CONTENTS

Safety information 13

Safety instructions 14

Operation 15

First use 16

Daily use 16

Hints and tips 17

Care and cleaning 18

Troubleshooting 19

Installation 21

Technical information 22

Subject to change without notice.

SAFETY INFORMATION

Before the installation and use of the appliance, carefully read

the supplied instructions. The manufacturer is not responsible

if an incorrect installation and use causes injuries and

damages. Always keep the instructions with the appliance for

future reference.

Children and vulnerable people safety

•This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved.

•Do not let children play with the appliance.

•Cleaning and user maintenance shall not be made by

children without supervision.

•Keep all packaging away from children.

General Safety

•This appliance is intended to be used in household and

similar applications such as:

–Farm houses; staff kitchen areas in shops, offices and

other working environments

–By clients in hotels, motels, bed and breakfast and other

residential type environments

•Keep ventilation openings, in the appliance enclosure or in

the built-in structure, clear of obstruction.

•Do not use mechanical devices or other means to accelerate

the defrosting process, other than those recommended by

the manufacturer.

•Do not damage the refrigerant circuit.

•Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

•Do not use water spray and steam to clean the appliance.

•Clean the appliance with a moist soft cloth. Only use neutral

detergents. Do not use abrasive products, abrasive cleaning

pads, solvents or metal objects.

•Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

•If the supply cord is damaged, it must be replaced by the

manufacturer, its Authorised Service Centre or similarly

qualified persons in order to avoid a hazard.

SAFETY INSTRUCTIONS

Installation

WARNING! Only a qualified

person must install this

appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction supplied

with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure the air can circulate around

the appliance.

• Wait at least 4 hours before connecting

the appliance to the power supply. This

is to allow the oil to flow back in the

compressor.

• Do not install the appliance close to

radiators or cookers, oven or hobs.

• The rear of the appliance must stand

against the wall.

• Do not install the appliance where there

is direct sunlight.

• Do not install this appliance in areas that

are too humid or too colds, such as the

construction appendices, garages or

wine cellars.

• When you move the appliance, lift it by

the front edge to avoid scratching the

floor.

Electrical connection

WARNING! Risk of fire and

electrical shock.

• The appliance must be earthed.

• Make sure that the electrical information

on the rating plate agrees with the

power supply. If not, contact an

electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

electrical components (e.g. mains plug,

mains cable, compressor). Contact the

Authorised Service Centre or an

electrician to change the electrical

components.

• The mains cable must stay below the

level of the mains plug.

• Connect the mains plug to the mains

socket only at the end of the installation.

Make sure that there is access to the

mains plug after the installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

Use

WARNING! Risk of injury,

burns, electrical shock or fire.

• Do not change the specification of this

appliance.

• Do not put electrical appliances (e.g. ice

cream makers) in the appliance unless

they are stated applicable by the

manufacturer.

• Be careful not to cause damage to the

refrigerant circuit. It contains isobutane

(R600a), a natural gas with a high level of

environmental compatibility. This gas is

flammable.

• If damage occurs to the refrigerant

circuit, make sure that there are no

flames and sources of ignition in the

room. Ventilate the room.

• Do not let hot items to touch the plastic

parts of the appliance.

• Do not store flammable gas and liquid in

the appliance.

• Do not put flammable products or items

that are wet with flammable products in,

near or on the appliance.

• Do not touch the compressor or the

condenser. They are hot.

Internal light

• The type of lamp used for this appliance

is not suitable for household room

illumination

Care and cleaning

WARNING! Risk of injury or

damage to the appliance.

• Before maintenance, deactivate the

appliance and disconnect the mains

plug from the mains socket.

• This appliance contains hydrocarbons in

the cooling unit. Only a qualified person

must do the maintenance and the

recharging of the unit.

• Regularly examine the drain of the

appliance and if necessary, clean it. If

the drain is blocked, defrosted water

collects in the bottom of the appliance.

Disposal

WARNING! Risk of injury or

suffocation.

