Snapper FAST-VAC 5600148 Bedienungsanleitung

Parts

Rev. Date: 10/2007

Fast-Vac

Grass Collection Systems

Manual

5101356

5375 North Main Street

Munnsville, NY 13409 USA

800-933-6175

Briggs and Stratton Yard Power Products Group

TP 400-7356-00-AT-SP

Models: Descri

tion:

5100857 3-Bag Dump From Seat

5600002 2-Bag Collection System (S150X - 48" Mower Deck)

5600003 3-Bag Collection System (S150X - 48" Mower Deck)

5600004 3-Bag Collection System (S150X S/N: 2012628762 & Below - 52" Mower Deck)

5600057 3-Bag Collection System (S200X - 61" Mower Deck)

5600148 3-Bag Collection System (S150X S/N: 2012628763 & Above - 52" Mower Deck)

Revision

Table Of Content

Tor

ue S

ecification Chart ............................................................................................. Inside Back Cover

MODEL COMPONENTS PAGE

Blower Group ..................................................................................................................................................................... 4

Blower Mount & Drive Group .............................................................................................................................................

2-Bag Catcher & Cover Group ........................................................................................................................................... 8

3-Ba

Catcher & Cover Group ........................................................................................................................................... 10

3-Ba

Dump From Seat ..................................................................................................................................................... 12

Weight Mount Group .......................................................................................................................................................... 14

Decals - Brand, Safety & Information ................................................................................................................................. 16

er Mount Group .........................................................................................................................................................

Model Reference Sheet 1 - Models w/Rubber Dischar

e chute ........................................................................................ 20

Model Reference Sheet 2 - Models w/Rubber Discharge chute ........................................................................................ 21

Blower Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

2007 4

5600148

(

S150X S/N: 2012628763 & Above - 52" Mower Deck

)

5600057

(

S200X - 61" Mower Deck

)

5600004

(

S150X S/N: 2012628762 & Below - 52" Mower Deck

)

5600003

(

S150X - 48" Mower Deck

)

5600002

(

S150X - 48" Mower Deck

)

TP 400-7356-00-AT-SP

PART NO. DESCRIPTIONREF NO QTY.

Blower Group

Footnotes

1 5403723A 1 BLOWER HOUSING

2 5403750A 1 BACK PLATE

3 5403754A 1 BLOWER IMPELLER

4 7100021 2 BEARING, FLANGE, 1" Bore

5 7091541 5 BOLT, 5/16-18 X 3/4" Self Tap

6 5403736A 1 BELT GUARD

7 5021097 1 PULLEY, IDLER V-NOTCH, 5"

8 3043613 2 IDLER PULLEY ASSEMBLY

9 5403749A 2 BELT KEEPER

10 5403740A 1 KEEPER, BELT TENSIONER

11 5025156 2 WASHER 3/8" SAE

12 5025013X16 2 BOLT, 3/8-16 X 2

13 5025017X18 1 BOLT, 1/2-13 X 2-1/4

14 5025056 1 NUT, 1/2-13 Hex Nylon Lock

15 5025394 4 NUT, 3/8-16 Hex Large Serrated Flange

16 5025011X10 1 BOLT, 5/16-18 X 1-1/4

17 5022308 3 U-CLIP, 5/16-18

18 7091811 6 BOLT, 5/16-18 X 5/8" Self Lock

19 5025145X6 6 CARRIAGE BOLT, 5/16-18 X 3/4

20 5025392 6 NUT, 5/16-18 Hex Nylock Flange

21 7010776 1 RETAINING RING, 1/2"

22 7014409 2 FLANGE BEARING, 9/16"

23 7044995 1 IDLER STUD

24 7091804 2 FLAT WASHER, 9/16" Narrow

25 5403746 1 IDLER ARM

26 5025171 1 WASHER, 3/8 Lock

27 5025035 1 NUT, 3/8-24 Hex

28 5020807 1 SPRING, Extension

29 7091575 1 NUT, 5/16-18 Hex Center Lock

30 5025013X48 1 BOLT, 3/8-16 X 6" GD5

The above parts group applies to the following Mfg. Nos.:

2007 5

5600148

(

S150X S/N: 2012628763 & Above - 52" Mower Deck

)

5600057

(

S200X - 61" Mower Deck

)

5600004

(

S150X S/N: 2012628762 & Below - 52" Mower Deck

)

5600003

(

S150X - 48" Mower Deck

)

5600002

(

S150X - 48" Mower Deck

)

TP 400-7356-00-AT-SP

Blower Mount & Drive Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

2007 6

5600003

(

S150X - 48" Mower Deck

)

5600004

(

S150X S/N: 2012628762 & Below - 52" Mower Deck

)

5600002

(

S150X - 48" Mower Deck

)

5600057

(

S200X - 61" Mower Deck

)

5600148

(

S150X S/N: 2012628763 & Above - 52" Mower Deck

)

TP 400-7356-00-AT-SP

PART NO. DESCRIPTIONREF NO QTY.

