Item#Part # Description Qty.
1 P20-3526 Base(Left) 1
2 P20-3527 Base(Right) 1
3 P20-3681 RearUpright1
4 P20-3531 VerticalTube Adjustable(Left) 1
5 P20-3530 VerticalTube Adjustable(Right) 1
6 P20-3529 OlympicBarSupport (Right) 1
7 P20-3528 OlympicBarSupport (Left) 1
8 P20-3534 HandleBarAdjustable(Left) 1
9 P20-3535 HandleBarAdjustable(Right) 1
10 P20-1534 OlympicBarAdjustable 2
11 P20-3684 OlympicBarAdjustable(Left) 1
12 P20-3682 Top Brace(Left) 1
13 P20-3686 Top Brace(Right) 1
14 P04-0616 Top Bar 1
15 P20-3676 Swiveling Pulley Handles Assembly 2
16 P11-0209 T Handle Pop Pin 2
17 P02-0753 Top Beam 2
18 P20-1536 Foot Plate 1
19 P02-0852 LBracket , Top 1
20 P02-0849 LBracket , Botton 1
21 P01-0868 GuideRod 19x1925L 4
22 P01-0869 LinerShaft 25x1881L 2
23 P20-3685 OlympicBarAdjustable(Right) 1
24 P03-0406 Shaft 16 x65L 32
25 P04-0794 OlympicBar 1
26 P03-0405 OlympicBarShaft 1
27 P02-0734 PulleyBracket 4
28 P20-1543 Top Weight +SelectorStem 2
29 P03-0284 Clevis25.4x63.5L 2
30 DAEE01251413NU Button Head Allen Screw1/2 -13uncx5 1/4"L 2
31 DAEE01243413NU Button Head Allen Screw1/2 -13uncx4 3/4"L 2
32 DAEE01230013NU Button Head Allen Screw1/2 -13uncx3 L 10
33 DAEE01223413NU Button Head Allen Screw1/2 -13uncx2 3/4"L 8
34 DAEE03851416NU Button Head Allen Screw3/8 -16uncx5 1/4"L 1
35 DAEE03843416NU Button Head Allen Screw3/8 -16uncx4 3/4"L 2
36 DAEE03823416NU Button Head Allen Screw3/8 -16uncx2 3/4"L 8
37 DAEE03821416NU Button Head Allen Screw3/8 -16uncx2 1/4"L 2
38 DAEE03821216NU Button Head Allen Screw3/8 -16uncx2 1/2"L 6
39 DAEE03820016NU Button Head Allen Screw3/8 -16uncx2 L 10
40 DC126013020U FlatWasher26 x13 x2.0t 44
41 DC125010020U FlatWasher25 x10 x2.0t 38
42 DB2E01212013U Nylon Nut 1/2 -13uncx12t 22
Page4
PartsReference
AssemblyParts
