SMSC USB3290 DATASHEET Revision1.5(11-02-07)

Datasheet

PRODUCT FEATURES

USB3290

Small Footprint Hi-Speed

USB 2.0 Device PHY with

UTMI Interface

Available in a 40 ball lead-free RoHS compliant

(4 x 4 x 0.9mm) VFBGA package

Interface compliant with the UTMI specification

(60MHz, 8-bit bidirectional interface)

Only one required power supply (+3.3V)

Supports 480Mbps Hi-Speed (HS) and 12Mbps Full

Speed (FS) serial data transmission rates

Integrated 45Ωand 1.5kΩ termination resistors

reduce external component count

Internal short circuit protection of DP and DM lines

On-chip oscillator operates with low cost 24MHz

crystal

Latch-up performance exceeds 150mA per EIA/JESD

78, Class II

ESD protection levels of 5kV HBM without external

protection devices

SYNC and EOP generation on transmit packets and

detection on receive packets

NRZI encoding and decoding

Bit stuffing and unstuffing with error detection

Supports the USB suspend state, HS detection, HS

Chirp, Reset and Resume

Support for all test modes defined in the USB 2.0

specification

55mA Unconfigured Current (typical) - ideal for bus

powered applications.

83uA suspend current (typical) - ideal for battery

powered applications.

Industrial Operating Temperature -40oC to +85oC

Applications

The USB3290 is the ideal companion to any ASIC, SoC

or FPGA solution designed with a UTMI Hi-Speed USB

device (peripheral) core.

The USB3290 is well suited for:

Cell Phones

MP3 Players

Scanners

External Hard Drives

Digital Still and Video Cameras

Portable Media Players

Entertainment Devices

Printers

ORDER NUMBER(S):

USB3290-FH FOR 40 BALL, VFBGA LEAD-FREE ROHS COMPLIANT PACKAGE

USB3290-FH-TR FOR 40 BALL, VFBGA LEAD-FREE ROHS COMPLIANT PACKAGE (TAPE AND REEL)

Reel Size is 4000 pieces.

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

Revision 1.5 (11-02-07) 2 SMSC USB3290

DATASHEET

80 ARKAY DRIVE, HAUPPAUGE, NY 11788 (631) 435-6000, FAX (631) 273-3123

Circuit diagrams and other information relating to SMSC products are included as a means of illustrating typical applications. Consequently, complete information sufficient for

construction purposes is not necessarily given. Although the information has been checked and is believed to be accurate, no responsibility is assumed for inaccuracies. SMSC

reserves the right to make changes to specifications and product descriptions at any time without notice. Contact your local SMSC sales office to obtain the latest specifications

before placing your product order. The provision of this information does not convey to the purchaser of the described semiconductor devices any licenses under any patent

rights or other intellectual property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms and conditions of the most recently dated

version of SMSC's standard Terms of Sale Agreement dated before the date of your order (the "Terms of Sale Agreement"). The product may contain design defects or errors

known as anomalies which may cause the product's functions to deviate from published specifications. Anomaly sheets are available upon request. SMSC products are not

designed, intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to personal injury or severe property

damage. Any and all such uses without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of

this document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com. SMSC is a registered

trademark of Standard Microsystems Corporation (“SMSC”). Product names and company names are the trademarks of their respective holders.

SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY,

FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE, AND ANY AND ALL WARRANTIES ARISING FROM ANY COURSE

OF DEALING OR USAGE OF TRADE. IN NO EVENT SHALL SMSC BE LIABLE FOR ANY DIRECT, INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR CONSEQUENTIAL

DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE FORM OF ACTION, WHETHER BASED ON CONTRACT;

TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR OTHERWISE; WHETHER OR NOT ANY REMEDY OF BUYER IS HELD

TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER OR NOT SMSC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

SMSC USB3290 3 Revision 1.5 (11-02-07)

DATASHEET

Table of Contents

Chapter 1 General Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chapter 2 Functional Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 3 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Chapter 4 Interface Signal Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 5 Limiting Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Chapter 6 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.1 Driver Characteristics of Full-Speed Drivers in High-Speed Capable Transceivers. . . . . . . . . . . . 16

6.2 High-speed Signaling Eye Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Chapter 7 Functional Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.1 Modes of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.2 System Clocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.3 Clock and Data Recovery Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

7.4 TX Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

7.5 RX Logic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

7.6 USB 2.0 Transceiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

7.6.1 High Speed and Full Speed Transceivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

7.6.2 Termination Resistors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

7.6.3 Bias Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7.7 Crystal Oscillator and PLL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7.8 Internal Regulators and POR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7.8.1 Internal Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7.8.2 Power On Reset (POR). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7.8.3 Reset Pin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Chapter 8 Application Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