Blower Mount & Drive Group

Footnotes

1 - - BLOWER ASSEMBLY

2 5402380A 1 WELD, BLOWER MOUNT 61 BLACK (All Models - 61" Mower Deck)

3 5100847 2 SNAPPERPIN, 5/16 X 2

4 7091811 6 BOLT, 5/16-18 X 3/4" SELF LOCK

5 5025013X8 3 BOLT, 3/8-16 X 1" GD5 YZ

6 5025096 3 NUT, 3/8-16 HEX NYLON LOCK

7 5022205 1 EYEBOLT, 1/4-20 X 2

8 5025391 1 NUT, 1/4-20 HEX NYLOCK FLANGE

9 5046807 1 PULLEY, BLOWER AXLE, 52 (All Models - 52" Mower Deck)

10 5022726 1 KEY 1/4 SQ X 1 1/2 LONG

11 5022308 2 BODY CLIP, 5/16-18 X 1/2" DEEP

12 5061858A 1 GUARD, DECK - BLACK (All Models - 48" & 52" Mower Decks)

13 5400007A 1 SHIELD, BELT (All Models - 48" & 52" Mower Decks)

14 5022319 2 KNOB, PLASTIC, 5/16-18 X 3/4"

15 5023177 1 PULLEY, BLOWER 52" DECK (All Models - 52" Mower Deck)

16 5021006 1 BELT, #7-6717, 88.8" E.L. (All Models - 52" Mower Deck)

17 5403650A 1 WELD, BLOWER MOUNT 52 BLACK (S/N: 2012628763 & Above Models - 52"

Mower Deck)

18 5402633A 1 WELD, BLOWER MOUNT 48 BLACK (All Models - 48" Mower Deck)

19 5402354A 1 WELD, BLOWER MOUNT 52 BLACK (S/N: 2012628762 & Below Models - 52"

Mower Deck)

20 5022844 1 BELT, #7-6718, 92.0" E.L. (All Models - 48" & 61" Mower Decks)

21 5046806 1 PULLEY, BLOWER AXLE, 48 (All Models - 48" Mower Deck)

22 5046808 1 PULLEY, BLOWER AXLE, 61 (All Models - 61" Mower Deck)

23 5023176 1 PULLEY, BLOWER 48" DECK (All Models - 48" Mower Deck)

24 5046702 1 PULLEY, BLOWER 61" DECK (All Models - 61" Mower Deck)

25 5401436A 1 SHIELD, BELT (All Models - 61" Mower Deck)

26 5061858A 1 GUARD, DECK - BLACK (All Models - 61" Mower Deck)

The above parts group applies to the following Mfg. Nos.:

2007 7

5600003

(

S150X - 48" Mower Deck

)

5600004

(

S150X S/N: 2012628762 & Below - 52" Mower Deck

)

5600002

(

S150X - 48" Mower Deck

)

5600057

(

S200X - 61" Mower Deck

)

5600148

(

S150X S/N: 2012628763 & Above - 52" Mower Deck

)

TP 400-7356-00-AT-SP

2-Bag Catcher & Cover Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

2007 8

5600002

(

S150X - 48" Mower Deck

)

TP 400-7356-00-AT-SP

PART NO. DESCRIPTIONREF NO QTY.

2-Bag Catcher & Cover Group

Footnotes

1 5100153 1 2 BAG AIR DOME

2 5100150 2 CATCHER BAG W/ HANDLE

3 5100152 2 GAS CYLINDER

4 5100151 1 DETENT PIN W/ LANYARD

5 5025011X6 12 BOLT, 5/16-18 X 3/4" GRD5

6 5025155 8 WASHER, 5/16" SAE

7 5025170 4 WASHER, 5/16" LOCK

8 5025056 3 NUT, 1/2-13 HEX NYLON LOCK

9 5025018X24 3 BOLT, 1/2-20 X 3" GD5

10 5025158 2 WASHER, 1/2" SAE

11 5025057 2 NUT 5/16-18 HEX NYLON LOCK

12 5025392 4 NUT 5/16-18 HEX NYLOCK FLANGE

13 5022875 1 HOSE CLAMP

14 5022833 1 HOSE

15 5022876 1 HOSE CLAMP

16 5400147A 1 WELD, INLET BLOWER

17 5100036A 1 BAFFLE

18 5100730 2 BAG FRAME CONNECTOR, PLASTIC

19 5100729 2 BAG FRAME

The above parts group applies to the following Mfg. Nos.:

2007 9

5600002

(

S150X - 48" Mower Deck

)

TP 400-7356-00-AT-SP

3-Bag Catcher & Cover Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

2007 10

5600004

(

S150X S/N: 2012628762 & Below - 52" Mower Deck

)

5600148

(

S150X S/N: 2012628763 & Above - 52" Mower Deck

)

5600003

(

S150X - 48" Mower Deck

)

5600057

(

S200X - 61" Mower Deck

)

TP 400-7356-00-AT-SP