• Disconnect the appliance from the mains

supply.

• Cut off the mains cable and discard it.

• Remove the door to prevent children

and pets to be closed inside of the

appliance.

• The refrigerant circuit and the insulation

materials of this appliance are ozone-

friendly.

• The insulation foam contains flammable

gas. Contact your municipal authority for

information on how to discard the

appliance correctly.

• Do not cause damage to the part of the

cooling unit that is near the heat

exchanger.

OPERATION

Switching on

1. Insert the plug into the wall socket.

2. Turn the Temperature regulator

clockwise to a medium setting.

Switching off

To turn off the appliance, turn the

temperature regulator to the "O" position.

Temperature regulation

The temperature is regulated automatically.

A medium setting is generally

the most suitable.

However, the exact setting

should be chosen keeping in

mind that the temperature inside

the appliance depends on:

• room temperature,

• how often the door is

opened,

• the quantity of food stored,

• the location of the appliance.

1. Turn the Temperature regulator toward

lower settings to obtain the minimum

coldness.

2. Turn the Temperature regulator toward

higher settings to obtain the maximum

coldness.

CAUTION! If the ambient

temperature is high or the

appliance is fully loaded, and the

appliance is set to the lowest

temperatures, it may run

continuously causing frost to

form on the rear wall. In this

case the dial must be set to a

higher temperature to allow

automatic defrosting and

therefore reduced energy

consumption.

FIRST USE

Cleaning the interior

Before using the appliance for the first time,

the interior and all internal accessories

should be washed with lukewarm water

and some neutral soap to remove the

typical smell of a brand-new product, then

dried thoroughly.

CAUTION! Do not use

detergents or abrasive powders,

as these will damage the finish.

DAILY USE

WARNING! Refer to Safety

chapters.

Positioning the door shelves

To permit storage of food packages of

various sizes, the door shelves can be

placed at different heights.

1. Gradually pull the shelf in the direction

of the arrows until it comes free.

2. Reposition as required.

Movable shelves

The walls of the refrigerator are equipped

with a series of runners so that the shelves

can be positioned as desired.

Do not move the glass shelf

above the vegetable drawer and

the bottle shelf to ensure correct

air circulation.

Temperature indicator

For proper storage of food the refrigerator is

equipped with the temperature indicator.

The symbol on the side wall of the

appliance indicates the coldest area in the

refrigerator.

If “OK” is displayed (A), put fresh food into

area indicated by symbol, if not (B), adjust

the temperature controller to a colder

setting and wait 12 hours before checking

the temperature indicator again.

After putting fresh food into the

appliance or after opening the

door repeatedly or for a long

period, it is normal for the

indicator not to show "OK"; wait

at least 12 hours before

readjusting the temperature

controller.

HINTS AND TIPS

Normal operating sounds

The following sounds are normal during

operation:

• A faint gurgling and bubbling sound from

coils sound when refrigerant is pumped.

• A whirring and pulsating sound from the

compressor when refrigerant is pumped.

• A sudden cracking noise from inside

appliance caused by thermic dilatation (a

natural and not dangerous physical

phenomenon).

• A faint click noise from the temperature

regulator when the compressor switches

on or off.

Hints for energy saving

• Do not open the door frequently or leave

it open longer than absolutely necessary.

• If the ambient temperature is high and

the Temperature Regulator is set to low

temperature and the appliance is fully

loaded, the compressor may run

continuously, causing frost or ice on the

evaporator. If this happens, set the

Temperature Regulator toward warmer

settings to allow automatic defrosting

and so a saving in electricity

consumption.

Hints for fresh food refrigeration

To obtain the best performance:

• do not store warm food or evaporating

liquids in the refrigerator

• do cover or wrap the food, particularly if

it has a strong flavour

• position food so that air can circulate

freely around it

Hints for refrigeration

Useful hints:

• Meat (all types) : wrap in polythene bags

and place on the glass shelf above the

vegetable drawer.

• For safety, store in this way only one or

two days at the most.