8.1 Linestate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

8.2 OPMODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

8.3 Test Mode Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

8.4 SE0 Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8.5 Reset Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8.6 Suspend Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

8.7 HS Detection Handshake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

8.8 HS Detection Handshake – FS Downstream Facing Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

8.9 HS Detection Handshake – HS Downstream Facing Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

8.10 HS Detection Handshake – Suspend Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

8.11 Assertion of Resume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

8.12 Detection of Resume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

8.13 HS Device Attach . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

8.14 Application Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Chapter 9 Package Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

Revision 1.5 (11-02-07) 4 SMSC USB3290

DATASHEET

List of Figures

Figure 2.1 USB3290 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Figure 3.1 USB3290 Pinout - Top View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Figure 6.1 Full-Speed Driver VOH/IOH Characteristics for High-speed Capable Transceiver . . . . . . . . 17

Figure 6.2 Full-Speed Driver VOL/IOL Characteristics for High-speed Capable Transceiver. . . . . . . . . 17

Figure 6.3 Eye Pattern Measurement Planes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Figure 6.4 Eye Pattern for Transmit Waveform and Eye Pattern Definition . . . . . . . . . . . . . . . . . . . . . . 19

Figure 6.5 Eye Pattern for Receive Waveform and Eye Pattern Definition. . . . . . . . . . . . . . . . . . . . . . . 20

Figure 7.1 FS CLK Relationship to Transmit Data and Control Signals . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 7.2 FS CLK Relationship to Receive Data and Control Signals. . . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 7.3 Transmit Timing for a Data Packet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 7.4 Receive Timing for Data with Unstuffed Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Figure 7.5 Receive Timing for a Handshake Packet (no CRC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Figure 7.6 Receive Timing for Setup Packet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 7.7 Receive Timing for Data Packet (with CRC-16). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 8.1 Reset Timing Behavior (HS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Figure 8.2 Suspend Timing Behavior (HS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 8.3 HS Detection Handshake Timing Behavior (FS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Figure 8.4 Chirp K-J-K-J-K-J Sequence Detection State Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Figure 8.5 HS Detection Handshake Timing Behavior (HS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Figure 8.6 HS Detection Handshake Timing Behavior from Suspend . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Figure 8.7 Resume Timing Behavior (HS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Figure 8.8 Device Attach Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Figure 8.9 USB3290 Application Diagram showing USB related signals . . . . . . . . . . . . . . . . . . . . . . . . 41

Figure 8.10 USB3290 Application Diagram showing power and miscellaneous signals. . . . . . . . . . . . . . 42

Figure 9.1 USB3290-FH 40 Ball, VFBGA Package Outline & Parameters 4x4x0.9mm Body, Lead-Free

RoHS Compliant 43

Figure 9.2 BGA, 4x4 Taping Dimensions and Part Orientation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Figure 9.3 Reel Dimensions for 12mm Carrier Tape. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Figure 9.4 Tape Length and Part Quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

SMSC USB3290 5 Revision 1.5 (11-02-07)

DATASHEET

List of Tables

Table 4.1 System Interface Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Table 4.2 Data Interface Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 4.3 USB I/O Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 4.4 Biasing and Clock Oscillator Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 4.5 Power and Ground Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Table 5.1 Absolute Maximum Ratings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Table 5.2 Recommended Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Table 5.3 Recommended External Clock Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Table 6.1 Electrical Characteristics: Supply Pins (Note 6.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 6.2 DC Electrical Characteristics: Logic Pins (Note 6.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 6.3 DC Electrical Characteristics: Analog I/O Pins (DP/DM) (Note 6.3) . . . . . . . . . . . . . . . . . . . . 14

Table 6.4 Dynamic Characteristics: Analog I/O Pins (DP/DM) (Note 6.4). . . . . . . . . . . . . . . . . . . . . . . . 15

Table 6.5 Dynamic Characteristics: Digital UTMI Pins (Note 6.5). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Table 7.1 DP/DM Termination vs. Signaling Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Table 8.1 Linestate States. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Table 8.2 Operational Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table 8.3 USB 2.0 Test Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table 8.4 Reset Timing Values (HS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table 8.5 Suspend Timing Values (HS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Table 8.6 HS Detection Handshake Timing Values (FS Mode). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Table 8.7 Reset Timing Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Table 8.8 HS Detection Handshake Timing Values from Suspend. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Table 8.9 Resume Timing Values (HS Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Table 8.10 Attach and Reset Timing Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

Revision 1.5 (11-02-07) 6 SMSC USB3290

DATASHEET

Chapter 1 General Description

The USB3290 provides the Physical Layer (PHY) interface to a USB 2.0 Device Controller. The IC is

available in a 40 ball lead-free RoHS compliant VFBGA package. The small footprint package makes

the USB3290 ideal for portable consumer electronics applications.

