carefully before using

the appliance.

Manufacturer’s liability

The manufacturer declines all liability for

damage to persons or property caused by:

• use of the appliance other than that

specified;

• failure to comply with the instructions in the

user manual;

• tampering with any part of the appliance;

• use of non-original spare parts.

Identification plate

The identification plate bears the technical data,

serial number and brand name of the

appliance. Do not remove the identification

plate for any reason.

Energy label

To be informed about the performance of your

device via the EU EPREL database

visit the following web address and enter the

model name (available on the identification

plate):

https://eprel.ec.europa.eu

On the energy label there is a QR code for a

quick access to the web address. Use a device

equipped with an appropriate reading

program.

The energy label must be kept together with all

documents supplied with the appliance.

To save energy

• Correct use of the appliance, correct

packaging of foodstuffs, a constant

temperature and food hygiene have effects

on the quality of storage.

• Reduce the number of times that the doors

are opened and the length of time they

remain open to prevent the compartments

from heating up excessively.

• Clean the condenser (if it can be accessed)

at the rear of the appliance periodically to

prevent the appliance from losing efficiency.

• Defrost frozen food in the refrigerator

compartment in order to make use of the

cold stored in the frozen foods.

• Placing the shelves at different heights does

not affect the stated energy consumption.

Light sources

• This appliance contains light sources which

cannot be replaced by the user and must

only be replaced by the technical assistance

service.

• This appliance contains light sources of

efficiency class "E".

READ AND KEEP THESE

INSTRUCTIONS

DESCRIPTION - 1191477A034/A

DESCRIPTION

General description

1 Ice maker

2 Freezer cell

Useful for storing frozen foods, freezing

fresh foods and making ice cubes.

3 Fan

Useful for temperature distribution and

decreasing condensation on support

surfaces.

4 Refrigerator compartment

Useful for the preservation of fresh food.

5 Internal lighting

The interior lighting of the appliance comes

into operation when the door is opened.

6 Super cold drawer

Useful for preserving the freshness and

flavor of delicate foods such as meat and

fish for longer.

7 Crisper drawer

8 Freezer door

9 Control panel

Useful for programming temperatures inside

the refrigerator compartment and freezer

cell.

10 Refrigerator door

Control panel

1 Freezer cell temperature setting button

12 - DESCRIPTION 91477A034/A

2 Refrigerator compartment temperature

setting button

3 Freezer cell temperature display

4 Refrigerator compartment temperature

display

5 "Eco" function indicator on/off

6 Freezer cell super cold function indicator

7 Alarm warning indicator

Accessories

Shelves

For optimising fridge space and placing

foodstuffs inside the refrigerator compartment.

Fruit and vegetable drawer

For storing fruit and vegetables, maintaining a

constant humidity level.

Super cool drawer

Useful for preserving the freshness and flavor of

delicate foods such as meat, fish and lightly

frozen foods for longer, as the temperature is

consistently maintained between 28°F/

-2°C and 37°F/3°C.

Door balconies and shelves

For storing foodstuffs in small containers. The

shelf in the lower part of the door is useful for

storing bottles.

Ice maker

Useful for the automatic production of ice cubes,

ready to put on the table thanks to the

removable collection tray.

Not all accessories are available on

some models.

The accessories intended to come into

contact with food are made of materials

that comply with the provisions of

current legislation.

Original supplied and optional

accessories can be requested to

Authorised Assistance Centres. Use only

original accessories supplied by the

manufacturer.

Do not store food items to be frozen or

trays to make ice in the chill drawer.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Smeg Kühlschrank Handbücher

Smeg

Smeg FC84EN4HX Konfigurationshandbuch

Smeg

Smeg CR328APLE Bedienungsanleitung

Smeg

Smeg S8L1721F Bedienungsanleitung

Smeg

Smeg FL102A Bedienungsanleitung

Smeg

Smeg C3180FP Bedienungsanleitung

Smeg

Smeg FAB10 Bedienungsanleitung

Smeg

Smeg FD239A1 Bedienungsanleitung

Smeg

Smeg WD315A Bedienungsanleitung

Smeg

Smeg American Style Fridge Freezer FA550XBI Bedienungsanleitung

Smeg

Smeg S41STRP Bedienungsanleitung

Smeg

Smeg FC32AP Bedienungsanleitung

Smeg

Smeg FA55PCIL Bedienungsanleitung

Smeg

Smeg CD7276NLD2P1 Bedienungsanleitung

Smeg

Smeg FA560X Bedienungsanleitung

Smeg

Smeg FI227B Bedienungsanleitung

Smeg

Smeg FC40PXNFE Bedienungsanleitung

Smeg

Smeg FAB32ROR3 Bedienungsanleitung

Smeg

Smeg FR165SE Bedienungsanleitung

Smeg

Smeg 142306 Bedienungsanleitung

Smeg

Smeg FD43PXNF1 Bedienungsanleitung

Smeg

Smeg UKS8L1721F Bedienungsanleitung

Smeg

Smeg Fridge-freezer Bedienungsanleitung

Smeg

Smeg TABLE-TOP REFRIGERATOR Bedienungsanleitung

Smeg

Smeg MTE30 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