• Cooked foods, cold dishes, etc. : these

should be covered and may be placed

on any shelf.

• Fruit and vegetables: these should be

thoroughly cleaned and placed in the

special drawer(s) provided.

• Butter and cheese: these should be

placed in special airtight containers or

wrapped in aluminium foil or polythene

bags to exclude as much air as possible.

• Bottles: these need a cap and should be

stored on the door bottle shelf, or (if

equipped) on the bottle rack.

• Bananas, potatoes, onions and garlic, if

not packed, must not be kept in the

refrigerator.

CARE AND CLEANING

WARNING! Refer to Safety

chapters.

General warnings

CAUTION! Unplug the

appliance before carrying out

any maintenance operation.

This appliance contains

hydrocarbons in its cooling unit;

maintenance and recharging

must therefore only be carried

out by authorized technicians.

The accessories and parts of

the appliance are not suitable for

washing in a dishwasher.

Periodic cleaning

CAUTION! Do not pull, move or

damage any pipes and/or

cables inside the cabinet.

CAUTION! Take care of not to

damage the cooling system.

CAUTION! When moving the

cabinet, lift it by the front edge

to avoid scratching the floor.

The equipment has to be cleaned regularly:

1. Clean the inside and accessories with

lukewarm water and some neutral soap.

2. Regularly check the door seals and

wipe clean to ensure they are clean and

free from debris.

3. Rinse and dry thoroughly.

4. If accessible, clean the condenser and

the compressor at the back of the

appliance with a brush.

This operation will improve the

performance of the appliance and save

electricity consumption.

Defrosting of the refrigerator

Frost is automatically eliminated from the

evaporator of the refrigerator compartment

every time the motor compressor stops,

during normal use. The defrost water drains

out through a trough into a special

container at the back of the appliance, over

the motor compressor, where it evaporates.

It is important to periodically clean the

defrost water drain hole in the middle of the

refrigerator compartment channel to

prevent the water overflowing and dripping

onto the food inside.

Periods of non-operation

When the appliance is not in use for long

periods, take the following precautions:

1. Disconnect the appliance from

electricity supply.

2. Remove all food.

3. Clean the appliance and all accessories.

4. Leave the door/doors open to prevent

unpleasant smells.

WARNING! If the cabinet will be

kept on, ask somebody to

check it once in a while to

prevent the food inside from

spoiling in case of a power

failure.

TROUBLESHOOTING

WARNING! Refer to Safety

chapters.

What to do if...

Problem Possible cause Solution

The appliance does not oper-

ate.

The appliance is switched off. Switch on the appliance.

The mains plug is not con-

nected to the mains socket

correctly.

Connect the mains plug to

the mains socket correctly.

There is no voltage in the

mains socket.

Connect a different electrical

appliance to the mains sock-

et. Contact a qualified electri-

cian.

The appliance is noisy. The appliance is not suppor-

ted properly.

Check if the appliance stands

stable.

The lamp does not work. The lamp is in stand-by. Close and open the door.

The lamp is defective. Refer to "Replacing the

lamp".

The compressor operates

continually.

Temperature is set incorrect-

ly.

Refer to "Operation" chapter.

Many food products to be

frozen were put in at the

same time.

Wait some hours and then

check the temperature again.

The room temperature is too

high.

Refer to climate class chart

on the rating plate.

Food products placed in the

appliance were too warm.

Allow food products to cool

to room temperature before

storing.

Problem Possible cause Solution

The door is not closed cor-

rectly.

Refer to "Closing the door".

Water flows on the rear plate

of the refrigerator.

During the automatic defrost-

ing process, frost melts on

the rear plate.

This is correct.

Water flows into the refrigera-

tor.

The water outlet is clogged. Clean the water outlet.

Food products prevent that

water flows into the water

collector.

Make sure that food prod-

ucts do not touch the rear

plate.

Water flows on the floor. The melting water outlet is

not connected to the evapo-

rative tray above the com-

pressor.

Attach the melting water out-

let to the evaporative tray.