1.1 Product Description

The USB3290 is an industrial temperature USB 2.0 physical layer transceiver (PHY) integrated circuit.

SMSC’s proprietary technology results in low power dissipation, which is ideal for building a bus

powered USB 2.0 peripheral. The PHY uses an 8-bit bidirectional parallel interface, which complies

with the USB Transceiver Macrocell Interface (UTMI) specification. It supports 480Mbps transfer rate,

while remaining backward compatible with USB 1.1 legacy protocol at 12Mbps.

All required termination and 5.25V short circuit protection of the DP/DM lines are internal to the chip.

The USB3290 also has an integrated 1.8V regulator so that only a 3.3V supply is required.

While transmitting data, the PHY serializes data and generates SYNC and EOP fields. It also performs

needed bit stuffing and NRZI encoding. Likewise, while receiving data, the PHY de-serializes incoming

data, stripping SYNC and EOP fields and performs bit un-stuffing and NRZI decoding.

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

SMSC USB3290 7 Revision 1.5 (11-02-07)

DATASHEET

Chapter 2 Functional Block Diagram

Figure 2.1 USB3290 Block Diagram

PWR

Control

FS SE+

UTMI

Interface

TX State

Machine

Parallel to

Serial

Conversion

Bit Stuff

NRZI

Encode

LOGIC

Clock

Recovery Unit

Clock

and

Data

Recovery

Elasticity

Buffer

BIASING

Bandgap Voltage Reference

Current Reference

RBIAS

VDD3.3

PLL and

XTAL OSC System

Clocking

FS RX

FS SE-

HS RX

HS SQ

RX State

Machine

Serial to

Parallel

Conversion

Bit Unstuff

NRZI

Decode

LOGIC

1.5kΩ

HS_DATA

HS_CS_ENABLE

HS_DRIVE_ENABLE

OEB

VMO

VPO

RPU_EN

MUX

RXVALID

RXACTIVE

RXERROR

TXREADY

RESET

SUSPENDN

XCVRSELECT

TERMSELECT

OPMODE[1:0]

LINESTATE[1:0]

CLKOUT

TXVALID

DATA[7:0]

1.8V

Regulator

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

Revision 1.5 (11-02-07) 8 SMSC USB3290

DATASHEET

Chapter 3 Pinout

Figure 3.1 USB3290 Pinout - Top View

TOP VIEW

TSELTXR

SPDN TXV

RST

V33

XSEL GND

CLK

V33

RXA OM0 LS1

LS0OM1

RXV

D2 D3

VIOV18A

XI XO

V18

V33

RXEREN

1765432

GND

GND GND

VIO

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

SMSC USB3290 9 Revision 1.5 (11-02-07)

DATASHEET

Chapter 4 Interface Signal Definition

Table 4.1 System Interface Signals

NAME DIRECTION ACTIVE

LEVEL DESCRIPTION

RESET

(RST) Input High Reset. Reset all state machines. After coming out of

reset, must wait 5 rising edges of clock before asserting

TXValid for transmit.

See Section 7.8.3

XCVRSELECT

(XSEL) Input N/A Transceiver Select. This signal selects between the FS

and HS transceivers:

0: HS transceiver enabled

1: FS transceiver enabled.

TERMSELECT

(TSEL) Input N/A Termination Select. This signal selects between the FS

and HS terminations:

0: HS termination enabled

1: FS termination enabled

SUSPENDN

(SPDN) Input Low Suspend. Places the transceiver in a mode that draws

minimal power from supplies. Shuts down all blocks not

necessary for Suspend/Resume operation. While

suspended, TERMSELECT must always be in FS mode

to ensure that the 1.5kΩpull-up on DP remains powered.

0: Transceiver circuitry drawing suspend current

1: Transceiver circuitry drawing normal current

CLKOUT

(CLK) Output Rising Edge System Clock. This output is used for clocking receive

and transmit parallel data at 60MHz.