The temperature in the appli-

ance is too low/too high.

The temperature regulator is

not set correctly.

Set a higher/lower tempera-

ture.

The door is not closed cor-

rectly.

Refer to "Closing the door".

The food products' tempera-

ture is too high.

Let the food products tem-

perature decrease to room

temperature before storage.

Many food products are stor-

ed at the same time.

Store less food products at

the same time.

The door has been opened

often.

Open the door only if neces-

sary.

There is no cold air circula-

tion in the appliance.

Make sure that there is cold

air circulation in the appli-

ance.

If the advice does not lead to

the desired result, call the

nearest Authorized Service

Centre.

Replacing the lamp

The appliance is equipped with

a longlife LED interior light.

CAUTION! Disconnect the plug

from the mains socket.

1. At the same time, with the fingers

expand up and down the transparent

cover and unhook it in the direction of

the arrows.

2. Replace the lamp with one of the same

power and shape, specifically designed

for household appliances. (the

maximum power is shown on the light

bulb cover).

3. Reassemble the lamp cover.

4. Connect the plug to the mains socket.

5. Open the door.

Make sure that the light comes on.

Closing the door

1. Clean the door gaskets.

2. If necessary, adjust the door. Refer to

"Installation".

3. If necessary, replace the defective door

gaskets. Contact the Authorised

Service Centre.

INSTALLATION

WARNING! Refer to Safety

chapters.

Location

Refer to the assembly

instructions for the installation.

To ensure best performance, install the

appliance well away from sources of heat

such as radiators, boilers, direct sunlight

etc. Make sure that air can circulate freely

around the back of the cabinet.

Positioning

This appliance can be installed in a dry, well

ventilated indoor where the ambient

temperature corresponds to the climate

class indicated on the rating plate of the

appliance:

Cli-

mate

class

Ambient temperature

SN +10°C to + 32°C

N +16°C to + 32°C

ST +16°C to + 38°C

T +16°C to + 43°C

Some functional problems might

occur for some types of models

when operating outside of that

range. The correct operation

can only be guaranteed within

the specified temperature range.

If you have any doubts

regarding where to install the

appliance, please turn to the

vendor, to our customer service

or to the nearest Authorised

Service Centre.

Ventilation requirements

The airflow behind the appliance must be

sufficient.

5 cm min.

200 cm2

min.

200 cm2

Inhaltsverzeichnis

Andere Smeg Kühlschrank Handbücher

Smeg

Smeg CV250PNF1 Bedienungsanleitung

Smeg

Smeg SCV36X Bedienungsanleitung

Smeg

Smeg CB3202PNFC Bedienungsanleitung

Smeg

Smeg FRP240SE1 Stücklistenhandbuch

Smeg

Smeg CR324A8 Bedienungsanleitung

Smeg

Smeg S3L172FP Bedienungsanleitung

Smeg

Smeg C8194TNE Bedienungsanleitung

Smeg

Smeg UKC4172F Bedienungsanleitung

Smeg

Smeg CB300UI Bedienungsanleitung

Smeg

Smeg MTE30 Bedienungsanleitung

Smeg

Smeg FAB32X Bedienungsanleitung

Smeg

Smeg FA326X Kurzanleitung

Smeg

Smeg FR155WE/1 Kurzanleitung

Smeg

Smeg S3L120P1 Bedienungsanleitung

Smeg

Smeg FD238A1 Bedienungsanleitung

Smeg

Smeg CR470SE Bedienungsanleitung

Smeg

Smeg S4C102F0 Bedienungsanleitung

Smeg

Smeg LF1700C Bedienungsanleitung

Smeg

Smeg FI281B Bedienungsanleitung

Smeg

Smeg Classica FA3905RX5 Bedienungsanleitung

Smeg

Smeg FA560X Bedienungsanleitung

Smeg

Smeg FR150SE Betriebsanleitung

Smeg

Smeg CR330SENF Benutzerhandbuch

Smeg

Smeg UKS4C092F Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