OPMODE[1:0]

(OM1)

(OM0)

Input N/A Operational Mode. These signals select between the

various operational modes:

[1] [0] Description

0 0 0: Normal Operation

0 1 1: Non-driving (all terminations removed)

1 0 2: Disable bit stuffing and NRZI encoding

1 1 3: Reserved

LINESTATE[1:0]

(LS1)

(LS0)

Output N/A Line State. These signals reflect the current state of the

USB data bus in FS mode, with [0] reflecting the state of

DP and [1] reflecting the state of DM. When the device is

suspended or resuming from a suspended state, the

signals are combinatorial. Otherwise, the signals are

synchronized to CLKOUT.

[1] [0] Description

0 0 0: SE0

0 1 1: J State

1 0 2: K State

1 1 3: SE1

Small Footprint Hi-Speed USB 2.0 Device PHY with UTMI Interface

Datasheet

Revision 1.5 (11-02-07) 10 SMSC USB3290

DATASHEET

Table 4.2 Data Interface Signals

NAME DIRECTION ACTIVE

LEVEL DESCRIPTION

DATA[7:0]

(D7)

(D0)

Bidirectional High Data bus. 8-bit Bidirectional mode.

TXVALID DATA[7:0]

0 output

1 input

TXVALID

(TXV) Input High Transmit Valid. Indicates that the DATA bus is valid for transmit. The

assertion of TXVALID initiates the transmission of SYNC on the USB

bus. The negation of TXVALID initiates EOP on the USB.

Control inputs (OPMODE[1:0], TERMSELECT,XCVRSELECT) must

not be changed on the de-assertion or assertion of TXVALID. The

PHY must be in a quiescent state when these inputs are changed.

TXREADY

(TXR) Output High Transmit Data Ready. If TXVALID is asserted, the SIE must always

have data available for clocking into the TX Holding Register on the

rising edge of CLKOUT. TXREADY is an acknowledgement to the

SIE that the transceiver has clocked the data from the bus and is

ready for the next transfer on the bus. If TXVALID is negated,

TXREADY can be ignored by the SIE.

RXVALID

(RXV) Output High Receive Data Valid. Indicates that the DATA bus has received valid

data. The Receive Data Holding Register is full and ready to be

unloaded. The SIE is expected to latch the DATA bus on the rising

edge of CLKOUT.

RXACTIVE

(RXA) Output High Receive Active. Indicates that the receive state machine has

detected Start of Packet and is active.

RXERROR

(RXE) Output High Receive Error.

0: Indicates no error.

1: Indicates a receive error has been detected.

This output is clocked with the same timing as the receive DATA lines

and can occur at anytime during a transfer.

Table 4.3 USB I/O Signals

NAME DIRECTION ACTIVE

LEVEL DESCRIPTION

DP I/O N/A USB Positive Data Pin.

DM I/O N/A USB Negative Data Pin.

Table 4.4 Biasing and Clock Oscillator Signals

NAME DIRECTION ACTIVE

LEVEL DESCRIPTION

RBIAS

(RB) Input N/A External 1% bias resistor. Requires a 12kΩresistor to ground.

Used for setting HS transmit current level and on-chip

termination impedance.

XI/XO Input N/A External crystal. 24MHz crystal connected from XI to XO.

Inhaltsverzeichnis

Andere SMSC Netzwerkkarte Handbücher

SMSC

SMSC USB97C242 Bedienungsanleitung

Beliebte Netzwerkkarte Handbücher anderer Marken

FirstComm

FirstComm OBiWiFi5G Bedienungsanleitung

Sun Microsystems

Sun Microsystems Interface Adapter Bedienungsanleitung

TRENDnet

TRENDnet TU2-ETG Bedienungsanleitung

YASKAWA

YASKAWA SI-EN3 Bedienungsanleitung

Paradyne

Paradyne BitStorm 2600 IP DSLAM Bedienungsanleitung

Belkin

Belkin F5D7050 Bedienungsanleitung

3Com

3Com EtherLink 3C509B Bedienungsanleitung

TRENDnet

TRENDnet TEG-PCITX Bedienungsanleitung

Cisco

Cisco MC16E Bedienungsanleitung

Delta Electronics

Delta Electronics Braking Modules VFDB Series Bedienungsanleitung

TwinMOS

TwinMOS Booming Bedienungsanleitung

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Bedienungsanleitung

Buffalo

Buffalo AirStation WLI-PCM-L11GP Bedienungsanleitung

National Instruments

National Instruments NI 9234 Bedienungsanleitung

Hama

Hama 49276 Bedienungsanleitung

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Bedienungsanleitung

Compaq

Compaq Wireless LAN 100 Bedienungsanleitung

Bose

Bose PowerMatch Dante Bedienungsanleitung
